認知無人機網絡中次級鏈路吞吐量優化研究

達新宇; 張宏偉; 胡航; 潘鈺; 井錦玲

doi:10.11999/JEIT200056

認知無人機網絡中次級鏈路吞吐量優化研究

doi: 10.11999/JEIT200056

1.
空軍工程大學信息與導航學院西安 710077
2.
空軍工程大學研究生院西安 710077
3.
中國人民解放軍94162部隊西安 710600

基金項目: 國家自然科學基金(61571460, 61901509, 61671475)，博士后創新人才計劃(BX201700108)，空軍工程大學校長基金 (XZJK2019033)，空軍工程大學信息與導航學院創新基金 (YNLX1904025)

詳細信息

作者簡介:
達新宇：男，1961年生，博士生導師，研究方向為現代通信理論與技術

張宏偉：男，1997年生，碩士生，研究方向為認知無線網絡

胡航：男，1989年生，講師，研究方向為綠色通信與無人機網絡

潘鈺：女，1995年生，博士生，研究方向為無人機協同通信

井錦玲：女，1977年生，工程師，研究方向為指揮自動化

通訊作者:
胡航　xd_huhang@126.com

中圖分類號: TN92
計量
- 文章訪問數: 2186
- HTML全文瀏覽量: 1086
- PDF下載量: 89
- 被引次數: 0
出版歷程
- 收稿日期: 2020-01-14
- 修回日期: 2020-04-30
- 網絡出版日期: 2020-07-08
- 刊出日期: 2020-08-18

Throughput Optimization of Secondary Link in Cognitive UAV Network

1.
Information and Navigation College, Aire Force Engineering University, Xi’an 710077, China
2.
Graduate School, Aire Force Engineering University, Xi’an 710077, China
3.
Unit 94162 of PLA, Xi’an 710600, China

Funds: The National Natural Science Foundation of China (61571460, 61901509, 61671475), The National Postdoctoral Program for Innovative Talents (BX201700108), The President Foundation of Air Force Engineering University (XZJK2019033), The Innovation Foundation of Air Force Engineering University (YNLX1904025)

摘要

摘要:
無人機(UAV)的便攜性和高機動性使其與認知無線電(CR)結合的應用場景更加實用。在構建的無人機認知無線網絡(CRN)模型中，該文提出UAV單弧度吞吐量優化方案，在確保檢測概率的前提下優化感知弧度最大化UAV平均吞吐量?？紤]在信道條件不理想情況下進一步改善感知性能，提出基于協作頻譜感知(CSS)的多弧度吞吐量優化方案，利用交替迭代優化(AIO)算法對感知弧度和弧度數量進行聯合優化以最大化吞吐量。仿真結果表明，該文提出的多弧度協作頻譜感知方案在信道衰落嚴重時，對于主用戶(PU)服務質量(QoS)和UAV吞吐量有明顯提升。
- 認知無線電 /
- 無人機 /
- 頻譜感知 /
- 幀結構 /
- 吞吐量
Abstract:
The application of Unmanned Air Vehicles (UAV)-enabled Cognitive Radio (CR) is widely used due to the convenience and high mobility of the UAV. In the UAV-based Cognitive Radio Network (CRN), the throughput optimization scheme in single radian is firstly investigated, in which the sensing radian is optimized to maximize the average throughput of UAV. Then, a multi-radian throughput optimization scheme based on Cooperative Spectrum Sensing (CSS) is studied to improve the sensing performance under the non-ideal channel, and the throughput of the UAV is maximized by utilizing an Alternative Iterative Optimization (AIO) algorithm. The simulation results show that the proposed scheme has better performance on improving the throughput of the UAV and ensuring the Quality-of-Service (QoS) of the Primary User (PU) when the channel fading is serious.
- Cognitive Radio (CR) /
- Unmanned Air Vehicle (UAV) /
- Spectrum Sensing (SS) /
- Frame structure /
- Throughput

HTML全文

圖 1 認知無人機網絡模型

下載: 全尺寸圖片幻燈片

圖 2 多弧度CSS幀結構

下載: 全尺寸圖片幻燈片

圖 3 ${R_{\rm{A}}}$與感知弧度$\beta $之間的關系曲線

下載: 全尺寸圖片幻燈片

圖 4 ${\beta ^{\rm{*}}}$與飛行軌跡的關系曲線

下載: 全尺寸圖片幻燈片

圖 5 $\max {R_{\rm{A}}}$與飛行軌跡的關系曲線

下載: 全尺寸圖片幻燈片

圖 6 ${R_{\rm{A}}}$與感知弧度數量$N$的關系曲線

下載: 全尺寸圖片幻燈片

圖 7 ${R_{\rm{A}}}$與微感知弧度${\beta _0}$的關系曲線

下載: 全尺寸圖片幻燈片

圖 8 最優弧度數量${N^*}$與${\beta _0}$的關系曲線

下載: 全尺寸圖片幻燈片

表 1 交替迭代優化算法

初始條件：$k = 0,i = 0,N = {N_i}$，誤差精度為$\delta $；
1：while $\left\| {{R_{\rm{A}}}({\beta _0}_{_k},{N_i}) - {R_{\rm{A}}}({\beta _0}_{_{k - 1}},{N_{^{i - 1}}})} \right\| > \delta $ do
2：　利用二分法，求出$N = {N_{^i}}$時的最優弧度${\beta _0}^*$
3：　令${\beta _0}_{_{^{k + 1}}} = {\beta _0}^*$
4：　利用枚舉法，求出${\beta _0}_{_{^{k + 1}}}$對應的最優數量${N^*}$
5：　令${N_{^{i + 1}}} = {N^*}$
6：　求出${R_{\rm{A}}}({\beta _0}_{_{^{k + 1}}},{N_{^{i + 1}}})$
7：　令$k = k + 1,\;\;\;i = i + 1$
8：end
輸出：${\beta _0}^* = {\beta _0}_{_k},{N^*} = {N_{^i}}$

下載: 導出CSV

表 2 仿真參數

參數	數值	參數	數值	參數	數值
${R_{\rm{P}}}$(m)	320	$B$(rad)	$\pi /3$	${P_{\rm{r}}}(\mu = 1)$	0.2
${R_{\rm{S}}}$(m)	50	${\omega _1}$	9.6	${L_{{\rm{LoS}}}}$	3
$H$(m)	60	${\omega _{\rm{2}}}$	0.28	${L_{{\rm{NLoS}}}}$	10
$f$(kHz)	500	${f_{\rm{s}}}$(kHz)	60	${\bar P_{\rmq7j3ldu95}}$	0.9
${P_{\rm{S}}}$(W)	10	${P_{\rm{P}}}$(W)	10	${\bar Q_{\rmq7j3ldu95}}$	0.9

下載: 導出CSV

參考文獻(21)

NIU Haoran, GONZALEZ-PRELCIC N, and HEATH R W. A UAV–based traffic monitoring system–invited paper[C]. The 87th IEEE Vehicular Technology Conference (VTC Spring). Porto, Portugal, 2018: 1–5. doi: 10.1109/vtcspring.2018.8417546.

高楊, 李東生, 程澤新. 無人機分布式集群態勢感知模型研究[J]. 電子與信息學報, 2018, 40(6): 1271–1278. doi: 10.11999/JEIT170877

GAO Yang, LI Dongsheng, and CHENG Zexin. UAV distributed swarm situation awareness model[J]. Journal of Electronics &Information Technology, 2018, 40(6): 1271–1278. doi: 10.11999/JEIT170877

倪磊, 達新宇, 王舒, 等. 基于物理層信息加密的衛星隱蔽通信研究[J]. 工程科學與技術, 2018, 50(1): 133–139. doi: 10.15961/j.jsuese.201700160

NI Lei, DA Xinyu, WANG Shu, et al. Research on satellite covert communication based on the information encryption of physical layer[J]. Advanced Engineering Sciences, 2018, 50(1): 133–139. doi: 10.15961/j.jsuese.201700160

趙太飛, 許杉, 屈瑤, 等. 基于無線紫外光隱秘通信的偵察無人機蜂群分簇算法[J]. 電子與信息學報, 2019, 41(4): 967–972. doi: 10.11999/JEIT180491

ZHAO Taifei, XU Shan, QU Yao, et al. Cluster–based algorithm of reconnaissance UAV swarm based on wireless ultraviolet secret communication[J]. Journal of Electronics &Information Technology, 2019, 41(4): 967–972. doi: 10.11999/JEIT180491

GUPTA A and JHA R K. A survey of 5G network: Architecture and emerging technologies[J]. IEEE Access, 2015, 3: 1206–1232. doi: 10.1109/ACCESS.2015.2461602

SULTANA A, ZHAO Lian, and FERNANDO X. Energy–efficient power allocation in underlay and overlay cognitive device–to–device communications[J]. IET Communications, 2019, 13(2): 162–170. doi: 10.1049/iet-com.2018.5464

LI He, OTA K, and DONG Mianxiong. Learning IoT in Edge: Deep learning for the internet of things with edge computing[J]. IEEE Network, 2018, 32(1): 96–101. doi: 10.1109/MNET.2018.1700202

SALEEM Y, REHMANI M H, and ZEADALLY S. Integration of cognitive radio technology with unmanned aerial vehicles: Issues, opportunities, and future research challenges[J]. Journal of Network and Computer Applications, 2015, 50: 15–31. doi: 10.1016/j.jnca.2014.12.002

NI Lei, Da Xinyu, HU Hang, et al. Outage constrained robust transmit design for secure cognitive radio with practical energy harvesting[J]. IEEE Access, 2018, 6: 71444–71454. doi: 10.1109/ACCESS.2018.2881477

XU Wenbo, WANG Shu, YAN Shu, et al. An efficient wideband spectrum sensing algorithm for unmanned aerial vehicle communication networks[J]. IEEE Internet of Things Journal, 2019, 6(2): 1768–1780. doi: 10.1109/JIOT.2018.2882532

AQUINO G P, GUIMAR?ES D A, MENDES L L, et al. Combined pre–distortion and censoring for bandwidth–efficient and energy–efficient fusion of spectrum sensing information[J]. Sensors, 2017, 17(3): 654. doi: 10.3390/s17030654

FAN Lisheng, LEI Xianfu, YANG Nan, et al. Secrecy cooperative networks with outdated relay selection over correlated fading channels[J]. IEEE Transactions on Vehicular Technology, 2017, 66(8): 7599–7603. doi: 10.1109/TVT.2017.2669240

KISHORE R, GURUGOPINATH S, MUHAIDAT S, et al. Sensing–throughput tradeoff for superior selective reporting–based spectrum sensing in energy harvesting HCRNs[J]. IEEE Transactions on Cognitive Communications and Networking, 2019, 5(2): 330–341. doi: 10.1109/TCCN.2019.2906915

SANTANA G M D, CRISTO R S, DEZAN C, et al. Cognitive radio for UAV communications: Opportunities and future challenges[C]. 2018 International Conference on Unmanned Aircraft Systems (ICUAS). Dallas, USA, 2018: 760–768. doi: 10.1109/ICUAS.2018.8453329.

SBOUI L, GHAZZAI H, REZKI Z, et al. Achievable rates of UAV–relayed cooperative cognitive radio MIMO systems[J]. IEEE Access, 2017, 5: 5190–5204. doi: 10.1109/ACCESS.2017.2695586

ZHENG Yi, WANG Yuwen, and MENG Fanji. Modeling and simulation of pathloss and fading for air–ground link of HAPs within a network simulator[C]. 2013 International Conference on Cyber–Enabled Distributed Computing and Knowledge Discovery. Beijing, China, 2013: 421–426. doi: 10.1109/CyberC.2013.78.

AL–HOURANI A, KANDEEPAN S, and LARDNER S. Optimal LAP altitude for maximum coverage[J]. IEEE Wireless Communications Letters, 2014, 3(6): 569–572. doi: 10.1109/lwc.2014.2342736

MOZAFFARI M, SAAD W, BENNIS M, et al. Drone small cells in the clouds: Design, deployment and performance analysis[C]. 2015 IEEE Global Communications Conference (GLOBECOM). San Diego, USA, 2015: 1–6. doi: 10.1109/GLOCOM.2015.7417609.

GHAZZAI H, GHORBEL M B, KADRI A, et al. Energy–efficient management of unmanned aerial vehicles for underlay cognitive radio systems[J]. IEEE Transactions on Green Communications and Networking, 2017, 1(4): 434–443. doi: 10.1109/TGCN.2017.2750721

LIANG Yingchang, ZENG Yonghong, PEH E C Y, et al. Sensing–throughput tradeoff for cognitive radio networks[J]. IEEE Transactions on Wireless Communications, 2008, 7(4): 1326–1337. doi: 10.1109/twc.2008.060869

LIU Liang, ZHANG Shuowen, and ZHANG Rui. CoMP in the Sky: UAV placement and movement optimization for multi–user communications[J]. IEEE Transactions on Communications, 2019, 67(8): 5645–5658. doi: 10.1109/TCOMM.2019.2907944
