超高頻射頻識別小間隔雙標簽天線增益特性研究

彭章友; 任秀方; 孟春陽; 李帥

doi:10.11999/JEIT141371

超高頻射頻識別小間隔雙標簽天線增益特性研究

doi: 10.11999/JEIT141371

基金項目:

上海市科學技術委員會(12510500600)

計量
- 文章訪問數: 1134
- HTML全文瀏覽量: 120
- PDF下載量: 473
- 被引次數: 0
出版歷程
- 收稿日期: 2014-10-27
- 修回日期: 2015-01-08
- 刊出日期: 2015-07-19

Study on Gain Characteristics of Dual Ultra-high-frequency Radio Frequency Identification Tag Antennas with Small Interval

摘要

摘要: 該文針對超高頻射頻識別(UHF RFID)標簽自身參數和標簽間互相耦合對標簽天線增益的影響，推導了相應的理論模型。首先從輻射場的角度將標簽等效為帶集總負載的對稱振子天線，然后基于對稱振子天線陣列的理論建立了小間隔雙標簽天線增益的簡化模型，并對密集多標簽應用場合進行了簡單拓展，仿真研究驗證了所建模型的有效性。最后對增益的方向性和輻射效率進行了研究，研究結果對密集標簽的性能研究具有一定的指導意義。
- 天線 /
- 射頻識別 /
- 密集標簽 /
- 互相耦合
Abstract: Parameters of the Ultra-High-Frequency Radio Frequency IDentification (UHF RFID) tags and the mutual coupling effect have great impact on antenna gain, and a corresponding theoretical model is developed. Firstly, from the perspective of the radiation field, the tag is equivalent to dipole antenna with lumped load. Then based on the theory of dipole array, a simplified gain model of dual tag antennas with small interval is derived, and application of multiple tags is expanded simply. The simulation results show that the model is effective. Finally, the directivity and radiation efficiency are studied. The results provide a theoretical guidance for the research of intensive tags performance.
- Antenna /
- Radio Frequency IDentification (RFID) /
- Intensive tags /
- Mutual coupling

HTML全文

參考文獻(19)

Dobkin D M and Weigand S M. UHF RFID and tag antenna scattering part I: experimental results-first in a two-part series on the use of radio frequency communications to identify physical objects in the commercial supply chain[J]. Microwave Journal, 2006, 49(5): 170-190.

Choi J S, Kang M, Elmasri R, et al.. Investigation of impact factors for various performances of passive UHF RFID system[C]. IEEE International Conference on RFID- Technologies and Applications, Sitges, Spain, 2011: 152-159.

Asl S E, Ghasr M T, Zawodniok M, et al.. Preliminary study of mutual coupling effect on a passive RFID antenna array [C]. IEEE International Instrumentation and Measurement Technology Conference, Minneapolis, USA, 2013: 138-141.

Jain A and Harish A R. Performance study of RFID tags placed on metallic cylinders[C]. IEEE-APS Topical Conference on Antennas and Propagation in Wireless Communications, Torino, Italy, 2013: 1052-1055.

Johnson J and Sainati R. Investigation of UHF RFID tag backscatter[C]. IEEE Antennas and Propagation Society International Symposium, Honolulu, USA, 2007: 2753-2756.

Dobkin D M and Weigand S M. UHF RFID and tag antenna scattering, part II: theory[J]. Microwave Journal, 2006, 49(6): 86-96.

Weigand S M and Dobkin D M. Multiple RFID tag plane array effects[C]. IEEE Antennas and Propagation Society International Symposium, Albuquerque, USA, 2006: 1027-1030.

佐磊, 何怡剛, 李兵, 等. 標簽密集環境下天線互偶效應研究[J]. 物理學報, 2013, 62(4): 1021-1029.

Zuo Lei, He Yi-gang, Li Bing, et al.. Theory and measurement for mutual coupling effect of ultra high frequency radio- frequency identification in dense environments[J]. Acta Physica Sinica, 2013, 62(4): 1021-1029.

Lu F, Chen X S, and Ye T T. Performance analysis of stacked RFID tags[C]. IEEE International Conference on RFID, Orlando, USA, 2009: 330-337.

鐘順時. 天線理論與技術[M]. 北京: 電子工業出版社, 2011: 83-85.

Zhong Shun-shi. Antenna theory and technology[M]. Beijing: Electronic Industry Press, 2011: 83-85.

Lagunes-Aranda L F, Carrion-Rivera L E, Zamora-Mejia G, et al.. Improvement in read range of an UHF RFID newborn hospital monitoring system using meander line antennas[C]. IEEE Colombian Conference on Communications and Computing, Bogota, Colombia, 2014: 1-6.

Ma Z L, Jiang L J, Xi J, et al.. A single-layer compact HF-UHF dual-band RFID tag antenna[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11: 1257-1260.

Endo T, Sunahara Y, Satoh S, et al.. Resonant frequency and radiation efficiency of meander line antennas[J]. Electronics and Communications in Japan (Part II: Electronics), 2000, 83(1): 52-58.

Bjorninen T, Sydanheimo L, Ukkonen L, et al.. Advances in antenna designs for UHF RFID tags mountable on conductive items[J]. IEEE Antennas and Propagation Magazine, 2014, 56(1): 79-103.

Sun X B, Xie J, and Cao M Y. RFID tag antenna design based on an improved coupling source shape[J]. IEEE Antennas and Wireless Propagation Letters, 2013, 12: 532-534.

Son H W and Pyo C S. Design of RFID tag antennas using an inductively coupled feed[J]. Electronics Letters, 2005, 41(18): 994-996.

Klair D K, Chin K W, and Raad R. A survey and tutorial of RFID anti-collision protocols[J]. IEEE Communications Surveys Tutorials, 2010, 12(3): 400-421.
