適用于二維陣列的無格稀疏波達方向估計算法

王劍書; 樊養余; 杜瑞; 呂國云

doi:10.11999/JEIT180340

適用于二維陣列的無格稀疏波達方向估計算法

doi: 10.11999/JEIT180340

西北工業大學電子信息學院 ??西安 ??710129

基金項目: 水聲對抗重點實驗室基金(kmb5494)

詳細信息

作者簡介:
王劍書：男，1989年生，博士生，研究方向?yàn)殛嚵行盘?hào)處理、DOA估計和波束形成等

樊養余：男，1960年生，教授，主要研究方向?yàn)閿?shù)字圖像處理、數字信號處理理論與應用、無線光通信技術和虛擬現實技術等

杜瑞：男，1988年生，博士生，研究方向?yàn)槔走_(dá)信號處理和模式識別等

呂國云：男，1975年生，副教授，主要研究方向?yàn)樾盘?hào)與信息處理、語音和圖像處理、虛擬現實和嵌入式系統和高速信號處理等

通訊作者:
王劍書　wangjs123@mail.nwpu.edu.cn

中圖分類號: TN911.7
計量
- 文章訪問數: 1662
- HTML全文瀏覽量: 1531
- PDF下載量: 90
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-12
- 修回日期: 2018-09-04
- 網絡出版日期: 2018-09-12
- 刊出日期: 2019-02-01

Gridless Sparse Method for Direction of Arrival Estimation for Two-dimensional Array

School of Electronics and Information, Northwestern Polytechnical University, Xi’an 710129, China

Funds: The Foundation of Key Laboratory of Underwater Acoustic Countermeasure (kmb5494)

摘要

摘要:
針對現有的適用于2維陣列的無格稀疏波達方向(DOA)估計方法性能不足的問題，該文提出一種新的方法。對2維陣列，從原子L0范數出發，證明其值等于一個以矩陣秩為目標函數的半定規劃(SDP)問題的最優解。對該矩陣使用第1類有限階貝塞爾函數近似表達，構造新的秩優化SDP問題。根據低秩矩陣恢復理論，對該SDP問題的目標函數使用log-det函數方法平滑替代，然后使用優化最小(MM)算法求解，最后通過(半)正定Toeplitz矩陣的范德蒙分解方法實現無格DOA估計。在MM算法求解模型時，使用樣本協方差矩陣構造初始優化問題，減少算法迭代。仿真實驗結果表明，相較于基于網格的MUSIC和其他無格DOA估計方法，該文方法具有更好的均方根誤差(RMSE)性能與對相鄰源的分辨能力；在快拍數充足且信噪比(SNR)較高時，適當?shù)牡?類貝塞爾函數階數選擇可以實現與較大階數接近的RMSE性能，同時能減少運行時間。
- 波達方向估計 /
- 無格 /
- 2維陣列 /
- 半定規劃 /
- 范德蒙分解
Abstract:
For the fact that current gridless Direction Of Arrival (DOA) estimation methods with two-dimensional array suffer from unsatisfactory performance, a novel girdless DOA estimation method is proposed in this paper. For two-dimensional array, the atomic L0-norm is proved to be the solution of a Semi-Definite Programming (SDP) problem, whose cost function is the rank of a Hermitian matrix, which is constructed by finite order of Bessel functions of the first kind. According to low rank matrix recovery theorems, the cost function of the SDP problem is replaced by the log-det function, and the SDP problem is solved by Majorization-Minimization (MM) method. At last, the gridless DOA estimation is achieved by Vandermonde decomposition method of semidefinite Toeplitz matrix built by the solutions of above SDP problem. Sample covariance matrix is used to form the initial optimization problem in MM method, which can reduce the iterations. Simulation results show that, compared with on-grid MUSIC and other gridless methods, the proposed method has better Root-Mean-Square Error (RMSE) performance and identifiability to adjacent sources; When snapshots are enough and Signal-Noise-Ratio (SNR) is high, proper choice of the order of Bessel functions of the first kind can achieve approximate RMSE performance as that of higher order ones, and can reduce the running time.
- Direction Of Arrival (DOA) estimation /
- Gridless /
- Two-dimensional array /
- Semi-Definite Programming (SDP) /
- Vandermonde decomposition

HTML全文

圖 1 RMSE仿真實驗結果

下載: 全尺寸圖片幻燈片

圖 2 相鄰源RMSE仿真實驗結果

下載: 全尺寸圖片幻燈片

圖 3 不同貝塞爾函數階數的本文方法仿真實驗結果

下載: 全尺寸圖片幻燈片

表 1 不同貝塞爾函數階數的本文方法平均運行時間

N 20 40 60 80

運行時間 0.7453 1.7536 4.0365 8.0497

下載: 導出CSV

參考文獻(34)

QIN Si, ZHANG Yimin D, and AMIN M G. DOA estimation of mixed coherent and uncorrelated targets exploiting coprime MIMO radar[J]. Digital Signal Processing, 2017, 61: 26–34. doi: 10.1016/j.dsp.2016.06.006

SAUCAN A A, CHONAVEL T, SINTES C, et al. CPHD-DOA tracking of multiple extended sonar targets in impulsive environments[J]. IEEE Transactions on Signal Processing, 2016, 64(5): 1147–1160. doi: 10.1109/TSP.2015.2504349

HE Saijuan and CHEN Huawei. Closed-form DOA estimation using first-order differential microphone arrays via joint temporal-spectral-spatial processing[J]. IEEE Sensors Journal, 2017, 17(4): 1046–1060. doi: 10.1109/JSEN.2016.2641449

WAN Liangtian, HAN Guangjie, JIANG Jinfang, et al. A DOA estimation approach for transmission performance guarantee in D2D communication[J]. Mobile Networks and Applications, 2017, 22(6): 998–1009. doi: 10.1007/s11036-017-0820-2

CAPON J. High-resolution frequency-wavenumber spectrum analysis[J]. Proceedings of the IEEE, 1969, 57(8): 1408–1418. doi: 10.1109/PROC.1969.7278

SCHMIDT R. Multiple emitter location and signal parameter estimation[J]. IEEE Transactions on Antennas and Propagation, 1986, 34(3): 276–280. doi: 10.1109/TAP.1986.1143830

ROY R and KAILATH T. ESPRIT—Estimation of signal parameters via rotational invariance techniques[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1989, 37(7): 984–995. doi: 10.1109/29.32276

MALIOUTOV D, CETIN M, and WILLSKY A S. A sparse signal reconstruction perspective for source localization with sensor arrays[J]. IEEE Transactions on Signal Processing, 2005, 53(8): 3010–3022. doi: 10.1109/TSP.2005.850882

WIPF D P and RAO B D. An empirical Bayesian strategy for solving the simultaneous sparse approximation problem[J]. IEEE Transactions on Signal Processing, 2007, 55(7): 3704–3716. doi: 10.1109/TSP.2007.894265

LIU Zhangmeng, HUANG Zhitao, and ZHOU Yiyu. An efficient maximum likelihood method for direction-of-arrival estimation via sparse Bayesian learning[J]. IEEE Transactions on Wireless Communications, 2012, 11(10): 1–11. doi: 10.1109/TWC.2012.090312.111912

BHASKAR B N, TANG Gongguo, and RECHT B. Atomic norm denoising with applications to line spectral estimation[J]. IEEE Transactions on Signal Processing, 2013, 61(23): 5987–5999. doi: 10.1109/TSP.2013.2273443

QIAN Tong, TIAN Jing, ZHANG Xu, et al. Atomic norm method for DOA estimation in random sampling condition[C]. 2016 CIE International Conference on Radar (RADAR), Guangzhou, China, 2016: 1–4.

ZHANG Yu, ZHANG Gong, and WANG Xinhai. Array covariance matrix-based atomic norm minimization for off-grid coherent direction-of-arrival estimation[C]. 2017 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), New Orleans, USA, 2017: 3196–3200. doi: 10.1109/ICASSP.2017.7952746.

CHEN Yuxin and CHI Yuejie. Robust spectral compressed sensing via structured matrix completion[J]. IEEE Transactions on Information Theory, 2014, 60(10): 6576–6601. doi: 10.1109/TIT.2014.2343623

YANG Zai, LI Jian, STOICA P, et al. Sparse methods for direction-of-arrival estimation[OL]. http://cn.arxiv.org/pdf/1609.09596v2, 2017.3.

YANG Zai, XIE Lihua, and ZHANG Cishen. A discretization-free sparse and parametric approach for linear array signal processing[J]. IEEE Transactions on Signal Processing, 2014, 62(19): 4959–4973. doi: 10.1109/TSP.2014.2339792

YANG Zai and XIE Lihua. On gridless sparse methods for multi-snapshot direction of arrival estimation[J]. Circuits, Systems, and Signal Processing, 2017, 36(8): 3370–3384. doi: 10.1007/s00034-016-0462-9

ZHANG Youwen, HONG Xiaoping, WANG Yonggang, et al. Gridless SPICE applied to parameter estimation of underwater acoustic frequency hopping signals[C]. 2016 IEEE/OES Chian Ocean Acoustics (COA), Harbin, China, 2016: 1–6.

MAHATA K and HYDER M M. Grid-less TV minimization for DOA estimation[J]. Signal Processing, 2017, 132: 155–164. doi: 10.1016/j.sigpro.2016.09.018

RAO B D and HARI K V S. Performance analysis of root-MUSIC[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1989, 37(12): 1939–1949. doi: 10.1109/29.45540

TANG Gongguo, BHASKAR B N, SHAH P, et al. Compressed sensing off the grid[J]. IEEE Transactions on Information Theory, 2013, 59(11): 7465–7490. doi: 10.1109/TIT.2013.2277451

MOHAN K and FAZEL M. Iterative reweighted algorithms for matrix rank minimization[J]. Journal of Machine Learning Research, 2012, 13(11): 3441–3473.

SUNDIN M, ROJAS C R, JANSSON M, et al. Relevance singular vector machine for low-rank matrix reconstruction[J]. IEEE Transactions on Signal Processing, 2016, 64(20): 5327–5339. doi: 10.1109/TSP.2016.2597121

SUN Ying, BABU P, and PALOMAR D P. Majorization-minimization algorithms in signal processing, communications, and machine learning[J]. IEEE Transactions on Signal Processing, 2017, 65(3): 794–816. doi: 10.1109/TSP.2016.2601299

HORN R A and JOHNSON C R. Matrix Analysis[M]. Cambridge: Cambridge University Press, 2013: 495–497.

LANDAU H J. The classical moment problem: Hilbertian proofs[J]. Journal of Functional Analysis, 1980, 38(2): 255–272. doi: 10.1016/0022-1236(80)90065-8

STOICA P and MOSES R L. Spectral Analysis of Signals[M]. Upper Saddle River, NJ: Pearson Prentice Hall, 2005: 172–177.

YANG Zai and XIE Lihua. Enhancing sparsity and resolution via reweighted atomic norm minimization[J]. IEEE Transactions on Signal Processing, 2016, 64(4): 995–1006. doi: 10.1109/TSP.2015.2493987

FERNANDEZGRANDA C. Super-resolution of point sources via convex programming[C]. IEEE International Workshop on Computational Advances in Multi-Sensor Adaptive Processing, Cancun, Mexico, 2015: 41–44.

CANDES E J and FERNANDEZ-GRANDA C. Towards a mathematical theory of super-resolution[J]. Communications on Pure and Applied Mathematics, 2014, 67(6): 906–956. doi: 10.1002/cpa.v67.6

STURM J F. Using SeDuMi 1.02, a MATLAB toolbox for optimization over symmetric cones[J]. Optimization Methods and Software, 1999, 11(1/4): 625–653. doi: 10.1080/10556789908805766

TOH K C, TODD M J, and TUTUNCU R H. SDPT3—A Matlab software package for semidefinite programming, Version 1.3[J]. Optimization Methods and Software, 1999, 11(1/4): 545–581. doi: 10.1080/10556789908805762

STURM J F. Implementation of interior point methods for mixed semidefinite and second order cone optimization problems[J]. Optimization Methods and Software, 2002, 17(6): 1105–1154. doi: 10.1080/1055678021000045123

STOICA P and NEHORAI A. Performance study of conditional and unconditional direction-of-arrival estimation[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1990, 38(10): 1783–1795. doi: 10.1109/29.60109
