路徑規劃算法的高層綜合設計研究

賴?yán)钛?/>
	<meta name=; 梁海成; 李華偉

doi:10.11999/JEIT240210

路徑規劃算法的高層綜合設計研究

doi: 10.11999/JEIT240210

1.
汕頭大學電子系汕頭 515063
2.
中國科學院計算技術研究所計算機體系結構國家重點實驗室北京 100190

基金項目: 國家自然科學基金(62090024)，廣東省自然科學基金(2022A1515011084)，廣東省揚帆計劃緊缺拔尖人才項目(140-14600602)，計算機體系結構國家重點實驗室開放課題(CARCH201912, 140-15220011)

詳細信息

作者簡介:
賴?yán)钛螅耗?，副教授，碩士生導師，博士，研究方向?yàn)榧呻娐房蓽y(cè)試性設計、電子設計自動化、容錯計算、芯片設計

鄭锫駿：男，碩士生，研究方向?yàn)镕PGA設計、集成電路可測試性設計

梁海成：男，碩士，研究方向?yàn)镕PGA設計、電子設計自動化

李華偉：女，研究員，博士生導師，博士，研究方向?yàn)閿?shù)字電路設計自動化、測試驗證、智能計算、近似計算

通訊作者:
賴?yán)钛蟆?a href="mailto:lylai@stu.edu.cn">lylai@stu.edu.cn

中圖分類號: TN47; TP391.72
計量
- 文章訪問數: 269
- HTML全文瀏覽量: 112
- PDF下載量: 37
- 被引次數: 0
出版歷程
- 收稿日期: 2024-03-27
- 修回日期: 2024-06-15
- 網絡出版日期: 2024-06-19
- 刊出日期: 2024-11-01

Case Study of High Level Synthesis on Path Planning Algorithm

1.
Department of Electronics and Information Engineering, Shantou University, Shantou 515063, China
2.
State key Laboratory of Computer Architecture, Institute of Computing Technology, Chinese Academy of Sciences, Beijing 100190, China

Funds: The National Natural Science Foundation of China(62090024), The Natural Science Foundation of Guangdong Province(2022A1515011084), Guangdong Province Yangfan Program for Shortage and Top-notch Talents (140-14600602), Open Project of State Key Laboratory of Computer Architecture (CARCH201912, 140-15220011)

摘要

摘要: 隨著機器人自動導航技術的快速發展，基于軟件實現的路徑規劃算法在實時性上已無法滿足許多應用場景的需求，這就要求對算法進行快速高效的硬件定制，從而獲得低延時的性能加速。該文以機器人路徑規劃中的經典A*算法為對象，通過構建面向硬件設計的C/C++數據結構和函數流程優化，采用高層綜合(HLS)實現快速的硬件架構探索和選取較優的設計方案，并完成硬件FPGA綜合。實驗數據表明，相較于傳統寄存器傳輸級(RTL)開發模式，基于HLS開發模式的路徑規劃算法在FPGA實現上在開發效率、硬件性能和資源占用率上都有顯著提升，驗證了高層綜合在硬件定制中的可行性和成本優勢。
- 機器人自動導航 /
- 路徑規劃算法 /
- 高層綜合 /
- 算法硬件加速
Abstract: With the advancement of robot automatic navigation technology, software-based path planning algorithms can no longer satisfy the needs in scenarios of many real-time applications. Fast and efficient hardware customization of the algorithm is required to achieve low-latency performance acceleration. In this work, High Level Synthesis (HLS) of classic A* algorithm is studied. Hardware-oriented data structure and function optimization, varying design constraints are explored to pick the right architecture, which is then followed by FPGA synthesis. Experimental results show that, compared to the conventional Register Transfer Level (RTL) method, the HLS-based FPGA implementation of the A* algorithm can achieve better productivity, improved hardware performance and resource utilization efficiency, which demonstrates the advantages of high level synthesis in hardware customization in algorithm-centric applications.
- Robot automatic navigation /
- Path panning algorithm /
- High Level Synthesis(HLS) /
- Hardware acceleration

HTML全文

圖 1 實現高層綜合的基本流程

下載: 全尺寸圖片幻燈片

圖 2 切片函數的讀操作示意圖

下載: 全尺寸圖片幻燈片

圖 3 格點信息的數據結構

下載: 全尺寸圖片幻燈片

圖 4 開啟列表數組

下載: 全尺寸圖片幻燈片

圖 5 原始算法中的開啟列表操作

下載: 全尺寸圖片幻燈片

圖 6 開啟列表操作優化

下載: 全尺寸圖片幻燈片

圖 7 優先級隊列實現的地圖路徑

下載: 全尺寸圖片幻燈片

圖 8 堆棧實現的地圖路徑

下載: 全尺寸圖片幻燈片

圖 9 隊列實現的地圖路徑

下載: 全尺寸圖片幻燈片

圖 10 地圖樣式1

下載: 全尺寸圖片幻燈片

圖 11 地圖樣式2

下載: 全尺寸圖片幻燈片

圖 12 地圖樣式3

下載: 全尺寸圖片幻燈片

圖 13 地圖樣式4

下載: 全尺寸圖片幻燈片

1 A*算法的基本流程

(1)初始化開啟列表和關閉列表為空
(2)將七點插入開啟列表中
(3)while(開啟列表不為空)
(4) 從開啟列表中取出最小F值的格點作為當前格點，并將之加　　入關閉列表
(5) 　foreach(當前格點的相鄰格點)
(6) 　　if(該格點在關閉列表中或是故障格點) then(跳過該格點)
(7) 　　elsif(該格點在開啟列表中) then(比較通過當前格點計算　　　　得出的F值是否更小，若更小則更新該格點的F值，設其　　　　父節點為當前節點，并將之插入開啟列表)
(8) 　　elsif(該格點不在開啟列表中) then(通過當前節點計算該　　　　節點的F值，設其父親節點為當前節點，并將之插入開啟　　　　列表)
(9) 　　elsif(該格點為終點) then(設其父節點為當前節點，并通　　　　過追蹤父節點鏈條至起點，輸出起點到終點的路徑，算　　　　法結束)
(10) end_foreach
(11)end_while
(12)if(開啟列表為空) then(路徑搜索失敗)

下載: 導出CSV

表 1 SOC FPGA 芯片 PL 資源

資源名稱	總數
邏輯單元 LUT	87 840
LUTRAM	57 600
觸發器 Flip-flop(FF)	175 680
BRAM	128
I/O 引腳	256
全局時鐘緩沖器 BUFG	352

下載: 導出CSV

表 2 15×15地圖下不同開啟列表優化比較

數據結構	LUT個數	FF個數	BRAM個數	運行時長(ns)
優先隊列	2 485	2 807	3.0	18 598
隊列	2 137	2 755	2.5	44 325
堆棧	2 148	2 739	2.5	38 779

下載: 導出CSV

表 3 使用優先隊列數據結構的HLS和RTL開發模式比較

FPGA開發模式	運行時間	LUT個數	FF個數	BRAM個數
HLS	483 445	3 208	3 303	34.5
RTL	523 046	7 253	7 161	59.5

下載: 導出CSV

表 4 使用堆棧數據結構的HLS和RTL開發模式比較

FPGA開發模式	運行時間	LUT個數	FF個數	BRAM個數
HLS	3 305 830	1 669	1 523	25
RTL	5 987 348	7 313	7 065	56

下載: 導出CSV

表 5 使用隊列數據結構的HLS和RTL開發模式比較

FPGA開發模式	運行時間	LUT個數	FF個數	BRAM個數
HLS	3 389 425	1 756	1 555	25
RTL	5 598 080	7 317	7 053	56

下載: 導出CSV
