衛星物聯網場景下基于節點選擇的協作波束成形技術研究

席博; 洪濤; 張更新

doi:10.11999/JEIT190707

衛星物聯網場景下基于節點選擇的協作波束成形技術研究

doi: 10.11999/JEIT190707

南京郵電大學通信與信息工程學院南京 210003

基金項目: 國家自然科學基金(91738201, 61801445, 61971440)

詳細信息

作者簡介:
席博：男，1996年生，碩博連讀生，研究方向為衛星通信

洪濤：男，1982年生，講師，研究方向為多天線收發系統、衛星通信

張更新：男，1967年生，教授，博士生導師，研究方向為衛星通信、深空通信、空間信息網絡等

通訊作者:
洪濤　hongt@njupt.edu.cn

中圖分類號: TN92
計量
- 文章訪問數: 2633
- HTML全文瀏覽量: 644
- PDF下載量: 136
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-16
- 修回日期: 2020-04-27
- 網絡出版日期: 2020-05-28
- 刊出日期: 2020-12-08

Research on the Collaborative Beamforming Technique Based on the Node Selection for Satellite Internet of Things

College of Telecommunications & Information Engineering, Nanjing University of Post and Telecommunications, Nanjing 210003, China

Funds: The National Natural Science Foundation of China (91738201, 61801445, 61971440)

摘要

摘要:
針對衛星物聯網(IoT)場景下信號長距離傳輸衰減大以及單個終端節點傳輸性能受限的問題，該文提出一種基于節點選擇的協作波束成形算法，增強終端節點的傳輸能力。在實際終端位置信息存在誤差的條件下，推導出了協作波束成形平均方向圖函數，分析了不同系統參數對于協作波束成形平均方向圖和瞬時方向圖差異的影響。在此基礎上，根據衛星物聯網鏈路傳輸性能需求，提出一種區域分組優化的協作節點選擇算法。仿真結果表明，相比于傳統的分布式協作波束成形節點選擇算法，該文提出的算法在實際的誤差模型中旁瓣抑制和零陷生成方面具有更好的性能。
- 衛星物聯網 /
- 協作波束成形 /
- 節點選擇 /
- 隨機天線陣
Abstract:
The transmission performance of nodes in the satellite Internet of Things(IoT) is limited due to the long-distance transmission and the power-constrained terminal. A collaborative beamforming technique is proposed based on the node selection algorithm to improve the transmission performance of nodes. An average far-field beampattern for collaborative beamforming is derived by considering the location information error in practical scenario. Furthermore, the difference between average beampattern and instantaneous beampattern is analyzed by the system parameters. On this basis, a node selection algorithm is proposed based on region grouping not only to meet the requirement of satellite link, but also to suppress the sidelobe. Simulation results show better performance of the proposed algorithm compared with the traditional node selection algorithms in the actural error model.
- Satellite Internet of Things (IoT) /
- Collaborative beamforming /
- Node selection /
- Random array antenna

HTML全文

圖 1 衛星物聯網場景下協作波束成形技術示意圖

下載: 全尺寸圖片幻燈片

圖 2 節點選擇模型示意圖

下載: 全尺寸圖片幻燈片

圖 3 節點閾值隨誤碼率變化曲線

下載: 全尺寸圖片幻燈片

圖 4 基于區域分組策略與基于虛擬陣列優化方向圖對比

下載: 全尺寸圖片幻燈片

圖 5 不同參數時${C_{m(\phi )}}(z)$隨門限功率z的變化曲線

下載: 全尺寸圖片幻燈片

圖 6 節點選擇平均功率方向圖和瞬時功率方向圖對比

下載: 全尺寸圖片幻燈片

圖 7 區域分組與虛擬陣選擇節點的${C_{m(\phi )}}(z)$對比

下載: 全尺寸圖片幻燈片

圖 8 分組策略算法與基于虛擬陣列算法的收斂性能對比

下載: 全尺寸圖片幻燈片

圖 9 區域分組與虛擬陣節點選擇算法的PSLL性能對比

下載: 全尺寸圖片幻燈片

表 1 區域分組節點選擇算法

${\rm{List}}m$=[]:存放$[{A_m}\sim {A_{m + k - 1}}]$中節點集合；${\rm{List}}m'$=[]:存放$[{A_{M + m}}\sim {A_{M + m + k - 1}}]$中節點集合；
${\rm{List}}C$=[]:存放$[{A_m}\sim {A_{m + k - 1}}]$中用于協作傳輸節點集合；${\rm{List}}C'$=[]:存放$[{A_{M + m}}\sim {A_{M + m + k - 1}}]$中用于協作傳輸節點集合；
${\rm{List}}F$=[]:存放代價函數值的集合；初始隨機產生$S$個節點：${P_s}({r_s},{\phi _s}),\;s = 1,2,···,S$；
$S$：源節點覆蓋節點數；$M$：分組對數；$N$：協作波束成形節點數；$E$：迭代次數；
For $s$=1 to $S$ do
For $m$=1 to $M$ do
If ${\phi _s} \in [\phi {A_m}\sim \phi {A_{m + k - 1}}]$ then
${\rm{List}}m$=${\rm{List}}m$+${P_s}$;
End
If ${\phi _s} \in [\phi {A_{M + m}}\sim \phi {A_{M + m + k - 1}}]$ then
${\rm{List}}m'$=${\rm{List}}m'$+${P_s}$;
End
End
End
For $e$=1 to $E$ do
For $m$=1 to $M$ do
從${\rm{List}}m$中隨機選擇${{[N} / {\rm{2}}}]$或${{[(N + 1)} / {\rm{2}}}]$個節點放入${\rm{List}}C$中；
從${\rm{List}}m'$中隨機選擇${{[N} / {\rm{2}}}]$或${{[(N + 1)} / {\rm{2}}}]$個節點放入${\rm{List}}C'$中；
根據${\rm{List}}C$和${\rm{List}}C'$中的節點計算代價函數${f_m}$；
End
${\rm{List}}F$=${\rm{List}}F + {f_m}$;
End
Find(min(${\rm{List}}F$(average)))$\xrightarrow{{}}$$\{ {A_{{\rm{best}}}}\sim {A_{{\rm{best}} + k - 1}},{A_{M + {\rm{best}}}}\sim {A_{M + {\rm{best}} + k - 1}}\} $。

下載: 導出CSV

表 2 仿真參數設計表

參數	值
衛星軌道高度	$d$=600 km
衛星天線增益	${G_R}$=25 dBi
衛星品質因數	${G / T}$=5 ${\rm{dB}}{{\rm{K}}^{ - 1}}$
空間傳播損耗	${L_f}$=168.7 dB
頻率	2.6 GHz
節點天線增益(全向天線)	${G_s}$=0 dBi
節點發射功率	${P_s}$=10 dBm
調制方式	QPSK
信息速率	${R_b}$=2048 kbps
無線傳感器網絡范圍	500$ \times $500 m²
網絡節點總數	300
源節點覆蓋范圍	R=100 m，約60個左右
定位誤差	$B$=1 m，(約10個波長)
期望/非期望方向	(600 km,${30^{ \circ} }$,${0^{ \circ} }$)/(600 km,${30^{ \circ} }$,${1^{ \circ} }$)

下載: 導出CSV

參考文獻(19)

CIONI S, DE GAUDENZI R, DEL RIO HERRERO O, et al. On the satellite role in the era of 5G massive machine type communications[J]. IEEE Network, 2018, 32(5): 54–61. doi: 10.1109/MNET.2018.1800024

QU Zhicheng, ZHANG Gengxin, CAO Haotong, et al. LEO satellite constellation for internet of things[J]. IEEE Access, 2017, 5: 18391–18401. doi: 10.1109/Access.2017.2735988

XIA Tingting, WANG M M, and YOU Xiaohu. Satellite Machine-type communication for maritime Internet of Things: An interference perspective[J]. IEEE Access, 2019, 7: 76404–76415. doi: 10.1109/Access.2019.2919253

DE SANCTIS M, CIANCA E, ARANITI G, et al. Satellite communications supporting internet of remote things[J]. IEEE Internet of Things Journal, 2016, 3(1): 113–123. doi: 10.1109/JIOT.2015.2487046

CHIEN W C, LAI C F, HOSSAIN M S, et al. Heterogeneous space and terrestrial integrated networks for IoT: Architecture and challenges[J]. IEEE Network, 2019, 33(1): 15–21. doi: 10.1109/MNET.2018.1800182

MUDUMBAI R, BROWN III D R, MADHOW U, et al. Distributed transmit beamforming: Challenges and recent progress[J]. IEEE Communications Magazine, 2009, 47(2): 102–110. doi: 10.1109/MCOM.2009.4785387

JAYAPRAKASAM S, RAHIM S K A, and LEOW C Y. Distributed and collaborative beamforming in wireless sensor networks: Classifications, trends, and research directions[J]. IEEE Communications Surveys & Tutorials, 2017, 19(4): 2092–2116. doi: 10.1109/COMST.2017.2720690

OCHIAI H, MITRAN P, POOR H V, et al. Collaborative beamforming for distributed wireless ad hoc sensor networks[J]. IEEE Transactions on Signal Processing, 2005, 53(11): 4110–4124. doi: 10.1109/tsp.2005.857028

AHMED M F A and VOROBYOV S A. Collaborative beamforming for wireless sensor networks with gaussian distributed sensor nodes[J]. IEEE Transactions on Wireless Communications, 2009, 8(2): 638–643. doi: 10.1109/TWC.2009.071339

JAYAPRAKASAM S, ABDUL RAHIM S K, LEOW C Y, et al. Multiobjective beampattern optimization in collaborative beamforming via NSGA-II with selective distance[J]. IEEE Transactions on Antennas and Propagation, 2017, 65(5): 2348–2357. doi: 10.1109/tap.2017.2684187

AHMED M F A and VOROBYOV S A. Sidelobe control in collaborative beamforming via node selection[J]. IEEE Transactions on Signal Processing, 2010, 58(12): 6168–6180. doi: 10.1109/tsp.2010.2077631

CHEN J C, WEN Chaokai, and WONG K K. An efficient sensor-node selection algorithm for sidelobe control in collaborative beamforming[J]. IEEE Transactions on Vehicular Technology, 2016, 65(8): 5984–5994. doi: 10.1109/TVT.2015.2478898

SUN Geng, LIU Yanheng, WANG Aimin, et al. Sidelobe control by node selection algorithm based on virtual linear array for collaborative beamforming in WSNs[J]. Wireless Personal Communications, 2016, 90(3): 1443–1462. doi: 10.1007/s11277-016-3403-9

SUN Geng, LIU Yanheng, ZHANG Jing, et al. Node selection optimization for collaborative beamforming in wireless sensor networks[J]. Ad Hoc Networks, 2016, 37: 389–403. doi: 10.1016/j.adhoc.2015.08.031

SUN Geng, LIU Yanheng, LIANG Shuang, et al. A sidelobe and energy optimization array node selection algorithm for collaborative beamforming in wireless sensor networks[J]. IEEE Access, 2018, 6: 2515–2530. doi: 10.1109/ACCESS.2017.2783969

蔣俊正, 李楊劍, 趙海兵, 等. 一種大規模傳感器網絡節點分布式定位算法[J]. 電子與信息學報, 2019, 41(12): 3022–3028. doi: 10.11999/JEIT181101

JIANG Junzheng, LI Yangjian, ZHAO Haibing, et al. A distributed node localization algorithm for large scale sensor networks[J]. Journal of Electronics &Information Technology, 2019, 41(12): 3022–3028. doi: 10.11999/JEIT181101

汪晗, 成昂軒, 王坤, 等. 無線傳感器網絡分布式迭代定位誤差控制算法[J]. 電子與信息學報, 2018, 40(1): 72–78. doi: 10.11999/JEIT170344

WANG Han, CHENG Angxuan, WANG Kun, et al. Error control algorithm of distributed localization in wireless sensor networks[J]. Journal of Electronics &Information Technology, 2018, 40(1): 72–78. doi: 10.11999/JEIT170344

KIM Y, LEE B, SO H, et al. Localization technique considering position uncertainty of reference nodes in wireless sensor networks[J]. IEEE Sensors Journal, 2018, 18(3): 1324–1332. doi: 10.1109/JSEN.2017.2782805

STOLERU R, STANKOVIC J A, and SON S H. On composability of localization protocols for wireless sensor networks[J]. IEEE Network, 2008, 22(4): 21–25. doi: 10.1109/MNET.2008.4579767
