FPGA雙端口存儲器映射優化算法

徐宇; 林郁; 楊海鋼

doi:10.11999/JEIT190077

FPGA雙端口存儲器映射優化算法

doi: 10.11999/JEIT190077

徐宇^{1, 2},
林郁³,
楊海鋼^{1, 2, ,}

1.
中國科學院電子學研究所北京 100190
2.
中國科學院大學 北京 100190
3.
賽靈思電子科技北京分公司北京 100101

基金項目: 國家自然科學基金(61474120, 61404140, 61704173)

詳細信息

作者簡介:
徐宇：男，1990年生，博士生，研究方向為FPGA軟件設計自動化

林郁：男，1982年生，高級工程師，研究方向為FPGA軟件設計自動化

楊海鋼：男，1960年生，研究員/教授，博士生導師，研究方向微電子學與集成電路技術

通訊作者:
楊海鋼　yanghg@mail.ie.ac.cn

中圖分類號: TN43
計量
- 文章訪問數: 1949
- HTML全文瀏覽量: 710
- PDF下載量: 115
- 被引次數: 0
出版歷程
- 收稿日期: 2019-01-28
- 修回日期: 2020-01-20
- 網絡出版日期: 2020-07-20
- 刊出日期: 2020-10-13

Optimization Algorithm of Dual-port Memory Mapping on FPGA

Yu XU^{1, 2},
Yu LIN³,
Haigang YANG^{1, 2
, ,}

1.
Institute of Electrics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
Xilinx Incorporated, Beijing 100101, China

Funds: The National Natural Science Foundation of China (61474120, 61404140, 61704173)

摘要

摘要: FPGA存儲器映射算法負責將用戶的邏輯存儲需求映射到芯片中的分布式存儲資源上實現。前人對雙端口存儲器的映射算法研究相對較少，成熟的商業EDA工具的映射結果仍有不少改進空間。該文分別針對面積、延時、功耗這3個常用指標，提出一種雙端口存儲器映射的優化算法，并給出了具體配置方案。實驗表明，在面向簡單存儲需求時，與商用工具Vivado的映射結果一致；在面向復雜存儲需求時，面積優化和功耗優化的映射結果對比商用工具改善了至少50%。
- FPGA /
- 雙端口存儲器映射 /
- 延時優化 /
- 面積優化 /
- 功耗優化
Abstract: FPGA memory mapping algorithm utilizes distributed storage resources on chip and cooperates with some auxiliary circuits to realize the different needs of users in designing logical storage functions. Previous studies on dual-port memory mapping algorithm are relatively few. There is still much space for improvement in the mapping results by mature commercial EDA tools. An optimization algorithm of dual-port memory mapping is proposed for area, delay and power consumption, and a specific configuration scheme is given. Experiments show that when facing simple storage requirements, the mapping results are consistent with those of commercial tools; when facing complex storage requirements, the mapping results of area optimization and power optimization are improved by at least 50% compared with commercial tools Vivado.
- FPGA /
- Dual-port memory mapping /
- Delay optimization /
- Area optimization /
- Power optimization

HTML全文

圖 1 AlgoPower映射算法圖示(視圖${V_k}$)

下載: 全尺寸圖片幻燈片

圖 2 AlgoDelay映射算法圖示(視圖${V_k}$)

下載: 全尺寸圖片幻燈片

圖 3 ${V_{{\rm{maxR}} }}$縱向存儲器塊設計

下載: 全尺寸圖片幻燈片

圖 4 AlgoArea映射策略配置方案

下載: 全尺寸圖片幻燈片

表 1 Virtex-4存儲器塊配置方式

i	索引
i	1	2	3	4	5	6	7
地址深度 d[i]	256	512	1k	2k	4k	8k	16k
地址位寬 b[i]	8	9	10	11	12	13	14
數據位寬 w[i]	72	36	18	9	4	2	1

下載: 導出CSV

表 2 AlgoPower映射策略方案

序號	視圖	配置	地址端口連接	數據端口連接	譯碼/選通
#1	V1	1k×18	a9 a8 ··· a1 a0	d33 d32 ··· d17 d16	–
	V2	1k×18	a10 a9 ··· a2 a1	d25 d24 ··· d9 d8	(a0) = 0
	V3 V4	1k×18	a11 a10 ··· a3 a2	d21 d20 ··· d5 d4	(a1 a0) = 00
#2	V1	1k×18	a9 a8 ··· a1 a0	d51 d50 ··· d35 d34	–
	V2	1k×18	a10 a9 ··· a2 a1	d43 d42 ··· d27 d26	(a0) = 0
	V3 V4	1k×18	a11 a10 ··· a3 a2	d21 d20 ··· d5 d4	(a1 a0) = 01
#3	V1	1k×18	a9 a8 ··· a1 a0	d69 d68 ··· d53 d52	–
	V2	1k×18	a10 a9 ··· a2 a1	d25 d24 ··· d9 d8	(a0) = 1
	V3 V4	1k×18	a11 a10 ··· a3 a2	d21 d20 ··· d5 d4	(a1 a0) = 10
#4	V1	1k×18	a9 a8 ··· a1 a0	d87 d86 ··· d71 d70	–
	V2	1k×18	a10 a9 ··· a2 a1	d43 d42 ··· d27 d26	(a0) = 1
	V3 V4	1k×18	a11 a10 ··· a3 a2	d21 d20 ··· d5 d4	(a1 a0) = 11
#5	V1	1k×18	a9 a8 ··· a1 a0	d15 d14 ··· d1 d0	–
	V2	2k×9	a10 a9 ··· a1 a0	d7 d6 ··· d1 d0	–
	V3 V4	4k×4	a11 a10 ··· a1 a0	d3 d2 d1 d0	–

下載: 導出CSV

表 3 AlgoDelay映射策略方案

序號	視圖	配置	地址端口連接	數據端口連接	譯碼/選通
#1	V1	8k×2	a12 a11 ··· a1 a0	d1 d0	(a′15 a′14) = 00
	V2	4k×4	a11 a10 ··· a1 a0	d3 d2 d1 d0	(a′14 a′13) = 00
	V3 V4	2k×8	a10 a9 ··· a1 a0	d7 d6 d5 d4 d3 d2 d1 d0	(a′13 a′12) = 00
#2	V1	8k×2	a12 a11 ··· a1 a0	d1 d0	(a′15 a′14) = 11
	V2	4k×4	a11 a10 ··· a1 a0	d3 d2 d1 d0	(a′14 a′13) = 11
	V3 V4	2k×8	a10 a9 ··· a1 a0	d7 d6 d5 d4 d3 d2 d1 d0	(a′13 a′12) = 11
#3	V1	16k×1	a12 a11 ··· a1 a0	d1	(a′15 a′14) = 01
	V2	8k×2	a11 a10 ··· a1 a0	d3 d1	(a′14 a′13) = 01
	V3 V4	4k×4	a10 a9 ··· a1 a0	d7 d5 d3 d1	(a′13 a′12) = 01
#4	V1	16k×1	a12 a11 ··· a1 a0	d0	(a′15 a′14) = 01
	V2	8k×2	a11 a10 ··· a1 a0	d2 d0	(a′14 a′13) = 01
	V3 V4	4k×4	a10 a9 ··· a1 a0	d6 d4 d2 d0	(a′13 a′12) = 01
#5	V1	4k×4	a13 a12 ··· a1 a0	d3 d2 d1 d0	(a′15 a′14) = 10
	V2	2k×8	a12 a11 ··· a1 a0	d7 d6 d5 d4 d3 d2 d1 d0	(a′14 a′13) = 10
	V3 V4	1k×16	a11 a10 ··· a1 a0	d15 d14 ··· d1 d0	(a′13 a′12) = 10

下載: 導出CSV

表 4 功耗優化實驗結果

序號	地址1	讀1	寫1	地址2	讀2	寫2	Vivado平均觸發數	AlgoPower平均觸發數	優化比例(%)
1	10	32	32	10	32	32	1	1.00	0
2	10	32	64	10	32	256	8	1.14	85.7
3	11	16	32	10	32	256	8	1.09	86.4
4	11	16	32	10	32	128	4	1.06	73.5
5	11	16	256	10	32	128	8	1.33	83.4
6	11	32	32	10	64	64	2	1.00	50.0
7	11	32	64	10	64	128	4	1.11	72.2
8	11	16	32	11	16	128	4	1.05	73.8

下載: 導出CSV

表 5 延時優化實驗結果

序號	V1(rd)	V2(rd)	V3(wr)	V4(wr)	AlgoDelay選通級數
1	36k×4	72k×2	18k×8	9k×16	V1: 2 V2: 3
2	81k×16	324k×4	162k×8	162k×8	V1: 3 V2: 5
3	18k×4	9k×8	36k×2	18k×4	V1: 2 V2: 1
4	4k×25	2k×50	1k×100	4k×25	V1: 1 V2: 1
5	16k×4	32k×2	8k×8	4k×16	V1: 1 V2: 2

下載: 導出CSV

表 6 面積優化實驗結果

序號	地址1	讀1	寫1	地址2	讀2	寫2	Vivado使用資源	AlgoArea使用資源	優化比例(%)
1	10	32	32	10	32	32	2	2	0
2	10	32	64	10	32	256	8	4	50
3	11	16	32	10	32	256	8	4	50
4	11	16	32	10	32	128	4	2	50
5	11	16	256	10	32	128	4	4	0
6	11	32	32	10	64	64	4	4	0
7	11	32	64	10	64	128	4	4	0
8	11	16	32	11	16	128	4	2	50

下載: 導出CSV

參考文獻(15)

TRIMBERGER S M. Three ages of FPGAs: A retrospective on the first thirty years of FPGA technology[J]. Proceedings of the IEEE, 2015, 103(3): 318–331. doi: 10.1109/JPROC.2015.2392104

KUON I and ROSE J. Measuring the gap between FPGAs and ASICs[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2007, 26(2): 203–215. doi: 10.1109/TCAD.2006.884574

WILTON S J E. Architectures and algorithms for Field-Programmable Gate Arrays with embedded memory[D]. [Ph. D. dissertation], University of Toronto, 1997.

TESSIER R, BETZ V, NETO D, et al. Power-efficient RAM mapping algorithms for FPGA embedded memory blocks[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2007, 26(2): 278–290. doi: 10.1109/TCAD.2006.887924

HSU T Y and WANG Tingchi. A generalized network flow based algorithm for power-aware FPGA memory mapping[C]. The 45th ACM/IEEE Design Automation Conference, Anaheim, USA, 2008: 30–33.

DU Fangqing, LIN C Y, CUI Xiuhai, et al. Timing-constrained minimum area/power FPGA memory mapping[C]. The 23rd International Conference on Field programmable Logic and Applications, Porto, Portugal, 2013: 1–4.

HO W K C and WILTON S J E. Logical-to-physical memory mapping for FPGAs with dual-port embedded arrays[C]. The 9th International Workshop on Field Programmable Logic and Applications, Glasgow, UK, 1999: 111–123.

CONG J and YAN K. Synthesis for FPGAs with embedded memory blocks[C]. 2000 ACM/SIGDA Eighth International Symposium on Field Programmable Gate Arrays, Monterey, USA, 2000: 75–82.

MA Yufei, CAO Yu, VRUDHULA S, et al. An automatic RTL compiler for high-throughput FPGA implementation of diverse deep convolutional neural networks[C]. The 27th International Conference on Field Programmable Logic and Applications (FPL), Ghent, Belgium, 2017: 1–8.

GUAN Yijin, LIANG Hao, XU Ningyi, et al. FP-DNN: An automated framework for mapping deep neural networks onto FPGAs with RTL-HLS hybrid templates[C]. The 25th IEEE Annual International Symposium on Field-Programmable Custom Computing Machines (FCCM), Napa, USA, 2017: 152–159.

LIANG Shuang, YIN Shouyi, LIU Leibo, et al. FP-BNN: Binarized neural network on FPGA[J]. Neurocomputing, 2018, 275: 1072–1086. doi: 10.1016/j.neucom.2017.09.046

GUO Kaiyuan, SUI Lingzhi, QIU Jiantao, et al. Angel-eye: A complete design flow for mapping CNN onto embedded FPGA[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2018, 37(1): 35–47. doi: 10.1109/TCAD.2017.2705069

MA Yufei, SUDA N, CAO Yu, et al. ALAMO: FPGA acceleration of deep learning algorithms with a modularized RTL compiler[J]. Integration, 2018, 62: 14–23. doi: 10.1016/j.vlsi.2017.12.009

Xilinx. Virtex-4 FPGA user guide[EB/OL]. https://china.xilinx.com/support/documentation/user_guides/ug070.pdf, 2008.

Xilinx. LogiCORE IP product guide block memory generator v8.4[EB/OL]. https://china.xilinx.com/support/documentation/ip_documentation/blk_mem_gen/v8_4/pg058-blk-mem-gen.pdf, 2019.
