軟件定義網絡中基于效率區間的負載均衡在線優化算法
doi: 10.11999/JEIT180464
-
合肥工業大學計算機與信息學院 ??合肥 ??230009
An Efficient Online Algorithm for Load Balancing in Software Defined Networks Based on Efficiency Range
-
School of Computer and Information, Hefei University of Technology, Hefei 230009, China
-
摘要:
在大型復雜軟件定義網絡中，為提高網絡負載均衡，減少控制器與交換機間的傳播時延，該文提出一種基于效率區間的負載均衡在線優化算法。在初始靜態網絡中，通過貪心算法選擇初始控制器集合，并以其為根節點構建M棵改進代價的最小生成樹(MST)，確定初始M個負載均衡的子網；當網絡流量發生變化時，通過廣度優先搜索(BFS)調整子網間交換機映射關系使其滿足效率區間，保證任意時刻網絡的負載均衡。算法均以網絡連通性為基礎，且均以傳播時延為目標重新更新控制器集合。仿真實驗表明，該算法在保證任意時刻網絡負載均衡的同時，可以保證較低的傳播時延，與Pareto模擬退火算法、改進的K-Means算法等相比，可以使網絡負載均衡情況平均提高40.65%。
-
關鍵詞:
- 軟件定義網絡 /
- 控制器部署 /
- 負載均衡 /
- 傳播時延
Abstract:Due to the limitation of individual controller’s processing capacity in large-scale complex Software Defined Networks (SDN), an efficient online algorithm for load balancing among controllers based on efficiency range is proposed to improve load balancing among controllers and reduce the propagation delay between a controller and the switch. In the initial static network, the initial set of controllers is selected by a greedy algorithm, then M improved Minimum Spanning Trees (MST) rooted at the initial set of controllers are constructed, so initial M subnets with load balancing are determined. With the dynamic changes of load, for the purpose of making the controller work within efficiency range at any time, several switches in different subnets are reassigned by Breadth First Search (BFS). The initial set of controllers is updated for minimizing propagation delay in the algorithms’ last step. The algorithm is based on the connectivity of intra-domain and inter-domain. Simulation results show that the proposed algorithms not only guarantee the load balancing among controllers, but also guarantee the lower propagation delay. As to compare to PSA algorithm, optimized K-Means algorithm, etc., it can make Network Load Balancing Index (NLBI) averagely increase by 40.65%.
-
表 1 初始M控制域選擇算法
算法1：初始M控制域選擇算法(IMCDS) 輸入：$G = (V, E) , f, {\rm{MLCC}}, {T_{\rm max}}, {W}, D, {\rm{ID}}, $
$ \{ {\rm{Flag}}, {\rm{Temp}}, {\rm{ICon}}, {\rm{IS}}\} = \varnothing $輸出：${\rm{ICon}}, {\rm{IS}}$ (1) $M \leftarrow {{\displaystyle\sum\nolimits_{i = 1}^{\left| V \,\right|} {{f_i}} }}\Bigr/{{\rm{OL}}} , {\rm{OL}} = 0.85 \times {\rm{MLCC}}$; (2) ${\rm{ICon}} \leftarrow {C_1}, {C_1} \in \{ \max (D) \cap \max ({\rm{ID}})\} $; (3) Adopt $ { \rm{Prim}} ({C_1}, {W}, {\rm{OL}}) $ to construct first improved MST
based 式(11) and 式(12);(4) Update $ {\rm{IS}}_1, {\rm{Flag}}_1 \leftarrow 1, {\rm{Temp}} \leftarrow 1$; (5) do (6) ${\rm{ICon}} \leftarrow {C_i}, {C_i} \in \{ {\rm{Flag}}_i = 0 \cap {\rm{furthest \;from\;}} {\rm{ICon}} \cap $
$ \max (D) \cap \max ({\rm{ID}}),i = 1, ·\!·\!· , n\} $;(7) Adopt $ { \rm{Prim}} ({C_i}, {W}, {\rm{OL}}) $ to construct improved MST
based on 式(11) and 式(12);(8) Update $ {\rm{IS}}_i, {\rm{Flag}}_i \leftarrow 1, {\rm{Temp}} \leftarrow {\rm{Temp}} + 1$; (9) while $ {\rm{Temp}} > M, {\rm{the \ network \ has \ been \ divided \ into}} \ $ M
domains;(10) if there are nodes has not been selected do (11) Add nodes to one closest improved MST by BFS based
on 式(11) and 式(12);(12) Update ${\rm{IS}} , {\rm{Flag}} \leftarrow 1$; (13) end if (14) Update centroids ${\rm{ICon}} = \{ {C_1}, {C_2}, ·\!·\!· , {C_M}\} $ based on the
sum of the shortest distance from all switches in ${\rm{IS}} _i $ to
new controller $ {C_i}$ is minimized;(15) Output ${\rm{ICon}} , {\rm{IS}}$。
下載: 導出CSV
表 2 M控制域調整算法
算法2：M控制域調整算法(M-CDA) 輸入：$G = (V, E), {T_{\max}}, f, {\rm{MLCC}}, (\alpha , \beta ), {\rm{ICon}}, {\rm IS}, T, $
$ \{ {\rm{LS}}, {\rm{LCon}}, {\rm{TNS}}\} = \varnothing $輸出：${\rm{LCon}}, {\rm{LS}}$ (1) for all $ {\rm{}} t\; {\rm{with}} \;0 \le t \le T\; $ do (2) for each $ i \in M $ do (3) ${\rm{TNS}} \leftarrow {\rm{BV}}_{i, j}, {\rm{BV}}_{i, j} \in \{ {\rm{furthest}} \;{\rm{from}} \; $
$ {\rm{ICon}}_i \cap\max \left(f_{i1}^t, ·\!·\!· ,f_{ij}^t\right) ,j \in {\rm{IS}}_i\} $;(4) end for (5) for each $ i \in M $ do (6) if $\sum\nolimits_{l = t - 1}^t {\rm{L C}}_i^l < \alpha \times {\rm{MLCC}} $ do (7) Add nodes in TNS closest from $ {\rm{ICon}}_i$ to ISi by BFS
based 式(11)，式(12)，式(13);(8) end if (9) if $\sum\nolimits_{l = t - 1}^t {\rm{L C}}_i^l > \beta \times {\rm{MLCC}} $ do (10) Add nodes in ISi furthest from ${\rm{ICon}}_i$ to TNS by BFS
based 式(11)，式(12)，式(13);(11) end if (12) end for (13) Compute function
${\rm{ }} {F_t} = \mu \times ({\rm{NLBI}}^t - 1) + \nu \times \sum\limits_{j = 1}^M {{\rm{TRDT}}_j^t} $(14) if ${F_t} < {F_{t - 1}} $ do (15) ${\rm{LS}} \leftarrow {\rm{IS}}$; (16) end if (17) end for (18) Update centroids $ {\rm{ICon}} = \{ {C_1}, {C_2}, ·\!·\!· , {C_M}\} $ based on the
sum of the shortest distance from all switches in ${\rm{}} {\rm{LS}}_i $ to
new controller Ci is minimized, ${\rm{LCon}} \leftarrow {\rm{ICon}}$;(19) Output $ {\rm{LCon}}, {\rm{LS}}$。
下載: 導出CSV
表 3 網絡拓?fù)涔?jié)點數和鏈路數分布
網絡名稱 Noel Darkstrand OS3E Arnes Ntelos Surfnet 節點數 19 28 34 34 48 50 鏈路數 35 31 43 49 61 73
下載: 導出CSV
表 4 初始靜態情況下多網絡拓?fù)涞呢?fù)載均衡情況
子網絡數 Noel Darkstrand OS3E Arnes Ntelos Surfnet 2 1.05 1.00 1.00 1.00 1.00 1.00 3 1.10 1.07 1.06 1.06 1.00 1.02 4 1.26 1.14 1.06 1.06 1.08 1.04 5 1.05 1.07 1.03 1.18 1.25 1.20 6 1.26 1.06 1.06 1.06 1.13 1.08 7 1.48 1.25 1.03 1.23 1.17 1.12 8 1.52 1.43 1.18 1.41 1.17 1.12
下載: 導出CSV
表 5 動態情況下多網絡拓?fù)涞呢?fù)載均衡情況
子網絡數 Noel Darkstrand OS3E Arnes Ntelos Surfnet 2 1.08 1.04 1.02 1.04 1.03 1.05 3 1.09 1.10 1.08 1.11 1.06 1.03 4 1.18 1.23 1.12 1.16 1.08 1.09 5 1.20 1.25 1.13 1.23 1.18 1.15 6 1.34 1.28 1.26 1.28 1.12 1.31 7 1.41 1.33 1.38 1.36 1.33 1.24 8 1.51 1.48 1.26 1.34 1.23 1.18
下載: 導出CSV
-
HLLER B, SHEERWOOD R, and MCKEOWN N. The controller placement problem[J]. ACM Sigcomm Computer Communication Review, 2012, 42(4): 473–478. doi: 10.1145/2377677.2377767 KOPONEN T, CASADO M, GUDE N, et al. Onix: A distributed control platform for large-scale production networks[C]. Usenix Conference on Operating Systems Design and Implementation, Vancouver, Canada, 2010: 351–364. TOOTOONCHIAN A and GANJALI Y. HyperFlow: A distributed control plane for OpenFlow[C]. Internet Network Management Conference on Research on Enterprise Networking, San Francisco, USA, 2010: 3–8. YU M, REXDORD J, FREEDMAN M J, et al. Scalable flow-based networking with DIFANE[J]. ACM Sigcomm Computer Communication Review, 2010, 40(4): 351–362. doi: 10.1145/1851275.1851224 WANG Guodong, ZHAO Yanxiao, HUANG Jun, et al. A K-means-based network partition algorithm for controller placement in software defined network[C]. IEEE International Conference on Communicat–uala Lumpur, Malaysia, 2016: 1–6. 張棟, 郭俊杰, 吳春明. 層次型多中心的SDN控制器部署[J]. 電子學報, 2017, 45(3): 680–686. doi: 10.3969/j.issn.0372-2112.2017.03.027ZHANG Dong, GUO Junjie, and WU Chunming. Controller placement based on hierarchical multi-center SDN[J]. Acta Electronica Sinica, 2017, 45(3): 680–686. doi: 10.3969/j.issn.0372-2112.2017.03.027 SAHOO K S, SAHOO B, DASH R, et al. Optimal controller selection in software defined network using a greedy-SA algorithm[C]. International Conference on Computing for Sustainable Global Development, New Delhi, India, 2016: 2342–2346. YAO Guang, BI Jun, LI Yuliang, et al. On the capacitated controller placement problem in software defined networks[J]. IEEE Communications Letters, 2014, 18(8): 1339–1342. doi: 10.1109/LCOMM.2014.2332341 SALLAHI A and ST-HILAIRE M. Optimal model for the controller placement problem in software defined networks[J]. IEEE Communications Letters, 2015, 19(1): 30–33. doi: 10.1109/LCOMM.2014.2371014 JIMENEZ Y, CERVALLO-PASTOR C, and GARCIA A J. On the controller placement for designing a distributed SDN control layer[C]. NETWORKING Conference, Trondheim, Norway, 2014: 1–9. LANGE S, GEBERT S, ZINNER T, et al. Heuristic approaches to the controller placement problem in large scale SDN networks[J]. IEEE Transactions on Network & Service Management, 2015, 12(1): 4–17. doi: 10.1109/TNSM.2015.2402432 JALILI A, AHMADI V, KESHTGARI M, et al. Controller placement in software-defined WAN using multi objective genetic algorithm[C]. International Conference on Knowledge-Based Engineering and Innovation, Tehran, Iran, 2016: 656–662. RATH H K, REVVOORI V, NADAF S M, et al. Optimal controller placement in software defined networks (SDN) using a non-zero-sum game[C]. International Symposium on A World of Wireless, Mobile and Multimedia Networks, Sydney, Australia, 2014: 1–6. 史久根, 邾偉. 軟件定義網絡中基于負載均衡的多控制器部署算法[J]. 電子與信息學報, 2018, 40(2): 455–461. doi: 10.11999/JEIT170464SHI Jiugen and ZHU Wei. Multi-controller deployment algorithm based on load balance in software defined network[J]. Journal of Electronics &Information Technology, 2018, 40(2): 455–461. doi: 10.11999/JEIT170464 WANG Tao, LIU Fangming, and XU Hong. An efficient online algorithm for dynamic SDN controller assignment in data center networks[J]. IEEE/ACM Transactions on Networking, 2017, 25(5): 2788–2801. doi: 10.1109/TNET.2017.2711641 覃匡宇, 黃傳河, 王才華, 等. SDN網絡中受時延和容量限制的多控制器均衡部署[J]. 通信學報, 2016, 37(11): 90–103. doi: 10.11959/j.issn.1000-436x.2016219QIN Kuangyu, HUANG Chuanhe, WANG Caihua, et al. Balanced multiple controllers placement with latency and capacity bound in software-defined network[J]. Journal on Communications, 2016, 37(11): 90–103. doi: 10.11959/j.issn.1000-436x.2016219 -
