一種基于多尺度核學習的仿射投影濾波算法

李群生; 趙剡; 寇磊; 王進達

doi:10.11999/JEIT190023

一種基于多尺度核學習的仿射投影濾波算法

doi: 10.11999/JEIT190023

李群生^{1, 2, ,},
趙剡¹,
寇磊³,
王進達²

1.
北京航空航天大學儀器科學與光電工程學院北京 100191
2.
中國空空導彈研究院洛陽 471009
3.
中航工業自控所飛行器控制一體化重點實驗室西安 710065

基金項目: 國家自然科學基金(61233005)，航空基金(20160812004, 20160112002, 2016ZA12002)

詳細信息

作者簡介:
李群生：男，1977年生，博士，研究方向為濾波信號處理，組合導航技術

趙剡：男，1956年生，教授，研究方向為慣性技術，信號處理技術

寇磊：女，1971年生，高級工程師，研究方向為慣性技術

王進達：男，1989年生，博士，研究方向為濾波信號處理，組合導航技術

通訊作者:
李群生　570658391@qq.com

中圖分類號: TN911.7, TP391
計量
- 文章訪問數: 2027
- HTML全文瀏覽量: 964
- PDF下載量: 81
- 被引次數: 0
出版歷程
- 收稿日期: 2019-01-09
- 修回日期: 2019-07-30
- 網絡出版日期: 2020-01-11
- 刊出日期: 2020-06-04

An Affine Projection Algorithm with Multi-scale Kernels Learning

Qunsheng LI^{1, 2
, ,},
Yan ZHAO¹,
Lei KOU³,
Jinda WANG²

1.
School of Instrumentation and Optoelectronic Engineering, Beihang University, Beijing 100191, China
2.
Air-to-Air Missile Research Institute, Luoyang 471009, China
3.
National Key Laboratory on Flight Vehicle Control Integrated Technology, Xi’an 710065, China

Funds: The National Natural Science Foundation of China (61233005), The Aviation Science Fund (20160812004, 20160112002, 2016ZA12002)

摘要

摘要:
為了提高強非線性信號的噪聲消除和信道均衡能力，在核學習自適應濾波方法的基礎上，該文提出一種基于驚奇準則的多尺度核學習仿射投影濾波方法(SC-MKAPA)。在核仿射投影濾波算法的基礎上，對核組合函數結構進行改進，將多個不同高斯核帶寬作為可變參數，與加權系數共同參與濾波器的更新；利用驚奇準則將計算結果稀疏化，根據仿射投影算法的約束條件對驚奇測度進行改進，簡化其方差項，降低了計算的復雜度。將該算法應用于噪聲消除、信道均衡以及MG時間序列預測中，與多種自適應濾波算法及核學習自適應濾波算法進行仿真結果的對比分析，驗證了該算法的優越性。
- 自適應濾波 /
- 核學習 /
- 可變核帶寬 /
- 多核仿射投影 /
- 驚奇準則
Abstract:
In order to improve the ability of noise elimination and channel equalization of strong non-linear signals, a Multi-scale Kernels learning Affine Projection filtering Algorithm based on Surprise Criterion (SC-MKAPA) is proposed on the basis of kernel learning adaptive filtering method. Based on the kernel affine projection filtering algorithm, the structure of the kernel combination function is improved, and the bandwidths of several different Gaussian kernels are taken as variable parameters to participate in the update of the filter together with the weighted coefficients.The calculation results are sparsed by using the surprise criterion, and the surprise measure is improved according to the constraints of the affine projection algorithm, which simplifies the variance term and reduces the calculation complexity. The algorithm is applied to noise cancellation, channel equalization, and Mackey Glass (MG) time series prediction. The simulation results are compared with the traditional adaptive filtering algorithm and the kernel learning adaptive filtering algorithm, it proves the superiority of the proposed algorithm.
- Adaptive filters /
- Kernel learning /
- Variable kernel bandwidth /
- Affine projection with multi-kernels /
- Surprise criterion

HTML全文

圖 1 濾波器除噪原理

下載: 全尺寸圖片幻燈片

圖 2 噪聲分布

下載: 全尺寸圖片幻燈片

圖 3 對數條件下MSE的學習曲線

下載: 全尺寸圖片幻燈片

圖 4 對數條件下MSE的學習曲線

下載: 全尺寸圖片幻燈片

圖 5 MG時間序列的預測學習曲線

下載: 全尺寸圖片幻燈片

表 1 算法參數

算法	核帶寬	收斂因子	正則化參數$\delta $
SC-MKAPA	${\eta _1} = 1.0$, ${\eta _{\rm{2}}} = {\rm{0}}{\rm{.5}}$, ${\eta _{\rm{3}}} = 1{\rm{0}}$	$\mu = 0.2$, $\Delta t = 0.01$	5.0×10^–3
NC-MKAPA	${\eta _1} = 1.0$, ${\eta _{\rm{2}}} = {\rm{0}}{\rm{.5}}$, ${\eta _{\rm{3}}} = 1{\rm{0}}$	$\mu = 0.2$	5.0×10^–3
NC-KAPA	${\eta _1} = 1.0$	$\mu = 0.2$	5.0×10^–3
KLMS	${\eta _1} = 1.0$	$\mu = 0.2$	5.0×10^–3
LMS	${\eta _1} = 1.0$	$\mu = 0.2$	5.0×10^–3

下載: 導出CSV

表 2 不同高次項下5種方法MMSE(dB)

高次項$N$	SC-MKAPA	NC-MKAPA	NC-KAPA	KLMS	LMS
2	–71.2	–62.8	–67.2	–32.7	–25.6
3	–62.1	–56.9	–60.6	–24.4	–19.3
6	–33.9	–29.3	–30.2	–21.5	–17.8
7	–18.3	–16.3	–15.2	–13.3	–12.9

下載: 導出CSV

參考文獻(22)

AIZERMAN A, BRAVERMAN E M, and ROZONER L I. Theoretical foundations of the potential function method in pattern recognition learning[J]. Automation and Remote Control, 1964, 25(5): 821–837.

FRIE? T and HARRISON R F. A kernel-based adaline for function approximation[J]. Intelligent Data Analysis, 1999, 3(4): 307–313. doi: 10.3233/IDA-1999-3405

龐業勇, 王少軍, 彭宇, 等. 一種在線時間序列預測的核自適應濾波器向量處理器[J]. 電子與信息學報, 2016, 38(1): 53–62. doi: 10.11999/JEIT150157

PANG Yeyong, WANG Shaojun, PENG Yu, et al. A kernel adaptive filter vector processor for online time series prediction[J]. Journal of Electronics &Information Technology, 2016, 38(1): 53–62. doi: 10.11999/JEIT150157

BLANDON J S, VALENCIA C K, ALVAREZ A, et al. Shape classification using Hilbert space embeddings and kernel adaptive filtering[C]. The 15th International Conference Image Analysis and Recognition, Portugal, 2018: 245–251. doi: 10.1007/978-3-319-93000-8_28.

GAO Wei, YAN Yi, ZHANG Lingling, et al. Convex combinations of multiple kernel adaptive filters[C]. 2017 IEEE International conference on Signal Processing, Communications and Computing, Xiamen, China, 2017: 1–5. doi: 10.1109/ICSPCC.2017.8242551.

孫丹華, 孫亮, 王彬, 等. α穩定分布噪聲下基于核方法的非線性信道均衡算法[J]. 信號處理, 2017, 33(3): 223–228. doi: 10.16798/j.issn.1003-0530.2017.02.013

SUN Danhua, SUN Liang, WANG Bin, et al. Nonlinear channel equalization algorithm based on kernel method for α-stable noise[J]. Journal of Signal Processing, 2017, 33(3): 223–228. doi: 10.16798/j.issn.1003-0530.2017.02.013

SHIN B S, YUKAWA M, CAVALCANTE R L G, et al. Distributed adaptive learning with multiple kernels in diffusion networks[J]. IEEE Transactions on Signal Processing, 2018, 66(21): 5505–5519. doi: 10.1109/TSP.2018.2868040

HAN Yina, YANG Yixin, LI Xuelong, et al. Matrix-regularized multiple kernel learning via (r, p) Norms[J]. IEEE Transactions on Neural Networks and Learning Systems, 2018, 29(10): 4997–5007. doi: 10.1109/TNNLS.2017.2785329

LIU Yuqi, SUN Chao, and JIANG Shouda. A reduced gaussian kernel least-mean-square algorithm for nonlinear adaptive signal processing[J]. Circuits, Systems, and Signal Processing, 2019, 38(1): 371–394. doi: 10.1007/s00034-018-0862-0

SHOAIB B, QURESHI I M, BUTT S A, et al. Adaptive step size kernel least mean square algorithm for Lorenz time series prediction[C]. The 12th International Bhurban Conference on Applied Sciences and Technology, Islamabad, Pakistan, 2015: 218–221. doi: 10.1109/IBCAST.2015.7058507.

胡站偉, 焦立國, 徐勝金, 等. 基于多尺度重采樣思想的類指數核函數構造[J]. 電子與信息學報, 2016, 38(7): 1689–1695. doi: 10.11999/JEIT151101

HU Zhanwei, JIAO Liguo, XU Shengjin, et al. Design of an exponential-like kernel function based on multi-scale resampling[J]. Journal of Electronics &Information Technology, 2016, 38(7): 1689–1695. doi: 10.11999/JEIT151101

PUAL T K and OGUNFUNMI T. A kernel adaptive algorithm for quaternion-valued inputs[J]. IEEE Transactions on Neural Networks and Learning Systems, 2015, 26(10): 2422–2439. doi: 10.1109/TNNLS.2014.2383912

NISHIKAWA K and NAKAZATO H. Mixture structure of kernel adaptive filters for improving the convergence characteristics[C]. 2012 Asia Pacific Signal and Information Processing Association Annual Summit and Conference, Hollywood, USA, 2012: 1–6.

POKHAREL R, SETH S, and PRINCIPE J C. Mixture kernel least mean square[C]. 2013 International Joint Conference on Neural Networks, Dallas, USA, 2013: 1–7. doi: 10.1109/IJCNN.2013.6706867.

VAN VAERENBERGH S, SCARDAPANE S, and SANTAMARIA I. Recursive multikernel filters exploiting nonlinear temporal structure[C]. The 25th European Signal Processing Conference, Kos, Greece, 2017: 2674–2678. doi: 10.23919/EUSIPCO.2017.8081696.

SILVA M T M, CANDIDO R, ARENAS-GARCIA J, et al. Improving multikernel adaptive filtering with selective bias[C]. 2018 IEEE International Conference on Acoustics, Speech and Signal Processing, Calgary, Canada, 2018: 4529–4533. doi: 10.1109/ICASSP.2018.8461290.

ISHIDA T and TANAKA T. Multikernel adaptive filters with multiple dictionaries and regularization[C]. 2013 Asia-Pacific Signal and Information Processing Association Annual Summit and Conference, Kaohsiung, China, 2013: 1–6. doi: 10.1109/APSIPA.2013.6694279.

TODA O and YUKAWA M. On kernel design for online model selection by Gaussian multikernel adaptive filtering[C]. Asia-Pacific Signal and Information Processing Association Annual Summit and Conference, Siem Reap, Camboya, 2014: 1–5. doi: 10.1109/APSIPA.2014.7041802.

LIU Weifeng and PRíNCIPE J. Kernel affine projection algorithms[J]. EURASIP Journal on Advances in Signal Processing, 2008, 2008: 784292. doi: 10.1155/2008/784292

RICHARD C, BERMUDEZ J C M, and HONEINE P. Online prediction of time series data with kernels[J]. IEEE Transactions on Signal Processing, 2009, 57(3): 1058–1066. doi: 10.1109/TSP.2008.2009895

GAO Wei, CHEN Jie, RICHARD C, et al. Kernel LMS algorithm with forward-backward splitting for dictionary learning[C]. 2013 IEEE International Conference on Acoustics, Speech and Signal Processing, Vancouver, Canada, 2013: 5735–5739. doi: 10.1109/ICASSP.2013.6638763.

TAKIZAWA M A and YUKAWA M. An efficient sparse kernel adaptive filtering algorithm based on isomorphism between functional subspace and Euclidean space[C]. 2014 IEEE International Conference on Acoustics, Speech and Signal Processing, Florence, Italy, 2014: 4508–4512. doi: 10.1109/ICASSP.2014.6854455.
