5G毫米波反向陣極簡構架與CMOS芯片實現

郭嘉誠; 胡三明; 沈一竹; 錢昀; 胡楚悠; 黃永明; 尤肖虎

doi:10.11999/JEIT240143

5G毫米波反向陣極簡構架與CMOS芯片實現

doi: 10.11999/JEIT240143

郭嘉誠^{1, 2},
胡三明^{1, 2},
沈一竹^{1, 2},
錢昀¹,
胡楚悠¹,
黃永明^{1, 2},
尤肖虎^{1, 2, ,}

1.
東南大學信息科學與工程學院南京 210096
2.
紫金山實驗室南京 211111

基金項目: 國家重點研發計劃(2019YFB2204701)，國家自然科學基金(61831006,62250610223)

詳細信息

作者簡介:
郭嘉誠：男，博士，研究方向為射頻、毫米波集成電路設計

胡三明：男，教授，博士生導師，研究方向為射頻、毫米波集成電路設計

沈一竹：女，教授，博士生導師，研究方向為毫米波電路及天線

錢昀：女，博士生，研究方向為射頻、毫米波集成電路設計

胡楚悠：女，碩士，研究方向為射頻、毫米波集成電路設計

黃永明：男，教授，博士生導師，研究方向為下一代移動通信技術

尤肖虎：男，教授，中國科學院院士，研究方向為未來移動通信理論與技術、智能信號處理與通信

通訊作者:
尤肖虎　xhyu@seu.edu.cn

中圖分類號: TN43
計量
- 文章訪問數: 413
- HTML全文瀏覽量: 341
- PDF下載量: 60
- 被引次數: 0
出版歷程
- 收稿日期: 2024-03-06
- 修回日期: 2024-04-29
- 網絡出版日期: 2024-05-12
- 刊出日期: 2024-05-30

Simplified Architecture of 5G Millimeter-wave Retrodirective Array and Its Implementation in CMOS Chips

GUO Jiacheng^{1, 2},
HU Sanming^{1, 2},
SHEN Yizhu^{1, 2},
QIAN Yun¹,
HU Chuyou¹,
HUANG Yongming^{1, 2},
YOU Xiaohu^{1, 2
, ,}

1.
School of Information Science and Engineering, Southeast University, Nanjing 210096, China
2.
Purple Mountain Laboratories, Nanjing 211111, China

Funds: The National Key Research and Development Program of China (2019YFB2204701), The National Natural Science Foundation of China (61831006, 62250610223)

摘要

摘要: 該文首次報道了一種極簡構架的5G毫米波反向陣設計原理及其CMOS芯片實現技術。該毫米波反向陣極簡構架，利用次諧波混頻器提供相位共軛和陣列反向功能，無需移相電路及波束控制系統，便可實現波束自動回溯移動通信功能。該文采用國產0.18 μm CMOS工藝研制了5G毫米波反向陣芯片，包括發射前端、接收前端及跟蹤鎖相環等核心模塊，其中發射及接收前端芯片采用次諧波混頻及跨導增強等技術，分別實現了19.5 dB和18.7 dB的實測轉換增益。所實現的跟蹤鎖相環芯片具備雙模工作優勢，可根據不同參考信號支持幅度調制及相位調制，實測輸出信號相噪優于–125 dBc/Hz@100 kHz。該文給出的測試結果驗證了所提5G毫米波反向陣通信架構及其CMOS芯片實現的可行性，從而為5G/6G毫米波通信探索了一種架構極簡、成本極低、拓展性強的新方案。
- 毫米波集成電路 /
- CMOS /
- 反向陣 /
- 射頻前端
Abstract: For the first time, a simplified architecture for 5G millimeter-wave retrodirective arrays and its implementation in CMOS chips is reported in this paper. Phase conjugation and retrodirective functions are provided by sub-harmonic mixers in the simplified architecture, eliminating the need for phase-shifting circuits and beam-controlling systems, thereby enabling automatic beam tracking for mobile communications. For validation, a domestic 0.18 μm CMOS process is employed to realize a 5G millimeter-wave retrodirective array chip, comprising core modules such as the transceiver front-ends and tracking phase-locked loop. Measured conversion gains of 19.5 dB for transmitting and 18.7 dB for receiving are achieved by the transceiver front-end chip utilizing sub-harmonic mixing and gm-boosting techniques. Dual-mode operation capabilities, supporting both amplitude modulation and phase modulation based on different reference signals, are provided by the implemented tracking phase-locked loop chip, with measured output signal phase noise lower than –125 dBc/Hz@100 kHz. The feasibility of the proposed 5G millimeter-wave retrodirective array communication architecture and its CMOS chip implementation is validated by the test results presented in this paper, thus offering a new solution for 5G/6G millimeter-wave communication characterized by its extremely simplified architecture, low cost, and high scalability.
- Millimeter-wave integrated circuit /
- CMOS /
- Retrodirective array /
- Radio Frequency (RF) front-end

HTML全文

圖 1 反向陣基本架構

下載: 全尺寸圖片幻燈片

圖 2 本文所提5G毫米波反向陣架構

下載: 全尺寸圖片幻燈片

圖 3 接收前端原理圖

下載: 全尺寸圖片幻燈片

圖 4 帶有補償電感的等效電路

下載: 全尺寸圖片幻燈片

圖 5 本振網絡輸出的瞬時仿真波形

下載: 全尺寸圖片幻燈片

圖 6 發射前端原理圖

下載: 全尺寸圖片幻燈片

圖 7 5G毫米波反向陣跟蹤鎖相環結構框圖

下載: 全尺寸圖片幻燈片

圖 8 跟蹤鎖相環中的整形電路

下載: 全尺寸圖片幻燈片

圖 9 5G毫米波頻段接收前端芯片顯微照片

下載: 全尺寸圖片幻燈片

圖 10 下變頻次諧波混頻器增益測試結果

下載: 全尺寸圖片幻燈片

圖 11 接收前端增益測試結果

下載: 全尺寸圖片幻燈片

圖 12 5G毫米波頻段發射前端芯片顯微照片

下載: 全尺寸圖片幻燈片

圖 13 上變頻混頻器增益測試結果

下載: 全尺寸圖片幻燈片

圖 14 發射前端增益測試結果

下載: 全尺寸圖片幻燈片

圖 15 5G毫米波頻段跟蹤相環芯片顯微照片

下載: 全尺寸圖片幻燈片

圖 16 跟蹤鎖相環芯片測試

下載: 全尺寸圖片幻燈片

圖 17 跟蹤鎖相環芯片測試結果

下載: 全尺寸圖片幻燈片

圖 18 跟蹤鎖相環芯片通信性能測試設置

下載: 全尺寸圖片幻燈片

圖 19 AM調制模式下的測試波形

下載: 全尺寸圖片幻燈片

圖 20 QPSK調制模式下測得的星座圖

下載: 全尺寸圖片幻燈片

表 1 下變頻次諧波混頻器性能對比總結

	文獻[27]	文獻[28]	文獻[29]	本文
工藝	0.13 μm CMOS	GaInP/GaAs	0.18 μm CMOS	0.18 μm CMOS
頻率(GHz)	8.65	10.00	21.00～40.00	22.00～29.00
增益(dB)	6.0	10.0	–8.2	7.0
輸入P1dB(dBm)	–18.0	–12.0	–4.0	–11.4
功耗(mW)	0.6	20.0	74.6	30.6

下載: 導出CSV

表 2 低噪聲放大器性能對比總結

	文獻[30]	文獻[31]	文獻[32]	本文
工藝	0.18 μm CMOS	0.18 μm CMOS	0.13 μm CMOS	0.18 μm CMOS
中心頻率(GHz)	22.0	25.7	24.0	25.0
增益(dB)	15.0	8.9	12.1	12.1
噪聲系數(dB)	6.00	6.93	10.40	7.30
功耗(mW)	16.0	30.0	12.0	34.2

下載: 導出CSV

表 3 上變頻次諧波混頻器性能對比總結

	文獻[33]	文獻[34]	文獻[35]	本文
工藝	65 nm CMOS	0.15 μm CMOS	65 nm CMOS	0.18 μm CMOS
頻率(GHz)	27.0～44.0	24.0～44.0	19.5～31.5	23.5～29.5
增益(dB)	–10.5	10.5	–5.1	6.0
輸出P1dB(dBm)	–9.0	–11.5	–15.4	–11.8
功耗(mW)	0	225.0	55.6	23.4

下載: 導出CSV

表 4 功率放大器性能對比總結

	文獻[36]	文獻[37]	本文
工藝	0.18 μm CMOS	0.18 μm CMOS	0.18 μm CMOS
中心頻率(GHz)	24	24	25
增益(dB)	7.0	11.0	14.5
輸出P1(dB)	11.0	10.0	4.5
功耗(mW)	100	42	118

下載: 導出CSV

表 5 反向陣構架對比總結

	文獻[38]	文獻[39]	文獻[10]	文獻[19]	文獻[22]	本文
芯片集成	×	×	×	√	√	√
工作頻段(GHz)	6.0	5.8	1.5	2.4	2.4	5G毫米波(26.0 GHz頻段)
調制方式及速率	BPSK 78.125 kB/s	AM 10 MB/s	16QAM 151.2 kB/s	×	AM 100 kB/s	AM 100 kB/s QPSK 1 MB/s

下載: 導出CSV
