基于博弈的機器人認知情感交互模型

黃宏程; 劉寧; 胡敏; 陶洋; 寇蘭

doi:10.11999/JEIT180867

基于博弈的機器人認知情感交互模型

doi: 10.11999/JEIT180867

黃宏程^{1, 2},
劉寧¹,
胡敏¹,
陶洋^{1, 2, ,},
寇蘭¹

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶市通信軟件工程技術研究中心重慶 400065

基金項目: 國家自然科學基金(61871062)，重慶郵電大學科研基金(A2018-07)

詳細信息

作者簡介:
黃宏程：男，1979年生，副教授，研究方向為認知情感計算研究、復雜網絡與信息傳播理論

劉寧：女，1995年生，碩士生，研究方向為認知情感計算研究

胡敏：女，1971年生，副教授，研究方向為信息通信網絡體系結構、人機交互理論與技術應用

陶洋：男，1964年生，教授，研究方向為人工智能、大數據與計算智能

寇蘭：女，1963年生，副教授，研究方向為D2D通信、人機交互理論與技術應用

通訊作者:
陶洋　taoyang@cqupt.edu.cn

中圖分類號: TP242.6
計量
- 文章訪問數: 2942
- HTML全文瀏覽量: 1202
- PDF下載量: 130
- 被引次數: 0
出版歷程
- 收稿日期: 2018-09-02
- 修回日期: 2019-02-26
- 網絡出版日期: 2019-04-03
- 刊出日期: 2019-10-01

Cognitive Emotion Interaction Model of Robot Based on Game Theory

Hongcheng HUANG^{1, 2},
Ning LIU¹,
Min HU¹,
Yang TAO^{1, 2
, ,},
Lan KOU¹

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Chongqing Engineering Research Center of Communication Software, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61871062), The Scientific Research Foundation of Chongqing University of Posts and Telecommunications (A2018-07)

摘要

摘要: 針對現有的人機交互系統普遍存在情感缺失、參與人參與度不高的問題，該文依據PAD情感空間提出一種基于博弈的機器人認知情感交互模型。首先，對參與人的交互輸入情感進行評估并分析當前人機交互關系，提取友好度和共鳴度2個影響因素。其次，模擬人際交往的心理博弈過程對參與人和機器人的情感生成過程進行建模，將嵌入博弈的子博弈完美均衡策略作為機器人的最優情感選擇策略；最后，根據最優情感策略更新機器人的情感狀態轉移概率，并以6種基本情感的空間坐標為標簽，得出受到情感刺激后機器人情感狀態的空間坐標。實驗結果表明，與其它認知交互模型相比，該文模型能夠減少機器人對外界情感刺激的依賴并有效引導參與人參與人機交互，為機器人的情感認知建模提供了新的方法和思路。
- 認知情感交互 /
- PAD情感空間 /
- 博弈 /
- 情感策略選擇
Abstract: To solve the problems of the existing in the process of human-computer interaction system, such as lack of emotion and low participation, a cognitive emotion interaction model based on game theory in PAD emotion space is proposed. Firstly, the interactive input emotion of participant is evaluated and some influence factors such as friendship and resonance are extracted to analyze the current human-computer interaction relationship. Secondly, modeling the emotional generation process of participants and robots by simulating the psychological game process in interpersonal communication, and the optimal emotional strategy of the robot is obtained by using the sub-game perfection equilibrium of the embedded game. Finally, the emotional state transition probability of the robot is updated according the optimal emotional strategy. The spatial coordinates of the six basic emotional states are used as labels to obtain the PAD spatial coordinate of the robot emotional state after emotional stimulate, The results of experiment show that compared with the others emotional interaction model, the proposed model can reduce the dependence of robots on external emotional stimuli and effective guide participants to participate in human-computer interaction, which provides some ideas for the emotion cognition model of robot in human-computer interaction.
- Cognitive emotion interaction /
- PAD emotion space /
- Game theory /
- Emotional strategy choice

HTML全文

圖 1 人機交互過程

下載: 全尺寸圖片幻燈片

圖 2 機器人的情感策略選擇過程

下載: 全尺寸圖片幻燈片

圖 3 不同認知模型作用下的機器人輸出情感與參與人輸入情感的關聯度分析

下載: 全尺寸圖片幻燈片

圖 4 參與人與不同認知模型作用下的聊天機器人交互時的滿意度統計

下載: 全尺寸圖片幻燈片

表 1 基于博弈的機器人認知情感交互模型構建

輸入：$k{{ - 1}}$次會話后友好度更新值$F(k - 1)$和機器人的情感狀態轉移概率${{\text{P}}_{\rm{R}}}(k - 1)$, $k$次會話參與人的交互輸入情感${\text{E}}_{{\rm{HR}}}^k$;
輸出：$k + 1$次會話時機器人的情感值${\text{E}}_{{\rm{RH}}}^{k{{ + 1}}}$;
Repeat:
參與人輸入交互情感${\text{E}}_{{\rm{HR}}}^k$;
根據式(1)—式(3)將${\text{E}}_{{\rm{HR}}}^k$評估轉化為強度值向量${\text{P}}({\text{E}}_{{\rm{HR}}}^k)$；
根據式(8)—式(11)計算針對$k + 1$次會話機器人每種情感策略選擇，預測$k + 2$次會話參與人每種情感策略選擇，$k + 3$次會話機器人每種情感策略下參與人和機器人的效用值；
根據式(12)，式(13)求解機器人的情感選擇策略$s$；
通過最優情感策略$s$對機器人的情感狀態轉移概率進行更新，對機器人情感的空間坐標進行標定；
更新人機交互友好度，并令$k = k + 2$；
Until 參與人停止輸入交互情感；
人機交互會話結束。

下載: 導出CSV

表 2 不同認知模型的自動評價結果

模型	MRR	MAP
Seq2Seq	0.3836	0.4015
ChatterBot	0.4623	0.4923
MECs	0.5903	0.6091
GCRs	0.6269	0.6435
本文	0.6507	0.6756

下載: 導出CSV

表 3 參與人與不同認知模型作用下的機器人交互的次數與時間統計

機器人的認知模型	平均交互輪數(輪)	平均交互時間
Seq2Seq	9	98.32
ChatterBot	6	60.69
MECs	7	88.16
GCRs	10	110.38
本文	12	130.51

下載: 導出CSV

參考文獻(20)

TURKER B B, YEMEZ Y, SEZGIN T M, et al. Audio-facial laughter detection in naturalistic dyadic conversations[J]. IEEE Transactions on Affective Computing, 2017, 8(4): 534–545. doi: 10.1109/TAFFC.2017.2754256

CHEN Min, HERRERA F, and HWANG K. Cognitive computing: Architecture, technologies and intelligent applications[J]. IEEE Access, 2018, 6: 19774–19783. doi: 10.1109/ACCESS.2018.2791469

ZUCCO C, CALABRESE B, and CANNATARO M. Sentiment analysis and affective computing for depression monitoring[C]. The 2017 IEEE International Conference on Bioinformatics and Biomedicine (BIBM), Kansas City, USA, 2017: 1988–1995. doi: 10.1109/BIBM.2017.8217966.

BELKAID M, CUPERLIER N, and GAUSSIER P. Autonomous cognitive robots need emotional modulations: Introducing the eMODUL model[J]. IEEE Transactions on Systems, Man, and Cybernetics: Systems, 2018, 49(1): 206–215. doi: 10.1109/TSMC.2018.2792542

韓晶, 解侖, 劉欣, 等. 基于Gross認知重評的機器人認知情感交互模型[J]. 東南大學學報: 自然科學版, 2015, 45(2): 270–274. doi: 10.3969/j.issn.1001-0505.2015.02.014

HAN Jing, XIE Lun, LIU Xin, et al. Cognitive emotion interaction model of robot based on Gross cognitive reappraisal[J]. Journal of Southeast University:Natural Science Edition, 2015, 45(2): 270–274. doi: 10.3969/j.issn.1001-0505.2015.02.014

LIU Xin, XIE Lun, and WANG Zhiliang. Empathizing with emotional robot based on cognition reappraisal[J]. China Communications, 2017, 14(9): 100–113. doi: 10.1109/CC.2017.8068769

ZHANG Rui, WANG Zhenyu, and MAI Dongcheng. Building emotional conversation systems using multi-task Seq2Seq learning[C]. The Sixth CCF International Conference on Natural Language Processing and Chinese Computing, Dalian, China, 2017: 612–621. doi: 10.1007/978-3-319-73618-1_51.

RODRíGUEZ L F, GUTIERREZ-GARCIA J O, and RAMOS F. Modeling the interaction of emotion and cognition in Autonomous Agents[J]. Biologically Inspired Cognitive Architectures, 2016, 17: 57–70. doi: 10.1016/j.bica.2016.07.008

NANTY A and GELIN R. Fuzzy controlled PAD emotional state of a NAO robot[C]. 2013 Conference on Technologies and Applications of Artificial Intelligence, Taipei, China, 2013: 90–96. doi: 10.1109/TAAI.2013.30.

曹東巖. 基于強化學習的開放領域聊天機器人對話生成算法[D]. [碩士論文], 哈爾濱工業大學, 2017.

CAO Dongyan. Research on reinforcement learning for open domain chatbot dialogue generation[D]. [Master dissertation], Harbin Institute of Technology, 2017.

ZHOU Hao, HUANG Minlie, ZHANG Tianyang, et al. Emotional chatting machine: Emotional conversation generation with internal and external memory[C]. The Thirty-Second AAAI Conference on Artificial Intelligence, New Orleans, USA, 2018: 730–738.

華生. 欲望心理學: 人際交往中的心理博弈[M]. 北京, 中央編譯出版社, 2016: 1–5.

HUA Sheng. Psychology on Desire: Psychological Game in Interpersonal Communication[M]. Beijing: Central Compilation & Translation Press, 2016: 1–5.

卜湛, 伍之昂, 曹杰, 等. 在線評論情感計算與博弈預測[J]. 電子學報, 2015, 43(12): 2530–2535. doi: 10.3969/j.issn.0372-2112.2015.12.028

BU Zhan, WU Zhiang, CAO Jie, et al. Affective computing and game theory based prediction for online reviews[J]. Acta Electronica Sinica, 2015, 43(12): 2530–2535. doi: 10.3969/j.issn.0372-2112.2015.12.028

PARK J W, KIM W H, LEE W H, et al. How to completely use the PAD space for socially interactive robots[C]. 2011 IEEE International Conference on Robotics and Biomimetics, Karon Beach, Thailand, 2011: 3005–3010. doi: 10.1109/ROBIO.2011.6181762.

LI Jiaqi, ZHANG Chunyan, SUN Qinglin, et al. Changing the Intensity of Interaction Based on Individual Behavior in the Iterated Prisoner’s Dilemma Game[J]. IEEE Transactions on Evolutionary Computation, 2017, 21(4): 506–517. doi: 10.1109/TEVC.2016.2628385

MARTINICH L P. Top ten lessons for managers: Deep dive into interpersonal communication[J]. IEEE Engineering Management Review, 2017, 45(2): 27–29. doi: 10.1109/EMR.2017.2701511

SHANG Lifeng, LU Zhengdong, and LI Hang. Neural responding machine for short-text conversation[C]. The 53rd Annual Meeting of the Association for Computational Linguistics and the 7th International Joint Conference on Natural Language Processing, Beijing, China, 2015: 1577-1586. doi: 10.3115/v1/p15-1152.

COX G. ChatterBot tutorial[EB/OL]. https://chatterbot.readthedocs.io/en/stable/tutorial.html, 2018.

SUTSKEVER I, VINYALS O, and LE Q V. Sequence to sequence learning with neural networks[C]. The 27th International Conference on Neural Information Processing Systems, Montreal, Canada, 2014: 3104–3112.

WU Yu, WU Wei, XING Chen, et al. Sequential matching network: A new architecture for multi-turn response selection in retrieval-based chatbots[C]. The 55th Annual Meeting of the Association for Computational Linguistics, Vancouver, Canada, 2017: 496–505.
