基于重疊網絡結構的服務功能鏈時空優化編排策略

谷允捷; 胡宇翔; 謝記超

doi:10.11999/JEIT190145

基于重疊網絡結構的服務功能鏈時空優化編排策略

doi: 10.11999/JEIT190145

國家數字交換系統工程技術研究中心鄭州 450002

基金項目: 國家重點研發計劃(2017YFB0803204)，國家自然科學基金(61521003, 61872382)，廣東省重點領域研發計劃(2018B010113001)

詳細信息

作者簡介:
谷允捷：男，1994年生，博士生，研究方向為新型網絡體系結構，網絡功能虛擬化

胡宇翔：男，1982年生，副研究員，研究方向為新型網絡體系結構，軟件定義網絡

謝記超：男，1995年生，碩士生，研究方向為網絡安全、網絡功能虛擬化與云安全

通訊作者:
谷允捷　lizardwhite@163.com

中圖分類號: TP393
計量
- 文章訪問數: 2558
- HTML全文瀏覽量: 1099
- PDF下載量: 63
- 被引次數: 0
出版歷程
- 收稿日期: 2019-03-13
- 修回日期: 2019-06-18
- 網絡出版日期: 2019-06-25
- 刊出日期: 2019-11-01

A Spatial and Temporal Optimal Method of Service Function Chain Orchestration Based on Overlay Network Structure

National Digital Switching System Engineering and Technological R&D Center, Zhengzhou 450002, China

Funds: The National Key Research and Development Project(2017YFB0803204), The National Natural Science Foundation of China (61521003, 61872382), The Research and Development Program in Key Areas of Guangdong Province (2018B010113001)

摘要

摘要: 網絡功能虛擬化(NFV)的引入大幅降低了互聯網業務的運營成本。針對現有的服務功能鏈(SFC)編排方法無法在優化底層資源的同時保證業務時延性能的問題，該文提出一種基于重疊網絡結構的SFC時空優化編排策略。在將計算、網絡資源與細粒度時延約束納入考慮的基礎上，該策略通過建立重疊網絡模型實現了計算與網絡資源的分離，將構建SFC所需的資源開銷與相關時延共同抽象化為重疊網絡鏈路權重,從而使SFC編排問題轉化為易于求解的最短路徑問題。對于需要批量處理的SFC集合設計了基于重疊網絡的模擬退火迭代優化編排算法(ONSA)。通過對比實驗證明了該策略下編排方案的平均端到端時延、鏈路資源占用率與運營開銷相對其他方案分別降低29.5%, 12.4%與15.2%，請求接受率提高22.3%，虛擬網絡功能(VNF)負載均衡性能得到顯著提升。
- 網絡功能虛擬化 /
- 時空優化 /
- 重疊網絡 /
- 迭代優化
Abstract: With the introduction of Network Function Virtualization (NFV), the operating costs of operators can be greatly reduced. However, most existing Service Function Chain (SFC) orchestration researches can not optimize the resources utilization while guaranteeing the performance of service delay. A spatial and temporal optimal method of Service Function Chain (SFC) orchestration based on an overlay network structure is proposed. Based on the consideration of the restrictions such as computing resource, network resource and fine-grained end to end delay, this method separates the computing resource and network resource. The resources cost and related delay of SFC can be abstracted into the links weight of overlay network, which can help to convert the SFC orchestration problem into the shortest path problem that can be easily solved. As for the SFC requests set requiring batch processing, an Overlay Network based Simulated Annealing iterative optimal orchestration algorithm(ONSA) is designed. The simulation results demonstrate that the proposed orchestration scheme can reduce the end-to-end delay, the utilization ratio of link bandwidth resource and the operational expenditure by 29.5%, 12.4% and 15.2%, and the acceptance ratio of requests set can be improved by 22.3%. The performance of Virtual Network Function (VNF) load balancing can be significantly improved.
- Network Function Virtualization (NFV) /
- Spatial and temporal optimization /
- Overlay network /
- Iterative optimization

HTML全文

圖 1 SFC請求及兩種編排方案

下載: 全尺寸圖片幻燈片

圖 2 SFC請求及其對應重疊網絡

下載: 全尺寸圖片幻燈片

圖 3 已部署的VNF在底層網絡分布情況

下載: 全尺寸圖片幻燈片

圖 4 服務請求處理時間

下載: 全尺寸圖片幻燈片

圖 5 請求接受率

下載: 全尺寸圖片幻燈片

圖 6 VNF負載強度分布變化

下載: 全尺寸圖片幻燈片

圖 7 鏈路資源利用率

下載: 全尺寸圖片幻燈片

圖 8 NFV系統運營開銷

下載: 全尺寸圖片幻燈片

圖 9 請求接受率

下載: 全尺寸圖片幻燈片

表 1 基于重疊網絡的模擬退火迭代優化編排策略

輸入：　$G = (V,E)$, $I$，底層網絡狀態
SA參數$\{ {\tau _0},{\tau _{\min }},\rho ,L\} $
輸出：　集合$I$的時空優化編排方案${\rm{O}}{{\rm{S}}_{{\rm{opt}}}}$
(1)　$\forall i \in I$，隨機部署$\beta _i^k$生成${\rm{O}}{{\rm{S}}_{{\rm{init}}}}$
(2)　初始化參數，$\tau \leftarrow {\tau _0},{\rm{Objec}}{{\rm{t}}_{{\rm{now}}}} \leftarrow {\rm{Object}}({\rm{O}}{{\rm{S}}_{{\rm{init}}}})$
(3)　while $\tau > {\tau _{\min }}$ do
(4)　　for $l = 1:L$ do
(5)　　　　if (rand<0.5)
(6)　　　　　計算$\bar C_{{\rm{load}}}^{}$與${p_{{\rm{rem}}}}$并選擇釋放實例$m$
(7)　　　　　將經$m$處理的請求納入${I_{{\rm{re}}}}$并釋放$m$
(8)　　　else
(9)　　　　$\forall i \in I$，將${\delta _i} > \delta _i^{s,o}$的請求納入${I_{{\rm{re}}}}$
(10)　　　end for
(11)　　for $i\;{\rm in}\;{I_{{\rm{re}}}}$ do
(12)　　　　依據$\beta _i^k$與底層網絡狀態構造${G_{{\rm{Overlay}}}}$
(13)　　刪除資源不足的節點與鏈路
(14)　　計算鏈路權重$w_{{\rm{ver}}}^e$，$w_{{\rm{hor}}}^e$
(15)　　${\rm{Path}}_{{\rm{Overlay}}}^i \leftarrow {\rm{Dijkstra}}(v_{{\rm{hor}}}^{1,{s_i}},v_{{\rm{hor}}}^{k + 1,{o_i}})$
(16)　　${\rm{Pat}}{{\rm{h}}_i} \leftarrow {\rm{Path}}_{{\rm{Overlay}}}^i$
(17)　　end for
(18)　　${\rm{Object}}({\rm{O}}{{\rm{S}}_{{\rm{new}}}}) = \sum\nolimits_{i \in I} {[\varepsilon {\varphi _i} + (1 + \varepsilon ){\delta _i}]} $
(19)　　if ${\Delta _{{\rm{Obj}}}} < 0$
(20)　　　　${\rm{O}}{{\rm{S}}_{{\rm{now}}}} \leftarrow {\rm{O}}{{\rm{S}}_{{\rm{new}}}}$
(21)　　else
(22)　　　　${P_{{\rm{acc}}}} = \exp ( - {\Delta _{{\rm{Obj}}}}/T)$
(23)　　$\tau \leftarrow \tau \rho $
(24)　　end while
(25) ${\rm{O}}{{\rm{S}}_{{\rm{opt}}}} \leftarrow {\rm{O}}{{\rm{S}}_{{\rm{now}}}}$

下載: 導出CSV

表 2 VNF參數

VNF	實例化開銷(MIPS)	計算資源(MIPS)	Packet處理時間(μs)
Firewall	5	60	15
Encryption	5	60	15
IDS	8	40	20
NAT	4	60	15

下載: 導出CSV

參考文獻(16)

鄔江興. 新型網絡技術發展思考[J]. 中國科學: 信息科學, 2018, 48(8): 1102–1111. doi: 10.1360/N112018-00062

WU Jiangxing. Thoughts on the development of novel network technology[J]. CIENTIA SINICA Informationis, 2018, 48(8): 1102–1111. doi: 10.1360/N112018-00062

HAN Bo, GOPALAKRISHNAN V, JI Lusheng, et al. Network function virtualization: Challenges and opportunities for innovations[J]. IEEE Communications Magazine, 2015, 53(2): 90–97. doi: 10.1109/mcom.2015.7045396

QUINN E and NADEAU T. Problem statement for service function chaining[R]. IETF RFC-Informational, 2015.

MOENS H and DE TURCK F. VNF-P: A model for efficient placement of virtualized network functions[C]. Proceedings of the 10th International Conference on Network and Service Management and Workshop, Rio de Janeiro, Brazil, 2014: 418–423.

BARI F, CHOWDHURY S R, AHMED R, et al. Orchestrating virtualized network functions[J]. IEEE Transactions on Network and Service Management, 2016, 13(4): 725–739. doi: 10.1109/TNSM.2016.2569020

JANG I, SUH D, PACK S, et al. Joint optimization of service function placement and flow distribution for service function chaining[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(11): 2532–2541. doi: 10.1109/JSAC.2017.2760162

史久根, 張徑, 徐皓, 等. 一種面向運營成本優化的虛擬網絡功能部署和路由分配策略[J]. 電子與信息學報, 2019, 41(4): 973–979. doi: 10.11999/JEIT180522

SHI Jiugen, ZHANG Jing, XU Hao, et al. Joint optimization of virtualized network function placement and routing allocation for operational expenditure[J]. Journal of Electronics &Information Technology, 2019, 41(4): 973–979. doi: 10.11999/JEIT180522

陳卓, 馮鋼, 劉蓓, 等. 運營商網絡中面向資源碎片優化的網絡服務鏈構建策略[J]. 電子與信息學報, 2018, 40(4): 763–769. doi: 10.11999/JEIT170641

CHEN Zhuo, FENG Gang, LIU Bei, et al. Construction policy of network service chain oriented to resource fragmentation optimization in operator network[J]. Journal of Electronics &Information Technology, 2018, 40(4): 763–769. doi: 10.11999/JEIT170641

WEN Tao, YU Hongfang, SUN Gang, et al. Network function consolidation in service function chaining orchestration[C]. Proceedings of 2016 IEEE International Conference on Communications, Kuala Lumpur, Malaysia, 2016: 512–519.

PEI Jianing, HONG Peilin, XUE Kaiping, et al. Efficiently embedding service function chains with dynamic virtual network function placement in geo-distributed cloud system[J]. IEEE Transactions on Parallel and Distributed Systems, 2018, 11(8): 367–379. doi: 10.1109/TPDS.2018.2880992

陳卓, 馮鋼, 劉蓓, 等. 運營商網絡中面向時延優化的服務功能鏈遷移重配置策略[J]. 電子學報, 2018, 46(9): 2229–2237. doi: 10.3969/j.issn.0372-2112.2018.09.026

CHEN Zhuo, FENG Gang, LIU Bei, et al. Delay optimization oriented service function chain migration and re-deployment in operator network[J]. Acta Electronica Sinica, 2018, 46(9): 2229–2237. doi: 10.3969/j.issn.0372-2112.2018.09.026

ARTEAGA C H T, RISSOI F, and RENDON O M C. An adaptive scaling mechanism for managing performance variations in network functions virtualization: A case study in an NFV-based EPC[C]. Proceedings of the 13th International Conference on Network and Service Management, Tokyo, Japan, 2017: 1–7.

LI Tong, BAUMBERGER D, HAHN S, et al. Efficient and scalable multiprocessor fair scheduling using distributed weighted round-robin[C]. Proceedings of the 14th ACM SIGPLAN Symposium on Principles and Practice of Parallel Programming, Raleigh, USA, 2009: 65–74.

AGARWAL S, MALANDRINO F, CHIASSERINI C F, et al. VNF placement and resource allocation for the support of vertical services in 5G networks[J]. IEEE/ACM Transactions on Networking, 2019, 27(1): 433–446. doi: 10.1109/TNET.2018.2890631

LANGE S, GRIGORJEW A, ZINNER T, et al. A multi-objective heuristic for the optimization of virtual network function chain placement[C]. Proceedings of the 29th International Teletraffic Congress, Genoa, Italy, 2017: 152–161.

WANG Xiaoke, WU Chuan, LE F, et al. Online VNF scaling in datacenters[C]. Proceedings of the IEEE 9th International Conference on Cloud Computing, San Francisco, USA, 2016: 140–147.
