面向可穿戴式的基于LSTM神經網絡的智能心音異常診斷芯片

周維新; 高肇崗; 肖宛昂

doi:10.11999/JEIT230934

面向可穿戴式的基于LSTM神經網絡的智能心音異常診斷芯片

doi: 10.11999/JEIT230934

周維新^{1, 2},
高肇崗³,
肖宛昂^{1, 2, ,}

1.
中國科學院半導體研究所北京 100083
2.
中國科學院大學集成電路學院北京 100049
3.
中國農業大學 北京 100083

基金項目: 中國科學院先導科技專項培育項目(XDPB22)

詳細信息

作者簡介:
周維新：男，博士生，研究方向為智能體音診斷算法研究、可穿戴式智能體音芯片設計

高肇崗：男，碩士生，研究方向為深度學習算法研究、數字電路設計

肖宛昂：男，研究員，研究方向為智能聲音信號處理芯片、無線通信基帶芯片以及機器學習的FPGA加速

通訊作者:
肖宛昂　waxiao@semi.ac.cn

中圖分類號: TN492;TP183
計量
- 文章訪問數: 480
- HTML全文瀏覽量: 334
- PDF下載量: 91
- 被引次數: 0
出版歷程
- 收稿日期: 2023-08-28
- 修回日期: 2024-01-17
- 網絡出版日期: 2024-01-23
- 刊出日期: 2024-02-29

Intelligent Heart Sound Abnormal Diagnosis Chip Based on LSTM for Wearable Applications

ZHOU Weixin^{1, 2},
GAO Zhaogang³,
XIAO Wan'ang^{1, 2
, ,}

1.
Institute of Semiconductors, Chinese Academy of Sciences, Beijing 100083, China
2.
School of Integrated Circuits, University of Chinese Academy of Sciences, Beijing 100049, China
3.
China Agricultural University, Beijing 100083, China

Funds: The Key Research Program of the Chinese Academy of Sciences (XDPB22)

摘要

摘要: 心血管疾病是造成全球死亡人數最多的疾病之一，因此對心血管疾病的預防與提前診斷至關重要。人工聽診技術與計算機心音診斷技術無法滿足對心音長時間聽診的需求，因而可穿戴式聽診設備越來越受到關注，但是其具有高精度與低功耗的要求。該文設計了低功耗的面向可穿戴式的基于長短期記憶網絡(Long Short-Term Memory, LSTM)的智能心音異常診斷芯片，提出了包括預處理、特征提取以及異常診斷的心音異常診斷系統，并搭建了基于聽診器的心音采集FPGA系統，采用了數據增強的方法解決數據集的不平衡問題。基于預訓練模型設計了智能心音異常診斷芯片，在SMIC180 nm工藝下完成了版圖設計和MPW流片。后仿真結果表明，智能心音異常診斷芯片的診斷準確率為98.6%，功耗為762 μW，面積為3.06 mm × 2.45 mm，滿足可穿戴式智能心音異常診斷設備的高性能與低功耗的需求。
- 可穿戴式 /
- 心音 /
- 異常診斷 /
- 長短期記憶網絡 /
- 低功耗
Abstract: The gravity of cardiovascular disease hazards necessitates the utmost importance of preventive measures and early diagnosis for such ailments. Conventional manual auscultation techniques and computer-based diagnostic methods prove inadequate in meeting the demands of auscultation. Consequently, wearable devices attract increasing attention, but they are required to obtain both a high accuracy and low-power consumption. An intelligent heart sound abnormal diagnostic chip based on LSTM for wearable applications is presented. The abnormal heart sound diagnostic system is developed, including preprocessing, feature extraction, and abnormal diagnosis. Furthermore, an FPGA-based system for heart sounds acquisition is constructed. The challenge of imbalanced datasets is addressed through the implementation of data augmentation techniques. By utilizing pre-trained model as a foundation, the intelligent heart sound abnormal diagnostic chip is developed, and the layout and MPW are finished under SMIC 180nm. The post-simulation results demonstrate that the chip achieves a diagnostic accuracy of 98.6%, a power consumption of 762 μW, and an area of 3.06 mm$ \times $2.45 mm, meeting the high-performance and low-power consumption prerequisites of wearable devices.
- Wearable applications /
- Heart sound /
- Abnormal diagnosis /
- LSTM /
- Low-power

HTML全文

圖 1 基于聽診器的心音采集FPGA系統

下載: 全尺寸圖片幻燈片

圖 2 采用數據增強技術后的心音

下載: 全尺寸圖片幻燈片

圖 3 心音異常診斷系統

下載: 全尺寸圖片幻燈片

圖 4 心肺音分離效果圖

下載: 全尺寸圖片幻燈片

圖 5 心音異常診斷模型訓練過程

下載: 全尺寸圖片幻燈片

圖 6 心音異常診斷芯片架構

下載: 全尺寸圖片幻燈片

圖 7 診斷模型的電路設計

下載: 全尺寸圖片幻燈片

圖 8 FPGA原型驗證方案

下載: 全尺寸圖片幻燈片

圖 9 心音異常診斷芯片的版圖

下載: 全尺寸圖片幻燈片

表 1 心音診斷模型訓練參數

訓練參數	值
框架	Pytorch
GPU型號	TITAN5 12 GB
EPOCH	300
BATCH SIZE	32
學習率	0.0001
優化器	Adam

下載: 導出CSV

表 2 不同方法的性能對比

方法	準確率(%)	功耗	面積(mm²)
YASEEN等人^[19]	97.9	/	/
CHOSH等人^[20]	98.3	/	/
ALKHODARI等人^[21]	99.3	/	/
KAO等人^[22]	/	12.6 mW @ 40 nm (前仿)	/
CHEN等人^[23]	/	6.6 mW @ 65 nm(實測)	10.15
心音異常診斷芯片	98.6	762 μW @ 180 nm (后仿)	7.50

下載: 導出CSV
