基于互相關協方差矩陣的改進多重信號分類高分辨波達方位估計方法

毛琳琳; 張群飛; 黃建國; 史文濤; 韓晶

doi:10.11999/JEIT141208

基于互相關協方差矩陣的改進多重信號分類高分辨波達方位估計方法

doi: 10.11999/JEIT141208

基金項目:

國家自然科學基金(61271415)

計量
- 文章訪問數: 1600
- HTML全文瀏覽量: 137
- PDF下載量: 704
- 被引次數: 0
出版歷程
- 收稿日期: 2014-09-17
- 修回日期: 2015-04-16
- 刊出日期: 2015-08-19

Improved Multiple Signal Classification Algorithm for Direction of Arrival Estimation Based on Covariance Matrix of Cross-correlation

摘要

摘要: 針對經典高分辨波達方位(DOA)估計方法在低信噪比下分辨性能較差的問題，該文提出一種適用于主動探測系統的基于互相關矩陣的改進多重信號分類(MUSIC)高分辨方位估計方法(I-MUSIC)。該方法首先利用主動聲吶發射信號已知的特性，將發射信號與陣元接收信號進行互相關，利用互相關序列形成新的空域協方差矩陣，再進行特征分解。理論分析表明，互相關處理在抑制噪聲的同時保留了陣元之間的相位信息，可以得到比MUSIC方法更準確的子空間劃分，進而提高低信噪比方位估計性能。在此基礎上，提出一種基于相關時間門限的改進MUSIC高分辨方位估計(T-MUSIC)方法，通過對互相關序列設置時間門限進一步提高方位估計信噪比。仿真結果表明，與MUSIC方法相比，I-MUSIC與T-MUSIC可以分別使低信噪比時的估計性能提高3 dB和6 dB，相應平均估計誤差分別為原方法的77%和53%。在陣元間接收噪聲存在相關性時，T-MUSIC與I-MUSIC方法相比可獲得8 dB的估計增益，估計性能更優。I-MUSIC與T-MUSIC應用于多目標主動探測，可大幅提高探測系統在低信噪比下的方位估計性能。
- 信號處理 /
- 波達方位估計 /
- 互相關 /
- 協方差矩陣 /
- 多重信號分類
Abstract: In view of the poor performance of traditional Direction of Arrival (DOA) methods at low signal-to-noise ratios, an improved MUltiple SIgnal Classification (MUSIC) algorithm for DOA estimation applied to active detection system based on covariance matrix decomposition of cross-correlation (I-MUSIC) is proposed. Exploiting the transmission feature of active sonar, cross-correlation sequence between the transmitted signal and the array output is formulated. The spatial covariance matrix is then constructed from the sequence. Then matrix decomposition is implemented over the new spatial covariance matrix to estimate the DOA. It is proved that cross-correlation can suppress noise while preserving the phase information between array elements, which facilitate the subspace separation at low SNRs. Furthermore, another novel method based on correlation Time threshold (T-MUSIC) is proposed to further improve the DOA performance. Simulation results indicate that I-MUSIC and T-MUSIC can obtain a performance gain of 3 dB and 6 dB, with the estimate error being 77% and 53% of the original method respectively. Due to data selection via time threshold, T-MUSIC is not appreciably affected by noise, and thus outperforms IM-MUISC for 8 dB at low SNRs. I-MUSIC and T-MUSIC can improve the DOA performance at low SNRs significantly if applied to active multi-target detection system.
- Signal processing /
- Direction of Arrival (DOA) estimation /
- Cross-correlation /
- Covariance matrix /
- MUltiple SIgnal Classification (MUSIC)

HTML全文

參考文獻(23)

Cheng Q, Lei H, and So H C. Improved unitary root-MUSIC for DOA estimation based on pseudo-noise resampling[J]. IEEE Signal Processing Letters, 2014, 21(2): 140-144.

Zeng W, So C and Lei H. lp-MUSIC: Robust direction-of- arrival estimator for impulsive noise environments[J]. IEEE Transactions on Signal Processing, 2013, 61(17): 4296-4308.

Vincent F, Besson O, and Chaumette E. Approximate maximum likelihood direction of arrival estimation for two closely spaced sources[C]. Proceedings of the 2013 IEEE 5th International Workshop on Computational Advances in Multi-Sensor Adaptive Processing (CAMSAP), St. Martin, France, 2013: 320-323.

Heidenreich P and Zoubir M. Fast maximum likelihood DOA estimation in the two-target case with applications to automotive radar[J]. Signal Processing, 2013, 93(12): 3400-3409.

Lee Y, Hudson E, and Yao K. Acoustic DOA estimation: an approximate maximum likelihood approach[J]. IEEE Systems Journal, 2014, 8(1): 131-141.

Park S, Choi H, Yang W, et al.. Direction of arrival estimation using weighted subspace fitting with unknown number of signal sources[C]. Proceedings of the 11th International Conference on Advanced Communication Technology, Piscataway, USA, 2009: 2295-2298.

Wang H, Kay S, and Saha S. An importance sampling maximum likelihood direction of arrival estimator[J]. IEEE Transactions on Signal Processing, 2008, 56(10): 5082-5092.

Li X and Huang J. Bayesian high resolution DOA estimator based on importance sampling[C]. Proceedings of IEEE Oceans 2005, Washington, D.C., USA, 2005, 1: 611-615.

Shi W, Huang J, and Hou Y. Fast DOA estimation algorithm for MIMO sonar based on ant colony optimization[J]. Journal of Systems Engineering and Electronics, 2012, 23(2): 173-178.

Yan F G, Jin M, and Qiao X L. Source localization based on symmetrical MUSIC and its statistical performance analysis[J]. Science China Information Sciences, 2013, 56(6): 1-13.

Di C, Elio D, and Giovanni J. Wideband source localization by space-time MUSIC subspace estimation[C]. Proceedings of 2013 8th International Symposium on Image and Signal Processing and Analysis (ISPA), Trieste, Italy, 2013: 331-336.

Choi W and Sarkar K. Minimum norm property for the sum of the adaptive weights for a direct data domain least squares algorithm[J]. IEEE Transactions on Antennas and Propagation, 2006, 54(3): 1045-1050.

Rangarao V and Venkatanarasimhan S. Gold-MUSIC: a variation on music to accurately determine peaks of the spectrum[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(4): 2263-2268.

Yan F, Jin M, and Qiao X. Low-complexity DOA estimation based on compressed MUSIC and its performance analysis[J]. IEEE Transactions on Signal Processing, 2013, 61(8): 1915-1930.

Reddy V, Ng B, and Khong A. Insights into MUSIC-like algorithm[J]. IEEE Transactions on Signal Processing, 2013, 61(10): 2551-2556.

Ying Z and Boon P. MUSIC-like DOA estimation without estimating the number of sources[J]. IEEE Transactions on Signal Processing, 2010, 58(3): 1668-1676.

Azaria M and Hertz D. Time delay estimation by generalized cross- correlation methods[J]. IEEE Transactions on Acoustics, Speech and Signal Processing, 1984, 32(2): 280-285.

Benesty J, Jingdong C, and Yiteng H. Time-delay estimation via linear interpolation and cross correlation[J]. IEEE Transactions on Speech and Audio Processing, 2004, 12(5): 509-519.

Pertil? P, Korhonen T, and Visa A. Measurement combination for acoustic source localization in a room environment[J]. EURASIP Journal on Audio, Speech, and Music Processing, 2008, 3: 1-14.

Dermatas S, Fakotakis D, and Kokkinakis K. Fast endpoint detection algorithm for isolated word recognition in office environment[C]. Proceedings of IEEE International Conference on Acoustics, Speech and Signal Processing, Toronto, Canada, 1991：733-736.

郭勝楠, 崔慧娟, 唐昆. 低信噪比下基于短時譜估計的語音增強[J]. 清華大學學報(自然科學版), 2010, 50(1): 149-152.

Guo Sheng-nan, Cui Hui-juan, and Tang Kun. Speech enhancement based on short time spectral amplitude estimates in low SNR[J]. Journal of Tsinghua University (Science and Technology), 2010, 50(1): 149-152.

李志舜. 魚雷自導信號與信息處理[M]. 西安: 西北工業大學出版社, 2004: 138-144.
