小樣本SAR目標的雙重一致性因果識別方法

王陳煒; 羅思懿; 黃鈺林; 裴季方; 張寅; 楊建宇

doi:10.11999/JEIT240140

小樣本SAR目標的雙重一致性因果識別方法

doi: 10.11999/JEIT240140

電子科技大學信息與通信工程學院成都 611731

基金項目: 四川省自然科學基金 (2023NSFSC1970)

詳細信息

作者簡介:
王陳煒：男，博士，研究方向為雷達目標識別、機器學習、雷達探測成像等

羅思懿：女，碩士，研究方向為雷達目標識別、機器學習、雷達探測成像等

黃鈺林：男，教授，研究方向為雷達探測成像、雷達目標檢測與識別、人工智能與機器學習等

裴季方：男，副研究員，研究方向為雷達目標識別、機器學習、雷達探測成像等

張寅：男，研究員，研究方向為新體制雷達、雷達信號處理、雷達成像等

楊建宇：男，教授，研究方向為雷達探測與成像、信號檢測與估計等

通訊作者:
黃鈺林　yulinhuang@uestc.edu.cn

中圖分類號: TN958
計量
- 文章訪問數: 265
- HTML全文瀏覽量: 105
- PDF下載量: 50
- 被引次數: 0
出版歷程
- 收稿日期: 2024-03-06
- 修回日期: 2024-08-28
- 網絡出版日期: 2024-09-01
- 刊出日期: 2024-10-30

A Causal Interventional SAR ATR Method with Limited Data via Dual Consistency

School of Information and Communication Engineering, University of Electronic Science and Technology of China, Chengdu 611731, China

Funds: The Natural Science Foundation of Sichuan Province (2023NSFSC1970)

摘要

摘要: 在小樣本條件下提升方法的泛化性能，是合成孔徑雷達自動目標識別(SAR ATR)的重要研究方向。針對該方向中的基礎理論問題，該文建立了一個SAR ATR因果模型，證明了SAR圖像中背景、相干斑等干擾在充足樣本條件下可以被忽略；但在小樣本條件下，這些因素將成為識別中的混雜因子，在提取的SAR圖像特征中引入虛假相關性，影響SAR ATR性能。為了甄別和消除這些特征中的虛假效應，該文提出一個基于雙重一致性的小樣本SAR ATR方法，其中雙重一致性包括類內一致性掩碼和效應一致性損失。首先，基于鑒別特征應具有類內一致和類間差異的原則，利用類內一致性掩碼，捕獲目標的類內一致鑒別特征，甄別出目標特征中的混淆部分，準確估計出干擾引入的虛假效應。其次，基于不變風險最小化的思想，利用效應一致性損失，將經驗風險最小化數據量需求轉變?yōu)閷π?yīng)相似度的度量需求，降低虛假效應消除對數據量的需求，消除特征中的虛假效應。因而，所提基于雙重一致性的小樣本SAR ATR方法可實現特征提取中的真實因果，實現準確的識別性能。兩個基準數據集上的識別實驗，驗證了該方法的合理性和有效性，可提升小樣本條件下SAR目標識別的性能。
- 合成孔徑雷達 /
- 自動目標識別 /
- 小樣本 /
- 因果推斷
Abstract: Improving the generalization performance of methods under limited sample conditions is an important research direction in Synthetic Aperture Radar Automatic Target Recognition (SAR ATR). Addressing the fundamental problem in this field, a causal model is established in this paper for SAR ATR, demonstrating that interferences in SAR images, such as background and speckle, can be neglected under sufficient sample conditions. However, under limited sample conditions, these factors become confounding variables, introducing spurious correlations into the extracted SAR image features and affecting the generalization of SAR ATR. To accurately identify and eliminate these spurious effects in the features, this paper proposes a limited-sample SAR ATR method via dual consistency, which includes an intra-class feature consistency mask and effect-consistency loss. Firstly, based on the principle that discriminative features should have intra-class consistency and inter-class differences, the intra-class feature consistency mask is used to capture the consistent discriminative features of the target, subtracting the confounded part in the target features, and identifying the spurious effects introduced by interferences. Secondly, based on the idea of invariant risk minimization, the effect-consistency loss transforms the data requirement of empirical risk minimization into a need for labeling the similarity among effects of different samples, reducing the data demand for eliminating spurious effects and removing the spurious effects in the features. Thus, the limited-sample SAR ATR method proposed in this paper achieves true causal feature extraction and accurate recognition performance. Experiments on two benchmark datasets validate the effectiveness of this method which can achieve superior performance of SAR target recognition with limited sample.
- Synthetic Aperture Radar (SAR) /
- Automatic target recognition /
- Limited data /
- Causal inference

HTML全文

圖 1 有限SAR樣本在ATR中引入的因果效應變化

下載: 全尺寸圖片幻燈片

圖 2 本文方法的總體框架

下載: 全尺寸圖片幻燈片

表 1 MSTAR數據集下的訓練集與測試集

類別	訓練集		測試集
類別	數量	俯仰角	數量	俯仰角
BMP2-9563	233	17°	195	15°
BRDM2-E71	298		274
BTR60-7532	256		195
BTR70-c71	233		196
D7-92	299		274
2S1-b01	299		274
T62-A51	299		273
T72-132	232		196
ZIL131-E12	299		274
ZSU234-d08	299		274

下載: 導出CSV

表 2 MSTAR數據集不同訓練樣本數量下10類目標的識別性能(%)

類別	每類目標訓練樣本數
類別	5	10	20	25	30	40	60	80	100
BMP2	73.33	83.59	92.31	94.87	95.90	97.95	98.97	97.44	98.46
BRDM2	77.74	94.89	93.80	96.72	97.08	98.18	99.27	99.64	98.91
BTR60	83.59	86.67	91.79	94.36	94.87	95.90	98.97	96.92	97.44
BTR70	70.92	90.82	92.35	95.92	96.94	98.47	97.96	98.98	98.98
D7	68.98	83.58	92.70	95.26	95.99	97.45	98.54	99.64	99.64
2S1	81.75	80.29	93.80	95.99	97.08	98.54	98.91	99.64	98.91
T62	74.36	90.11	92.67	95.60	97.07	98.53	97.44	99.63	99.63
T72	89.80	86.22	91.84	95.41	96.94	98.47	98.98	98.98	98.98
ZIL131	68.25	85.77	93.07	96.72	97.81	98.54	98.91	99.64	99.64
ZSU234	74.45	80.29	93.80	96.72	97.08	98.18	98.54	99.64	99.64
平均值	76.13	86.38	93.00	96.07	97.01	98.24	98.79	99.32	99.35

下載: 導出CSV

表 3 OpenSARShip數據集中訓練與測試集

類別	成像條件	訓練樣本數	測試樣本數	總樣本數
Bulk Carrier	VH 和 VV, C 波段分辨率=5～20 m 入射角=20°～45° 仰角=±11° Rg20 m×az22 m	200	475	675
Container Ship		200	811	1011
Tanker		200	354	554

下載: 導出CSV

表 4 OpenSARShip數據集不同訓練樣本數量下3類艦船目標的識別性能(%)

類別	每類訓練樣本數
類別	10	20	30	40	50	60	70	80	100	200
Bulk Carrier	65.89	63.58	65.68	75.16	60.21	66.11	68.21	65.26	72.84	73.47
Container Ship	71.27	75.46	75.96	76.57	82.49	79.04	80.02	85.20	83.35	90.75
Tanker	79.10	82.77	81.92	74.01	84.46	86.16	84.46	81.92	78.81	82.77
平均值	71.51	73.75	74.41	75.66	76.58	76.92	77.66	78.86	79.41	84.12

下載: 導出CSV

表 5 消融實驗：20個訓練樣本下不同消融配置的識別性能(%)

方法配置	特征	效應	BMP2	BRDM2	BTR60	BTR70	D7	2S1	T62	T72	ZIL131	ZSU234	平均值
V1	×	×	80.51	75.91	74.87	80.10	73.72	76.28	78.75	82.14	84.31	86.86	79.59
V2	√	×	88.21	89.05	81.54	88.27	85.77	96.35	81.68	84.18	87.23	94.16	88.16
V3	√	√	92.31	93.80	91.79	92.35	92.70	93.80	92.67	91.84	93.07	93.80	93.00

下載: 導出CSV

表 6 MSTAR數據集下SAR目標識別性能對比(%)

方法		每類樣本數
方法		10	20	40	55	80	110	165	220	All data
傳統方法	PCA+SVM ^[14]	–	76.43	87.95	–	92.48	–	–	–	94.32
	ADaboost ^[14]	–	75.68	86.45	–	91.45	–	–	–	93.51
	DGM^[14]	–	81.11	88.14	–	92.85	–	–	–	96.07
數據增強	GAN-CNN ^[14]	–	81.80	88.35	–	93.88	–	–	–	97.03
數據增強	MGAN-CNN^[14]	–	85.23	90.82	–	94.91	–	–	–	97.81
新穎模型	Deep CNN ^[15]	–	77.86	86.98	–	93.04	–	–	–	95.54
	Simple CNN ^[16]	–	75.88	–	–	–	–	–	–	–
	Dens-CapsNet ^[17]	80.26	92.95	96.50	–	–	–	–	–	99.75
	ASC-MACN ^[18]	62.85	79.46	–	–	–	–	–	–	99.42
	本文方法	86.38	93.00	98.24	–	99.32	–	–	–	–

下載: 導出CSV

參考文獻(18)

[1]	CURLANDER J C and MCDONOUGH R N. Synthetic Aperture Radar: Systems and Signal Processing[M]. New York: Wiley, 1991.
[2]	KREUCHER C. SAR-ATR using EO-based deep networks[C]. 2023 IEEE Radar Conference (RadarConf23), San Antonio, USA, 2023: 1–5. doi: 10.1109/RadarConf2351548.2023.10149584.
[3]	MAO Deqing, YANG Jianyu, ZHANG Yongchao, et al. Angular superresolution of real aperture radar with high-dimensional data: Normalized projection array model and adaptive reconstruction[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5117216. doi: 10.1109/TGRS.2022.3203131.
[4]	MAO Deqing, YANG Jianyu, TUO Xingyu, et al. Angular superresolution of real aperture radar for target scale measurement using a generalized hybrid regularization approach[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5109314. doi: 10.1109/TGRS.2023.3315310.
[5]	CHOI J H, LEE M J, JEONG N H, et al. Fusion of target and shadow regions for improved SAR ATR[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5226217. doi: 10.1109/TGRS.2022.3165849.
[6]	HUANG Zhongling, YAO Xiwen, LIU Ying, et al. Physically explainable CNN for SAR image classification[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2022, 190: 25–37. doi: 10.1016/j.isprsjprs.2022.05.008.
[7]	WANG Chenwei, LUO Siyi, PEI Jifang, et al. Crucial feature capture and discrimination for limited training data SAR ATR[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2023, 204: 291–305. doi: 10.1016/j.isprsjprs.2023.09.014.
[8]	FENG Sijia, JI Kefeng, WANG Fulai, et al. PAN: Part attention network integrating electromagnetic characteristics for interpretable SAR vehicle target recognition[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5204617. doi: 10.1109/TGRS.2023.3256399.
[9]	WANG Chenwei, LUO Siyi, HUANG Yulin, et al. SAR ATR method with limited training data via an embedded feature augmenter and dynamic hierarchical-feature refiner[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5216215. doi: 10.1109/TGRS.2023.3314501.
[10]	PEARL J. Causal inference in statistics: An overview[J]. Statistics Surveys, 2009, 3: 96–146. doi: 10.1214/09-SS057.
[11]	SCH?LKOPF B, JANZING D, PETERS J, et al. On causal and anticausal learning[C]. Proceedings of the 29th International Conference on Machine Learning, Edinburgh, UK, 2012.
[12]	GREENLAND S, PEARL J, and ROBINS J M. Causal diagrams for epidemiologic research[J]. Epidemiology, 1999, 10(1): 37–48. doi: 10.1097/00001648-199901000-00008.
[13]	ZHANG Tianwen, ZHANG Xiaoling, KE Xiao, et al. HOG-ShipCLSNet: A novel deep learning network with hog feature fusion for SAR ship classification[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5210322. doi: 10.1109/TGRS.2021.3082759.
[14]	ZHENG Ce, JIANG Xue, and LIU Xingzhao. Semi-supervised SAR ATR via multi-discriminator generative adversarial network[J]. IEEE Sensors Journal, 2019, 19(17): 7525–7533. doi: 10.1109/JSEN.2019.2915379.
[15]	MORGAN D A E. Deep convolutional neural networks for ATR from SAR imagery[C]. SPIE 9475, Algorithms for Synthetic Aperture Radar Imagery XXII, Baltimore, USA, 2015: 94750F. doi: 10.1117/12.2176558.
[16]	LI Yibing, LI Xiang, SUN Qian, et al. SAR image classification using CNN embeddings and metric learning[J]. IEEE Geoscience and Remote Sensing Letters, 2022, 19: 4002305. doi: 10.1109/LGRS.2020.3022435.
[17]	WANG Quan, XU Haixia, YUAN Liming, et al. Dense capsule network for SAR automatic target recognition with limited data[J]. Remote Sensing Letters, 2022, 13(6): 533–543. doi: 10.1080/2150704X.2022.2044089.
[18]	FENG Sijia, JI Kefeng, WANG Fulai, et al. Electromagnetic Scattering Feature (ESF) module embedded network based on ASC model for robust and interpretable SAR ATR[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5235415. doi: 10.1109/TGRS.2022.3208333.
