基于深度布隆過濾器的NDN網絡三級名字查找方法

吳慶濤; 師君如; 張明川; 王倩玉; 朱軍龍; 張宏科

doi:10.11999/JEIT200766

基于深度布隆過濾器的NDN網絡三級名字查找方法

doi: 10.11999/JEIT200766 cstr: 32379.14.JEIT200766

1.
河南科技大學信息工程學院洛陽 471023
2.
北京交通大學下一代互聯網互聯設備國家工程實驗室北京 100044

基金項目: 國家自然科學基金(61871430, 61976243)，中原科技創新領軍人才(214200510012)，河南省教育廳基礎研究專項(19zx010)，河南省教育廳重點科研項目(20A520011)

詳細信息

作者簡介:
吳慶濤：男，1975年生，教授，研究方向?yàn)樵朴?jì)算、物聯網、下一代網絡

師君如：女，1997年生，碩士生，研究方向?yàn)樾畔⒅行木W(wǎng)絡

張明川：男，1977年生，教授，研究方向?yàn)槲锫?lián)網、下一代網絡、機器學習

王倩玉：女，1991年生，碩士生，研究方向?yàn)樾畔⒅行木W(wǎng)絡

朱軍龍：男，1982年生，副教授，研究方向?yàn)槿斯ぶ悄?、機器學習、新型網絡

張宏科：男，1957年生，教授，研究方向?yàn)橄乱淮W(wǎng)絡、智慧協同網絡

通訊作者:
張明川　zhang_mch@haust.edu.cn

中圖分類號: TN919.2; TP393
計量
- 文章訪問數: 663
- HTML全文瀏覽量: 441
- PDF下載量: 57
- 被引次數: 0
出版歷程
- 收稿日期: 2020-08-27
- 修回日期: 2021-09-24
- 網絡出版日期: 2021-10-22
- 刊出日期: 2021-12-21

A Three-level Name Lookup Method Based on Deep Bloom Filter for Named Data Networking

1.
School of Information Engineering, Henan University of Science and Technology, Luoyang 471023, China
2.
National Engineering Laboratory for Next Generation Internet Interconnection Devices, Beijing Jiaotong University, Beijing 100044, China

Funds: The National Natural Science Foundation of China (61871430, 61976243), The Leading Talents of Science and Technology in the Central Plain of China (214200510012), The Basic Research Projects in the University of Henan Province (19zx010), The Key Project of the Education Department Henan Province (20A520011)

摘要

摘要: 為提高命名數據網絡(Name Data Networking, NDN)路由過程中內容名字查找的效率，該文提出一種基于深度布隆過濾器的3級名字查找方法。該方法使用長短記憶神經網絡(Long Short Term Memory, LSTM)與標準布隆過濾器相結合的方法優化名字查找過程；采用3級結構優化內容名字在內容存儲器(Content Store, CS)、待定請求表(Pending Interest Table, PIT)中的精確查找過程，提高查找精度并降低內存消耗。從理論上分析了3級名字查找方法的假陽性率，并通過實驗驗證了該方法能夠有效節省內存、降低查找過程的假陽性。
- 命名數據網絡 /
- 內容名字查找 /
- 深度布隆過濾器 /
- 內存消耗
Abstract: A three-level name lookup method based on deep Bloom filter is proposed to improve the searching efficiency of content name in the routing progress of the Named Data Networking (NDN). Firstly, in this method, the Long Short Term Memory (LSTM) is combined with standard Bloom filter to optimize the name searching progress. Secondly, a three-level structure is adopted to optimize the accurate content name lookup progresses in the Content Store (CS) and the Pending Interest Table (PIT) to promote lookup accuracy and reduce memory consumption. Finally, the error rate generated by content name searching method based on deep Bloom filter structure is analyzed in theory, and the experiment results prove that the proposed the three-level lookup structure can compress memory and decrease the error effectively.
- Named Data Networking (NDN) /
- Content name lookup /
- Deep Bloom filter /
- Memory consumption

HTML全文

圖 1 深度布隆過濾器查找結構

下載: 全尺寸圖片幻燈片

圖 2 學習模型結構

下載: 全尺寸圖片幻燈片

圖 3 名字字符串長度分布

下載: 全尺寸圖片幻燈片

圖 4 初始過濾器系數選擇對假陽性率的影響

下載: 全尺寸圖片幻燈片

圖 5 GRU大小對假陰性率和假陽性率的影響

下載: 全尺寸圖片幻燈片

圖 6 閾值τ大小對假陽性率和假陰性率的影響

下載: 全尺寸圖片幻燈片

圖 7 假陽性率

下載: 全尺寸圖片幻燈片

圖 8 內存消耗

下載: 全尺寸圖片幻燈片

表 1 面向深度布隆過濾器的名字查找算法

輸入：內容集合S，非內容集合U，閾值$\tau $
輸出：內容名字x
1: 調用LSTM架構使用集合S和集合U獲得一個集合D；
2: 查找x在初始過濾器中進行精確匹配；
3: while 對每一個$x \in S$ do
4：　If b[i]=1 then
5: 　　將匹配內容x發送到深度學習模型中；
6: 　else
7：　　將未匹配的x發送到FIB表中進行最長前綴匹配查找；
8: end while
9: if $(x, y) \in D $ then//在第2級深度學習模型中進行精確匹配查找
10:　計算$f(x)=\dfrac{1}{1+{ \rm{e} }^{-x} }$；
11: end if
12: if $x \in S $且$ f(x) < \tau $ then
13:　將查找獲得的內容名x在路由表中對應的數據包進行轉發；
14: else if $x \in S $且$f(x) < \tau $ then
15:　將未匹配的內容名字x發送到第3級備份過濾器進行查找；
16:　while在備份布隆過濾器查找b[i]=1 do
17:　　將查找獲得的內容名x在路由表中對應的數據包進行轉發；
18:　end while
19: else
20:　將第3級未匹配的內容發送到FIB表中進行最長前綴匹配查找；
21: end if

下載: 導出CSV

表 2 服務器配置

主要模塊	具體配置
主板	LENOVO-LNVNB161216
CPU	Intel Core? i7-9750H (6核，主頻2.60 GHz)
內存	DDR4 8GB (內存頻率 2667 MHz)

下載: 導出CSV

表 3 GRU和隱藏層參數配置與編號

配置編號	參數配置	配置編號	參數配置	配置編號	參數配置
I型	GRU大小=32，隱藏層大小=8	IV型	GRU大小=16，隱藏層大小=8	VII型	GRU大小=8，隱藏層大小=4
II型	GRU大小=32，隱藏層大小=4	V型	GRU大小=16，隱藏層大小=4	VIII型	GRU大小=4，隱藏層大小=4
III型	GRU大小=16，隱藏層大小=16	VI型	GRU大小=8，隱藏層大小=8	VIIII型	GRU大小=4，隱藏層大小=8

下載: 導出CSV
