軟件定義無線接入網絡的組件化研究

徐海東; 王江; 易輝躍

doi:10.11999/JEIT191049

軟件定義無線接入網絡的組件化研究

doi: 10.11999/JEIT191049

徐海東^{1, 2, ,},
王江²,
易輝躍^{1, 2}

1.
上海無線通信研究中心上海 201899
2.
中國科學院上海微系統與信息技術研究所上海 200050

基金項目: 上海市自然科學基金(17ZR1428900)，中國科學院創新基金(CXJJ-20S037)

詳細信息

作者簡介:
徐海東：男，1972年生，高級工程師，研究方向為軟件定義網絡、物聯網與蜂窩通信

王江：男，1975年生，正高級工程師，研究方向為軟件定義網絡、物聯網與蜂窩通信

易輝躍：男，1970年生，副研究員，研究方向為5G軟件定義終端、MIMO算法

通訊作者:
徐海東　haidong.xu@wico.sh

中圖分類號: TN92
計量
- 文章訪問數: 1266
- HTML全文瀏覽量: 565
- PDF下載量: 64
- 被引次數: 0
出版歷程
- 收稿日期: 2019-12-30
- 修回日期: 2021-01-05
- 網絡出版日期: 2021-01-11
- 刊出日期: 2021-04-20

Research on Componentization of Software Defined Wireless Access Network

Haidong XU^{1, 2
, ,},
Jiang WANG²,
Huiyue YI^{1, 2}

1.
Shanghai Research Center for Wireless Communications, Shanghai 201899, China
2.
Shanghai Institute of Microsystem and Information Technology, Chinese Academy of Sciences, Shanghai 200050, China

Funds: The Natural Science Foundation of Shanghai (17ZR1428900), The Innovation Foundation of Chinese Academy of Sciences (CXJJ-20S037)

摘要

摘要: 針對5G通信技術高傳輸速率、多業務場景的挑戰，該文提出一種組件化的軟件定義無線接入網絡新架構。該架構在5G接入網集中單元(CU)，分布單元(DU)，有源天線單元(AAU)架構的基礎上，進一步朝組件化方向演進，形成一種由集中控制單元(CCU), CU, DU，射頻單元(RU)，AAU等組件化通信單元組成的新架構。這種新架構既有利于切片化、虛擬化實現無線接入網，又有利于應用分布式計算技術和硬件加速技術突破通用處理器的計算能力瓶頸，還能降低DU與AAU之間的前傳壓力。該文還研制了基于此架構的組件化軟基站試驗原型并進行了測試，結果表明該組件化方案在提供高度靈活性的同時，還能夠提升通用處理器軟基站的吞吐能力，并有效降低遠端站址傳輸流量。
- 軟件定義網絡 /
- 無線接入網 /
- 組件化
Abstract: In view of the challenges of 5G communication technology with high speed and multiple service scenarios, this paper proposes a new component-based Software Defined wireless access Network (SDN) architecture. Based on the architecture of Centralized Unit (CU), Distributed Unit (DU) and Active Antenna Unit(AAU) in 5G access network, further component-based evolution is carried out to form a new architecture composed the communication units of Centralized Control Unit (CCU), CU, DU, Radio Unit(RU), and AAU. This new architecture is not only conducive to the realization of wireless access network with slicing and virtualization, but also conducive to the adoption of distributed computing technology and hardware accelerating technology to break through the processing bottleneck of general-purpose processor, and reduce the forward transmission pressure between DU and AAU. In this paper, a prototype of component-based soft base station is developed and tested. The results show that the component-based scheme can not only provide high flexibility, but also improve the processing capacity of the general processor soft base station and reduce effectively the traffic of remote stations.
- Software Defined Network(SDN) /
- Wireless access network /
- Componentization

HTML全文

圖 1 組件化、可切片的分布式軟基站架構

下載: 全尺寸圖片幻燈片

圖 2 CU和DU拆分選項

下載: 全尺寸圖片幻燈片

圖 3 DU和RU拆分選項

下載: 全尺寸圖片幻燈片

圖 4 組件化的原型基站模塊圖

下載: 全尺寸圖片幻燈片

圖 5 CU, DU和RU組件間流量測試結果

下載: 全尺寸圖片幻燈片

表 1 拆分方案流量分析，以LTE單天線、正常循環前綴為例

選項	方向	5 MB	10 MB	20 MB
Option8	上行、下行	245.76 Mbps	491.52 Mbps	983.04 Mbps
Option7.1	上行、下行	134.40 Mbps	268.80 Mbps	537.60 Mbps
Option7.1a	上行	各信道解映射后的流量之和，與業務量有關，最大值與Option7.1相等
Option7.2	上行	各信道估計之后、均衡之前的流量之和，包含信道估計信息，流量約為Option7.1a兩倍
Option7.2	下行	與應用層數據量有關，滿負荷時比Option7.1略小，不包括參考信號、下行同步信號
Option7.3	上行	各信道解調后、譯碼前的流量之和，流量比Option7.1a略小
Option7.3	下行	各信道調制前的流量之和，與應用層數據流量相當

下載: 導出CSV

表 2 組件化與非組件化對比測試結果

測試項目		組件化(CU+DU+RU)	非組件化
上行傳輸(5 Mbps)	時延抖動	0.09 ms	0.06 ms
	內存消耗	22.7%(CU 4.2% DU14.3% RU 4.2%)	14.4%
	CPU占用率	50.9%(CU 3.0% DU28.6% RU19.3%)	38.3%
下行傳輸(10 Mbps)	時延抖動	0.38 ms	0.40 ms
	內存消耗	22.8%(CU 4.3% DU14.3% RU 4.2%)	14.5%
	CPU占用率	40.0%(CU 3.7% DU15.0% RU21.3%)	26.6%

下載: 導出CSV

表 3 組件化C-RAN方案與CU-DU C-RAN方案比較(以10 Mbps下行傳輸為例)

傳輸情況	比較項目	組件化C-RAN方案	傳統CU-DU C-RAN方案	優勢倍數
理想傳輸條件	組網方案	CU, DU和RU都部署在中心機房
	云資源池計算集中度	100%		1.00
	站址傳輸流量	245.76 Mbps		1.00
非理想傳輸條件	組網方案	中心機房部署CU和DU遠端站址部署RU	中心機房部署CU遠端站址部署DU
	云資源池計算集中度	49.48%	1.39%	35.60
	站址傳輸流量	15.5 Mbps	11.5 Mbps	1.35

下載: 導出CSV
