基于最大時域瞬態噪聲的去耦電容選擇方法

劉洋; 白鈺杰; 羅厚興; 夏建強

doi:10.11999/JEIT170210

基于最大時域瞬態噪聲的去耦電容選擇方法

doi: 10.11999/JEIT170210

基金項目:

國家自然科學基金項目(61501345)，中央高?；究蒲袠I(yè)務費(JB150212)

計量
- 文章訪問數: 1408
- HTML全文瀏覽量: 130
- PDF下載量: 161
- 被引次數: 0
出版歷程
- 收稿日期: 2017-03-07
- 修回日期: 2017-07-10
- 刊出日期: 2017-11-19

Decoupling Capacitor Selection Method Based on Maximum Time-domain Transient Noise

Funds:

The National Natural Science Foundation of China (61501345), The Fundamental Research Funds for the Central Universities of China (JB150212)

摘要

摘要: 針對傳統的基于頻域目標阻抗的去耦電容選擇方法存在過度設計的問題，該文提出基于最大時域瞬態噪聲的去耦電容選擇方法。首先，利用板級電流可由一系列三角脈沖近似合成這一性質，推導出了去耦電容瞬態電壓噪聲達到局部最大值的時刻及時域瞬態阻抗應該滿足的條件，并通過分析VRM支路最大瞬態電壓噪聲確定了去耦電容的去耦時間范圍；其次，通過研究去耦電容時域瞬態阻抗曲線的性質和特點，制定了去耦電容的選擇標準。最后，提出基于最大時域瞬態噪聲的去耦設計方案。通過對4個具有典型激勵輸入的實例進行去耦設計，結果表明，在輸入激勵條件相同且滿足電壓噪聲要求的前提下，與傳統頻域目標阻抗法獲得的去耦方案相比，該文提出的算法所需電容數量至少能減少24.59%以上。
- 集成電路 /
- 最大時域瞬態噪聲 /
- 時域瞬態阻抗 /
- 時域去耦范圍
Abstract: A decoupling capacitor selection method based on maximum time-domain transient noise is proposed to solve the over-design problem caused by the traditional method based on the frequency-domain target impedance. According to the property that the current in board level can be approximated by a series of triangular pulses, the time to reach the decoupling capacitor's local maximum transient voltage noise and the condition which should be satisfied for the time-domain transient impedance are derived. Meanwhile, the time range of decoupling is determined by analyzing the maximum transient voltage noise of VRM branch. In addition, the selection criteria for the decoupling capacitors are developed by researching the properties and characteristics of the time-domain transient impedance curves of the decoupling capacitors. Finally, the decoupling design scheme based on the maximum time-domain transient noise is proposed. Comparing with the traditional frequency-domain decoupling scheme, the results of decoupling design for four examples with typical stimulus settings show that the quantity of capacitors can be reduced by more than 24.59% by the proposed algorithm under the condition of the same input excitation and satisfying the requirement of voltage noise.
- Integrated Circuit (IC) /
- Maximum time-domain transient noise /
- Time-domain transient impedance /
- Time-domain decoupling range

HTML全文

參考文獻(17)

YAO Shengpeng, LI Chunlai, TENG Yun, et al. Research on reactive power and voltage optimization control method based on active distribution network[C]. 2016 International Conference on Smart City and Systems Engineering (ICSCSE), Hunan, 2016: 435-438. doi: 10.1109/ICSCSE.2016. 0121.

YANG Hong, LI Gengfeng, ZENG Fangdi, et al. Researches on the optimization model and strategies against low voltage in power distribution network[C]. 2016 IEEE PES Asia- Pacific Power and Energy Engineering Conference (APPEEC), Xi,an, 2016: 435-438. doi: 10.1109/APPEEC. 2016.7779902.

BOUAKRA A and FOUAD S H. Voltage regulation of power distribution networks interconnected with a decentralized photovoltaic power producer[C]. 2016 3rd International Conference on Renewable Energies for Developing Countries (REDEC), Berlin, 2016: 1-6. doi: 10.1109/ICSCSE.2016. 0121.

CHOI J Y and SWAMINATHAN M. Decoupling capacitor placement in power delivery networks using MFEM[J]. IEEE Transactions on Components, Packaging and Manufacturing Technology, 2011, 1(10): 1651-1661. doi: 0.1109/TCPMT. 2011.2165954.

GUANG Chen. Challenges and solutions for core power distribution network designs[J]. IEEE Electromagnetic Compatibility Magazine, 2016, 5(4): 104-111. doi: 10.1109/ MEMC.2016.7866247.

KIM Y W, KIM K Y, CHOI J Y, et al. Power distribution network design and optimization based on frequency dependent target impedance[C]. 2015 IEEE Electrical Design of Advanced Packaging and Systems Symposium (EDAPS), Seoul, 2015: 39-92. doi: 10.1109/EDAPS.2015.7383675.

YOON J and KIM J. A slope and amplitude controllable triangular-current generator for the injection of a broad-band PDN noise[J]. IEEE Electromagnetic Compatibility Magazine, 2016, 5(4): 112-116. doi: 0.1109/TCPMT.2011.2165954.

KIM J, WU S P, WANG H F, et al. Improved target impedance and IC transient current measurement for power distribution network design[C]. 2010 IEEE International Symposium on Electromagnetic Compatibility (EMC), Fort Lauderdale, 2010: 445-450. doi: 10.1109/ISEMC.2010. 5711316.

LIU Yang, YUAN Yuzhang, CHEN Kongqian, et al. Decoupling capacitors selection algorithm based on maximum anti-resonance points and quality factor of capacitor[J]. Electronics Letters, 2015, 51(1): 90-92. doi: 10.1049/el.2014.2236.

LI Xingming and HU Shanqing. Power distribution network design from charge delivery perspective[J]. Electromagnetic Compatibility Magazine, 2014, 3(4): 55-58. doi: 10.1109/ MEMC.2014.7023199.

SMITH L D and LEE J. Power distribution system for JEDEC DDR2 memory DIMM[C]. Electrical Performance of Electronic Packages (EPEP), Princeton N.J, 2003: 121-124. doi: 10.1109/EPEP.2003.1250013.

ARCHAMBEAULT B and CONNOR S. The effect of decoupling capacitor distance on printed circuit boards using both frequency and time domain analysis[C]. IEEE International Symposium on Electromagnetic Compatibility, Chicago, 2005: 650-654. doi: 10.1109/ISEMC.2005.1513594.

DREWNIAK J L. Comparing time-domain and frequency domain techniques for investigation on charge delivery and power-bus noise for high-speed printed circuit boards[OL]. http: //design.iconnect007.com/index.php/article/19600/ comparing-time-domain-and-frequency-domain-techniques

for-investigation-on-charge-delivery-and-power-bus-noise-for-high-speed-printed-circuit-boards/19603/?skin=design, 2016.

ZHANG Mushui, LI Yushan, LI Liping, et al. An efficient power-delivery method for the design of the power distribution networks for high-speed digital systems[J]. IEEE Transactions on Microwave Theory and Techniques, 2009, 57(3): 693-707. doi: 10.1109/TMTT.2009.2013308.

ZHANG Mushui, TAN Hongzhou, and MAO Junfa. New power distribution network design method for digital systems using time-domain transient impedance[J]. IEEE Transactions on Components Packaging and Manufacturing Technology, 2013, 3(3): 1399-1408. doi: 10.1109/TCPMT. 2013.2261932.

JIN Hanbiao, LI Erping, ALBERT E, et al. Time domain PDN noise modeling for high performance system[C]. 2016 IEEE 25th Conference on Electrical Performance of Electronic Packaging and Systems (EPEPS), San Diego, 2016: 61-64. doi: 10.1109/EPEPS.2016.7835418.
