面向業務的彈性光網絡光路損傷感知能效路由策略
doi: 10.11999/JEIT180580
-
1.
重慶郵電大學通信與信息工程學院 ??重慶 ??400065
-
2.
重慶郵電大學工業物聯網與網絡化控制教育部重點實驗室 ??重慶 ??400065
-
3.
國網冀北電力有限公司信息通信分公司 ??北京 ??100053
Energy Efficiency Routing Strategy with Lightpath Impairment Awareness in Service-Oriented Elastic Optical Networks
-
1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
-
2.
Key Laboratory of Industrial Internet of Things and Networked Control, Ministry of Education, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
-
3.
Information & Telecommunication Company, State Grid Jibei Electric Power Co., Ltd., Beijing 100053, China
-
摘要:
針對彈性光網絡中物理損傷導致業務頻譜利用率低和傳輸能耗高問題，該文提出一種面向業務的鏈路損傷感知頻譜分區(LI-ASP)能效路由策略。在LI-ASP策略中，為降低不同信道間非線性損傷，基于負載均衡設計一個綜合考慮鏈路頻譜狀態和傳輸損傷的路徑權重公式，根據調制方式的頻譜效率和最大傳輸距離構造分層輔助圖，從最高調制等級開始，為高質量業務選擇K條邊分離的最大權重傳輸路徑；為低質量業務選擇K條邊分離的最短能效路徑。然后，LI-ASP策略根據業務速率比值對頻譜分區，采用首次命中(FF)和尾端命中(LF)聯合頻譜分配方式，減少不同傳輸速率業務間的交叉相位調制。仿真結果表明，該文所提LI-ASP策略在有效降低帶寬阻塞率的同時，減少了業務傳輸能耗。
-
關鍵詞:
- 彈性光網絡 /
- 物理損傷感知 /
- 負載均衡 /
- 頻譜分區 /
- 能耗
Abstract:To address the problems of low spectrum utilization and high energy consumption caused by physical impairment in elastic optical networks, a service differentiated energy efficiency routing strategy with Link Impairment-Aware Spectrum Partition (LI-ASP) is proposed. For reducing the nonlinear impairment between different channels, a path weight formula jointly considering the link spectrum state and transmission impairment is designed to balance the load. A modulation level-layered auxiliary graph is constructed according to traffic’s spectrum efficiency and maximum transmission distance. Starting from the highest modulation in the auxiliary graph, the K link-disjoined maximum weight paths are selected for high quality requests, and the K link-disjoined shortest energy efficiency paths are selected for low quality requests. Then, LI-ASP strategy divides spectrum partition according to requests rate ratio. The First-Fit (FF) and Last-Fit (LF) spectrum allocation policies are used to reduce cross-phase modulation between the requests with different rates. The simulation results show that the proposed LI-ASP strategy can reduce the bandwidth blocking probability and energy consumption effectively.
-
表 1 不同調制方式下子載波傳輸速率、能耗、最大傳輸距離及信噪比閾值
調制方式 調制等級m 傳輸速率(Gb/s) 能耗功率(W) 最大傳輸距離 信噪比閾值(dB) BPSK 1 12.5 112.374 4000 6.8 QPSK 2 25.0 133.416 2000 9.8 8QAM 3 37.5 154.457 1000 13.7 16QAM 4 50.0 175.489 500 16.5 32QAM 5 62.5 196.539 250 19.7
下載: 導出CSV
表 2 LI-ASP能效路由策略步驟
輸入 光網絡拓?fù)?{{G}}\left( {{{V}}, {{E}}, {{S}}} \right)$，節點集${{V}} = \left\{ {{v_i}|i = 1, 2, ·\!·\!· , |{{V}}|} \right\}$，鏈路集${{E}} = \left\{ {{e_{ij}}|i, j \in {{V}}, i \ne j} \right\}$，鏈路頻隙集${{S}} = \left\{ {{s_i}|i = 1, 2, ·\!·\!· , |{{S}}|} \right\}$，
業務集${{R}} = \left\{ {{r_i}|i = 1, 2, ·\!·\!· , |{{R}}|} \right\}$表示，令$k = 1$，$m = M$，業務請求${r_i}\left( {s, d, {\rm{fs}}\_n, Q} \right)$，s為源節點，d為目的節點，${\rm{fs}}\_n$為業務請求
頻隙數目，Q=1表示高質量業務；Q=0為低質量業務。使用Dijkstra算法計算所有源目的節點間的K條最短路徑KSP集合(預處理)，
M層調制等級輔助圖(預處理)。輸出 業務${r_i}$的傳輸路徑${p_k}$和分配的第1個、最后頻隙索引值${f_ {\rm{ts}}}$和${f_ {\rm{te}}}$。 步驟 1 業務${r_i}\left( {s, d, {\rm{fs}}\_n, Q} \right)$到達，從頻譜效率最高調制等級m=M分層輔助圖開始為業務選擇傳輸路徑； 步驟 2 判斷Q是否為1，若為1，為高質量業務，算法轉步驟3；否則，為低質量業務，轉算法步驟4； 步驟 3 根據式(8)計算源和目的節點間K條滿足跳數閾值Hop的最大權重路徑${{{P}}^H}\{{p_1}, {p_2}, ·\!·\!· , {p_K}\}$，轉步驟5； 步驟 4 根據業務源節點和目的節點選擇存放在KSP中的K條最短路徑，根據能耗模型計算路徑能耗，按照能耗大小升序排列K條路徑
${{{P}}^L}\{ {p_1}, {p_2}, ·\!·\!· , {p_K}\}$；步驟 5 計算當前調制等級下業務${r_i}$傳輸所需的頻隙數目，從路徑集合中選擇第${p_k}$條路徑，$k = 1, 2, ·\!·\!· , K$，計算該路徑上可用頻譜塊Block
$\{ {b_1}, {b_2}, ·\!·\!· , {b_j}\} $，若可用頻譜塊集合非空，轉算法步驟8；否則轉算法步驟6；步驟 6 若$m < 1$，當前傳輸路徑無可用調制方式，轉步驟7；否則降低調制等級，$m = m - 1$，轉步驟2； 步驟 7 若$k > K$，業務${r_i}$被阻塞，釋放網絡中已傳輸業務占用的頻譜資源，更新光網絡G的頻譜資源；否則，$k = k + 1$，$m = M$，轉算
法步驟5；步驟 8 根據業務請求頻隙數目${\rm{fs}}\_n$，分別計算采用FF和LF頻譜分區分配策略需要占用候選路徑上各鏈路相鄰信道數目和的值，選擇占
用相鄰信道數目和值較小的FF或LF頻譜分配方式；步驟 9 根據物理損傷模型計算該路徑上業務的傳輸誤比特率${\rm{BER}}_{{r_i}}^k$，若${\rm{BER}}_{{r_i}}^k$小于業務誤碼率閾值，轉算法步驟10；否則，$m = m - 1$，
轉算法步驟5；步驟 10 判斷傳輸路徑${p_k}$是否造成網絡中其他正傳輸業務阻塞，若是，記錄阻塞的業務BT$\{ {\rm{rb}}_1, {\rm{rb}}_2, ·\!·\!· , {\rm{rb}}_i\} $，調用LI-ASP能效路由策略重
配置被阻塞的業務BT$\{ {\rm{rb}}_1, {\rm{rb}}_2, ·\!·\!· , {\rm{rb}}_i\} $；否則，轉算法步驟12；步驟 11 若業務重配置成功，轉算法步驟12；否則，$m = m - 1$，轉算法步驟5； 步驟 12 業務${r_i}$成功傳輸，記錄傳輸路徑${p_k}$，記錄分配的第1個頻隙索引值${f_ {\rm{ts}}}$和最后頻隙索引值${f_ {\rm{te}}}$。
下載: 導出CSV
表 3 物理損傷參數設置
參數 值 參數 值 G(W/THz) 0.015 L(km) 80 $\alpha $(dB/km) 0.22 v(THz) 193 nsp 1.8 ${\beta _2}$(ps2/km) –21.7 h(J/s) $6.626 \times {10^{ - 34}}$ $\gamma $(W·km)–1 1.32 ${\rm{BER}}_t^h$ ${10^{ - 12}}$ ${\rm{BER}}_t^l$ ${10^{ - 9}}$
下載: 導出CSV
-
熊余, 劉川菠, 孫鵬. 考慮業務服務質量的光線路終端節能算法[J]. 重慶郵電大學學報, 2017, 29(2): 208–215. doi: 10.3979/j.issn.1673-825X.2017.02.011XIONG Yu, LIU Chuanbo, and SUN Peng. Energy saving algorithm for optical line terminal considering quality of service[J]. Journal of Chongqing University of Posts and Telecommunications, 2017, 29(2): 208–215. doi: 10.3979/j.issn.1673-825X.2017.02.011 劉煥淋, 熊翠連, 陳勇. 頻譜效率優先的任播路由沖突感知的彈性光網絡資源重配置[J]. 電子與信息學報, 2017, 39(7): 1697–1703. doi: 10.11999/JEIT161093LIU Huanlin, XIONG Cuilian, and CHEN Yong. Collision-aware reconfiguration resource based on spectrum efficiency first for anycast routing in elastic optical networks[J]. Journal of Electronics &Information Technology, 2017, 39(7): 1697–1703. doi: 10.11999/JEIT161093 LIU Huanlin, Lü Lei, CHEN Yong, et al. Fragmentation-avoiding spectrum assignment strategy based on spectrum partition for elastic optical networks[J]. IEEE Photonics Journal, 2017, 9(5): 1–13. doi: 10.1109/JPHOT.2017.2739750 鮑寧海, 劉翔, 張治中, 等. WDM節能光網絡中的抗毀保護算法研究[J]. 重慶郵電大學學報, 2012, 24(3): 278–282. doi: 10.3979/j.issn.1673-825X.2015.03.002BAO Ninghai, LIU Xiang, ZHANG Zhizhong, et al. Survival protection algorithm in WDM energy-efficient optical network[J]. Journal of Chongqing University of Posts and Telecommunications, 2012, 24(3): 278–282. doi: 10.3979/j.issn.1673-825X.2015.03.002 TAN Yanxia, GU Rentao, and JI Yuefeng. Energy-efficient routing, modulation and spectrum allocation in elastic optical networks[J]. Optical Fiber Technology, 2017, 36(2017): 297–305. doi: 10.1016/j.yofte.2017.05.001 YANG Song and KUIPERS F. Impairment-aware routing in translucent spectrum-sliced elastic optical path networks[C]. European Conference on Networks and Optical Communications, Vilanova, Spain, 2012: 1–6. doi: 10.1109/NOC.2012.6249946. AGRELL E, ZHAO Juzi, LI Yan, et al. Traffic-grooming-and multipath-routing-enabled impairment-aware elastic optical networks[J]. Journal of Optical Communications and Networking, 2016, 8(2): 58–70. doi: 10.1364/JOCN.8.000058 ZHAO Juzi, WYMEERSCH H, and AGRELL E. Nonlinear impairment-aware static resource allocation in elastic optical networks[J]. Journal of Lightwave Technology, 2015, 33(22): 4554–4564. doi: 10.1109/JLT.2015.2474130 REN Rongrong, HOU Weigang, GUO Lei, et al. Spectrum and energy-efficient survivable routing algorithm in elastic optical network[J]. Optik - International Journal for Light and Electron Optics, 2016, 127(20): 8795–8806. doi: 10.1016/j.ijleo.2016.06.088 KLEKAMP A, DISCHLER R, and BUCHALI F. Transmission reach of optical-OFDM superchannels with 10-600 Gb/s for transparent bit-rate adaptive networks[C]. European Conference and Exhibition on Optical Communication, Geneva, Switzerland, 2011: 1–3. doi: 10.1364/ECOC.2011.Tu.3.K.2. ZHAO Jijun, WANG Wenyan, LI Wei, et al. A novel partition-plane impairment aware routing and spectrum assignment algorithm in mixed line rates elastic optical networks[J]. Photonic Network Communications, 2017, 33(1): 1–8. doi: 10.1007/s11107-015-0601-4 ABKENAR F S, RAHBAR A G, EBRAHIMZADEH A. Providing Quality of Service (QoS) for data traffic in Elastic Optical Networks (EONs)[J]. Arabian Journal for Science and Engineering, 2016, 41(3): 1–10. doi: 10.1007/s13369-015-1886-4 GUO Lei, WU Ying, HOU Weigang, et al. Green grooming in spectrum-sliced elastic optical path networks[J]. Photonic Network Communications, 2016, 32(1): 115–125. doi: 10.1007/s11107-015-0580-5 LIU Huanlin, ZHOU Bangtao, and CHEN Yong. Spectrum allocation based on spectrum integration and re-routing for elastic optical networks[J]. IET Optoelectronics, 2016, 10(5): 179–183. doi: 10.1049/iet-opt.2015.0136 TANAKA T, INUI T, KADOHATA A, et al. Multiperiod IP-over-elastic network reconfiguration with adaptive bandwidth resizing and modulation[J]. Journal of Optical Communications and Networking, 2016, 8(7): A180–A190. doi: 10.1364/JOCN.8.00A180 -
