基于迭代模糊聚類算法與K近鄰和數據字典的集成TSK模糊分類器

張雄濤; 蔣云良; 潘興廣; 胡文軍; 王士同

doi:10.11999/JEIT190214

基于迭代模糊聚類算法與K近鄰和數據字典的集成TSK模糊分類器

doi: 10.11999/JEIT190214

張雄濤^{1, 2, ,},
蔣云良²,
潘興廣^{1, 3},
胡文軍²,
王士同¹

1.
江南大學數字媒體學院無錫 214122
2.
湖州師范學院信息工程學院湖州 313000
3.
貴州民族大學工程實訓中心貴陽 550025

基金項目: 國家自然科學基金(61572236, 61300151, 61772198, 61771193)，中央高?；究蒲袠I(yè)務費專項資金(JUDCF13030)

詳細信息

作者簡介:
張雄濤：男，1984年生，博士，研究方向為模式識別、模糊系統

蔣云良：男，1967年生，教授，主要研究方向為智能計算、數據挖掘

潘興廣：男，1979年生，博士，研究方向為神經網絡、數據挖掘

胡文軍：男，1977年生，教授，主要研究方向為機器學習、模式識別

王士同：男，1964年生，教授，博士生導師，主要研究方向為模式識別、人工智能

通訊作者:
張雄濤　1047897965@qq.com

中圖分類號: TP391
計量
- 文章訪問數: 3195
- HTML全文瀏覽量: 1477
- PDF下載量: 78
- 被引次數: 0
出版歷程
- 收稿日期: 2019-04-03
- 修回日期: 2019-11-08
- 網絡出版日期: 2019-11-18
- 刊出日期: 2020-03-19

Iterative Fuzzy C-means Clustering Algorithm & K-Nearest Neighbor and Dictionary Data Based Ensemble TSK Fuzzy Classifiers

1.
School of Digital Media, Jiangnan University, Wuxi 214122, China
2.
School of Information Engineering, Huzhou University, Huzhou 313000, China
3.
Engineer Training Center, Guizhou Minzu University, Guiyang 550025, China

Funds: The National Natural Science Foundation of China (61572236, 61300151, 61772198, 61771193), The Fundamental Research Funds of the Central Universities (JUDCF13030)

摘要

摘要:
該文提出一種新型的集成TSK模糊分類器(IK-D-TSK)，首先通過并行學習的方式組織所有0階TSK模糊子分類器，然后每個子分類器的輸出被擴充到原始(驗證)輸入空間，最后通過提出的迭代模糊聚類算法(IFCM)作用在增強驗證集上生成數據字典，從而利用KNN對測試數據進行快速預測。IK-D-TSK具有以下優點：在IK-D-TSK中，每個0階TSK子分類器的輸出被擴充到原始入空間，以并行方式打開原始(驗證)輸入空間中存在的流形結構，根據堆棧泛化原理，可以保證提高分類精度；和傳統TSK模糊分類器相比，IK-D-TSK以并行方式訓練所有的子分類器，因此運行速度可以得到有效保證；由于IK-D-TSK是在以IFCM & KNN所獲得的數據字典的基礎上進行分類的，因此具有強魯棒性。理論和實驗驗證了模糊分類器IK-D-TSK具有較高的分類性能、強魯棒性和高可解釋性。
- TSK模糊分類器 /
- 迭代模糊聚類算法 /
- 數據字典 /
- 可解釋性
Abstract:
A new ensemble TSK fuzzy classifier (i,e. IK-D-TSK) is proposed. First, all zero-order TSK fuzzy sub-classifiers are organized in a parallel way, then the output of each sub-classifier is augmented to the original (validation) input space, finally, the proposed Iterative Fuzzy C-Means (IFCM) clustering algorithm generates dictionary data on augmented validation dataset, and then KNN is used to predict the result for test data. IK-D-TSK has the following advantages: the output of each zero-order TSK subclassifier is augmented to the original input space to open the manifold structure in parallel, according to the principle of stack generalization, the classification accuracy can be improved; Compared with traditional TSK fuzzy classifiers which trains sequentially, IK-D-TSK trains all the sub-classifiers in parallel, so the running speed can be effectively guaranteed; Because IK-D-TSK works based on dictionary data obtained by IFCM & KNN, it has strong robustness. The theoretical and experimental results show that IK-D-TSK has high classification performance, strong robustness and high interpretability.
- TSK fuzzy classifier /
- Iterative Fuzzy C-Means (IFCM) clustering algorithm /
- Dictionary data /
- Interpretability

HTML全文

圖 1 IK-D-TSK的框架

下載: 全尺寸圖片幻燈片

圖 2 IFCM & KNN

下載: 全尺寸圖片幻燈片

圖 3 分類器在各數據集上的測試精度

下載: 全尺寸圖片幻燈片

圖 4 模糊分類器在各數據集上的模糊規則數

下載: 全尺寸圖片幻燈片

表 1 IFCM算法

　輸入：數據集${ { X} } = \{ { { { x} }_1},{ { { x} }_2}, ··· ,{ { { x} }_N}\} \in {R^{N \times D} }$，及其標簽$ { { Y} } = $　　　　$\{ {y_1},{y_2}, ··· ,{y_N}\} $，真實類別數Q，每一類的聚類中心點數
　　　　c，每一類的樣本數${N_1},{N_2}, ··· ,{N_Q}$，最大誤差閾值$\tau $。

　輸出：中心點矩陣${{V}}$及其標簽。

　(1)通過FCM初始化每類中的中心點，然后形成中心點矩陣${{ V}}$。
　　初始化q=1，其中$1 \le q \le Q$。

　(2)重復；

　　(a)重復；

　　?、佼?i \in \left\{ {1,2, ··· ,{N_q}} \right\}$時，通過式(12)和式(13)計算隸屬度
　　　 ${\mu ^q}\left( {{{ x}}_i^q,{{ v}}_j^q} \right)$；當$ i \in \{ {N_q}{\rm{ + }}1,{N_q}{\rm{ + 2}}, ··· ,{N_q}{\rm{ + }}$$\left( {Q - 1} \right) \cdot c \}$
　　　時，通過式(14)和式(15)計算隸屬度${\mu ^q}\left( {{{ v}}_i^{\bar q},{{ v}}_j^q} \right)$；

　　?、谕ㄟ^式(17)計算中心點${{ v}}_j^q$；

　　(b)直到中心點矩陣保持幾乎不變或達到內部迭代的最大次數
　　　為止；

　　(c)利用${{ v}}_j^q$更新中心點矩陣${{ V}}$，并且$q = ( q + $$ 1 ){\rm{ mod }}\;Q$；
　(3)直到$\mathop {\max }\limits_{j \in \left\{ {1,2, ··· ,Q \cdot c} \right\}} \left\| {{{ v}}_j^q - {{ v}}_j^{q - 1}} \right\| < \tau $或達到外部最大迭代次
　　數為止；

　(4)根據中心點矩陣${{ V}}$輸出所有的中心點及其標簽。

下載: 導出CSV

表 2 IK-D-TSK學習算法

　輸入：訓練數據集${ {{D} }_{\rm tr} }{\rm{ = } }\left[ { { {{X} }_{\rm tr} }\;{ {{Y} }_{\rm tr} } } \right]$，驗證數據集${{{D}}_v}{\rm{ = }}\left[ {{{{X}}_v}\;{{{Y}}_v}} \right]$，　　　　其中${ {{X} }_{\rm tr} }$和${{{X}}_v}$分別表示訓練數據和驗證數據，對應的標
　　　　簽集為${ {{Y} }_{\rm tr} }$和${{{Y}}_v}$，子分類器數$L$, ${K_1},{K_2}, ··· ,{K_L}$表示每
　　　　個子分類器的模糊規則數

　輸出：IK-D-TSK的結構，數據字典

　訓練過程

　(1)初始化：為每個子分類器從${{{D}}_{\rm tr}}$中隨機抽樣訓練數據子集
　　 ${{{D}}_1},{{{D}}_2}, \!···\! ,{{{D}}_L}$，并且${{{D}}_1} \cup {{{D}}_2} \cup ······ \cup $${{{D}}_L}={{{D}}_{\rm tr}} $

　(2)并行訓練L個零階TSK模糊子分類器；

　　(a)為每個子分類器分配模糊規則數；

　　(b)構造5個高斯型隸屬度函數，在每一維上從中心點集合{0,
　　　 0.25, 0.50, 0.75, 1.00}中隨機指定一個值并構造規則組合矩
　　　陣${{{ \varTheta }}_l}{\rm{ = }}{[\upsilon _{ik}^l]_{{K_l} \times d}}$. 通過給每個元素分配一個隨機正數來構
　　　造核寬度矩陣${{{ \varPhi }}_l}= {\rm{ [}}\delta _{ik}^l{{\rm{]}}_{{K_l} \times d}}$，利用式(2)計算模糊隸屬度，
　　　正則化并構造矩陣

$ \qquad{ {{X} }_g} = \left[ {\begin{array}{*{20}{c} }\tilde \omega _1^1 & \tilde \omega _1^2 & ··· & \tilde \omega _1^{ {K_l} }\\\tilde \omega _2^1 & \tilde \omega _2^2 & ···& \tilde \omega _2^{ {K_l} }\\ \vdots & \vdots & \ddots & \vdots \\\tilde \omega _{ {N_l} }^1 & \tilde \omega _{ {N_l} }^2 &··· & \tilde \omega _{ {N_l} }^{ {K_l} }\end{array} } \right]_{ {N_l} \times {K_l} } \qquad\quad (18)$

　　通過LLM計算后件參數${{{ a}}_g}$，即

$\qquad\qquad\qquad\ { {{a} }_{\rm g} } = {\left( \left( { {1 / C} } \right){{I} } + { {{X} }_{\rm g}^{\rm T} }{ {{X} }_{\rm g}}\right)^{ - 1} } {{X} }_{\rm g}^{\rm T} {{y} } \qquad\qquad\qquad\ \ (19)$

　　其中${{ I}}$是$K \times K$單位矩陣，C是給定的正則化參數；

　　(c)通過式(3)生成L個子分類器的輸出函數${F_1}\left( {{ x}} \right),{F_2}\left( {{ x}} \right), $　　 $ ··· ,{F_L}\left( {{ x}} \right)$；

　(3)生成增強驗證數據集；

　對于驗證數據集的每個樣本，計算對應每個輸出函數${F_1}\left( {{ x}} \right)$,　$ {F_2}\left( {{ x}} \right), ··· ,{F_L}\left( {{ x}} \right)$的值并將其作為增強特征，將原始特征和增強　特征合并，從而形成增強驗證數據集${{ D}}_v^{\rm new}{\rm{ = }}\left[ {{{{ X}}_v}\;{{{\bar { X}}}_v}\;{{{ Y}}_v}} \right]$，其中　${{\bar { X}}_v}$表示驗證數據的增強特征集；

　(4)生成數據字典；

　在${ { D} }_v^{\rm new}$上調用IFCM算法后，生成代表性的中心點及其對應的
　標簽，去掉增強特征，即得到數據字典。

　預測過程

　(1)對于任何測試樣本，利用KNN方法在數據字典上找到最近的
　　 k個點，基于投票策略，確定其類標；

　(2)輸出測試樣本的標簽。

下載: 導出CSV

表 3 數據集

數據集	類別數	特征數	樣本數
SATimage(SAT)	6	36	6435
MUShroom(MUS)	2	22	8124
WAVeform3(WAV)	3	21	5000
PENBased(PENB)	10	16	10992
WDBc(WDB)	2	14	569
ADUlt(ADU)	2	14	48841

下載: 導出CSV

表 4 IK-D-TSK參數設置

數據集	分類器	規則數	數據字典
(WDB)	3	2～15	3～4
(WAV)		1.10～120 2.15～140 3.18～160	17～20
(PENB)		1.10～120 2.15～140 3.18～160	10～13
(SAT)	5	1.5～90 2.8～120 3.10～150 4.13～170 5.15～190	10～13
(ADU)			40～45
(MUS)			20～23

下載: 導出CSV

表 5 各分類器運行時間比較結果

數據集	Zero-order-TSK-FC^[1]		First-order-TSK-FC^[14]		IFCM-KNN-C		DBN^[18]		BLS^[19]		IK-D-TSK
	5%噪音	10%噪音	5%噪音	10%噪音	5%噪音	10%噪音	5%噪音	10%噪音	5%噪音	10%噪音	5%噪音	10%噪音
	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間	訓練時間
	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間	測試時間
WDB	0.0216 (0.0039)	0.0224 (0.0057)	0.0237 (0.0034)	0.0243 (0.0023)	0.0162 (0.0019)	0.0141 (0.0018)	4.1844 (0.1861)	4.1555 (0.1592)	0.0122 (0.0013)	0.0122 (0.0011)	0.0209 (0.0032)	0.0205 (0.0023)
WDB	0.0004	0.0005	0.0004	0.0004	0.0016	0.0016	0.0086	0.0079	0.0102	0.0104	0.0021	0.0020
WAV	0.7982 (0.0256)	0.7984 (0.0346)	3.8207 (0.0719)	4.1065 (0.2303)	0.2863 (0.0222)	0.2808 (0.0181)	35.4047 (0.2407)	35.2445 (0.1511)	0.0256 (0.0028)	0.0261 (0.0016)	0.3333 (0.0366)	0.3130 (0.0409)
WAV	0.0050	0.0071	0.0059	0.0112	0.0128	0.0129	0.0430	0.0391	0.0155	0.0170	0.0143	0.0142
PENB	0.9656 (0.0181)	0.9794 (0.0320)	3.7465 (0.1615)	3.9261 (0.1764)	0.5067 (0.0225)	0.4809 (0.0151)	15.1945 (0.1656)	15.2313 (0.1790)	0.0189 (0.0013)	0.0191 (0.0012)	0.6105 (0.0372)	0.5659 (0.0323)
PENB	0.0098	0.0097	0.0196	0.0224	0.0353	0.0311	0.0086	0.0086	0.0124	0.0125	0.0352	0.0340
MUS	0.9496 (0.0230)	0.9965 (0.0377)	7.6208 (0.2844)	8.1693 (0.2367)	0.8053 (0.0629)	0.8124 (0.0223)	47.1515 (0.2267)	47.3102 (0.3248)	0.0323 (0.0038)	0.0321 (0.0032)	0.9432 (0.0415)	0.9513 (0.0323)
MUS	0.0123	0.0125	0.0283	0.0361	0.0253	0.0231	0.0469	0.0602	0.0189	0.0187	0.0241	0.0244
SAT	1.2282 (0.0720)	1.2301 (0.0738)	13.3579 (0.4825)	14.2199 (0.6745)	0.3393 (0.0262)	0.3221 (0.0134)	338.383 (1.2035)	346.9789 (4.4332)	0.1491 (0.0052)	0.1578 (0.0099)	0.4881 (0.0441)	0.4528 (0.0383)
SAT	0.0073	0.0062	0.0167	0.0254	0.0183	0.0184	0.2492	0.2039	0.0644	0.0658	0.0209	0.0209
ADU	5.9016 (0.1901)	6.0366 (0.1239)	15.9947 (0.8757)	17.3695 (0.8218)	3.1255 (0.0415)	3.0311 (0.0215)	56.4922 (0.3625)	64.3266 (0.6555)	0.0337 (0.0028)	0.0389 (0.0051)	5.9502 (0.7296)	5.5299 (0.5056)
ADU	0.0322	0.0370	0.0768	0.1047	0.1126	0.1127	0.0305	0.0656	0.0200	0.0230	0.1549	0.1536

下載: 導出CSV

表 6 WDB數據集在IK-D-TSK上生成的數據字典

${{{ \upsilon }}_{1,1}} = [0.3221,0.6299,0.3633,0.3023,0.5487,0.5950,0.5260,0.3796,0.4162,0.4037,0.5162,0.2613,0.7203,0.4236, - 1]{\rm{ }}$

${{{ \upsilon }}_{1,2}} = [0.3589,0.5702,0.3630,0.2741,0.5715,0.5258,0.5245,0.4388,0.4216,0.3926,0.4954,0.2346,0.5913,0.3333, - 1]{\rm{ }}$

${{{ \upsilon }}_{1,3}} = [0.2962,0.5501,0.4035,0.2355,0.5358,0.5635,0.5233,0.4925,0.3430,0.3778,0.5045,0.4081,0.7043,0.5754, - 1]$

${{{ \upsilon }}_{2,1}}{\rm{ = [}}0.3555,0.5604,0.3788,0.2586,0.5516,0.5644,0.5155,0.4579,0.4592,0.3885,0.5256,0.3284,0.5952,0.1384{\rm{,1]}}$

${{{ \upsilon }}_{2,2}} = [0.3646,0.3985,0.2364,0.2755,0.4574,0.5489,0.4467,0.4598,0.3965,0.4276,0.4772,0.4100,0.4240,0.2729,1]$

${{{ \upsilon }}_{2,3}} = [0.3582,0.6097,0.2785,0.3392,0.3736,0.6051,0.5651,0.4549,0.4203,0.3447,0.4312,0.4583,0.5412,0.1683,1]$

下載: 導出CSV

參考文獻(19)

TEH C Y, KERK Y W, TAY K M, et al. On modeling of data-driven monotone zero-order TSK fuzzy inference systems using a system identification framework[J]. IEEE Transactions on Fuzzy Systems, 2018, 26(6): 3860–3874. doi: 10.1109/TFUZZ.2018.2851258

PEDRYCZ W and GOMIDE F. Fuzzy Systems Engineering: Toward Human-Centric Computing[M]. Hoboken, NJ: Wiley, 2007: 85–101.

TAKAGI T and SUGENO M. Fuzzy identification of systems and its applications to modeling and control[J]. IEEE Transactions on Systems, Man, and Cybernetics, 1985, SMC-15(1): 116–132. doi: 10.1109/TSMC.1985.6313399

TAO Dapeng, CHENG Jun, YU Zhengtao, et al. Domain-weighted majority voting for crowdsourcing[J]. IEEE Transactions on Neural Networks and Learning Systems, 2019, 30(1): 163–174. doi: 10.1109/TNNLS.2018.2836969

HU Mengqiu, YANG Yang, SHEN Fumin, et al. Robust Web image annotation via exploring multi-facet and structural knowledge[J]. IEEE Transactions on Image Processing, 2017, 26(10): 4871–4884. doi: 10.1109/TIP.2017.2717185

ZHANG Yuanpeng, ISHIBUCHI H, and WANG Shitong. Deep Takagi-Sugeno-Kang fuzzy classifier with shared linguistic fuzzy rules[J]. IEEE Transactions on Fuzzy Systems, 2018, 26(3): 1535–1549. doi: 10.1109/TFUZZ.2017.2729507

CORDON O, HERRERA F, and ZWIR I. Linguistic modeling by hierarchical systems of linguistic rules[J]. IEEE Transactions on Fuzzy Systems, 2002, 10(1): 2–20. doi: 10.1109/91.983275

NASCIMENTO D S C, BANDEIRA D R C, CANUTO A M P, et al. Investigating the impact of diversity in ensembles of multi-label classifiers[C]. 2018 International Joint Conference on Neural Networks, Rio de Janeiro, Brazil, 2018: 1–8. doi: 10.1109/IJCNN.2018.8489660.

BISHOP C M. Pattern Recognition and Machine Learning[M]. New York: Springer, 2006: 51–75.

王士同, 鐘富禮. 最小學習機[J]. 江南大學學報: 自然科學版, 2010, 9(5): 505–510. doi: 10.3969/j.issn.1671-7147.2010.05.001

WANG Shitong and CHUNG K F L. On least learning machine[J]. Journal of Jiangnan University:Natural Science Edition, 2010, 9(5): 505–510. doi: 10.3969/j.issn.1671-7147.2010.05.001

TUR G, DENG Li and HAKKANI-TüR D, et al. Towards deeper understanding: Deep convex networks for semantic utterance classification[C]. 2012 IEEE International Conference on Acoustics, Speech and Signal Processing, Kyoto, Japan, 2012: 5045-5048. doi: 10.1109/ICASSP.2012.6289054.

WOLPERT D H. Stacked generalization[J]. Neural Networks, 1992, 5(2): 241–259. doi: 10.1016/s0893-6080(05)80023-1

ZADEH L A. Fuzzy sets[J]. Information and Control, 1965, 8(3): 338–353. doi: 10.1016/S0019-9958(65)90241-X

DENG Zhaohong, JIANG Yizhang, CHUNG F L, et al. Knowledge-leverage-based fuzzy system and its modeling[J]. IEEE Transactions on Fuzzy Systems, 2013, 21(4): 597–609. doi: 10.1109/TFUZZ.2012.2212444

GU Xin, CHUNG F L, ISHIBUCHI H, et al. Multitask coupled logistic regression and its fast implementation for large multitask datasets[J]. IEEE Transactions on Cybernetics, 2015, 45(9): 1953–1966. doi: 10.1109/TCYB.2014.2362771

BACHE K and LICHMAN M. UCI machine learning repository[EB/OL]. http://archive.ics.uci.edu/ml, 2015.

ALCALá-FDEZ J, FERNáNDEZ A, LUENGO J, et al. KEEL data-mining software tool: Data set repository, integration of algorithms and experimental analysis framework[J]. Journal of Multiple-Valued Logic & Soft Computing, 2011, 17(2/3): 255–287.

HINTON G E, OSINDERO S, and TEH Y W. A fast learning algorithm for deep belief nets[J]. Neural Computation, 2006, 18(7): 1527–1554. doi: 10.1162/neco.2006.18.7.1527

CHEN C L P and LIU Zhulin. Broad learning system: An effective and efficient incremental learning system without the need for deep architecture[J]. IEEE Transactions on Neural Networks and Learning Systems, 2018, 29(1): 10–24. doi: 10.1109/TNNLS.2017.2716952
