基于機器學習主用戶發射模式分類的蜂窩認知無線電網絡頻譜感知
doi: 10.11999/JEIT191012
-
重慶郵電大學通信與信息工程學院 重慶 400065
Machine Learning Based Primary User Transmit Mode Classification for Spectrum Sensing in Cellular Cognitive Radio Network
-
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
-
摘要:
近年來，基于機器學習(ML)的頻譜感知技術為認知無線電系統提供了新型的頻譜狀態監測解決方案。利用蜂窩認知無線電網絡(CCRN)中的次級用戶設備(SUE)所能提供的大量頻譜觀測數據，該文提出了一種基于主用戶(PU)傳輸模式分類的頻譜感知方案。首先，基于多種典型的ML算法，對于網絡中的多個主用戶發射機(PUT)的傳輸模式進行分類辨識，在網絡整體層面上確定所有PUT的聯合工作狀態。然后，網絡中的SUE根據其所處地理位置或者頻譜觀測數據，判斷其在當前已判定的PUT發射模式下接入授權頻譜的可能性。由于PUT在網絡中的實際位置可能事先已知或者無法提前確定，該文給出了3種不同的處理方法。理論推導與實驗結果表明，所提方案與傳統的能量檢測方案相比，不僅改善了頻譜感知性能，還增加了蜂窩認知網絡對于授權頻譜的動態訪問機會。該方案可以作為蜂窩認知無線電網絡中的一種高效實用的頻譜感知解決方案。
-
關鍵詞:
- 蜂窩認知無線電網絡 /
- 機器學習 /
- 頻譜感知 /
- 支持向量機 /
- 卷積神經網絡
Abstract:In recent years, Machine Learning (ML) based spectrum sensing technology has provided a new solution in spectrum status identification for cognitive radio systems. Based on the large amount of spectrum observations captured by the Secondary User Equipment (SUE) in the Cellular Cognitive Radio Network (CCRN), this paper proposes a spectrum sensing scheme based on the Primary User (PU) transmission mode classification. Firstly, based on a variety of typical ML classification algorithms, the proposed scheme classifies the transmission mode of multiple Primary User Transmitters (PUTs) in the CCRN, and determines the joint operating state of all the PUTs in the CCRN. Subsequently, the SUE evaluates the possibility of accessing the licensed spectrum in the currently determined PUT transmission mode according to its geographical location or spectrum observation data. Since the actual locations of the PUTs in the network may be readily known in advance or unaware of at all, the proposed scheme solves the problem in three different methods. Theoretical derivation and experimental results show that compared with the traditional energy detection scheme, the proposed scheme not only remarkably improves the spectrum sensing performance, but also significantly increases the opportunities of dynamic accessing to the licensed spectrum for the SUEs. The proposed scheme can be used as an efficient and practical spectrum sensing solution in the CCRN.
-
算法1 基于能量值模板差值的PUT模式分類 輸入：${{{Y}}_m},\widehat {{Y}},G,$閾值$\varphi $ 輸出：${\hat {{S}}^{(m)} }$ 初始化 (1) ${{{y}}_{m,1} } = {\rm{vec} }({{{Y}}_m})$%矩陣轉化為列向量 (2) ${{{y}}_{m,2} } = {\rm{sort} }({{{y}}_{m,1} },{\rm{descending} })$%降序排列 (3) ${\rm{ = \{ }}{Z_{{x_1},{y_1}}},{Z_{{x_2},{y_2}}}, \cdots ,{Z_{{x_Q},{y_Q}}}\} $ (4) 獲取行位置索引向量 ${{x}}{\rm{ = \{ } }{x_1}{\rm{,} }{x_2}{\rm{,} } ··· {\rm{,} }{x_Q}{\rm{\} } }$及 (5) 列位置索引向量 ${{y}}{\rm{ = \{ } }{y_1}{\rm{,} }{y_2}{\rm{,} } ··· {\rm{,} }{y_Q}{\rm{\} } }$ (6) IF$({Z_{ {x_1},{y_1} } } < \varphi )\& ({Z_{ {x_2},{y_2} } } < \varphi )\& ··· \& ({Z_{ {x_G},{y_G} } } < \varphi )$ (7) ${\hat {{S}}^{(m)} } = {\mathbb{S}_0}$ (8) Else (9) For $i = 1:1:G$ (10) For $j = i + 1:1:G$ (11) If $(\left| {{x_i} - {x_j}} \right| < g)\& (\left| {{y_i} - {y_j}} \right| < g)$ (12) ${Z_{{x_j},{y_j}}} = 0$ (13) EndIF (14) EndFor (15) EndFor (16) EndIF (17) For $i = 1:1:G$ (18) ${{{h}}_{\rm{1} } }(i) = {\rm{find} }({x_i}\left| { {Z_{ {x_i},{y_i} } } \ne 0} \right.)$ (19) ${{{h}}_{\rm{2} } }(i) = {\rm{find} }({y_i}\left| { {Z_{ {x_i},{y_i} } } \ne 0} \right.)$ (20) EndFor (21) ${\varDelta _l} = \displaystyle\sum\limits_{i = 1}^{\left| { {h_1} } \right|} {|{ {{Y} }_m}({ {{h} }_1}(i),{ {{h} }_2}(i)) - { {{Y} }_l}({ {{h} }_1}(i),{ {{h} }_2}(i))|}$ (22) ${l_{ {\rm{opt} } } } = \mathop {\arg \min }\limits_{l = 1,2, \cdots ,{2^N} - 1} {\varDelta _l}$ 輸出：${\hat {{S}}^{(m)} } = {\mathbb{S}_{ {l_{ {\rm{opt} } } } } }$ 注：${\rm{|} }{{{h}}_1}{\rm{|} }$為集合${{{h}}_1}$的勢，即其所包含的所有元素的個數。
下載: 導出CSV
表 1 CNN分類算法采用的結構參數
層類型 輸入尺寸 濾波器尺寸 激活函數 卷積層(1) 120×120 3×3×32 ReLu 卷積層(2) 60×60 3×3×64 ReLu 全連接層 14400×1 1024個神經元 Softmax
下載: 導出CSV
表 2 PUT傳輸功率為32 dBm時，PUT傳輸模式分類準確率
算法名稱 數據充分性條件 11.1% 47.4% 100% 能量值模板差值 0.12 0.26 0.28 K-means 0.42 0.43 0.44 HOG+SVM_8*8 0.12 0.16 0.17 HOG+SVM_16*16 0.12 0.12 0.18 CNN 0.62 0.96 0.99
下載: 導出CSV
-
ALI A and HAMOUDA W. Advances on spectrum sensing for cognitive radio networks: Theory and applications[J]. IEEE Communications Surveys & Tutorials, 2017, 19(2): 1277–1304. doi: 10.1109/COMST.2016.2631080 AXELL E, LEUS G, LARSSON E G, et al. Spectrum sensing for cognitive radio: State-of-the-art and recent advances[J]. IEEE Signal Processing Magazine, 2012, 29(3): 101–116. doi: 10.1109/msp.2012.2183771 黃河, 袁超偉. 基于動態自適應雙門限能量檢測的序貫協作頻譜感知算法[J]. 電子與信息學報, 2018, 40(5): 1037–1043. doi: 10.11999/JEIT170731HUANG He and YUAN Chaowei. A sequential cooperative spectrum sensing algorithm based on dynamic adaptive double-threshold energy detection[J]. Journal of Electronics &Information Technology, 2018, 40(5): 1037–1043. doi: 10.11999/JEIT170731 KIM J and CHOI J P. Sensing coverage-based cooperative spectrum detection in cognitive radio networks[J]. IEEE Sensors Journal, 2019, 19(13): 5325–5332. doi: 10.1109/JSEN.2019.2903408 申濱, 王志強, 青晗. 基于次用戶功率控制輔助的合作頻譜感知[J]. 電子與信息學報, 2018, 40(10): 2337–2344. doi: 10.11999/JEIT171232SHEN Bin, WANG Zhiqiang, and QING Han. Secondary user power control aided cooperative spectrum sensing[J]. Journal of Electronics &Information Technology, 2018, 40(10): 2337–2344. doi: 10.11999/JEIT171232 MAUWA H, BAGULA A, ZENNARO M, et al. Systematic analysis of geo-location and spectrum sensing as access methods to TV white space[J]. Journal of ICT Standardization, 2016, 4(2): 147–176. doi: 10.13052/jicts2245-800X.423 陳思吉, 王欣, 申濱. 一種基于支持向量機的認知無線電頻譜感知方案[J]. 重慶郵電大學學報: 自然科學版, 2019, 31(3): 313–322. doi: 10.3979/j.issn.1673-825X.2019.03.005CHEN Siji, WANG Xin, and SHEN Bin. A support vector machine based spectrum sensing for cognitive radios[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2019, 31(3): 313–322. doi: 10.3979/j.issn.1673-825X.2019.03.005 THILINA K M, CHOI K W, SAQUIB N, et al. Machine learning techniques for cooperative spectrum sensing in cognitive radio networks[J]. IEEE Journal on Selected Areas in Communications, 2013, 31(11): 2209–2221. doi: 10.1109/jsac.2013.131120 AWE O P and LAMBOTHARAN S. Cooperative spectrum sensing in cognitive radio networks using multi-class support vector machine algorithms[C]. The 9th International Conference on Signal Processing and Communication Systems, Cairns, Australia, 2015: 1–7. doi: 10.1109/ICSPCS.2015.7391780. LI Zan, WU Wen, LIU Xiangli, et al. Improved cooperative spectrum sensing model based on machine learning for cognitive radio networks[J]. IET Communications, 2018, 12(19): 2485–2492. doi: 10.1049/iet-com.2018.5245 LU Yingqi, ZHU Pai, WANG Donglin, et al. Machine learning techniques with probability vector for cooperative spectrum sensing in cognitive radio networks[C]. s2016 IEEE Wireless Communications and Networking Conference, Doha, Qatar, 2016: 1–6. doi: 10.1109/WCNC.2016.7564840. CHEN Siji, SHEN Bin, WANG Xin, et al. A strong machine learning classifier and decision stumps based hybrid adaboost classification algorithm for cognitive radios[J]. Sensors, 2019, 19(23): 5077. doi: 10.3390/s19235077 WEI Zhiqing, FENG Zhiyong, ZHANG Qixun, et al. Three regions for space-time spectrum sensing and access in cognitive radio networks[C]. 2012 IEEE Global Communications Conference, Anaheim, USA, 2012: 1283–1288. doi: 10.1109/GLOCOM.2012.6503290. 阮麗華, 李勇, 程偉. 一種空時二維聯合頻譜感知區域劃分方案[J]. 系統工程與電子技術, 2016, 38(5): 1146–1152. doi: 10.3969/j.issn.1001-506X.2016.05.27RUAN Lihau, LI Yong, and CHENG Wei. Novel region division approach for joint space-time spectrum 2-dimensions sensing in cognitive radio[J]. Systems Engineering and Electronics, 2016, 38(5): 1146–1152. doi: 10.3969/j.issn.1001-506X.2016.05.27 SINGH G and CHHABRA I. Effective and fast face recognition system using complementary OC-LBP and HOG feature descriptors with SVM classifier[J]. Journal of Information Technology Research, 2018, 11(1): 91–110. doi: 10.4018/JITR.2018010106 DADI H S, PILLUTLA G K M, and MAKKENA M L. Face recognition and human tracking using GMM, HOG and SVM in surveillance videos[J]. Annals of Data Science, 2018, 5(2): 157–179. doi: 10.1007/s40745-017-0123-2 MERCHANT K, REVAY S, STANTCHEV G, et al. Deep learning for RF device fingerprinting in cognitive communication networks[J]. IEEE Journal of Selected Topics in Signal Processing, 2018, 12(1): 160–167. doi: 10.1109/JSTSP.2018.2796446 -
