基于復合域通用低熵高階掩碼的設計與實現
doi: 10.11999/JEIT190257
-
1.
哈爾濱理工大學理學院 哈爾濱 150080
-
2.
哈爾濱理工大學軟件與微電子學院 哈爾濱 150080
-
3.
哈爾濱理工大學計算機科學與技術學院 哈爾濱 150040
基金項目: 國家自然科學基金(61604050, 51672062)，黑龍江省普通本科高等學校青年創新人才培養計劃(UNPYSCT-2017081)，黑龍江省博士后科研啟動基金(LBH-Q18065)
Design and Implementation of Generic Low-entropy High-order Composite Field Based Masking Scheme
-
1.
School of Sciences, Harbin University of Science and Technology, Harbin 150080, China
-
2.
School of Software and Microelectronics, Harbin University of Science and Technology, Harbin 150080, China
-
3.
School of Computer Sciences and Technology, Harbin University of Science and Technology, Harbin 150040, China
Funds: The National Natural Science Foundation of China (61604050, 51672062), The University Nursing Program for Young Scholars with Creative Talents in Heilongjiang Province (UNPYSCT-2017081), The Heilongjiang Postdoctoral Funds for Scientific Research Initiation (LBH-Q18065)
-
摘要:
通過對基于復合域S-box構造算法的深入研究，該文提出一種低面積復雜度的通用低熵高階掩碼算法。在有限域GF(24)上引入低熵掩碼思想，并采用部分模塊復用設計，有效降低了基于復合域S-box求逆運算的乘法數量。該算法能夠適用于由求逆運算構成的任意分組加密算法，進一步將本方案應用于分組加密算法高級加密標準(AES)，給出了詳細的綜合仿真結果并進行了版圖面積優化，較傳統的掩碼方案相比有效減少了邏輯資源的使用，此外，對其安全性進行了理論驗證。
-
關鍵詞:
- 高階掩碼 /
- 復合域算法 /
- S-box /
- 低熵 /
- 高級加密標準
Abstract:Based on the in-depth research on the S-box constitution arithmetic of composite, an area optimized generic low-entropy higher-order masking scheme is proposed in this paper. The low entropy masking method is introduced on GF(24), and the partial module reusing design is adopted, which reduces effectively the number of multiplications based on the S-box inversion operation of the composite. The algorithm can be applied to any order masking scheme of arbitrary S-box composed of inversion operation. This scheme is applied to AES, gives detailed simulation results and optimizes the layout area, compared with the traditional masking scheme, reduces effectively the use of logical resources. In addition, the security is theoretically proved.
-
Key words:
- High-order masking /
- Composite arithmetic /
- S-box /
- Low entropy /
- Advanced Encryption Standard(AES)
-
表 1 低熵通用高階掩碼算法
算法1 低熵通用高階掩碼算法 輸入：經掩碼值$x = a + {m_1} + {m_2} + ··· + {m_d}$，掩碼值${m_1},{m_2}, ··· ,{m_d}$ 輸出：輸入值的求逆${a^{ - 1}} + {m_1} + {m_2} + ··· + {m_d}$ (1) 通過同構矩陣$ \delta $，將有限域${\rm{GF}}({2^k})$上的輸入值$x,$m1, m2, ··· ,md分別映射到有限域${\rm{GF}}({2^n})$上，$({x_h},{x_l}){\rm{ }} \leftarrow x$; $({m_{h1}},{m_{l1}}) \leftarrow {m_1}$;
$({m_{h2}},{m_{l2}}) \leftarrow {m_2}$; ··· ; $({m_{hd}},{m_{ld}}) \leftarrow {m_d}$；(2) 將有限域${\rm{GF}}({2^k})$上的求逆運算轉化成有限域${\rm{GF}}({2^n})$上的加法、乘法，求逆運算； (3) 利用有限域${\rm{GF}}({2^n})$上的運算求取$d$的掩碼防護值$d + {m_{h1} } + {m_{h2} } + ··· + {m_{hd} }$，$\begin{align} d + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}} = & {f_d}({x_h},({x_l} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}} + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}}),\\&({x_h} + {x_l} + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}}),{m_{h1}},{m_{h2}}, ··· ,{m_{hd}},{m_{l1}},{m_{l2}}, ··· ,{m_{ld}},{{\rm{P}}_0})\\ =& {a_h}^2 \times {{\rm{P}}_0} + {a_h} \times {a_l} + {a_l}^2 + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}};\end{align}$ (4) 在有限域${\rm{GF}}({2^n})$上對$d + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}}$進行掩碼求逆，求逆結果為${d^{ - 1}} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}}$； (5) 利用有限域${\rm{GF}}({2^n})$上的運算求取${x_h},{x_l}$的掩碼防護值${x_h}^\prime + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}}$, ${x_l}^\prime + {m_{l1} } + {m_{l2} } + ··· + {m_{ld} }$, $\begin{align}\quad\quad\ \; {x_h}^\prime + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}} =& {f_{bh}}({x_h},({d^{ - 1}} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}}),\\&({x_h} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}} + {d^{ - 1}} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}}){\rm{ }},{m_{h1}},{m_{h2}}, ··· ,{m_{hd}})\\ = & {a_h} \times {d^{ - 1}} + {m_{h1}} + {m_{h2}} + ··· + {m_{hd}};\end{align}$$\begin{align}\quad\quad\ \; {x_l}^\prime + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}} =& {f_{bl}}({x_h},({d^{ - 1}} + {m_{h1}} + {m_{h{\rm{2}}}} + ··· + {m_{hd}}), ({x_l} + {m_{h1}} + {m_{h{\rm{2}}}} + ··· + {m_{hd}} + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}}),\\&({x_h} + {x_l} + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}}) ,{m_{h1}},{m_{h2}}, ··· ,{m_{hd}},{m_{l1}},{m_{l2}}, ··· ,{m_{ld}})\\ =& ({a_h} + {a_l}) \times {d^{ - 1}} + {m_{l1}} + {m_{l2}} + ··· + {m_{ld}};\end{align}$ (6) 通過同構逆矩陣${{ \delta} ^{ - 1} }$，將有限域${\rm{GF}}({2^n})$上的求逆結果映射回有限域${\rm{GF}}({2^k})$上，得到有限域${\rm{GF}}({2^k})$上求逆結果
${a^{ - 1}} + {m_1} + {m_2} + {\rm{ }} ··· + {m_d}$。
下載: 導出CSV
表 2 AES低熵通用高階掩碼算法
算法2 有限域${\rm{GF}}({2^k})$上對掩碼單元$a' = a + {m_1} + {m_2}$求逆 輸入：$(x = a + {m_1} + {m_2},{m_1},{m_2}) \in {\rm{GF}}({2^k})$ 輸出：$(x' = {a^{ - 1}} + {m_1} + {m_2})$ (1) 映射${ \delta} ({m_1}) \to ({m_{h1} },{m_{l1} }) \in {\rm{GF} }({2^n})$，
映射$\delta ({m_2}) \to ({m_{h2}},{m_{l2}}) \in {\rm{GF}}({2^n})$；(2) 映射$\delta (x) \to ({x_h},{x_l}) \in {\rm{GF}}({2^n})$，即$\{ ({x_h},{x_l}) = ({a_h} + {m_{h1}} + {m_{h2}},{a_h} + {m_{l1}} + {m_{l2}})\} $；
$\begin{align}(3) \ d + {m_{h1}} + {m_{h2}} =& {({x_h})^2}{{\rm{P}}_0} + {m_h}{_1^2}{{\rm{P}}_0} + {m_h}{_2^2}{{\rm{P}}_0} + {({x_l} + {m_{h1}} + {m_{h2}} + {m_{l1}} + {m_{l2}})^2} + {x_h}({x_l} + {m_{h1}} + {m_{h2}} + {m_{l1}} + {m_{l2}})\\ &+ ({x_h} + {x_l} + {m_{l1}} + {m_{l2}})({m_{h1}} + {m_{h2}}) + {m_h}{_1^2} + {m_h}{_2^2} + {m_{h1}} + {m_{h2}};\end{align}$(4) ${d^{ - 1} } + {m_{h1} } + {m_{h2} } =\text{算法}2.(d + {m_{h1} } + {m_{h2} },{m_{h1} },{m_{h2} })$； (5) ${x_h}^\prime + {m_{h1}} + {m_{h2}} = {x_h}({d^{ - 1}} + {m_{h1}} + {m_{h2}}) + ({x_h} + {d^{ - 1}} + {m_{h1}} + {m_{h2}} + {m_{h1}} + {m_{h2}})({m_{h1}} + {m_{h2}}) + {m_{h1}} + {m_{h2}}$；
$\begin{align}(6) \ {x_l}^\prime + {m_{l1}} + {m_{l2}} =& {x_h}({d^{ - 1}} + {m_{h1}} + {m_{h2}}) + ({x_l} + {m_{h1}} + {m_{h2}} + {m_{l1}} + {m_{l2}})({d^{ - 1}} + {m_{h1}} + {m_{h2}}) + ({x_h} + {x_l} + {m_{l1}} + {m_{l2}})({m_{h1}} \\&+ {m_{h2}}) + {m_h}{_1^2} + {m_h}{_2^2} + {m_{l1}} + {m_{l2}}{text{；}}\end{align}$(7) 映射${\delta ^{ - 1}}({x_h}^\prime + {m_{h1}} + {m_{h2}},{x_l}^\prime + {m_{l1}} + {m_{l2}}) \to {\rm{ }}({a^{ - 1}} + {m_1} + {m_2})$。
下載: 導出CSV
表 3 不同方案的S-box實現對比
下載: 導出CSV
表 5 不同AES方案實現結果對比方案
思想 總的邏輯單元 組合邏輯 總的寄存器 非掩碼 23890(21%) 19811(17%) 10769(9%) Oswald[12]
1階掩碼45549(40%)
(90.7%)40368(35%)
(103.8%)16036(14%)
(48.9%)汪鵬君[17]
1階掩碼42161(37%)
(76.5%)36584(32%)
(84.7%)13780(12%)
(28%)Ahn[18]
1階掩碼42087(37%)
(76.2%)36510(32%)
(84.3%)12820(11%)
(19%)本文方法
1階掩碼38456(34%)
(60.9%)32879(28%)
(66.1%)12820(11%)
(19%%)本文方法
2階掩碼44475(39%)
(86.1%)38282(33%)
(93.2%)18980(17%)
(76.2%%)
下載: 導出CSV
表 6 本方案S-box不同掩碼階數的綜合結果
掩碼階數 邏輯名稱 邏輯面積(μm2) 合計(μm2) 非掩碼S-box 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 221, 14, 46 268 1階掩碼S-box 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 489, 19, 88 577 2階掩碼S-box 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 551, 22, 88 639
下載: 導出CSV
表 7 本方案AES不同掩碼階數的綜合結果
掩碼階數 邏輯名稱 邏輯面積(μm2) 合計(μm2) 非掩碼AES 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 14484, 586, 53834 67518 1階掩碼AES 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 53626, 2888, 59614 113241 2階掩碼AES 組合邏輯，緩沖器/反相器邏輯，非組合邏輯 116797, 4594, 100564 217361
下載: 導出CSV
-
HUANG Hai, LIU Leibo, HUANG Qihuan, et al. Low area-overhead low-entropy masking scheme (LEMS) against correlation power analysis attack[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2019, 38(2): 208–219. doi: 10.1109/TCAD.2018.2802867 歐慶于, 羅芳, 葉偉偉, 等. 分組密碼算法抗故障攻擊能力度量方法研究[J]. 電子與信息學報, 2017, 39(5): 1266–1270. doi: 10.11999/JEIT160548OU Qingyu, LUO Fang, YE Weiwei, et al. Metric for defences against fault attacks of block ciphers[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1266–1270. doi: 10.11999/JEIT160548 CORON J S, GREUET A, PROUFF E, et al. Faster evaluation of sboxes via common shares[C]. The 18th International Conference on Cryptographic Hardware and Embedded Systems, Santa Barbara, USA, 2016: 498–514. doi: 10.1007/978-3-662-53140-2_24. 臧鴻雁, 黃慧芳. 基于均勻化混沌系統生成S盒的算法研究[J]. 電子與信息學報, 2017, 39(3): 575–581. doi: 10.11999/JEIT160535ZANG Hongyan and HUANG Huifang. Research on algorithm of generating s-box based on uniform chaotic system[J]. Journal of Electronics &Information Technology, 2017, 39(3): 575–581. doi: 10.11999/JEIT160535 汪鵬君, 張躍軍, 張學龍. 防御差分功耗分析攻擊技術研究[J]. 電子與信息學報, 2012, 34(11): 2774–2784. doi: 10.3724/SP.J.1146.2012.00555WANG Pengjun, ZHANG Yuejun, and ZHANG Xuelong. Research of differential power analysis countermeasures[J]. Journal of Electronics &Information Technology, 2012, 34(11): 2774–2784. doi: 10.3724/SP.J.1146.2012.00555 王建新, 方華威, 段曉毅, 等. 基于滑動平均的能量分析攻擊研究與實現[J]. 電子與信息學報, 2017, 39(5): 1256–1260. doi: 10.11999/JEIT160637WANG Jianxin, FANG Huawei, DUAN Xiaoyi, et al. Research and implementation of power analysis based on moving average[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1256–1260. doi: 10.11999/JEIT160637 CORON J S. Higher order masking of look-up tables[C]. The 33rd Annual International Conference on the Theory and Applications of Cryptographic Techniques Advances in Cryptology, Berlin, Germany, 2014: 441–458. 徐佩. 智能卡AES加密模塊抗側信道攻擊掩碼技術研究與實現[D]. [碩士論文], 重慶大學, 2015: 26–53.XU Pei. Research and implementation with mask technology on AES encryption module of smartcard against side channel attack[D]. [Master dissertation], The Chongqing University, 2015: 26–53. CARLET C and PROUFF E. Polynomial evaluation and side channel analysis[M]. RYAN P Y A, NACCACHE D, and QUISQUATER J J. The New Codebreakers: Essays Dedicated to David Kahn on the Occasion of His 85th Birthday. Berlin, Heidelberg: Springer, 2016: 315–341. doi: 10.1007/978-3-662-49301-4_20. 黃海, 馮新新, 劉紅雨, 等. 基于隨機加法鏈的高級加密標準抗側信道攻擊對策[J]. 電子與信息學報, 2019, 41(2): 348–354. doi: 10.11999/JEIT171211HUANG Hai, FENG Xinxin, LIU Hongyu, et al. Random addition-chain based countermeasure against side-channel attack for advanced encryption standard[J]. Journal of Electronics &Information Technology, 2019, 41(2): 348–354. doi: 10.11999/JEIT171211 NASSAR M, SOUISSI Y, GUILLEY S, et al. RSM: A small and fast countermeasure for AES, secure against 1st and 2nd-order zero-offset SCAs[C]. 2012 Design, Automation & Test in Europe Conference & Exhibition, Dresden, Germany, 2012: 1173–1178. OSWALD E, MANGARD S, PRAMSTALLER N, et al. A side-channel analysis resistant description of the AES s-box[C]. The 12th International Workshop on Fast Software Encryption, Paris, France, 2005: 413–423. doi: 10.1007/11502760_28. ZAKERI B, SALMASIZADEH M, MORADI A, et al. Compact and secure design of masked AES s-box[C]. The 9th International Conference on Information and Communications Security, Zhengzhou, China, 2007: 216–229. TRICHINA E and KORKISHKO T. Secure AES hardware module for resource constrained devices[C]. Proceedings of the 1st European Workshop on Security in Ad-hoc and Sensor Networks, Heidelberg, Germany, 2005: 215–229. doi: 10.1007/978-3-540-30496-8_18. OSWALD E and SCHRAMM K. An efficient masking scheme for AES software implementations[C]. The 6th International Workshop on Information Security Applications. Jeju Island, Korea, 2006: 292–305. KIM H S, HONG S, and LIM J. A fast and provably secure higher-order masking of AES s-box[C]. Proceedings of the 13th International Conference on Cryptographic Hardware and Embedded Systems. Nara, Japan, 2011: 95–107. 汪鵬君, 郝李鵬, 張躍軍. 防御零值功耗攻擊的AES SubByte模塊設計及其VLSI實現[J]. 電子學報, 2012, 40(11): 2183–2187. doi: 10.3969/j.issn.0372-2112.2012.11.007WANG Pengjun, HAO Lipeng, and ZHANG Yuejun. Design of AES subbyte module of anti-zero value power attack and its VLSI implementation[J]. Acta Electronica Sinica, 2012, 40(11): 2183–2187. doi: 10.3969/j.issn.0372-2112.2012.11.007 AHN S and CHOI D. An improved masking scheme for s-box software implementations[C]. The 16th International Workshop on Information Security Applications, Jeju Island, Korea, 2016: 200–212. -
