一種基于匹配博弈的服務鏈協同映射方法
doi: 10.11999/JEIT180385
-
中國人民解放軍信息工程大學 ??鄭州 ??450001
A Collaborative Mapping Method for Service Chain Based on Matching Game
-
The Information Engineering University of PLA, Zhengzhou 450001, China
-
摘要:
針對軟件定義網絡(SDN)/網絡功能虛擬化(NFV)環境下服務鏈映射難以兼顧效率與物理資源利用率的問題，該文提出一種基于匹配博弈的服務鏈協同映射方法。首先，以最大化網絡資源效用為目標，建立服務鏈映射模型MUSCM；然后，分虛擬網絡功能(VNF)部署和組鏈兩個部分解決服務鏈映射問題，VNF部署部分，設計基于多對一匹配博弈理論的算法協同服務鏈和服務節點雙方互相進行選擇，有效提升了服務鏈的映射效率和物理資源的利用率，在此基礎上，設計基于分段路由策略的算法實現各VNF實例間的流量牽引以完成VNF組鏈，有效降低了鏈路傳輸時延。實驗結果表明，與經典算法相比，該算法在保證映射請求接受率的同時，有效降低了服務鏈的平均傳輸延時，提升了系統的物理資源利用率。
-
關鍵詞:
- 軟件定義網絡 /
- 網絡功能虛擬化 /
- 服務鏈映射 /
- 匹配博弈 /
- 分段路由
Abstract:Considering that it is difficult to balance efficiency and resource utilization of Service Chain (SC) mapping problem in Software Defined Network (SDN)/Network Function Virtualization (NFV) environment, this paper proposes a collaborative mapping method for SC based on matching game. Firstly, it defines a SC mapping model named MUSCM to maximize the utility of network resources. Secondly, it divides the SC mapping problem into Virtual Network Function (VNF) deployment and connection parts. As for the VNF deployment part, an algorithm is designed to collaborate the selection of the SC and the service node based on many-to-one matching game, improving the mapping efficiency of SC and utilization of physical resource effectively. On the basis of it, an algorithm is designed based on segment routing strategy to accomplish the traffic steering between VNF instances to finish the VNF connection part, reducing the link transmission delay effectively. The experiment result shows that, compared with the classical algorithm, this algorithm ensures the mapping request received rate, and at the same time, it reduces the average transmission delay of the service chain and improves the physical resources utilization of the system effectively.
-
表 1 主要符號列表
符號 描述 $G$ 物理基礎設施無向圖$G = (N,E)$ $N$ 物理節點集合，$n \in N$ $E$ 物理鏈路集合，$e\left( {{n_i},{n_j}} \right) \in E$ ${N^F}$ 轉發節點集合 ${N^S}$ 服務節點集合 ${I_k}$ 資源種類，${I_k} = \left\{ {{\rm{CPU}},{\rm{Me}},{\rm{Th}}} \right\}$ ${\rm{vol}}_n^{{I_k}}$ 服務節點$n$的${I_k}$類資源的容量 ${\rm{vol}}_{e\left( {{n_i},{n_j}} \right)}^{\rm band}$ 服務節點${n_i}$和${n_j}$間物理鏈路的帶寬資源容量 $P$ 網絡中可提供的所有VNF種類集合 ${F^p}$ 類型為$p$的VNF實例集合，${f^p} \in {F^p}$ ${R^c}$ 構成服務鏈$c$的VNF實例集合 $d_{{f^p}}^{{I_k}}$ VNF實例${f^p}$的${I_k}$類資源需求 $C$ 服務鏈集合，$c \in C$ $d_c^{{I_k}}$ 服務鏈$c$的${I_k}$類資源需求 $d_{{f^p},{f^{p'}}}^c$ 服務鏈$c$中實例${f^p}$和${f^{p'}}$間的帶寬資源需求 $X_{{f^p},n}^c$ 服務鏈$c$中VNF實例${f^p}$與服務節點$n$映射關系
下載: 導出CSV
表 2 服務鏈匹配偏好表構建算法
算法1 服務鏈匹配偏好表構建算法 輸入：構成服務鏈$c$的VNF實例集合${R^c}$，服務節點集合${N^S}$，物 理基礎設施圖$G$ 輸出：服務鏈匹配偏好表${\rm SC}\left( {{N^S}} \right)$ (1) 根據輸入初始化； (2) for each $n$ in ${N^S}$ do 依據式(8)計算資源偏差$\Delta R$； 選擇$\Delta R$最小的服務節點${n_0}$； ${\rm{SC}}\left( {{N^S}} \right) \leftarrow \left\{ {{n_0}} \right\}$；//將${n_0}$作為起始節點，并加入偏好表 將${n_0}$標記為已讀； end for (3) while ${N^S}$中存在未讀節點 do 依據NNA算法尋找圖$G$中距離當前節點最近的且滿足資源 約束條件(式(3)、式(4))的下一服務節點${n_w}$； ${\rm{SC}}\left( {{N^S}} \right) \cup \left\{ {{n_w}} \right\}$；//將${n_w}$加入偏好表
將${n_w}$標記為已讀；(4) 所有服務節點已讀則終止； (5) 返回步驟(3)； (6) 輸出服務鏈匹配偏好表${\rm{SC}}\left( {{N^S}} \right)$
下載: 導出CSV
表 3 服務節點匹配偏好表構建算法
算法2 服務節點匹配偏好表構建算法 輸入：構成服務鏈$c$的VNF實例集合${R^c}$，服務節點集合${N^S}$ 輸出：服務節點匹配偏好表${N^S}\left( {\rm{SC}} \right)$ (1) 根據輸入初始化； (2) for each ${f^p}$ in ${R^c}$ do 按資源需求對${f^p}$進行排序； //資源需求優先級依次為
$\rm{CPU} > \rm{Me} > \rm{Th}$依據BFA算法選擇剩余資源空間最小的VNF實例${f^p}$； ${N^S}\left( {\rm{SC}} \right) \cup \left\{ {{f^p}} \right\}$； //將${f^p}$加入偏好表
將VNF實例${f^p}$標記為已讀；end for (3) 所有VNF實例已讀則終止； (4) 返回步驟(2) (5) 輸出服務節點匹配偏好表${N^S}\left( {\rm{SC}} \right)$
下載: 導出CSV
表 4 博弈選擇算法
算法3 博弈選擇算法
輸入：構成服務鏈$c$的VNF實例集合${R^c}$，服務節點集合${N^S}$
輸出：服務鏈和服務節點的平穩匹配結果
根據輸入初始化；
if 服務鏈$c$是不飽和的 do
for each ${f^p}$ in ${R^c}$ do
$n \leftarrow $get highest rank in ${\rm \rm{SC}}\!\left( {{N^S}} \right)$;
if $\left( {{\rm{vol}}_n^{{I_k}} > d_{{f^p}}^{{I_k}}} \right)\& \& \left( {{f^p} \ \ {\rm in} \ \ {N^S}\left( {\rm{SC}} \right)} \right)$ then
將${f^p}$匹配給$n$；
${\rm{vol}}_n^{{I_k}} = {\rm{vol}}_n^{{I_k}} - d_{{f^p}}^{{I_k}}$;
end
else
找出所有滿足${f^p}\mathop \succ \limits_n {f^{p'}}$的${f^{p'}}$;
拒絕所有${f^{p'}}$并更新服務節點$n$的資源；
${\rm{vol}}_n^{{I_k}} = {\rm{vol}}_n^{{I_k}} - d_{{f^p}}^{{I_k}}$;
將${f^{p'}}$從服務節點映射偏好表${N^S}\left( {\rm{SC}} \right)$中移除；
將$n$從服務鏈映射偏好表${\rm{SC}}\left( {{N^S}} \right)$中移除；
end
end for
輸出匹配結果；
else
return
下載: 導出CSV
表 5 分段路由連接算法
算法4 分段路由連接算法 輸入：VNF實例與服務節點間的映射關系$\varOmega $ 輸出：服務鏈$c$的路由路徑 根據輸入初始化； 依據式(11)表達$\varOmega $中服務節點的分段路徑，構成集合$S$ for each ${\rm{FG}}\left( {n_{i - 1}^{ma},n_i^{ma}} \right)$ in $S$ do 利用SPA算法計算連接路徑； end for 輸出計算結果； return
下載: 導出CSV
表 7 VNF參數設置
VNF種類 CPU 內存(GB) 吞吐量(Mbps) Firewall 8 4 200 IDS 8 4 80 IPS 4 4 268 WAN-opt 2 2 10
下載: 導出CSV
-
KREUTZ D, RAMOS F M V, VERíSSIMO P E, et al. Software-defined networking: A comprehensive survey[J]. Proceedings of the IEEE, 2015, 103(1): 14–76. doi: 10.1109/JPROC.2014.2371999 MIJUMBI R, SERRAT J, GORRICHO J L, et al. Network function virtualization: State-of-the-art and research challenges[J]. IEEE Communications Surveys and Tutorials, 2017, 18(1): 236–262. doi: 10.1109/COMST.2015.2477041 OCAMPO A F, GIL-HERRERA J, ISOLANI P H, et al. Optimal service function chain composition in network functions virtualization[C]. International Conference on Autonomous Infrastructure, Management and Security, Zurich, Switzerland, 2017: 62–76. LI Yong and CHEN Min. Software-defined network function virtualization: A survey[J]. IEEE Access, 2015, 3: 2542–2553. doi: 10.1109/ACCESS.2015.2499271 BHAMARE D, JAIN R, SAMAKA M, et al. A survey on service function chaining[J]. Journal of Network and Computer Applications, 2016, 75: 138–155. doi: 10.1016/j.jnca.2016.09.001 DWARAKI A and WOLF T. Adaptive service-chain routing for virtual network functions in software-defined networks[C]. The Workshop on Hot Topics in Middleboxes and Network Function Virtualization, Salvador, Brazil, 2016: 32–37. XIONG Gang, HU Yunxiang, LAN Julong, et al. A mechanism for configurable network service chaining and its implementation[J]. KSII Transactions on Internet and Information Systems, 2016, 10(8): 3701–3727. doi: 10.3837/tiis.2016.08.016 SEKAR V, EGI N, RATNASAMY S, et al. Design and implementation of a consolidated middlebox architecture[C]. Usenix Conference on Networked Systems Design and Implementation, Lombard, Italy, 2012: 24–34. KUO Tunwei, LIOU Bangheng, LIN Chingju, et al. Deploying chains of virtualnetwork functions: On the relation between link and server usage[C]. IEEE International Conference on Computer Communications, San Francisco, USA, 2016: 1–9. ZHANG Qixia, XIAO Yikai, LIU Fangming, et al. Joint optimization of chain placement and request scheduling for network function virtualization[C]. IEEE International Conference on Distributed Computing Systems, Atlanta, USA, 2017: 731–741. GALE D and SHAPLEY L S. College admissions and the stability of marriage[J]. American Mathematical Monthly, 1962, 69(1): 9–15. doi: 10.4169/amer.math.monthly.120.05.386 XU Hong and LI Baochun. Anchor: A versatile and efficient framework for resource management in the cloud[J]. IEEE Transactions on Parallel and Distributed Systems, 2013, 24(6): 1066–1076. doi: 10.1109/TPDS.2012.308 ZHANG Yan and ANSARI N. Heterogeneity aware dominant resource assistant heuristics for virtual machine consolidation[C]. Global Communications Conference, Austin, USA, 2014: 1297–1302. CORMEN T T, LEISERSON C E, RIVEST R L, et al. Introduction to Algorithms[M]. McGraw, USA, MIT Press, 2002: 145–167. MANLOVE D. Algorithmics of Matching under Preferences[M]. Glasgow, UK, World Scientific Pub. Co, 2013: 266–278. FILSFILS C, NAINAR N K, PIGNATARO C, et al. The segment routing architecture[C]. Global Communications Conference, San Diego, USA, 2015: 1–6. CALVERT K L and BHATTACHARJEE S. How to model an internetwork[C]. IEEE Conference of Computer Societies, San Francisco, USA, 1996: 594–602. -
