3DSARBuSim 1.0：人造建筑高分辨星載SAR三維成像仿真數據集

焦?jié)欀?/>
	<meta name=; 韓亞權; 黃海風; 王青松; 賴濤; 王小青

doi:10.11999/JEIT230882

3DSARBuSim 1.0：人造建筑高分辨星載SAR三維成像仿真數據集

doi: 10.11999/JEIT230882

焦?jié)欀?/a>,

中山大學電子與通信工程學院深圳 518107

基金項目: 國家自然科學基金(62071499, 62273365)

詳細信息

作者簡介:
焦?jié)欀耗校┦可?，研究方向為層析合成孔徑雷達技術等

鄧嘉：男，碩士生，研究方向為計算機圖像模擬技術等

韓亞權：男，博士生，研究方向為層析合成孔徑雷達成像技術等

黃海風：男，教授，主要研究方向為空間電子和智能感知領域的基礎理論和關鍵技術，包括智慧遙感、測繪、海洋、監視、地質災害等

王青松：男，副教授，研究方向為遙感圖像精化處理、智能視覺導航、協同探測感知與信息融合等

賴濤：男，副教授，研究方向為SAR系統設計與信息處理、MIMO成像雷達系統設計與信息處理等

王小青：男，教授，研究方向為雷達海洋遙感、農業遙感、雷達信號處理等

通訊作者:
黃海風　huanghaifeng@mail.sysu.edu.cn

中圖分類號: TN918
計量
- 文章訪問數: 732
- HTML全文瀏覽量: 370
- PDF下載量: 105
- 被引次數: 0
出版歷程
- 收稿日期: 2023-08-11
- 修回日期: 2024-04-08
- 網絡出版日期: 2024-04-26
- 刊出日期: 2024-07-29

3DSARBuSim 1.0: High-Resolution Space Borne SAR 3D Imaging Simulation Dataset of Man-Made Buildings

School of Electronics and Communication Engineering, Sun Yat-sen University, Shenzhen 518107, China

Funds: The National Natural Science Foundation of China (62071499, 62273365)

摘要

摘要: 層析合成孔徑雷達(Tomographic Synthetic Aperture Radar, TomoSAR)成像技術可有效解決陡峭地形疊掩恢復難題，因此成為城市測繪技術的研究熱點之一?；诠_數據集的評估是TomoSAR算法研究與系統論證的必要過程，但目前存在的公開數據集缺乏相應的地物模型真值，無法對算法進行定量驗證。為解決這一問題，并進一步推動TomoSAR技術的發展，該文首先提出一種基于射線追蹤的先進星載雷達模擬器(Ray Tracing Space Borne Radar Advanced Simulator, RT-SBRAS)，相較過往方法，該模擬器可快速穩定地模擬復雜建筑物星載SAR圖像?；诖?，構建了人造建筑物高分辨SAR三維成像仿真(3D SAR Building Simulation, 3DSARBuSim)數據集的1.0版本，其中包含8個典型建筑物場景的雙頻段多航過全鏈路仿真數據。最后給出正交匹配追蹤(Orthogonal Matching Pursuit, OMP)算法和雙頻OMP算法在所提數據集上的驗證實驗，該數據集可對算法進行清晰、準確的定量比較。
- 合成孔徑雷達(SAR) /
- 層析成像 /
- 雙頻 /
- 數據集
Abstract: Tomographic Synthetic Aperture Radar (TomoSAR) can effectively recover the information of ground objects in steep terrain, and is one of the research hotspots in urban mapping. However, the current public data sets lack the true values of the object models, and cannot quantitatively verify the TomoSAR algorithm. To solve this problem and further promote the development of TomoSAR technology, this paper first proposes an RT-SBRAS (Ray Tracing Based Space Borne Radar Advanced Simulator), which can quickly and stably simulate the spaceborne SAR images of complex buildings compared with previous methods. Based on this, the 1.0 version of the 3D SAR Building Simulation (3DSARBuSim) data set is constructed, which contains the full-link simulation data of eight typical building scenes in dual-band and multi-pass. Finally, Orthogonal Matching Pursuit (OMP) and dual-frequency OMP algorithms are verified on the proposed data set, and the data set can provide clear and accurate quantitative comparison for the algorithms.
- Synthetic Aperture Radar (SAR) /
- Tomography /
- Dual-frequency /
- Data set

HTML全文

圖 1 RT-SBRAS系統結構框圖

下載: 全尺寸圖片幻燈片

圖 2 多次反射示意圖

下載: 全尺寸圖片幻燈片

圖 3 射線追蹤示意圖

下載: 全尺寸圖片幻燈片

圖 4 二維成像驗證模型

下載: 全尺寸圖片幻燈片

圖 5 場景模型局部放大

下載: 全尺寸圖片幻燈片

圖 6 各方法仿真結果與實測數據對比

下載: 全尺寸圖片幻燈片

圖 7 各方法仿真結果與實測數據間相似度指標圖

下載: 全尺寸圖片幻燈片

圖 8 互相關系數圖與干涉圖

下載: 全尺寸圖片幻燈片

圖 9 點目標三維模型與其場景建模散射特性計算結果

下載: 全尺寸圖片幻燈片

圖 10 雙波段點目標圖像

下載: 全尺寸圖片幻燈片

圖 12 波段點目標層析成像結果

下載: 全尺寸圖片幻燈片

圖 11 航過及其采樣示意圖

下載: 全尺寸圖片幻燈片

圖 13 不同方法獲得的其他仿真數據三維成像結果的3D點云

下載: 全尺寸圖片幻燈片

圖 14 埃菲爾鐵塔的各波段所選航過數據重建結果點云

下載: 全尺寸圖片幻燈片

圖 15 埃菲爾鐵塔的各波段所選航過數據重建結果點云與場景建模結果點云配準圖

下載: 全尺寸圖片幻燈片

表 1 分布式干涉SAR衛星軌道六根數

序號	參數
序號	半長軸a(km)	偏心率e	軌道傾角i(°)	升交點赤經$\varOmega $(°)	近地點幅角ω(°)	真近點角f(°)
1	6893.38	0.00135	97.4478	295.305	66.7208	76.6798
30	6893.38	0.00138	97.4535	295.314	72.2645	71.1363

下載: 導出CSV

表 2 3DSARBUsim 1.0數據集衛星雷達載荷仿真參數

參數	數值
工作頻率1 (GHz)	9.6
工作頻率2 (GHz)	7.2
下視角 (°)	36.52
脈沖重復頻率 (Hz)	3785
接收信號采樣頻率 (MHz)	400
發射信號帶寬 (MHz)	300
發射信號峰值功率 (W)	7680
發射信號脈寬 (s)	4.7×10^–5
圖像方位向采樣頻率 (Hz)	7570
理論方位分辨率 (m)	1.01
理論斜距分辨率 (m)	0.50

下載: 導出CSV

表 3 數據集文件構成

序號	文件后綴	說明
1	*.skp	各建筑物原始三維模型文件
2	*BulidingPc[Name].dat	各建筑物場景構建結果點云文件
3	*BulidingSLC[Name].dat	各建筑物雙頻段SLC數據，float32格式，實部虛部交替存放
4	*Parameters.dat	實現三維成像所需要的詳盡參數，包括衛星軌道數據、天線相位中心數據、雷達系統參數等
5	*readme.pdf	說明文件，給出數據集中文件數據存儲地址、字節數

下載: 導出CSV

表 4 3DSARBuSim 1.0建筑物選擇

英國倫敦塔橋	泰國泰姬陵	俄羅斯圣巴西勒大教堂	悉尼歌劇院	希臘萬神殿	中國黃鶴樓	法國埃菲爾鐵塔	法國巴黎圣母院

下載: 導出CSV

表 5 3DSARBuSim 1.0建筑物參考衛星仿真SAR圖像

泰姬陵	倫敦塔橋	希臘萬神殿	巴黎圣母院	悉尼歌劇院	圣巴西勒大教堂	黃鶴樓	埃菲爾鐵塔

下載: 導出CSV

表 6 算法恢復雙頻、單頻數據三維場景重建完整性和精確度

指標	波段	倫敦橋	悉尼歌劇院	巴黎圣母院	泰姬陵	黃鶴樓	埃菲爾鐵塔	圣巴西勒大教堂	希臘萬神殿
完整性	C	44.6201	5.1023	16.1274	10.8159	2.1040	6.6170	7.9663	5.6728
	X	64.3135	6.5311	14.9781	20.7736	2.4556	17.6414	6.5897	5.6028
	雙頻	4.3683	4.1709	13.0377	10.6187	2.6998	9.5862	4.5173	3.1208
精確度	C	20.3231	7.1584	2.3680	2.6077	11.2004	4.2615	2.0330	6.2672
	X	28.3335	15.0973	4.2324	3.8414	9.5589	4.6720	2.1939	6.0266
	雙頻	3.5853	3.2969	5.4178	3.4100	8.3067	4.0461	2.3919	5.3200

下載: 導出CSV
