完全可編程閥門陣列生物芯片下容錯導向的高階綜合算法

朱予涵; 劉博文; 黃興; 劉耿耿

doi:10.11999/JEIT240049

完全可編程閥門陣列生物芯片下容錯導向的高階綜合算法

doi: 10.11999/JEIT240049

朱予涵^{1, 2, 3},
劉博文^{1, 2, 3},
黃興⁴,
劉耿耿^{1, 2, 3, ,}

1.
福州大學計算機與大數據學院福州 350116
2.
大數據智能教育部工程研究中心福州 350116
3.
福建省網絡計算與智能信息處理重點實驗室福州 350116
4.
西北工業大學計算機學院西安 710072

基金項目: 福建省杰出青年科學基金(2023J06017)

詳細信息

作者簡介:
朱予涵：女，博士生，研究方向為微流體生物芯片設計自動化

劉博文：男，博士生，研究方向為微流體生物芯片設計自動化

黃興：男，博士，教授，研究方向為微流體生物芯片及超大規模集成電路設計自動化

劉耿耿：男，博士，教授，研究方向為微流體生物芯片及超大規模集成電路設計自動化

通訊作者:
劉耿耿　liugenggeng@fzu.edu.cn

中圖分類號: TN402; TP391.41
計量
- 文章訪問數: 163
- HTML全文瀏覽量: 84
- PDF下載量: 23
- 被引次數: 0
出版歷程
- 收稿日期: 2024-01-24
- 修回日期: 2024-09-04
- 網絡出版日期: 2024-09-17
- 刊出日期: 2024-11-01

Fault-tolerance-oriented High-level Synthesis Algorithm for Fully Programmable Valve Array Biochips

ZHU Yuhan^{1, 2, 3},
LIU Bowen^{1, 2, 3},
HUANG Xing⁴,
LIU Genggeng^{1, 2, 3
, ,}

1.
College of Computer and Data Science, Fuzhou University, Fuzhou 350116, China
2.
Engineering Research Center of Big Data Intelligence, Ministry of Education, Fuzhou 350116, China
3.
Fujian Key Laboratory of Network Computing and Intelligent Information Processing, Fuzhou 350116, China
4.
School of Computer Science, Northwestern Polytechnical University, Xi’an 710072, China

Funds: Fujian Science Fund for Distinguished Young Scholars (2023J06017)

摘要

摘要: 作為新一代流式微流控生物芯片，完全可編程閥門陣列(FPVA)生物芯片具有更高的靈活性和可編程性，已經成為一種流行的生物化學實驗平臺。然而，由于環境或人為因素，制造過程中通常存在一些物理故障，如通道阻塞和泄漏，這無疑會影響生化檢測的結果。此外，高階綜合作為架構綜合的首要階段，其結果的質量直接影響著后續設計的優劣。因此，該文首次研究了FPVA生物芯片高階綜合過程中的容錯問題，提出了單元功能轉換方法、雙向冗余方法、故障映射方法等動態容錯技術，為實現高效的容錯設計提供了技術保障。通過將這些技術集成到高階綜合設計中，進一步實現了一種高質量的FPVA生物芯片下容錯導向的高階綜合算法，包括故障感知的實時綁定策略和故障感知的優先級調度策略，為實現芯片架構的魯棒性和檢測結果的準確性奠定了良好的基礎。實驗結果顯示，所提算法能夠得到一個FPVA生物芯片下高質量且容錯的高階綜合方案，為后續實現容錯物理設計方案提供了有力保障。
- 微流控生物芯片 /
- 完全可編程閥門陣列 /
- 物理故障 /
- 容錯 /
- 高階綜合
Abstract: As a new generation of flow-based microfluidics, Fully Programmable Valve Array (FPVA) biochips have become a popular biochemical experimental platform that provide higher flexibility and programmability. Due to environmental and human factors, however, there are usually some physical faults in the manufacturing process such as channel blockage and leakage, which, undoubtedly, can affect the results of bioassays. In addition, as the primary stage of architecture synthesis, high-level synthesis directly affects the quality of sub-sequent design. The fault tolerance problem in the high-level synthesis stage of FPVA biochips is focused on for the first time in this paper, and dynamic fault-tolerant techniques, including a cell function conversion method, a bidirectional redundancy scheme, and a fault mapping method, are presented, providing technical guarantee for realizing efficient fault-tolerant design. By integrating these techniques into the high-level synthesis stage, a high-quality fault-tolerance-oriented high-level synthesis algorithm for FPVA biochips is further realized in this paper, including a fault-aware real-time binding strategy and a fault-aware priority scheduling strategy, which lays a good foundation for the robustness of chip architecture and the correctness of assay outcomes. Experimental results confirm that a high-quality and fault-tolerant high-level synthesis scheme of FPVA biochips can be obtained by the proposed algorithm, providing a strong guarantee for the subsequent realization of a fault-tolerant physical design scheme.
- Microfluidics biochips /
- Fully Programmable Valve Array (FPVA) /
- Physical faults /
- Fault tolerance /
- High-level synthesis

HTML全文

圖 1 FPVA架構及其拓?fù)溥B接圖

下載: 全尺寸圖片幻燈片

圖 2 制造缺陷示例^[11]

下載: 全尺寸圖片幻燈片

圖 3 FPVA生物芯片高階綜合示例

下載: 全尺寸圖片幻燈片

圖 4 FPVA下容錯導向的高階綜合算法流程圖

下載: 全尺寸圖片幻燈片

圖 5 動態容錯技術示例

下載: 全尺寸圖片幻燈片

1 動態容錯綁定算法

輸入：FPVA單元集$C$，操作集$O$，組件數量為${N_M}$的組件庫$M$，物理故障位置${F_i}$(包括合并單元、故障單元及包含故障連接的單元)
輸出：一個容錯的綁定方案
//初始綁定階段
for each operation ${O_i}$ of $O$ do
Banding(${O_i}$,${M_j}$) = Random(0, ${N_M}$–1)；//將操作${O_i}$隨機綁定到一個組件${M_j}$
end for
for each cell ${C_i}$ of $C$ do
if ${C_i}$ == ${F_i}$ then
${C_i}$_state = –1；//標記為不可用單元
Continue;
else
${C_i}$_state = 0；//標記為空閑單元
Continue;
end if
end for
//綁定調整階段
for each module ${M_j}$ of M do
for each cell ${C_k}$ of ${M_j}$ do
if ${C_k}$_state == –1 then //${C_k}$為不可用單元
Construct_spare_module(${M_j}$)；//根據雙向冗余技術從空閑單元中選擇備用單元
Banding(${O_i}$,${M_j}$);
end if
if Done(${M_j}$) == True do //組件上的操作已執行完成
${C_k}$_state = 0; //根據單元功能轉換將組件${M_j}$占據單元轉換為空閑單元
end if
end for
end for

下載: 導出CSV

2 動態容錯調度算法

輸入：FPVA單元集$C$, 操作集$O$，操作間的依賴關系，每個操作執行時間$ {t_{\text{e}}}\left( {{O_j}} \right) $，和輸入流體，物理故障位置${F_i}$(包括故障單元以及包　含故障連接的單元)
輸出：一個容錯的調度方案
//初始調度順序生成
for each operation ${O_i}$ of $O$ do
${\text{pri}}\left( {{O_i}} \right) = \displaystyle\sum\nolimits_{{O_j} \in {\text{son}}\left( {{O_i}} \right)} {{t_{\text{e}}}\left( {{O_j}} \right) + {t_{\text{c}}} \times \left\| {{\text{son}}\left( {{O_i}} \right) - 1} \right\|} $；//計算操作${O_i}$的優先級
end for
Sorting($O$)；//根據調度優先級由大到小將操作排序
for each cell ${C_i}$ of $C$ do
if ${C_i}$ == ${F_i}$ then
${C_i}$_state = –1；//標記為不可用單元
Continue;
else
${C_i}$_state = 0；//標記為空閑單元
Continue;
end if
end for
//調度順序調整
for each operation ${O_i}$ of $O$ do
for each fluid ${r_j}$ of ${O_i}$ do
for each cell ${C_k}$ of ${r_j}$ do
if ${C_k}$_state == –1 then // ${C_k}$為不可用單元
Construct_spare_path(${r_j}$)；//根據雙向冗余技術從空閑單元中選擇備用單元
end if
if Reached (${r_j}$) == True do //輸入流體已到達目標組件
${C_k}$_state = 0；//根據單元功能轉換將流體${r_j}$占據單元轉換為空閑單元
end if
end for
end for
end for

下載: 導出CSV

表 1 圖3對應的綁定與調度方案

時間	動作
$0$～$ {t_{\text{c}}} $	分別運輸輸入流體${r_1}$, ${r_3}$, ${r_5}$到組件${M_1}$, ${M_2}$, ${M_3}$
$ {t_{\text{c}}} $～$2{t_{\text{c}}}$	分別運輸輸入流體${r_2}$, ${r_4}$到組件${M_1}$, ${M_2}$
$2{t_{\text{c}}}$～($2{t_{\text{c}}} + 4$)	執行混合操作${O_1}$, ${O_2}$
$\left( {2{t_{\text{c}}} + 4} \right)$～$\left( {3{t_{\text{c}}} + 4} \right)$	運輸${O_1}$, ${O_2}$的混合產物到混合器${M_3}$
$\left( {3{t_{\text{c}}} + 4} \right)$～$\left( {3{t_{\text{c}}} + 8} \right)$	執行混合操作${O_3}$

下載: 導出CSV

表 2 策略有效性對比結果

測試用例	(輸入流體數，輸出流體數，混合操作數)	FPVA 尺寸	生物測定完成時間			流體運輸路徑總長度
測試用例	(輸入流體數，輸出流體數，混合操作數)	FPVA 尺寸	基準算法	本文算法	優化(%)	基準算法	本文算法	優化(%)
PCR	(8,1,7)	$ \times $$8 \times 8$	14.5	13.8	4.8	56.9	54.4	4.4
IVD1	(12,6,6)	$8 \times 8$$ \times $	7.2	6.5	9.7	84.0	82.3	2.0
IVD2	(18,9,9)	$10 \times 10$$ \times $	8.8	8.4	4.5	174.3	171.3	1.7
ProteinSplit1	(14,2,12)	$10 \times 10$$ \times $	27.4	26.9	1.8	126.4	122.5	3.1
ProteinSplit2	(32,4,23)	$13 \times 13$	35.4	33.8	4.5	491.6	486.6	1.0
Synthetic1	(5,1,4)	$8 \times 8$	13.5	12.8	5.2	37.2	35.8	3.8
Synthetic2	(13,1,12)	$10 \times 10$$ \times $	22.6	21.8	3.5	121.6	116.8	3.9
Synthetic3	(18,1,17)	$12 \times 12$	28.1	27.4	2.5	217.6	210.7	3.2
Synthetic4	(22,1,21)	$13 \times 13$	27.4	26.6	2.9	312.6	305.4	2.3
Synthetic5	(27,1,26)	$13 \times 13$	29.9	28.7	4.0	386.9	377.2	2.5
平均值					4.3			2.8

下載: 導出CSV

表 3 與RAS-FT^[5]的性能對比結果

測試用例	生物測定完成時間			流體運輸路徑總長度			容錯成功率(%)
測試用例	RAS-FT^[5]	基于本文算法的架構綜合算法	優化(%)	RAS-FT^[5]	基于本文算法的架構綜合算法	優化(%)	RAS-FT^[5]	基于本文算法的架構綜合算法	優化
PCR	21.2	13.8	34.9	82.8	54.4	34.3	100.0	53.0	47.0
IVD1	11.5	6.5	43.5	121.9	82.3	32.5	100.0	40.0	60.0
IVD2	14.3	8.4	41.3	239.8	171.3	28.6	100.0	38.0	62.0
ProteinSplit1	38.7	26.9	30.5	173.1	122.5	29.2	100.0	13.0	87.0
ProteinSplit2	50.1	33.8	32.5	732.0	486.6	33.5	100.0	3.0	97.0
Synthetic1	18.1	12.8	29.3	57.1	35.8	37.3	100.0	29.0	71.0
Synthetic2	30.0	21.8	27.3	181.8	116.8	35.8	100.0	25.0	75.0
Synthetic3	36.4	27.4	24.7	327.4	210.7	35.6	100.0	16.0	84.0
Synthetic4	35.8	26.6	25.7	401.6	305.4	24.0	100.0	11.0	89.0
Synthetic5	38.5	28.7	25.5	505.3	377.2	25.4	100.0	8.0	92.0
平均值			31.5			31.6			76.4

下載: 導出CSV
