全輪超輕量級分組密碼PFP的相關密鑰差分分析
doi: 10.11999/JEIT240782
-
1.
桂林電子科技大學廣西密碼學與信息安全重點實驗室 桂林 541000
-
2.
密碼科學技術國家重點實驗室 北京 100878
Related-key Differential Cryptanalysis of Full-round PFP Ultra-lightweight Block Cipher
-
1.
Guangxi Key Laboratory of Cryptography and information Security, Guilin University of Electronic Technology, Guilin 541004, China
-
2.
State Key Laboratory of Cryptology, Beijing 100878, China
-
摘要: 2017年,PFP作為一種超輕量級分組密碼被提出,而因其卓越的實現性能備受業界廣泛關注。該算法不僅硬件開銷需求低(僅需約
1355 GE(等效門))、功耗小,而且加解密速度快(其速度甚至比國際著名算法 PRESENT的實現速度快1.5倍),非常適合在物聯網環境中使用。在PFP算法的設計文檔中,作者聲稱該算法具有足夠的能力抵御差分攻擊、線性攻擊及不可能差分攻擊等多種密碼攻擊方法。然而該算法是否存在未知的安全漏洞是目前研究的難點。該文基于可滿足性模理論(SMT),結合PFP算法輪函數特點,構建兩種區分器自動化搜索模型。實驗測試結果表明:該算法在32輪加密中存在概率為2–62的相關密鑰差分特征。由此,該文提出一種針對全輪PFP算法的相關密鑰恢復攻擊,即只需263個選擇明文和248次全輪加密便可破譯出80 bit的主密鑰。這說明該算法無法抵抗相關密鑰差分攻擊。-
關鍵詞:
- 輕量級分組密碼算法 /
- 差分密碼分析 /
- 密鑰恢復攻擊 /
- 可滿足性模理論
Abstract:Objective In 2017, the PFP algorithm was introduced as an ultra-lightweight block cipher to address the demand for efficient cryptographic solutions in constrained environments, such as the Internet of Things (IoT). With a hardware footprint of approximately 1355 GE and low power consumption, PFP has attracted attention for its ability to deliver high-speed encryption with minimal resource usage. Its encryption and decryption speeds outperform those of the internationally recognized PRESENT cipher by a factor of 1.5, making it highly suitable for real-time applications in embedded systems. While the original design documentation asserts that PFP resists various traditional cryptographic attacks, including differential, linear, and impossible differential attacks, the possibility of undiscovered vulnerabilities remains unexplored. This study evaluates the algorithm’s resistance to related-key differential attacks, a critical cryptanalysis method for lightweight ciphers, to determine the actual security level of the PFP algorithm using formal cryptanalysis techniques.Methods To evaluate the security of the PFP algorithm, Satisfiability Modulo Theories (SMT) is used to model the cipher’s round function and automate the search for distinguishers indicating potential design weaknesses. SMT, a formal method increasingly applied in cryptanalysis, facilitates automated attack generation and the detection of cryptographic flaws. The methodology involved constructing mathematical models of the cipher’s rounds, which are tested for differential characteristics under various key assumptions. Two distinguisher models are developed: one based on single-key differentials and the other on related-key differentials, the latter being the focus of this analysis. These models automated the search for weak key differentials that could enable efficient key recovery attacks. The analysis leveraged the nonlinear substitution-permutation structure of the PFP round function to systematically identify vulnerabilities. The results are examined to estimate the probability of key recovery under different attack scenarios and assess the effectiveness of related-key differential cryptanalysis against the full-round PFP cipher. Results and Discussions The SMT-based analysis revealed a critical vulnerability in the PFP algorithm. A related-key differential characteristic with a probability of 2–62 is identified, persisting through 32 encryption rounds. This characteristic indicates a predictable pattern in the cipher’s behavior under related-key conditions, which can be exploited to recover the secret key. Such differentials are particularly concerning as they expose a significant weakness in the cipher’s resistance to related-key attacks, a critical threat in IoT applications where keys may be reused or related across multiple devices or sessions.Based on this finding, a key recovery attack is developed, requiring only 263 chosen plaintexts and 248 full-round encryptions to retrieve the 80-bit master key. The efficiency of this attack demonstrates the vulnerability of the PFP cipher to practical cryptanalysis, even with limited computational resources. The attack’s relatively low complexity suggests that PFP may be unsuitable for applications demanding high security, particularly in environments where adversaries can exploit related-key differential characteristics. Moreover, these results indicate that the existing resistance claims for the PFP cipher are insufficient, as they do not account for the effectiveness of related-key differential cryptanalysis. This challenges the assertion that the PFP algorithm is secure against all known cryptographic attacks, emphasizing the need for thorough cryptanalysis before lightweight ciphers are deployed in real-world scenarios.( Fig. 2 : Related-key differential characteristic with probability 2–62 in 32 rounds;Table 1 : Attack complexity and resource requirements for related-key recovery.)Conclusions In conclusion, this paper presents a cryptographic analysis of the PFP lightweight block cipher, revealing its vulnerability to related-key differential attacks. The proposed key recovery attack demonstrates that, despite its efficiency in hardware and speed, PFP fails to resist attacks exploiting related-key differential characteristics. This weakness is particularly concerning for IoT applications, where key reuse or related keys across devices is common. These findings highlight the need for further refinement in lightweight cipher design to ensure robust resistance against advanced cryptanalysis techniques. As lightweight ciphers continue to be deployed in security-critical systems, it is essential that designers consider all potential attack vectors, including related-key differentials, to strengthen security guarantees. Future work should focus on enhancing the cipher’s security by exploring alternative key-schedule designs or increasing the number of rounds to mitigate the identified vulnerabilities. Additionally, this study emphasizes the effectiveness of SMT-based formal methods in cryptographic analysis, providing a systematic approach for identifying previously overlooked weaknesses in cipher designs. -
表 3 S盒的差分分布表
輸入差分 輸出差分 0 1 2 3 4 5 6 7 8 9 A B C D E F 0 16 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 4 0 0 0 4 0 4 0 0 0 4 0 0 2 0 0 0 2 0 4 2 0 0 0 2 0 2 2 2 0 3 0 2 0 2 2 0 4 2 0 0 2 2 0 0 0 0 4 0 0 0 0 0 4 2 2 0 2 2 0 2 0 2 0 5 0 2 0 0 2 0 0 0 0 2 2 2 4 2 0 0 6 0 0 2 0 0 0 2 0 2 0 0 4 2 0 0 4 7 0 4 2 0 0 0 2 0 2 0 0 0 2 0 0 4 8 0 0 0 2 0 0 0 2 0 2 0 4 0 2 0 4 9 0 0 2 0 4 0 2 0 2 0 0 0 2 0 4 0 A 0 0 2 2 0 4 0 0 2 0 2 0 0 2 2 0 B 0 2 0 0 2 0 0 0 4 2 2 2 0 2 0 0 C 0 0 2 0 0 4 0 2 2 2 2 0 0 0 2 0 D 0 2 4 2 2 0 0 2 0 0 2 2 0 0 0 0 E 0 0 2 2 0 0 2 2 2 2 0 0 2 2 0 0 F 0 4 0 0 4 0 0 0 0 0 0 0 0 0 4 4 下載: 導出CSV
表 4 PFP算法的差分界
輪數 最大期望差分特征概率 輪數 最大期望差分特征概率 單密鑰 相關密鑰 單密鑰 相關密鑰 1 20 20 18 2–44 2–34 2 2–2 20 19 2–46 2–36 3 2–4 20 20 2–48 2–38 4 2–6 20 21 2–51 2–40 5 2–8 20 22 2–54 2–42 6 2–12 2–3 23 2–56 2–44 7 2–16 2–5 24 2–58 2–46 8 2–18 2–9 25 2–61 2–48 9 2–21 2–14 26 2–64 2–50 10 2–24 2–18 27 2–66 2–52 11 2–26 2–20 28 2–68 2–54 12 2–28 2–22 29 2–71 2–56 13 2–31 2–24 30 2–74 2–58 14 2–34 2–26 31 2–76 2–60 15 2–36 2–28 32 2–78 2–62 16 2–38 2–30 33 2–81 2–64 17 2–41 2–32 34 2–84 2–66 下載: 導出CSV
表 5 差分特征概率為2–61的25輪差分區分器
輪數 左分支差分 右分支差分 輪數 左分支差分 右分支差分 0 0x00040D00 0x00000900 13 0x00000900 0x00000900 1 0x00000900 0x00000900 14 0x00000900 0x00000D00 2 0x00000900 0x00000D00 15 0x00000D00 0x00000D00 3 0x00000D00 0x00000D00 16 0x00000D00 0x00000900 4 0x00000D00 0x00000900 17 0x00000900 0x00000900 5 0x00000900 0x00000900 18 0x00000900 0x00000D00 6 0x00000900 0x00000D00 19 0x00000D00 0x00000D00 7 0x00000D00 0x00000D00 20 0x00000D00 0x00000900 8 0x00000D00 0x00000900 21 0x00000900 0x00000900 9 0x00000900 0x00000900 22 0x00000900 0x00000D00 10 0x00000900 0x00000D00 23 0x00000D00 0x00000D00 11 0x00000D00 0x00000D00 24 0x00000D00 0x00000900 12 0x00000D00 0x00000900 25 0x00000900 0x00040D00 下載: 導出CSV
表 6 差分特征概率為2–62的32輪相關密鑰差分區分器
輪數 左右分支差分 相關密鑰差分 輪數 左右分支差分 相關密鑰差分 0 0x8BBBBA22D1111177 0xD111117777444445DDDD 17 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 1 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 18 0x8BBBBA22D1111177 0xD111117777444445DDDD 2 0x8BBBBA22D1111177 0xD111117777444445DDDD 19 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 3 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 20 0x8BBBBA22D1111177 0xD111117777444445DDDD 4 0x8BBBBA22D1111177 0xD111117777444445DDDD 21 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 5 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 22 0x8BBBBA22D1111177 0xD111117777444445DDDD 6 0x8BBBBA22D1111177 0xD111117777444445DDDD 23 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 7 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 24 0x8BBBBA22D1111177 0xD111117777444445DDDD 8 0x8BBBBA22D1111177 0xD111117777444445DDDD 25 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 9 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 26 0x8BBBBA22D1111177 0xD111117777444445DDDD 10 0x8BBBBA22D1111177 0xD111117777444445DDDD 27 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 11 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 28 0x8BBBBA22D1111177 0xD111117777444445DDDD 12 0x8BBBBA22D1111177 0xD111117777444445DDDD 29 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 13 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 30 0x8BBBBA22D1111177 0xD111117777444445DDDD 14 0x8BBBBA22D1111177 0xD111117777444445DDDD 31 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 15 0xD11111778BBBBA22 0x8BBBBA22222EEEE88888 32 0x8BBBBA22D1111177 - 16 0x8BBBBA22D1111177 0xD111117777444445DDDD 下載: 導出CSV
表 7 相關密鑰下PFP算法密鑰恢復階段的復雜度計算
步數 猜測密鑰 篩選后剩余明密文對數量 時間復雜度 1 ${K_{33}}[31,30,29,28]$ ${2^{m - 33 - 4}}$ $ 2 \cdot {2^{m - 33}} \cdot {2^4} $ 2 ${K_{33}}[23,22,21,20]$ ${2^{m - 37 - 4}}$ $ 2 \cdot {2^{m - 37}} \cdot {2^8} $ 3 ${K_{33}}[15,14,13,12]$ ${2^{m - 41 - 4}}$ $ 2 \cdot {2^{m - 41}} \cdot {2^{12}} $ 4 ${K_{33}}[7,6,5,4]$ ${2^{m - 45 - 4}}$ $ 2 \cdot {2^{m - 45}} \cdot {2^{16}} $ 5 ${K_{33}}[27,26,25,24]$ ${2^{m - 49 - 3}}$ $ 2 \cdot {2^{m - 49}} \cdot {2^{20}} $ 6 ${K_{33}}[19,18,17,16]$ ${2^{m - 52 - 3}}$ $ 2 \cdot {2^{m - 52}} \cdot {2^{24}} $ 7 ${K_{33}}[11,10,9,8]$ ${2^{m - 55 - 3}}$ $ 2 \cdot {2^{m - 55}} \cdot {2^{28}} $ 8 ${K_{33}}[3,2,1,0]$ ${2^{m - 58 - 3}}$ $ 2 \cdot {2^{m - 58}} \cdot {2^{32}} $ 9 ${K_{32}}[31,30,29,28]$ ${2^{m - 61 - 4}}$ $ 2 \cdot {2^{m - 61}} \cdot {2^{32}} $ 總和 ${2^{m - 24}} + {2^{m - 26}}$ 下載: 導出CSV
-
