基于能效的NOMA蜂窩車聯網動態資源分配算法
doi: 10.11999/JEIT190006
-
1.
重慶郵電大學通信與信息工程學院 重慶 400065
-
2.
重慶郵電大學移動通信技術重點實驗室 重慶 400065
Energy Efficiency Based Dynamic Resource Allocation Algorithm for Cellular Vehicular Based on Non-Orthogonal Multiple Access
-
1.
School of Communication and Information Engineering, Chongqing University of Post and Telecommunications, Chongqing 400065, China
-
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Post and Telecommunications, Chongqing 400065, China
-
摘要:
在支持車與車直接通信(V2V)的非正交多址接入(NOMA)蜂窩網絡場景下，針對V2V用戶與蜂窩用戶的干擾以及NOMA準則下的功率分配問題，該文提出一種基于能效的動態資源分配算法。該算法首先為了保證V2V用戶的時延及可靠性同時滿足蜂窩用戶的速率需求，聯合考慮子信道調度、功率分配和擁塞控制，建立了最大化系統能效的隨機優化模型。其次，利用李雅普諾夫隨機優化方法，通過控制可接入數據量保證隊列穩定性以避免網絡擁塞，并根據實時網絡負載狀態動態地進行資源調度，設計一種次優化子信道匹配算法獲得用戶調度方案，進一步，利用凸優化理論和拉格朗日對偶分解方法得到功率分配策略。最后，仿真結果表明，該文算法可以滿足不同用戶的服務質量(QoS)需求，并在保證網絡穩定性前提下提高系統能效。
-
關鍵詞:
- 非正交多址接入 /
- 蜂窩車聯網 /
- 資源分配 /
- 李雅普諾夫優化
Abstract:In the Non-Orthogonal Multiple Access (NOMA) based cellular network with Vehicle-to-Vehicle (V2V) communication, to mitigate the co-channel interference between V2V users and cellular users as well as the power allocation problem based on the NOMA principle, an energy efficiency dynamic resource allocation algorithm is proposed. Firstly, a stochastic optimization model is established to maximize the energy efficiency by considering subchannel scheduling, power allocation and congestion control, in order to guarantee the delay and reliability of V2V users while satisfying the rate of cellular users. Then, leveraging on the Lyapunov stochastic optimization method, the traffic queues can be stabilized by admitting as much traffic data as possible to avoid network congestion, and the radio resource can be allocated dynamically according to the real-time network traffic and thus a suboptimal subchannel matching algorithm is designed to obtain the user scheduling scheme. Furthermore, the power allocation policy is obtained by utilizing successive convex optimization theory and Lagrange dual decomposition method. Finally, the simulation results show that the proposed algorithm can improve the system energy efficiency and ensure the Quality of Service (QoS) requirements of different users and network stability.
-
表 1 基于能效的動態資源分配算法
(1) 初始化控制參數$V$, NOMA用戶隊列${Q_i}(0) = 0$、虛擬隊列${Q_k}(0) = 0$、${H_i}(0) = 0$, ${\varGamma _i}(t)$, $R_k^{\min }$, $\forall k \in K,i \in I$； (2) 設置時隙長度${T_{\max }}$； (3) For $t = 0,1, ··· ,{T_{\max }} - 1,$ do； (4) 觀察該時隙每個NOMA用戶的隊列狀態${Q_i}(t)$以及虛擬隊列${Q_k}(t)$和${H_i}(t)$； (5) 計算輔助變量${\gamma _i}(t)$，然后根據式(18)和式(19)得到擁塞控制優化解$\varGamma _i^*$； (6) 執行表2求解優化問題式(16)得到子信道調度策略$x_i^*,\alpha _k^*$； (7) 執行表3求解問題式(21)得到優化的功率分配方案$\{ p_1^{\rm{*}},p_2^{\rm{*}},···,p_{M{\rm{ - }}1}^{\rm{*}}\} $； (8) 根據下面公式分別更新下一時隙NOMA用戶的隊列狀態${Q_i}(t + 1)$，虛擬隊列狀態${Q_k}(t + 1)$和${H_i}(t + 1)$;
${Q_i}(t + 1) = \max \{ {Q_i}(t) + {\varGamma _i}(t) - {r_i}(t),0\} ,\;\;\forall i$, ${Q_k}(t + 1) = \max \{ {Q_k}(t) + R_k^{\min } - {r_k}(t),0\} ,\forall k$;
${H_i}(t + 1) = \max \{ {H_i}(t) - {\varGamma _i}(t) + {\gamma _i}(t),0\} ,\forall i$；(9) $t = t + 1$； (10) End； (11) 輸出優化擁塞控制策略、頻譜和功率分配方案$\varGamma _i^*$, $x_i^*,\alpha _k^*$, $p_i^*,p_k^*$。
下載: 導出CSV
表 2 聯合次優化子信道匹配算法
(1) 初始化${p_i},{p_k}$, ${Q_i}(0) = 0$, ${Q_k}(0) = 0$, ${H_i}(0) = 0$，初始化未分配子信道的NOMA和V2V用戶集$S_{{\rm{un}}}^C$, $S_{{\rm{un}}}^V$，復用同一信道的用戶集
${{U}} = \{ U_1,U_2,···,U_N\} $, ${\psi _n} = \varnothing $，用戶調度策略${{x}} = \varnothing ,{{\alpha}} = \varnothing $，分別構造NOMA用戶和V2V用戶的信道增益矩陣，${{ H}_i} \triangleq {[|{h_{i,n}}|]_{I \times N}}$,
${{ H}_k} \triangleq {[|{h_{k,n}}|]_{K \times N}}$；(2) while ${S_{{\rm{un}}}}^C \ne \varnothing $&${S_{\rm{un}}}^V \ne \varnothing$ do； (3) for $n = 1:N$； (4) 從${{ H}_i}$中找到最大信道增益，將子信道$n$調度給用戶$i$，更新${{x}}$，并將矩陣中的第$i$行元素置0； (5) 更新${U_n} = {U_n} \cup u_n^i$ & $S_{{\rm{un}}}^C = S_{{\rm{un}}}^C\backslash u_n^i$； (6) end for； (7) for $n = 1:N$； (8) while ${N_{{U_n}}} < M$ do； (9) 分別從信道矩陣${{ H}_i}$和${{ H}_k}$ 中找到最大信道增益$|{h_{i,n}}|$和$|{h_{k,n}}|$； (10) if ${\rm{|}}{h_{i,n}}| > {h_{k,n}}|$； (11) 將子信道$n$分配給用戶$i$，更新${U_n} = {U_n} \cup u_i^n$； (12) else； (13) 將子信道$n$分配給用戶$k$，更新${U_n} = {U_n} \cup u_k^n$； (14) end if； (15) end while； (16) if ${N_{{U_n}}} = M$； (17) 計算用戶集${U_n}$復用在子信道$n$上的$\varphi (t)$，并將結果保存于${\psi _n}$ (18) 求解式(16)得到用戶調度的解$x_i^n,\alpha _k^n$以及被調度用戶集$u_n^C,u_n^V$，更新未調度用戶集$S_{un}^C = S_{un}^C\backslash u_n^C$ & $S_{un}^V = S_{un}^V\backslash u_n^V$，并將
信道矩陣${{ H}_i}$中的第$i$行置0，或?qū)?{{ H}_k}$中的第$k$行元素及第$n$列元素置0；(19) end if； (20) end for； (21) end while； (22) 輸出用戶調度策略${{x}},{{\alpha}} $。
下載: 導出CSV
表 3 基于連續凸逼近和拉格朗日對偶的迭代功率優化算法
(1) 初始化最大迭代次數${T_1}$及最大允許誤差${\xi _1}$，初始化${[{\tilde p_i}(t),{\tilde p_k}(t)]^0}$，迭代次數索引$t$； (2) while $g \le {T_1}$ or ${\rm{||}}\tilde \varphi ({[{\tilde p_i}(t),{\tilde p_k}(t)]^g}) - \tilde \varphi ({[{\tilde p_i}(t),{\tilde p_k}(t)]^{g - 1}})|| \le {\xi _1}$ do； (3) 根據迭代得到的${[{\tilde p_i}(t),{\tilde p_k}(t)]^g}$和$\tilde r_k^n$, $\tilde r_i^n$計算$c_k^n$ $d_k^n$ $c_i^n$ $d_i^n$，得到更新后的${{{c}}^g},{{q7j3ldu95}^g}$； (4) 求解優化問題式(20)，更新當前最優解${[{\tilde p_i}(t),{\tilde p_k}(t)]^{{\rm{g + 1}}}}$并令$g = g + 1$； (5) end while； (6) 輸出連續凸逼近迭代后的優化解$\tilde P(t) = {\left[ {{{\tilde p}_i}(t),\tilde p{}_k(t)} \right]^g}$； (7) 初始化最大迭代次數${N_1}$和${N_2}$及收斂條件${\varDelta _1}$和${\varDelta _2}$，初始化迭代索引$m = 0,n = 0$，初始化拉格朗日乘子${\nu ^0},{\lambda ^0},{\mu ^0},{\eta ^0}$,
${[{\tilde p_i}{(t)_m},\tilde p{}_k{(t)_m}]^0} = {[{\tilde p_i}{(t)_n},{\tilde p_k}{(t)_n}]^0} = {[{\tilde p_i}(t),{\tilde p_k}(t)]^g}$；(8) 觀察時隙$t$每個NOMA用戶的隊列狀態${Q_i}(t)$和虛擬隊列狀態${Q_k}(t)$, ${H_i}(t)$； (9) while $m < {N_1}$ or ${\rm{||} }\tilde \varphi ({[{\tilde p_i}{(t)_m},{\tilde p_k}{(t)_m}]^{m + 1} }) - \tilde \varphi ({[{\tilde p_i}{(t)_m},{\tilde p_k}{(t)_m}]^m})|| \ge {\varDelta _1}$ do； (10) while $n < {N_2}$ or $||{J^{n + 1} }(t) - {J^n}(t)|| \ge {\varDelta _2}$ do； (11) 將${\nu ^m},{\lambda ^m},{\mu ^m},{\eta ^m}$和${[{\tilde p_i}{(t)_n},{\tilde p_k}{(t)_n}]^n}$分別代入表達式(21)求導； (12) 通過KKT條件和二分搜索法求得功率分配${[{\tilde p_i}{(t)_n},{\tilde p_k}{(t)_n}]^{n + 1}}$，更新拉格朗日乘子； (13) $n = n + 1$； (14) end while； (15) $m = m + 1$； (16) end while；
下載: 導出CSV
-
3GPP. Study on LTE-based V2X services 14.0.0[R]. 3GPP TR 36.885, 2016. 3GPP. Study on enhancement of 3GPP support for 5G V2X services 16.2.0[R]. 3GPP TR 22.886, 2017. SAHIN T, KLUGEL M, ZHOU Chan, et al. Virtual cells for 5G V2X communications[J]. IEEE Communications Standards Magazine, 2018, 2(1): 22–28. doi: 10.1109/MCOMSTD.2018.1700060 YANG Zhaohui, XU Wei, PAN Cunhua, et al. On the optimality of power allocation for NOMA downlinks with individual QoS constraints[J]. IEEE Communications Letters, 2017, 21(7): 1649–1652. doi: 10.1109/LCOMM.2017.2689763 PAN Yijin, PAN Cunhua, YANG Zhaohui, et al. Resource allocation for D2D communications underlaying a NOMA-based cellular network[J]. IEEE Wireless Communications Letters, 2018, 7(1): 130–133. doi: 10.1109/LWC.2017.2759114 LIANG Le, LI G Y, and XU Wei. Resource allocation for D2D-enabled vehicular communications[J]. IEEE Transactions on Communications, 2017, 65(7): 3186–3197. doi: 10.1109/TCOMM.2017.2699194 LIU Chenfeng and BENNIS M. Ultra-reliable and low-latency vehicular transmission: An extreme value theory approach[J]. IEEE Communications Letters, 2018, 22(6): 1292–1295. doi: 10.1109/LCOMM.2018.2828407 SUN Wanlu, STR?M E, BR?NNSTR?M F, et al. Radio resource management for D2D-based V2V communication[J]. IEEE Transactions on Vehicular Technology, 2016, 65(8): 6636–6650. doi: 10.1109/TVT.2015.2479248 SUN Wanlu, STR?M E, BR?NNSTR?M F, et al. D2D-based V2V communications with latency and reliability constraints[C]. 2014 IEEE Globecom Workshops, Austin, USA, 2014: 1414–1419. doi: 10.1109/GLOCOMW.2014.7063632. PENG Mugen, YU Yuling, XIANG Hongyu, et al. Energy-efficient resource allocation optimization for multimedia heterogeneous cloud radio access networks[J]. IEEE Transactions on Multimedia, 2016, 18(5): 879–892. doi: 10.1109/TMM.2016.2535722 LAU V K N, ZHANG Fan, and CUI Ying. Low complexity delay-constrained beamforming for multi-user MIMO systems with imperfect CSIT[J]. IEEE Transactions on Signal Processing, 2013, 61(16): 4090–4099. doi: 10.1109/TSP.2013.2264058 CHUNG S T and GOLDSMITH A J. Degrees of freedom in adaptive modulation: A unified view[J]. IEEE Transactions on Communications, 2001, 49(9): 1561–1571. doi: 10.1109/26.950343 LI Jian, PENG Mugen, YU Yuling, et al. Energy-efficient joint congestion control and resource optimization in heterogeneous cloud radio access networks[J]. IEEE Transactions on Vehicular Technology, 2016, 65(12): 9873–9887. doi: 10.1109/TVT.2016.2531184 ZHAO Long and WANG Xiaodong. Round-trip energy efficiency of wireless energy powered massive MIMO system with latency constraint[J]. IEEE Communications Letters, 2017, 21(1): 12–15. doi: 10.1109/LCOMM.2016.2616858 KHAN Z, FAN Pingzhi, ABBAS F, et al. Two-level cluster based routing scheme for 5G V2X communication[J]. IEEE Access, 2019, 7: 16194–16205. doi: 10.1109/ACCESS.2019.2892180 ZHANG Yi, WANG Huiming, ZHENG Tongxing, et al. Energy-efficient transmission design in non-orthogonal multiple access[J]. IEEE Transactions on Vehicular Technology, 2017, 66(3): 2852–2857. doi: 10.1109/TVT.2016.2578949 -
