基于圖像協方差無關的增量特征提取方法研究
doi: 10.11999/JEIT181138
-
1.
天津理工大學天津市先進機電系統設計與智能控制重點實驗室 ??天津 ??300384
-
2.
天津理工大學機電工程國家級實驗教學示范中心 ??天津 ??300384
基金項目: 國家重點研發計劃(2017YFB1303304)，天津市科技計劃重大專項(17ZXZNGX00110)，天津市自然科學重點基金(16JCZDJC30400)
An Incremental Feature Extraction Method without Estimating Image Covariance Matrix
-
1.
Tianjin Key Laboratory for Advanced Mechatronical System Design and Intelligent Control, Tianjin University of Technology, Tianjin 300384, China
-
2.
National Experimental Teaching Demonstration Center of Electromechanical Engineering, Tianjin University of Technology, Tianjin 300384, China
Funds: The National Key R & D Plan of China (2017YFB1303304), The Tianjin Science and Technology Planed Key Project (17ZXZNGX00110), The Tianjin Natural Science Key Foundation (16JCZDJC30400)
-
摘要: 針對2維主成分分析(2DPCA)算法無法實現在線特征提取及無法體現完整數據結構信息等問題，該文提出一種基于圖像協方差無關的增量式2DPCA(I2DPCA)算法。該算法無需對圖像協方差矩陣進行特征值分解奇異值分解，復雜度將大為降低，提高了特征提取速度。針對I2DPCA僅提取了橫向特征的問題，又提出一種增量式行列順序2DPCA(IRC2DPCA)算法，該算法對I2DPCA的特征矩陣再次進行縱向特征提取，保留了圖像的橫向與縱向結構信息，實現了行列兩個方向上的特征提取與數據降維。最后，以自建的物塊數據集、通用的ORL和Yale人臉數據集分別進行對比實驗，結果表明，該文算法在收斂率、分類率及復雜度等性能方面均得到了顯著提高，其收斂率達到99%以上，分類率可達97.6%，平均處理速度為29 幀/s，能夠滿足增量特征提取的實時處理需求。
-
關鍵詞:
- 模式識別 /
- 協方差無關 /
- 特征提取 /
- 增量學習 /
- 2維主成分分析
Abstract: To solve the problems that Two-Dimensional Principal Component Analysis (2DPCA) can not implement the on-line feature extraction and can not represent the complete structure information, an Incremental 2DPCA (I2DPCA) without estimating covariance matrices is presented by an iterative estimation method, not to deal with the image covariance matrices by the eigenvalue decomposition or the singular value decomposition. The complexity will be greatly reduced and the on-line feature extraction speed can be improved. The proposed I2DPCA can only extract the horizontal features, and thus another Incremental Row-Column 2DPCA (IRC2DPCA) is proposed to incrementally extract the longitudinal ones from the feature matrices of the I2DPCA. The IRC2DPCA can preserve the horizontal and longitudinal features and implement the dimensionality reduction in both row and column directions. Finally, a series of experiments are carried out with the self-built block dataset, ORL and Yale face datasets, respectively. The results show that the proposed algorithms have significantly improved the performances of the convergence rate, the classification rate and the complexity. The convergence rate is over 99%, the classification rate can reach 97.6% and the average processing speed is about 29 frames per second, and it can meet the on-line feature extraction requirements for incremental learning. -
表 1 不同數據集下特征向量收斂率的均值及標準差
數據集 輸入次數 I2DPCA(均值/標準差) IRC2DPCA(均值/標準差) 前4個特征向量 后4個特征向量 前4個特征向量 后4個特征向量 物塊 $m = 2$ 0.99442/0.00361 0.86836/0.17826 0.98964/0.00573 0.96564/0.01135 $m = 5$ 0.99924/0.00041 0.95478/0.15818 0.99824/0.00101 0.97302/0.01020 $m = 10$ 0.99981/0.00010 0.98453/0.02225 0.99950/0.00030 0.99495/0.00322 ORL $m = 2$ 0.99991/0.00004 0.89400/0.06763 0.99753/0.00203 0.98175/0.01027 $m = 5$ 0.99997/0.00002 0.91620/0.05154 0.99951/0.00037 0.99441/0.00231 $m = 10$ 0.99998/0.00001 0.92833/0.05163 0.99986/0.00010 0.99755/0.00074 Yale $m = 2$ 0.93732/0.07244 0.96069/0.03026 0.99602/0.00441 0.98308/0.00659 $m = 5$ 0.96001/0.04678 0.98261/0.01609 0.99924/0.00074 0.99528/0.00140 $m = 10$ 0.97283/0.03180 0.99041/0.00970 0.99975/0.00024 0.99793/0.00088
下載: 導出CSV
表 2 物塊數據集的最佳分類率
每類訓練
樣本數2DPCA
(120×4)[8]RC2DPCA
(8×8)[11]Angle-2DPCA
(120×4)[12]BA2DPCA
(8×8)[13]BDPCA
(8×8)[10]IBDPCA
(8×8)[17]I2DPCA
(120×4)IRC2DPCA
(8×8)L=10 0.933 0.927 0.922 0.931 0.930 0.930 0.926 0.922 L=25 0.957 0.960 0.958 0.961 0.959 0.959 0.962 0.968 L=50 0.959 0.961 0.961 0.961 0.961 0.967 0.962 0.972 L=75 0.954 0.957 0.954 0.957 0.958 0.956 0.955 0.958 L=100 0.966 0.963 0.966 0.964 0.963 0.973 0.971 0.976
下載: 導出CSV
表 3 ORL數據集的最佳分類率
每類訓練
樣本數2DPCA
(112×4)[8]RC2DPCA
(8×8)[11]Angle-2DPCA
(112×4)[12]BA2DPCA
(8×8)[13]BDPCA
(8×8)[10]IBDPCA
(8×8)[17]I2DPCA
(112×4)IRC2DPCA
(8×8)L=1 0.744 0.728 0.742 0.725 0.728 0.708 0.736 0.717 L=2 0.850 0.844 0.850 0.847 0.847 0.844 0.847 0.841 L=3 0.868 0.857 0.868 0.861 0.861 0.846 0.864 0.857 L=4 0.888 0.896 0.888 0.892 0.904 0.904 0.883 0.900 L=5 0.905 0.905 0.905 0.905 0.915 0.915 0.905 0.925
下載: 導出CSV
表 4 Yale數據集的最佳分類率
每類訓練
樣本數2DPCA
(100×4)[8]RC2DPCA
(8×8)[11]Angle-2DPCA
(100×4)[12]BA2DPCA
(8×8)[13]BDPCA
(8×8)[10]IBDPCA
(8×8)[17]I2DPCA
(100×4)IRC2DPCA
(8×8)L=1 0.560 0.560 0.560 0.560 0.560 0.553 0.573 0.560 L=2 0.719 0.733 0.719 0.733 0.741 0.741 0.726 0.726 L=3 0.800 0.808 0.792 0.800 0.817 0.825 0.792 0.825 L=4 0.857 0.876 0.857 0.876 0.876 0.876 0.857 0.867 L=5 0.856 0.889 0.856 0.889 0.889 0.889 0.856 0.889
下載: 導出CSV
表 5 物塊數據集處理的所需時間對比
算法 L=10 L=25 L=50 L=75 L=100 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 2DPCA(120×4)[8] 2.152 5.279 9.568 6.561 32.745 7.990 69.065 9.015 123.779 10.319 RC2DPCA(8×8)[11] 2.029 0.941 9.208 1.140 32.630 1.362 66.446 1.335 115.344 1.554 Angle-2DPCA(120×4)[12] 4.991 1.097 15.604 1.174 93.28 1.296 67.788 1.471 57.624 1.545 BA2DPCA(8×8)[13] 13.117 1.179 14.261 1.190 46.107 1.203 65.105 1.250 48.089 1.233 BDPCA(8×8)[10] 2.356 0.933 9.456 0.966 32.988 1.248 67.501 1.414 127.39 1.556 IBDPCA(8×8)[17] 11.826 0.868 29.074 1.055 56.778 1.221 86.120 1.408 114.845 1.604 I2DPCA(120×4) 3.103 5.361 7.381 6.225 14.693 7.778 21.938 8.963 29.039 11.181 IRC2DPCA(8×8) 7.159 0.846 17.047 1.043 34.413 1.266 51.577 1.443 65.510 1.669
下載: 導出CSV
表 6 物塊數據集處理的所需內存對比(kB)
算法 L=10 L=25 L=50 L=75 L=100 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 特征提取 分類識別 2DPCA(120×4)[8] 16.658 70.889 37.588 69.935 72.753 68.149 107.941 66.383 143.179 64.622 RC2DPCA(8×8)[11] 16.736 11.354 38.199 11.423 73.977 11.227 109.867 10.805 145.764 10.612 Angle-2DPCA(120×4)[12] 16.096 48.774 16.096 48.118 16.080 46.768 16.080 45.596 16.080 44.440 BA2DPCA(8×8)[13] 16.080 21.642 16.088 21.142 16.104 20.57 16.12 20.504 16.096 20.036 BDPCA(8×8)[10] 16.379 11.345 37.040 11.427 71.663 11.243 106.438 10.768 141.160 10.620 IBDPCA(8×8)[17] 8.830 11.382 8.499 11.403 8.482 11.218 8.478 10.780 8.486 10.612 I2DPCA(120×4) 8.847 70.897 8.503 69.935 8.486 68.141 8.486 66.301 8.503 64.602 IRC2DPCA(8×8) 8.511 11.350 8.507 11.419 8.486 11.243 8.536 10.797 8.511 10.604
下載: 導出CSV
-
WANG Hongjuan, HU Jiani, and DENG Weihong. Face feature extraction: a complete review[J]. IEEE Access, 2018, 6: 6001–6039. doi: 10.1109/ACCESS.2017.2784842 CHAUDHARY G, SRIVASTAVA S, and BHARDWAJ S. Feature extraction methods for speaker recognition: A review[J]. International Journal of Pattern Recognition and Artificial Intelligence, 2017, 31(12): 1–39. doi: 10.1142/S0218001417500410 SOORA N R and DESHPANDE P S. Review of feature extraction techniques for character recognition[J]. IETE Journal of Research, 2018, 64(2): 280–295. doi: 10.1080/03772063.2017.1351323 NEIVA D H and ZANCHETTIN C. Gesture recognition: A review focusing on sign language in a mobile context[J]. Expert Systems with Applications, 2018, 103: 159–183. doi: 10.1016/j.eswa.2018.01.051 陳小龍, 關鍵, 于曉涵, 等. 基于短時稀疏時頻分布的雷達目標微動特征提取及檢測方法[J]. 電子與信息學報, 2017, 39(5): 1017–1023. doi: 10.11999/JEIT161040CHEN Xiaolong, GUAN Jian, YU Xiaohan, et al. Radar micro-Doppler signature extraction and detection via short-time sparse time-frequency distribution[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1017–1023. doi: 10.11999/JEIT161040 ISLAM S, ANAND S, HAMID J, et al. Comparing the performance of linear and nonlinear principal components in the context of high-dimensional genomic data integration[J]. Statistical Applications in Genetics and Molecular Biology, 2017, 16(3): 199–216. doi: 10.1515/sagmb-2016-0066 BRO R and SMILDE A K. Principal component analysis[J]. Analytical Methods, 2014, 6(9): 2812–2831. doi: 10.1039/c3ay41907j YANG Jian, ZHANG David, FRANGI A F, et al. Two-dimensional PCA: a new approach to appearance-based face representation and recognition[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2004, 26(1): 131–137. doi: 10.1109/TPAMI.2004.1261097 ZHANG Daoqiang and ZHOU Zhihua. (2D)2PCA: Two-directional two-dimensional PCA for efficient face representation and recognition[J]. Neurocomputing, 2005, 69(1-3): 224–231. doi: 10.1016/j.neucom.2005.06.004 ZUO Wangmeng, ZHANG David, and WANG Kuanquan. Bidirectional PCA with assembled matrix distance metric for image recognition[J]. IEEE Transactions on Systems, Man, and Cybernetics, Part B (Cybernetics) , 2006, 36(4): 863–872. doi: 10.1109/TSMCB.2006.872274 YANG Wankou, SUN Changyin, and RICANEK K. Sequential Row–Column 2DPCA for face recognition[J]. Neural Computing and Applications, 2012, 21(7): 1729–1735. doi: 10.1007/s00521-011-0676-5 GAO Quanxue, MA Lan, LIU Yang, et al. Angle 2DPCA: A new formulation for 2DPCA[J]. IEEE Transactions on Cybernetics, 2018, 48(5): 1672–1678. doi: 10.1109/TCYB.2017.2712740. ZHOU Shuisheng and ZHANG Danqing. Bilateral angle 2DPCA for face recognition[J]. IEEE Signal Processing Letters, 2019, 26(2): 317–321. doi: 10.1109/LSP.2018.2889925 DIAZ-CHITO K, FERRI F J, and HERNáNDEZ-SABATé A. An overview of incremental feature extraction methods based on linear subspaces[J]. Knowledge-Based Systems, 2018, 145: 219–235. doi: 10.1016/j.knosys.2018.01.020 WENG Juyang, ZHANG Yilu, and HWANG Weyshiuan. Candid covariance-free incremental principal component analysis[J]. IEEE Transactions on Pattern Analysis & Machine Intelligence, 2003, 25(8): 1034–1040. doi: 10.1109/TPAMI.2003.1217609 王肖鋒, 張明路, 劉軍. 基于增量式雙向主成分分析的機器人感知學習方法研究[J]. 電子與信息學報, 2018, 40(3): 618–625. doi: 10.11999/JEIT170561WANG Xiaofeng, ZHANG Minglu, and LIU Jun. Robot perceptual learning method based on incremental bidirectional principal component analysis[J]. Journal of Electronics &Information Technology, 2018, 40(3): 618–625. doi: 10.11999/JEIT170561 謝自強, 葛為民, 王肖鋒, 等. 發展型機器人實時特征提取方法研究[J]. 機器人, 2017, 39(2): 189–196. doi: 10.13973/j.cnki.robot.2017.0189XIE Ziqiang, GE Weimin, WANG Xiaofeng, et al. Real time feature extraction method of developmental robot[J]. Robot, 2017, 39(2): 189–196. doi: 10.13973/j.cnki.robot.2017.0189 REN Chuanxian and DAI Daoqing. Incremental learning of bidirectional principal components for face recognition[J]. Pattern Recognition, 2010, 43(1): 318–330. doi: 10.1016/j.patcog.2009.05.020 曹向海, 劉宏偉, 吳順君. 一種有效的增量BDPCA算法[J]. 系統仿真學報, 2008, 20(20): 5530–5533. doi: 10.16182/j.cnki.joss.2008.20.041CAO Xianghai, LIU Hongwei, and WU Shunjun. A kind of efficient incremental BDPCA algorithm[J]. Journal of System Simulation, 2008, 20(20): 5530–5533. doi: 10.16182/j.cnki.joss.2008.20.041 文穎, 施鵬飛. 一種基于共同向量結合2DPCA的人臉識別方法[J]. 自動化學報, 2009, 35(2): 202–205. doi: 10.3724/SP.J.1004.2009.00202WEN Ying and SHI Pengfei. An approach to face recognition based on common vector and 2DPCA[J]. Acta Automatica Sinica, 2009, 35(2): 202–205. doi: 10.3724/SP.J.1004.2009.00202 -
