基于深度強化學習的服務功能鏈可靠部署算法
doi: 10.11999/JEIT190969
-
1.
重慶郵電大學通信與信息工程學院 重慶 400065
-
2.
重慶郵電大學移動通信技術重點實驗室 重慶 400065
Reliable Deployment Algorithm of Service Function Chain Based on Deep Reinforcement Learning
-
1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
-
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Post and Telecommunications, Chongqing 400065, China
-
摘要:
針對當前關于服務功能鏈(SFC)的部署問題都未考慮到虛擬網絡功能(VNF)的失效重要度，該文提出了基于深度強化學習的SFC可靠部署算法。首先建立VNF和虛擬鏈路可靠映射模型，為重要的VNF設置高可靠性需求，并通過鏈路部署長度限制盡可能保證虛擬鏈路可靠性需求。其次，以負載均衡為資源協調原則，與VNF可靠性聯合優化，最終使用深度強化學習得到服務功能鏈部署策略。另外，提出了基于重要度的節點備份和鏈路備份策略，用于應對部署過程中VNF/鏈路可靠性難以滿足的情況。仿真結果表明，該文的可靠部署算法在保證可靠性需求的基礎上能夠有效減少SFC失效損失，同時使虛擬網絡更加穩定可靠。
-
關鍵詞:
- 網絡虛擬化 /
- 服務功能鏈 /
- 可靠性 /
- 深度強化學習
Abstract:In view of the current deployment of the Service Function Chain (SFC), the failure importance of the Virtual Network Function (VNF) is not considered,an SFC reliable deployment algorithm based on deep reinforcement learning is proposed. Firstly, a reliable mapping model of VNF and virtual links is establised, high reliability requirements is set for important VNFs, and the reliability requirements of virtual links is ensured as much as possible through link deployment length restrictions. Secondly, taking load balancing as the resource coordination principle, joint optimization the VNF reliability is jointly optimized. Finally, the deep reinforcement learning is used to get the service function chain deployment strategy. In addition, node backup and link backup strategies based on importance are proposed to deal with situations where VNF/link reliability is difficult to meet during deployment. Simulation results show that the reliable deployment algorithm in this paper can effectively reduce the failure SFC loss on the basis of ensuring the reliability requirements, and at the same time make the virtual network more stable and reliable.
-
表 1 基于深度強化學習的服務功能鏈可靠部署算法
算法1 基于深度強化學習的服務功能鏈可靠部署算法 經驗回放池初始化為空，隨機初始化主網絡的參數，并復制給目標網絡，探尋環境信息基于式(6)～式(9)得到${w_I}$,${u'_k}$ for episode=1, 2, ···, E do 初始化狀態為${{{s}}_1} = \{ {{{B}}_{{\rm{left}}}}{{,}}{{{C}}_{{\rm{left}}}}{{,}}{{}_{{\rm{map}}}}{{,}}{{{c}}_{{\rm{map}}}}\} $, ${{}_{{\rm{map}}}}{{,}}{{{c}}_{{\rm{map}}}}$為空 for t=1,2…D do 確定可選動作集${N'_{k{n_i}}}$, ${N''_{k{n_i}}}$隨機產生0到1的數$\tau $ if $\tau < \varepsilon $：先從${ {{N'} }_{k{n_i} } }$中選擇動作${a_t}$，若為空則根據算法2在${ {{N''} }_{k{n_i} } }$中選擇${a_t}$，都無動作選擇則${a_t}$為空 else：依據主神經網絡估值${\pi ^*}(s) = {{\arg }}\max\limits_{a'} Q({{{s}}_t},{{{a'}}_t})$選取動作。end if 執行動作${{{a}}_t}$，獲得獎勵${r_t}$、下一狀態${{{s}}_{t + 1}}$，將向量$[{{{s}}_t},{{{a}}_t},{r_t},{{{s}}_{t + 1}}]$放入經驗回放池。 隨機取出小批量樣本向量$[{{{s}}_t},{{{a}}_t},{r_t},{{{s}}_{t + 1}}]$組成樣本向量集${\upsilon _t}$ for $[{{{s}}_t},{{{a}}_t},{r_t},{{{s}}_{t + 1}}]$ in ${\upsilon _t}$ do $L{{(}}\theta {{)}} = {(\tilde Q({{{s}}_t},{{{a}}_t}|{\theta ^ - }) - Q({{{s}}_t},{{{a}}_t}|\theta ))^2}$，$\theta \leftarrow \theta - {\lambda _{{\rm{SGD}}}}\nabla L(\theta )$ end for 在θ更新T次后將主網絡參數復制給目標網絡。end for end for 通過主網絡得到每個VNF的策略${\pi ^*}(s)$ if累計獎勵$Q({s_t},{a_t}) < - 100$：拒絕該請求 else if 部署結果不滿足鏈路可靠性需求：執行算法3 end if
下載: 導出CSV
表 2 基于虛擬網絡功能重要度節點備份算法
算法2：基于虛擬網絡功能重要度的節點備份算法 初始化節點部署方案$g'(v_I^k)$為空 repeat： if ${\omega _I} < 1/D$：搜尋${N''_{k{n_i}}}$已作為備份節點的節點集$V_{I'}^k$ if $V_{I'}^k$非空：$g'(v_I^k)$←從$V_{I'}^k$中尋找備份節點，從${{{N''}}_{k{n_i}}}/V_{I'}^k$中尋
找部署節點else：$g'(v_I^k)$←從${N''_{k{n_i}}}$中選出2個節點?？煽啃宰罡叩臑椴渴鸸?jié)
點，另一備份。endifelse：$g'(v_I^k)$←從${N''_{k{n_i}}}$中選出2個節點?？煽啃宰罡叩臑椴渴鸸?jié)
點，另一備份。endifuntil $RN(g'(v_I^k)) > {(R_k^{{\rm{req}}})^{{w_I}}}$or 已遍歷所有組合 return 節點部署方案$g'(v_I^k)$
下載: 導出CSV
表 3 基于鏈路備份重要度的鏈路備份算法
算法3：基于鏈路備份重要度的鏈路備份算法 基于$\gamma _{I,J}^k$對虛擬鏈路鏈路$l_{I,J}^k \in L_v^k$排序 for 排過序的鏈路鏈路$l_{I,J}^k \in L_v^k$ if 鏈路可靠性不滿足： 確定$l_{I,J}^k$映射的段物理起始節點${n_i}$和終止節點${n_j}$:${p_{I,J}}$ $p{{ = \{ }}{\ell _{i,j}}|{L'_{k{l_{i,j}}}}/{p_{I,J}}\} $，部署方案增加鏈路P else: break end for return 部署方案
下載: 導出CSV
-
