基于深度特征學習的網絡流量異常檢測方法
doi: 10.11999/JEIT190266
-
1.
中國人民解放軍戰略支援部隊信息工程大學 鄭州 450001
-
2.
河南省信息安全重點實驗室 鄭州 450001
Network Traffic Anomaly Detection Method Based on Deep Features Learning
-
1.
PLA SSF Information Engineering University, Zhengzhou 450001, China
-
2.
Henan Key Laboratory of Information Security, Zhengzhou 450001, China
-
摘要:
針對網絡流量異常檢測過程中提取的流量特征準確性低、魯棒性差導致流量攻擊檢測率低、誤報率高等問題，該文結合堆疊降噪自編碼器(SDA)和softmax，提出一種基于深度特征學習的網絡流量異常檢測方法。首先基于粒子群優化算法設計SDA結構兩階段尋優算法：根據流量檢測準確率依次對隱藏層層數及每層節點數進行尋優，確定搜索空間中的最優SDA結構，從而提高SDA提取特征的準確性。然后采用小批量梯度下降算法對優化的SDA進行訓練，通過最小化含噪數據重構向量與原始輸入向量間的差異，提取具有較強魯棒性的流量特征。最后基于提取的流量特征對softmax進行訓練構建異常檢測分類器，從而實現對流量攻擊的高性能檢測。實驗結果表明：該文所提方法可根據實驗數據及其分類任務動態調整SDA結構，提取的流量特征具有更高的準確性和魯棒性，流量攻擊檢測率高、誤報率低。
-
關鍵詞:
- 流量異常檢測 /
- 深度學習 /
- 堆疊降噪自編碼器 /
- 粒子群優化
Abstract:In view of the problems of low attack detection rate and high false positive rate caused by poor accuracy and robustness of the extracted traffic features in network traffic anomaly detection, a network traffic anomaly detection method based on deep features learning is proposed, which is combined with Stacked Denoising Autoencoders (SDA) and softmax. Firstly, a two-stage optimization algorithm is designed based on particle swarm optimization algorithm to optimize the structure of SDA, the number of hidden layers and nodes in each layer is optimized successively based on the traffic detection accuracy, and the optimal structure of SDA in the search space is determined, improving the accuracy of traffic features extracted by SDA. Secondly, the optimized SDA is trained by the mini-batch gradient descent algorithm, and the traffic features with strong robustness are extracted by minimizing the difference between the reconstruction vector of the corrupted data and the original input vector. Finally, softmax is trained by the extracted traffic features to construct an anomaly detection classifier for detecting traffic attacks with high performance. The experimental results show that the proposed method can adjust the structure of SDA based on the experimental data and its classification tasks, extract traffic features with a higher accuracy and robustness, and detect traffic attacks with high detection rate and low false positive rate.
-
表 1 隱藏層層數尋優算法
輸入：流量異常檢測數據集，NP,${t_{\max }}$, $w$, ${c_1}$, ${c_2}$, ${l_{\max }}$, ${l_{\min }}$, ${v_{l,\max }}$, ${v_{l,\min }}$, ${n_{\max }}$, ${n_{\min }}$, ${v_{n,\max }}$, ${v_{n,\min }}$ 輸出：具有${l_{{\rm{gbest}}}}$個隱藏層且每層節點數為${n_{{\rm{gbest}}}}$的SDA for $i = 1\;{\rm{to}}\;{{\rm{NP}}}$ do 采用式(5)—式(8)對粒子群進行初始化，并分別將${l_{i,{\rm{pbest}}}}$和${n_{i,{\rm{pbest}}}}$初始化為${l_i}(0)$和${n_i}(0)$； 基于實驗數據，采用式(9)計算粒子i的適應度值； 將最小適應度值對應的l和n設置為${l_{{\rm{gbest}}}}$和${n_{{\rm{gbest}}}}$初始化值； for $t = {1_{}}{\rm{t}}{{\rm{o}}_{}}\begin{array}{*{20}{c}} {{t_{\max }}} \end{array}$ do for $i = {1_{}}{\rm{t}}{{\rm{o}}_{}}\begin{array}{*{20}{c}} {{\rm{NP}}} \end{array}$ do 采用式(1)—式(4)更新粒子i的${l_i}(t)$速度和數值，以及${n_i}(t)$的速度和數值； if ${v_{{l_i}}}(t)$, ${l_i}(t)$,${v_{{n_i}}}(t)$ or ${n_i}(t)$超過其搜索范圍 對${v_{{l_i}}}(t)$, ${l_i}(t)$,${v_{{n_i}}}(t)$ or ${n_i}(t)$再次進行隨機初始化； 生成具有${l_i}(t)$個隱藏層且每層節點數為${n_i}(t)$的SDA； 基于實驗數據，采用式(9)計算粒子i的適應度值； if(${\rm{fit} } ({l_i}(t),{n_i}(t)) < {\rm{fit} } ({l_{i,{\rm pbest}} },{n_{i,{\rm{pbest} } } })$)//若粒子i的適應度值小于局部最優值對應的適應度值，則對局部最優值進行更新 分別將${l_i}(t)$和${n_i}(t)$賦值給${l_{i,{\rm{pbest}}}}$和${n_{i,{\rm{pbest}}}}$； if(${\rm{fit}} ({l_i}(t),{n_i}(t)) < {\rm{fit}} ({l_{{\rm{gbest}}}},{n_{{\rm{gbest}}}})$)//若粒子i的適應度值小于全局最優值對應的適應度值，則對全局最優值進行更新 分別將${l_i}(t)$和${n_i}(t)$賦值給${l_{{\rm{gbest}}}}$和${n_{{\rm{gbest}}}}$； 迭代結束后，生成具有${l_{{\rm{gbest}}}}$個隱藏層且每層節點數為${n_{{\rm{gbest}}}}$的SDA； return 具有${l_{{\rm{gbest}}}}$個隱藏層且每層節點數為${n_{{\rm{gbest}}}}$的SDA。
下載: 導出CSV
表 2 隱藏層每層節點數尋優算法
輸入：流量異常檢測數據集，NP, ${t_{\max }}$, $w$, ${c_1}$, ${c_2}$, ${v_{\max }}$, ${v_{\min }}$, ${l_{{\rm{gbest}}}}$, ${n_{{\rm{gbest}}}}$ 輸出：最優SDA結構 for $i = {1 }\ {\rm{t} }{ {\rm{o} }_{} }\ { {\rm{NP} } } $ do for $h = {1_{} }\ {\rm{t} }{ {\rm{o} }_{} }\ {l_{ {\rm{gbest} } } }$ do 初始化粒子位置$n_i^{(h)}(0) = {n_{{\rm{gbest}}}}$，采用式(12)初始化粒子速度，并將局部最優向量${{{n}}_{i,{\rm{pbest}}}}$中的$n_{i,{\rm{pbest}}}^{(h)}$初始化為${n_{{\rm{gbest}}}}$； 設置全局最優向量${ {{n} }_{ {\rm{gbest} } } } = \min \{ { {{n} }_{ {\rm{1,pbest} } } },{ {{n} }_{ {\rm{2,pbest} } } }, ··· ,{ {{n} }_{ {\rm{NP,pbest} } } }\} = {[{n_{ {\rm{gbest} } } }_{}{n_{ {\rm{gbest} } } } ··· {n_{ {\rm{gbest} } } }]^{\rm T}}$； for $t = {1_{}}{\rm{t}}{{\rm{o}}_{}}\begin{array}{*{20}{c}} {{t_{\max }}} \end{array}$ do for $i = {1_{}}{\rm{t}}{{\rm{o}}_{}}\begin{array}{*{20}{c}} {{\rm{NP}}} \end{array}$ do for $h = {1_{}}{\rm{t}}{{\rm{o}}_{}}{l_{{\rm{gbest}}}}$ do 采用式(10)和式(11)更新粒子i位置向量${{{n}}_i}(t)$中元素$n_i^{(h)}(t)$的速度和數值； if $v_i^{(h)}(t)$ or $n_i^{(h)}(t)$超過其搜索范圍 對$v_i^{(h)}(t)$ or $n_i^{(h)}(t)$再次進行隨機初始化； 根據更新后的${{{n}}_i}(t)$，將SDA每個隱藏層的節點數分別更新為$n_i^{(1)}(t),n_i^{(2)}(t), ··· ,n_i^{({l_{{\rm{gbest}}}})}(t)$； 基于實驗數據，采用式(13)計算粒子i的適應度值； if(${\rm{fit}} ({{{n}}_i}(t)) < {\rm{fit}} ({{{n}}_{i,{\rm{pbest}}}})$)//若粒子i的適應度值小于局部最優向量對應的適應度值，則對局部最優向量進行更新 ${{{n}}_{i,{\rm{pbest}}}} \leftarrow {{{n}}_i}(t)$； ${{{n}}_{{\rm{gbest}}}} \leftarrow \min \{ {{{n}}_{{\rm{1,pbest}}}},{{{n}}_{{\rm{2,pbest}}}}, ··· ,{{{n}}_{{\rm{NP,pbest}}}}\} $；//采用局部最優向量中的最小值更新全局最優向量 迭代結束后，根據最終${{{n}}_{{\rm{gbest}}}}$分別將SDA的隱藏層每層節點數更新為$n_{{\rm{gbest}}}^{(1)},n_{{\rm{gbest}}}^{(2)}, ··· ,n_{{\rm{gbest}}}^{({l_{{\rm{pbest}}}})}$； return 最優SDA結構。
下載: 導出CSV
表 3 二分類場景不同模型檢測性能
模型類型 基于SAE的異常
檢測模型基于傳統SDA的
異常檢測模型基于一階段尋優SDA的
異常檢測模型基于兩階段尋優SDA的
異常檢測模型模型結構 [28, 3, 2, 2, 2, 1, 3, 3, 3, 2] [28, 28, 28, 28, 2] [28, 2, 2, 2, 2, 2, 2, 2, 2, 2] [28, 3, 2, 2, 2, 1, 3, 3, 3, 2] Acc (%) 86.29 86.52 86.58 92.68 DR (%) 92.85 96.10 94.75 96.80 Rec (%) 90.04 92.68 89.26 94.48 FPR (%) 4.96 3.38 3.51 2.72 ${T_{{\rm{tr}}}}$(m) 8.24 8.52 7.45 8.50 ${T_{{\rm{te}}}}$(s) 0.18 0.18 0.18 0.18
下載: 導出CSV
表 4 多分類場景不同模型檢測性能
模型類型 基于SAE的異常
檢測模型基于傳統SDA的
異常檢測模型基于一階段尋優SDA的
異常檢測模型基于兩階段尋優SDA的
異常檢測模型模型結構 [28, 24, 5] [28, 28, 28, 28, 5] [28, 25, 5] [28, 24, 5] Acc (%) 84.12 84.31 84.96 85.37 Normal DR (%) 84.58 85.37 85.87 86.34 Rec (%) 96.74 96.88 97.01 97.28 FPR (%) 17.98 18.89 18.06 17.25 DoS DR (%) 94.08 94.74 94.92 95.59 Rec (%) 83.65 84.51 82.63 85.88 FPR (%) 2.05 2.04 2.02 1.72 Probe DR (%) 79.42 75.58 79.71 83.27 Rec (%) 65.14 67.29 63.78 68.28 FPR (%) 1.78 2.21 1.70 1.34 R2L DR (%) 90.96 92.06 83.78 90.50 Rec (%) 58.23 60.99 58.34 60.23 FPR (%) 0.27 0.21 0.57 0.30 U2R DR (%) 88.05 28.60 72.58 76.19 Rec (%) 2.50 2.00 4.50 3.00 FPR (%) 0.01 0.03 0.01 0.01 ${T_{{\rm{tr}}}}$(m) 3.94 6.32 6.54 5.36 ${T_{{\rm{te}}}}$(s) 0.20 0.40 0.41 0.26
下載: 導出CSV
表 5 多分類場景不同模型檢測含噪流量的準確率
模型類型 Acc (%) 0.1 0.2 0.3 基于SAE的異常檢測模型 81.57 79.31 76.69 基于傳統SDA的異常檢測模型 83.63 83.54 83.48 基于一階段尋優SDA的異常檢測模型 84.71 84.52 84.23 基于兩階段尋優SDA的異常檢測模型 85.08 85.01 85.02
下載: 導出CSV
-
KWON D, KIM H, KIM J, et al. A survey of deep learning-based network anomaly detection[J]. Cluster Computing, 2019, 22(Suppl 1): 949–961. 高妮, 高嶺, 賀毅岳, 等. 基于自編碼網絡特征降維的輕量級入侵檢測模型[J]. 電子學報, 2017, 45(3): 730–739. doi: 10.3969/j.issn.0372-2112.2017.03.033GAO Ni, GAO Ling, HE Yiyue, et al. A lightweight intrusion detection model based on autoencoder network with feature reduction[J]. Acta Electronica Sinica, 2017, 45(3): 730–739. doi: 10.3969/j.issn.0372-2112.2017.03.033 ALRAWASHDEH K and PURDY C. Toward an online anomaly intrusion detection system based on deep learning[C]. The 15th IEEE International Conference on Machine Learning and Applications, Anaheim, USA, 2016: 195–200. doi: 10.1109/ICMLA.2016.0040. JAVAID A, NIYAZ Q, SUN Weiqing, et al. A deep learning approach for network intrusion detection system[C]. The 9th EAI International Conference on Bio-inspired Information and Communications Technologies, New York, USA, 2015: 21–26. doi: 10.4108/eai.3-12-2015.2262516. YOUSEFI-AZAR M, VARADHARAJAN V, HAMEY M, et al. Autoencoder-based feature learning for cyber security applications[C]. The 2017 International Joint Conference on Neural Networks, Anchorage, USA, 2017: 3854–3861. doi: 10.1109/IJCNN.2017.7966342. WANG Wei, ZHU Ming, ZENG Xuewen, et al. Malware traffic classification using convolutional neural network for representation learning[C]. 2017 International Conference on Information Networking, Da Nang, Vietnam, 2017: 712–717. doi: 10.1109/ICOIN.2017.7899588. 王勇, 周慧怡, 俸皓, 等. 基于深度卷積神經網絡的網絡流量分類方法[J]. 通信學報, 2018, 39(1): 14–23. doi: 10.11959/j.issn.1000-436x.2018018WANG Yong, ZHOU Huiyi, FENG Hao, et al. Network traffic classification method basing on CNN[J]. Journal on Communications, 2018, 39(1): 14–23. doi: 10.11959/j.issn.1000-436x.2018018 YU Yang, LONG Jun, and CAI Zhiping. Session-based network intrusion detection using a deep learning architecture[C]. The 14th International Conference on Modeling Decisions for Artificial Intelligence, Kitakyushu, Japan, 2017: 144–155. doi: 10.1007/978-3-319-67422-3_13. VINCENT P, LAROCHELLE H, LAJOIE I, et al. Stacked Denoising Autoencoders: Learning useful representations in a deep network with a local denoising criterion[J]. The Journal of Machine Learning Research, 2010, 11: 3371–3408. Canadian Institute for Cybersecurity. NSL-KDD dataset[EB/OL]. https://www.unb.ca/cic/datasets/nsl.html, 2018. QOLOMANY B, MAABREH M, AL-FUQAHA, et al. Parameters optimization of deep learning models using particle swarm optimization[C]. The 13th International Wireless Communications and Mobile Computing Conference, Valencia, Spain, 2017: 1285–1290. doi: 10.1109/IWCMC.2017.7986470. WANG Yao, CAI Wandong, and WEI Pengcheng. A deep learning approach for detecting malicious JavaScript code[J]. Security and Communication Networks, 2016, 9(11): 1520–1534. doi: 10.1002/sec.1441 陳建廷, 向陽. 深度神經網絡訓練中梯度不穩定現象研究綜述[J]. 軟件學報, 2018, 29(7): 2071–2091. doi: 10.13328/j.cnki.jos.005561CHEN Jianting and XIANG Yang. Survey of unstable gradients in deep neural network training[J]. Journal of Software, 2018, 29(7): 2071–2091. doi: 10.13328/j.cnki.jos.005561 谷叢叢, 王艷, 嚴大虎, 等. 基于自編碼組合特征提取的分類方法研究[J]. 系統仿真學報, 2018, 30(11): 4132–4140. doi: 10.16182/j.issn1004731x.joss.201811011GU Congcong, WANG Yan, YAN Dahu, et al. Research on classification based on autoencoder combination features extraction method[J]. Journal of System Simulation, 2018, 30(11): 4132–4140. doi: 10.16182/j.issn1004731x.joss.201811011 FIORE U, PALMIERI F, CASTIGLIONE A, et al. Network anomaly detection with the restricted Boltzmann machine[J]. Neurocomputing, 2013, 122: 13–23. doi: 10.1016/j.neucom.2012.11.050 KINGMA D and BA J. Adam: A method for stochastic optimization[C/OL]. https://arxiv.org/abs/1412.6980, 2017. -
