一種基于三維可變換CNN加速結構的并行度優化搜索算法

屈心媛; 徐宇; 黃志洪; 蔡剛; 方震

doi:10.11999/JEIT210059

一種基于三維可變換CNN加速結構的并行度優化搜索算法

doi: 10.11999/JEIT210059

1.
中國科學院空天信息創新研究院北京 100190
2.
中國科學院大學電子電氣與通信工程學院北京 100049

基金項目: 國家自然科學基金(61704173, 61974146)，北京市科技重大專項(Z171100000117019)

詳細信息

作者簡介:
屈心媛：女，1994年生，博士生，研究方向?yàn)榛贔PGA的CNN加速器架構設計

徐宇：男，1990年生，博士，研究方向?yàn)榇笠?guī)模集成電路設計自動化

黃志洪：男，1984年生，高級工程師，研究方向?yàn)榭删幊绦酒O(shè)計與FPGA硬件加速

蔡剛：男，1980年生，正高級工程師，碩士生導師，研究方向?yàn)榧呻娐吩O(shè)計、抗輻照加固設計、人工智能系統設計

方震：男，1976年生，研究員，博士生導師，研究方向?yàn)樾滦歪t(yī)療電子及醫學人工智能技術

通訊作者:
黃志洪　huangzhihong@mail.ie.ac.cn

¹⁾本節給出的數據均為基于KCU1500的AlexNet加速器的實驗結果。²⁾ (Para_in=1, Para_seg=2)相當于Para_in=1/2；(Para_in=3, Para_seg=5)相當于Para_in=3/5；以此類推。
中圖分類號: TN47
計量
- 文章訪問數: 1112
- HTML全文瀏覽量: 454
- PDF下載量: 110
- 被引次數: 0
出版歷程
- 收稿日期: 2021-01-08
- 修回日期: 2021-08-04
- 網絡出版日期: 2021-09-09
- 刊出日期: 2022-04-18

A Parallelism Strategy Optimization Search Algorithm Based on Three-dimensional Deformable CNN Acceleration Architecture

1.
Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100190, China
2.
School of Electronic, Electrical, and Communication Engineering, University of Chinese Academy of Sciences (UCAS), Beijing 100049, China

Funds: The National Natural Science Foundation of China (61704173, 61974146), The Major Program of Beijing Science and Technology (Z171100000117019)

摘要

摘要: 現場可編程門陣列(FPGA)被廣泛應用于卷積神經網絡(CNN)的硬件加速中。為優化加速器性能，Qu等人(2021)提出了一種3維可變換的CNN加速結構，但該結構使得并行度探索空間爆炸增長，搜索最優并行度的時間開銷激增，嚴重降低了加速器實現的可行性。為此該文提出一種細粒度迭代優化的并行度搜索算法，該算法通過多輪迭代的數據篩選，高效地排除冗余的并行度方案，壓縮了超過99%的搜索空間。同時算法采用剪枝操作刪減無效的計算分支，成功地將計算所需時長從10⁶ h量級減少到10 s內。該算法可適用于不同規格型號的FPGA芯片，其搜索得到的最優并行度方案性能突出，可在不同芯片上實現平均(R1, R2)達(0.957, 0.962)的卓越計算資源利用率。
- 現場可編程門陣列 /
- 卷積神經網絡 /
- 硬件加速
Abstract: Field Programmable Gate Array (FPGA) is widely used in Convolutional Neural Network (CNN) hardware acceleration. For better performance, a three-dimensional transformable CNN acceleration structure is proposed by Qu et al (2021). However, this structure brings an explosive growth of the parallelism strategy exploration space, thus the time cost to search the optimal parallelism has surged, which reduces severely the feasibility of accelerator implementation. To solve this issue, a fine-grained iterative optimization parallelism search algorithm is proposed in this paper. The algorithm uses multiple rounds of iterative data filtering to eliminate efficiently the redundant parallelism schemes, compressing more than 99% of the search space. At the same time, the algorithm uses pruning operation to delete invalid calculation branches, and reduces successfully the calculation time from 10⁶ h to less than 10 s. The algorithm can achieve outstanding performance in different kinds of FPGAs, with an average computing resource utilization (R1, R2) up to (0.957, 0.962).
- Field Programmable Gate Array (FPGA) /
- Convolutional Neural Network (CNN) /
- Hardware acceleration
¹⁾本節給出的數據均為基于KCU1500的AlexNet加速器的實驗結果。²⁾ (Para_in=1, Para_seg=2)相當于Para_in=1/2；(Para_in=3, Para_seg=5)相當于Para_in=3/5；以此類推。

HTML全文

圖 1 CNN加速器單層結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 矩陣卷積分段計算示意圖

下載: 全尺寸圖片幻燈片

圖 3 β=0.20時，算法搜索的計算量隨α的變化情況

下載: 全尺寸圖片幻燈片

圖 4 基于不同規格FPGA的AlexNet加速器性能隨(α, β)變化色溫圖

下載: 全尺寸圖片幻燈片

表 1 AlexNet網絡結構參數

層	N_in	N_out	SIZE_in	SIZE_out	SIZE_ker	Stride	N_pad
CONV1	3	96	227	55	11	4	0
POOL1	96	96	55	27	3	2	0
CONV2	48	256	27	27	5	1	2
POOL2	256	256	27	13	3	2	0
CONV3	256	384	13	13	3	1	1
CONV4	192	384	13	13	3	1	1
CONV5	192	256	13	13	3	1	1
POOL5	256	256	13	6	3	2	0
FC1	9216	4096	1	1	–	–	–
FC2	4096	4096	1	1	–	–	–
FC3	4096	1000	1	1	–	–	–

下載: 導出CSV

表 2 不同F(xiàn)PGA CNN加速器的資源利用率

文獻	VGG		文獻	AlexNet
文獻	R1	R2	文獻	R1	R2
[5]	0.8	0.8	[3]	0.32	0.38
[11]	0.71	0.71	[4]	0.42	0.55
[14]	0.77	0.84	[6]	0.50	0.85
[8]	0.78	0.99	[8]	0.67	0.76
[15]	0.66	0.80	[14]	0.62	0.78

下載: 導出CSV

表 3 細粒度并行度迭代算法

輸入：片上可用DSP數#DSP_limit、可用BRAM數量#BRAM_limit、CNN網絡結構參數及α, β
輸出：Para_in，Para_out及Para_seg
(1) 計算各層計算量#OP_i與網絡總計算量#OP_total之比γ_i。
(2) 按照計算量分布比例將片上可用DSP分配給各層，各層分配到的DSP數#DSPⁱ_alloc←γ_i·#DSP_total
(3)根據計算總量和計算資源總數，算出理論最小計算周期數#cycle_baseline。
(4) 第i層，遍歷Para_in，Para_out及ROW_out的所有離散可行取值(即3者定義域形成的笛卡兒積)，生成全組合情況下的并行度參數配置　　集S⁰_i，計算對應的#cycle_i、#BRAM_i與#DSP_i。
(5) 篩選滿足α, β約束的數據集S_i。
S_i←select ele from S⁰_iwhere (#cycle_i/#cycle_baseline in [1–α,1+α] and #DSP_i/#DSPⁱ_alloc in [1–β,1+β])
(6)數據粗篩，集合S’_i：任意相鄰的兩個元素不存在“KO”偏序關系。
for i in range(5):
orders←[(cycle, dsp, bram), (dsp, cycle, bram), (bram, cycle, dsp)]
for k in range(3):
S_i.sort_ascend_by(orders[k])
p←0
for j in range(1, size(S_i)):
if σ_j KO σ_p then S_i.drop(σ_p), p←j
else S_i.drop(σ_j)
S’_i←S_i
(7)數據精篩，集合T_i：任意兩個元素不存在“KO”偏序關系。
for i in range(5):
S’_i.sort_ascend_by((cycle,dsp,bram))
for j in range(1, size(S’_i)):
for k in range(j):
if σ_k KO σ_j then S’_i.drop(σ_j), break
T_i←S’_i
(8)搜索剪枝。
maxCycle←INT_MAX, dspUsed←0, bramUsed←0
def calc(i):
if i==5 then
update(maxCycle)
return
for j in range(size(T_i)):
tmpDsp←dspUsed+dsp^j_i, tmpBram←bramUsed+bram^j_i
if not(tmpDsp>dspTotal or tmpBram>bramTotal or
cycle^j_i≥maxCycle) then
dspUsed←tmpDsp, bramUsed←tmpBram
calc(i+1)
dspUsed←tmpDsp-dsp^j_i, bramUsed←tmpBram-bram^j_i
else
continue
calc(0)
(9)選出maxCycle（即min{max{#cycle_i}}）對應的并行度元素，輸出約束條件下最優并行度的參數信息。

下載: 導出CSV

表 4 不同規格FPGA上AlexNet加速器資源利用率、計算量與計算時長

FPGA型號	DSP資源數	R1	R2	原始計算量	壓縮比(%)	執行時間
Arria10 GT 1150	1518	0.987	0.989	5.683×10⁷	99.892	1.544
KU060	2760	0.947	0.951	3.026×10⁸	99.979	6.444
Virtex7 VX485T	2800	0.936	0.941	9.903×10⁸	99.994	5.841
Virtex7 VX690T	3600	0.960	0.967	2.082×10⁸	99.998	2.775
KCU1500	5520	0.955	0.962	5.772×10⁹	99.999	8.115

下載: 導出CSV

表 5 AlexNet加速器性能對比

型號	文獻[4]	文獻[11]	文獻[12]	文獻[8]	本文
量化位寬	16 bit定點	16 bit定點	16 bit定點	16 bit定點	16 bit定點
頻率(MHz)	250/500	200	150	220	230
FPGA型號	KCU1500	Arria10GX1150	ZynqXC7Z045	KCU1500	KCU1500
吞吐率(GOP/s)	2335.4	584.8	137.0	1633.0	2425.5
性能功耗比(GOP/s/W)	37.31	無數據	14.21	72.31	62.35
資源利用率(R1, R2)	(0.42, 0.55)	(0.48, 0.48)	(0.51, 0.59)	(0.67, 0.76)	(0.96, 0.96)

下載: 導出CSV
