一種基于人體輪廓形變場的雙流網絡步態識別方法

霍威; 王科; 唐俊; 王年; 梁棟

doi:10.11999/JEIT231025

一種基于人體輪廓形變場的雙流網絡步態識別方法

doi: 10.11999/JEIT231025

霍威¹,
王科²,
唐俊^1, ,,
王年¹,
梁棟²

1.
安徽大學電子信息工程學院合肥 230601
2.
安徽大學互聯網學院合肥 230039

基金項目: 國家自然科學基金(62273001, 61772032)，安徽省重點研究與開發計劃(2022k07020006)，安徽高校自然科學研究重大項目(KJ2021ZD0004)

詳細信息

作者簡介:
霍威：男，博士生，研究方向為圖像處理

王科：男，講師，研究方向為機器學習、模式識別

唐?。耗?，教授，研究方向為圖像處理、模式識別

王年：男，教授，研究方向為信號處理、模式識別

梁棟：男，教授，研究方向為信號處理、模式識別

通訊作者:
唐俊　tangjunahu@163.com

中圖分類號: TN911.73;TP391.41
計量
- 文章訪問數: 256
- HTML全文瀏覽量: 111
- PDF下載量: 46
- 被引次數: 0
出版歷程
- 收稿日期: 2023-09-19
- 修回日期: 2024-09-04
- 網絡出版日期: 2024-09-16
- 刊出日期: 2024-10-30

A Dual-stream Network Based on Body Contour Deformation Field for Gait Recognition

HUO Wei¹,
WANG Ke²,
TANG Jun^{1
, ,},
WANG Nian¹,
LIANG Dong²

1.
School of Electronic and Information Engineering, Anhui University, Hefei 230601, China
2.
School of Internet, Anhui University, Hefei 230039, China

Funds: The National Natural Science Foundation of China (62273001, 61772032), Anhui Provincial Key Research and Development Project (2022k07020006), The Natural Science Research Key Project of Anhui Educational Committee (KJ2021ZD0004)

摘要

摘要: 步態識別易受相機視角、服裝和攜帶物等外界因素影響而性能下降。為此，該文將非剛性點集配準引入步態識別，利用相鄰步態幀之間的形變場表征行走過程中人體輪廓發生的位移量，從而提升對人體形態變化的動態感知能力。在此基礎上，該文提出一種基于人體輪廓形變場的雙流卷積神經網絡GaitDef，該網絡模型由形變場和步態剪影兩路特征提取分支構成。針對形變場數據的稀疏性設計多尺度特征提取模塊，以獲取形變場的多層次空間結構信息。針對步態剪影提出動態差異捕捉模塊和上下文信息增強模塊，以捕捉動態區域的變化特性和利用上下文信息增強步態表征能力。雙分支網絡的輸出特征經過特征融合得到最終的步態表示。大量實驗結果表明了該文方法的有效性，在CASIA-B和CCPG數據集上，該文方法的平均Rank-1準確率分別能達到93.5%和68.3%。
- 步態識別 /
- 點集配準 /
- 卷積神經網絡 /
- 特征融合
Abstract: Gait recognition is susceptible to external factors such as camera viewpoints, clothing, and carrying conditions, which could lead to performance degradation. To address these issues, the technique of non-rigid point set registration is introduced into gait recognition, which is used to improve the dynamic perception ability of human morphological changes by utilizing the deformation field between adjacent gait frames to represent the displacement of human contours during walking. Accordingly, a dual-flow convolutional neural network-GaitDef exploiting human contour deformation field is proposed in this paper, which consists of deformation field and gait silhouette extraction branches. Besides, a multi-scale feature extraction module is designed for the sparsity of deformation field data to obtain multi-level spatial structure information of the deformation field. A dynamic difference capture module and a context information augmentation module are proposed to capture the changing characteristics of dynamic regions in gait silhouettes and consequently enhance gait representation ability by utilizing context information. The output features of the dual-branch network structure are fused to obtain the final gait representation. Extensive experimental results verify the effectiveness of GaitDef. The average Rank-1 accuracy of GaitDef can achieve 93.5%和68.3% on CASIA-B and CCPG datasets, respectively.
- Gait recognition /
- Point set registration /
- Convolutional Neural Network (CNN) /
- Feature fusion

HTML全文

圖 1 GaitDef網絡框架

下載: 全尺寸圖片幻燈片

圖 2 多尺度特征提取模塊(MSFEM)的網絡結構

下載: 全尺寸圖片幻燈片

圖 3 幀間差異性和上下文信息特征提取模塊(ACFEM)

下載: 全尺寸圖片幻燈片

圖 4 人體輪廓點離散化和配準過程

下載: 全尺寸圖片幻燈片

圖 5 基于不同人體輪廓點數量的形變場分支網絡在CASIA-B數據集上的實驗結果

下載: 全尺寸圖片幻燈片

表 1 Rank-1識別準確率在CASIA-B數據集上的對比結果，不包括相同視角的情況(%)

驗證集 NM＃1-4			0°～180°											均值
探針集			0°	18°	36°	54°	72°	90°	108°	126°	144°	162°	180°	均值
NM＃ 5-6	GaitSet	AAAI19	90.8	97.9	99.4	96.9	93.6	91.7	95.0	97.8	98.9	96.8	85.8	95.0
	GaitPart	CVPR20	94.1	98.6	99.3	98.5	94.0	92.3	95.9	98.4	99.2	97.8	90.4	96.2
	GaitGL	ICCV21	96.0	98.3	99.0	97.9	96.9	95.4	97.0	98.9	99.3	98.8	94.0	97.4
	CSTL	ICCV21	97.2	99.0	99.2	98.1	96.2	95.5	97.7	98.7	99.2	98.9	96.5	97.8
	Lagrange	CVPR22	95.2	97.8	99.0	98.0	96.9	94.6	96.9	98.8	98.9	98.0	91.5	96.9
	MetaGait	ECCV22	97.3	99.2	99.5	99.1	97.2	95.5	97.6	99.1	99.3	99.1	96.7	98.1
	GaitGCI-T	CVPR23	–	–	–	–	–	–	–	–	–	–	–	97.9
	GaitDef	本文	95.3	98.1	99.2	98.0	96.7	96.0	98.6	99.4	99.2	99.1	94.1	97.6
BG＃ 5-6	GaitSet	AAAI19	83.8	91.2	91.8	88.8	83.3	81.0	84.1	90.0	92.2	94.4	79.0	87.2
	GaitPart	CVPR20	89.1	94.8	96.7	95.1	88.3	94.9	89.0	93.5	96.1	93.8	85.8	91.5
	GaitGL	ICCV21	92.6	96.6	96.8	95.5	93.5	89.3	92.2	96.5	98.2	96.9	91.5	94.5
	CSTL	ICCV21	91.7	96.5	97.0	95.4	90.9	88.0	91.5	95.8	97.0	95.5	90.3	93.6
	Lagrange	CVPR22	89.9	94.5	95.9	94.6	93.9	88.0	91.1	96.3	98.1	97.3	88.9	93.5
	MetaGait	ECCV22	92.9	96.7	97.1	96.4	94.7	90.4	92.9	97.2	98.5	98.1	92.3	95.2
	GaitGCI-T	CVPR23	–	–	–	–	–	–	–	–	–	–	–	95.0
	GaitDef	本文	93.8	97.0	97.1	96.7	95.8	92.5	95.2	97.5	98.3	97.0	92.0	95.7
CL＃ 5-6	GaitSet	AAAI19	61.4	75.4	80.7	77.3	72.1	70.1	71.5	73.5	73.5	68.4	50.0	70.4
	GaitPart	CVPR20	70.7	85.5	86.9	83.3	77.1	72.5	76.9	82.2	83.8	80.2	66.5	78.7
	GaitGL	ICCV21	76.6	90.0	90.3	87.1	84.5	79.0	84.1	87.0	87.3	84.4	69.5	83.6
	CSTL	ICCV21	78.1	89.4	91.6	86.6	82.1	79.9	81.8	86.3	88.7	86.6	75.3	84.2
	Lagrange	CVPR22	81.6	91.0	94.8	92.2	85.5	82.1	86.0	89.8	90.6	86.0	73.5	86.6
	MetaGait	ECCV22	80.0	91.8	93.0	87.8	86.5	82.9	85.2	90.0	90.8	89.3	78.4	86.9
	GaitGCI-T	CVPR23	–	–	–	–	–	–	–	–	–	–	–	86.4
	GaitDef	本文	77.8	92.8	94.2	91.0	87.7	82.7	86.4	90.1	91.9	88.5	75.6	87.2

下載: 導出CSV

表 2 Rank-1識別準確率在CCPG數據集上的對比結果，不包括相同視角的情況(%)

			相機編號
			1	2	3	4	5	6	7	8	9	10	均值
CL-FULL	GaitSet	AAAI19	50.6	44.7	57.0	63.8	59.2	61.4	58.3	65.9	62.5	67.4	59.1
	GaitPart	CVPR20	49.8	42.4	56.5	60.3	58.8	62.4	56.1	63.7	62.1	66.1	57.8
	GaitGL	ICCV21	56.0	47.9	60.9	65.8	60.7	64.9	58.2	67.8	68.2	65.7	61.6
	GaitDef	本文	59.3	52.3	65.4	66.5	66.3	70.3	62.9	70.1	68.5	72.3	65.4
CL-UP	GaitSet	AAAI19	59.2	56.0	64.2	65.2	66.8	70.7	66.0	66.3	64.5	72.2	65.1
	GaitPart	CVPR20	58.6	52.3	62.4	65.1	65.9	68.3	61.8	65.8	64.4	67.6	63.2
	GaitGL	ICCV21	61.8	59.1	67.4	68.9	68.6	72.3	65.0	71.6	73.9	69.8	67.8
	GaitDef	本文	66.1	62.4	71.2	71.2	72.7	76.8	69.3	72.9	73.0	75.6	71.1
CL-DN	GaitSet	AAAI19	59.9	52.9	62.7	68.0	65.1	66.3	63.7	69.6	67.6	72.4	64.8
	GaitPart	CVPR20	58.2	49.6	61.1	65.5	64.9	68.0	60.8	66.2	69.4	69.4	63.3
	GaitGL	ICCV21	63.4	51.7	63.7	65.1	63.4	67.1	59.3	68.3	71.6	66.9	64.1
	GaitDef	本文	63.8	51.2	62.5	62.5	66.8	68.9	61.2	69.1	70.0	69.4	64.5
BG	GaitSet	AAAI19	64.3	54.8	69.9	74.1	69.6	73.3	67.5	67.7	66.2	73.6	68.1
	GaitPart	CVPR20	62.7	56.0	67.1	68.3	70.1	72.8	63.4	67.4	65.0	72.9	66.6
	GaitGL	ICCV21	64.7	55.0	71.6	72.6	67.3	74.9	66.0	74.1	73.1	75.4	69.5
	GaitDef	本文	67.6	55.2	74.1	76.0	72.3	77.0	71.2	75.2	74.6	77.8	72.1

下載: 導出CSV

表 3 不同分支網絡結構在CASIA-B數據集上的Rank-1識別準確率,不包括相同視角的情況(%)

網絡分支	特征提取模塊結構	NM	BG	CL	均值
形變場分支	MSFEM只使用卷積核尺寸為(3,3,3)的卷積	88.9	80.2	58.1	75.7
	MSFEM只使用卷積核尺寸為(3,5,5)的卷積	92.4	85.3	66.9	81.5
	MSFEM只包含卷積核尺寸為(3,7,7)的卷積	92.4	84.8	67.3	81.5
	MSFEM使用卷積核尺寸為(3,3,3)和(3,5,5)的卷積	92.5	85.7	67.6	81.9
	MSFEM使用卷積核尺寸為(3,3,3)和(3,7,7)的卷積	92.8	85.4	67.3	81.8
	MSFEM使用卷積核尺寸為(3,5,5)和(7,7,7)的卷積	93.1	85.7	67.9	82.2
	MSFEM	93.0	86.4	69.2	82.9
步態剪影分支	ACFEM只使用全局特征分支	96.8	94.1	84.1	91.7
	ACFEM只使用幀間差異性特征提取分支	97.0	94.6	84.6	92.1
	ACFEM只使用上下文特征提取分支	96.6	94.0	83.7	91.4
	ACFEM使用全局特征和幀間差異性特征提取分支	97.2	95.3	86.1	92.9
	ACFEM使用全局特征和上下文特征提取分支	97.2	94.7	85.2	92.4
	ACFEM使用幀間差異性特征和上下文特征提取分支	97.1	95.1	86.4	92.9
	ACFEM	97.5	95.4	86.6	93.2
特征融合	形變場分支(MSFEM)+步態剪影分支(ACFEM)	97.6	95.7	87.2	93.5

下載: 導出CSV

表 4 不同分支網絡結構在CCPG數據集上的Rank-1識別準確率,不包括相同視角的情況(%)

網絡分支	特征提取模塊結構	CL-Full	CL-UP	CL-DN	BG	均值
形變場分支	MSFEM	50.5	59.8	57.5	61.4	57.3
步態剪影分支	ACFEM	62.0	67.5	62.8	68.2	65.1
特征融合	形變場分支(MSFEM)+步態剪影分支(ACFEM)	65.4	71.1	64.5	72.1	68.3

下載: 導出CSV

表 5 3元組損失函數中的不同邊界值在CASIAB數據集上的Rank-1識別準確率對比,不包括相同視角的情況(%)

m	NM	BG	CL	均值
0.1	97.3	95.3	85.9	92.8
0.2	97.6	95.7	87.2	93.5
0.3	97.3	94.9	84.9	92.4
0.4	97.3	94.9	85.2	92.5
0.5	97.5	95.0	84.6	92.4

下載: 導出CSV

表 6 平均Rank-1識別準確率(%)、參數量(M)和浮點計算次數(G)在CASIA-B數據集上的對比

方法	平均Rank-1 識別準確率	參數量	浮點計算次數
GaitSet	84.2	2.59	6.54
GaitPart	88.8	1.20	113.92
GaitGL	91.8	2.49	25.24
GaitDef(形變場分支)	82.9	8.07	136.45
GaitDef(步態剪影分支)	93.2	2.48	55.91
GaitDef(形變場分支+ 步態剪影分支)	93.5	10.55	178.38

下載: 導出CSV

參考文獻(28)

[1]	楊旗, 薛定宇. 基于雙尺度動態貝葉斯網絡及多信息融合的步態識別[J]. 電子與信息學報, 2012, 34(5): 1148–1153. doi: 10.3724/SP.J.1146.2011.01012. YANG Qi and XUE Dingyu. Gait recognition based on two-scale dynamic Bayesian network and more information fusion[J]. Journal of Electronics & Information Technology, 2012, 34(5): 1148–1153. doi: 10.3724/SP.J.1146.2011.01012.
[2]	王茜, 蔡競, 郭柏冬, 等. 面向公共安全的步態識別技術研究[J]. 中國人民公安大學學報: 自然科學版, 2023, 29(1): 68–76. doi: 10.3969/j.issn.1007-1784.2023.01.009. WANG Qian, CAI Jing, GUO Baidong, et al. Research on gait recognition technology for public security[J]. Journal of People’s Public Security University of China: Science and Technology, 2023, 29(1): 68–76. doi: 10.3969/j.issn.1007-1784.2023.01.009.
[3]	LIAO Rijun, YU Shiqi, AN Weizhi, et al. A model-based gait recognition method with body pose and human prior knowledge[J]. Pattern Recognition, 2020, 98: 107069. doi: 10.1016/j.patcog.2019.107069.
[4]	CAO Zhe, SIMON T, WEI S E, et al. Realtime multi-person 2D pose estimation using part affinity fields[C]. 2017 IEEE Conference on Computer Vision and Pattern Recognition, Honolulu, USA, 2017: 1302–1310. doi: 10.1109/CVPR.2017.143.
[5]	TEEPE T, GILG J, HERZOG F, et al. Towards a deeper understanding of skeleton-based gait recognition[C]. 2022 IEEE/CVF Conference on Computer Vision and Pattern Recognition, New Orleans, USA, 2022: 1568–1576. doi: 10.1109/CVPRW56347.2022.00163.
[6]	AN Weizhi, YU Shiqi, MAKIHARA Y, et al. Performance evaluation of model-based gait on multi-view very large population database with pose sequences[J]. IEEE Transactions on Biometrics, Behavior, and Identity Science, 2020, 2(4): 421–430. doi: 10.1109/tbiom.2020.3008862.
[7]	WANG Likai, CHEN Jinyan, and LIU Yuxin. Frame-level refinement networks for skeleton-based gait recognition[J]. Computer Vision and Image Understanding, 2022, 222: 103500. doi: 10.1016/j.cviu.2022.103500.
[8]	TEEPE T, KHAN A, GILG J, et al. Gaitgraph: Graph convolutional network for skeleton-based gait recognition[C]. 2021 IEEE International Conference on Image Processing, Anchorage, USA, 2021: 2314–2318. doi: 10.1109/icip42928.2021.9506717.
[9]	LIAO Rijun, CAO Chunshui, GARCIA E B, et al. Pose-based temporal-spatial network (PTSN) for gait recognition with carrying and clothing variations[C]. The 12th Chinese Conference on Biometric Recognition, Shenzhen, China, 2017: 474–483. doi: 10.1007/978-3-319-69923-3_51.
[10]	LI Xiang, MAKIHARA Y, XU Chi, et al. End-to-end model-based gait recognition[C]. The 15th Asian Conference on Computer Vision, Kyoto, Japan, 2020: 3–20. doi: 10.1007/978-3-030-69535-4_1.
[11]	HAN Ju and BHANU B. Individual recognition using gait energy image[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2006, 28(2): 316–322. doi: 10.1109/TPAMI.2006.38.
[12]	LIU Jianyi and ZHENG Nanning. Gait history image: A novel temporal template for gait recognition[C]. 2007 IEEE International Conference on Multimedia and Expo, Beijing, China, 2007: 663–666. doi: 10.1109/ICME.2007.4284737.
[13]	CHEN Changhong, LIANG Jimin, ZHAO Heng, et al. Frame difference energy image for gait recognition with incomplete silhouettes[J]. Pattern Recognition Letters, 2009, 30(11): 977–984. doi: 10.1016/j.patrec.2009.04.012.
[14]	CHAO Hanqing, HE Yiwei, ZHANG Junping, et al. GaitSet: Regarding gait as a set for cross-view gait recognition[C]. The 33th AAAI Conference on Artificial Intelligence, Honolulu, USA, 2019: 8126–8133. doi: 10.1609/aaai.v33i01.33018126.
[15]	HOU Saihui, CAO Chunshui, LIU Xu, et al. Gait lateral network: Learning discriminative and compact representations for gait recognition[C]. The 16th European Conference on Computer Vision, Glasgow, UK, 2020: 382–398. doi: 10.1007/978-3-030-58545-7_22.
[16]	LIN Beibei, ZHANG Shunli, and YU Xin. Gait recognition via effective global-local feature representation and local temporal aggregation[C]. 2021 IEEE/CVF International Conference on Computer Vision, Montreal, Canada, 2021: 14628–14636. doi: 10.1109/ICCV48922.2021.01438.
[17]	WANG Ming, LIN Beibei, GUO Xianda, et al. GaitStrip: Gait recognition via effective strip-based feature representations and multi-level framework[C]. The 16th Asian Conference on Computer Vision, Macao, China, 2023: 711–727. doi: 10.1007/978-3-031-26316-3_42.
[18]	LI Huakang, QIU Yidan, ZHAO Huimin, et al. GaitSlice: A gait recognition model based on spatio-temporal slice features[J]. Pattern Recognition, 2022, 124: 108453. doi: 10.1016/j.patcog.2021.108453.
[19]	FAN Chao, PENG Yunjie, CAO Chunhui, et al. GaitPart: Temporal part-based model for gait recognition[C]. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Seattle, USA, 2020: 14213–14221. doi: 10.1109/CVPR42600.2020.01423.
[20]	HUANG Xiaohu, ZHU Duowang, WANG Hao, et al. Context-sensitive temporal feature learning for gait recognition[C]. 2021 IEEE/CVF International Conference on Computer Vision, Montreal, Canada, 2021: 12889–12898. doi: 10.1109/ICCV48922.2021.01267.
[21]	LIN Beibei, ZHANG Shunli, and BAO Feng. Gait recognition with multiple-temporal-scale 3D convolutional neural network[C]. The 28th ACM International Conference on Multimedia, Seattle, USA, 2020: 3054–3062. doi: 10.1145/3394171.3413861.
[22]	CHAI Tianrui, LI Annan, ZHANG Shaoxiong, et al. Lagrange motion analysis and view embeddings for improved gait recognition[C]. 2022 IEEE/CVF Conference on Computer Vision and Pattern Recognition, New Orleans, USA, 2022: 20217–20226. doi: 10.1109/CVPR52688.2022.01961.
[23]	LIANG Junhao, FAN Chao, HOU Saihui, et al. GaitEdge: Beyond plain end-to-end gait recognition for better practicality[C]. The 17th European Conference on Computer Vision, Tel Aviv, Israel, 2022: 375–390. doi: 10.1007/978-3-031-20065-6_22.
[24]	CHUI H and RANGARAJAN A. A new point matching algorithm for non-rigid registration[J]. Computer Vision and Image Understanding, 2003, 89(2/3): 114–141. doi: 10.1016/s1077-3142(03)00009-2.
[25]	YU Shiqi, TAN Daoliang, and TAN Tieniu. A framework for evaluating the effect of view angle, clothing and carrying condition on gait recognition[C]. The 18th International Conference on Pattern Recognition, Hong Kong, China 2006: 441–444. doi: 10.1109/icpr.2006.67.
[26]	LI Weijia, HOU Saihui, ZHANG Chunjie, et al. An in-depth exploration of person re-identification and gait recognition in cloth-changing conditions[C]. 2023 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Vancouver, Canada, 2023: 13824–13833. doi: 10.1109/CVPR52729.2023.01328.
[27]	DOU Huanzhang, ZHANG Pengyi, SU Wei, et al. MetaGait: Learning to learn an Omni sample adaptive representation for gait recognition[C]. The 17th European Conference on Computer Vision, Tel Aviv, Israel, 2022: 357–374. doi: 10.1007/978-3-031-20065-6_21.
[28]	DOU Huanzhang, ZHANG Pengyi, SU Wei, et al. GaitGCI: Generative counterfactual intervention for gait recognition[C]. 2023 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Vancouver, Canada, 2023: 5578–5588. doi: 10.1109/cvpr52729.2023.00540.
