雙模曲折懸置帶線環四極微波濾波器
4-pole microwave filters using dual-mode meander suspensive strip line loop resonators
-
摘要: 該文研制了雙模曲折懸置帶線環四極微波濾波器。采用全波技術對該種濾波器特性進行的計算表明,它具有優良的窄通帶、高選擇性和小體積,與同類型二極濾波器相比,過渡帶更陡峭。采用優化設計方法設計出了濾波器電路尺寸,制造了以r=2.8的Teflon為介質基片的濾波器,測試得到的雙模曲折懸置帶線四極濾波器的中心頻率為f0=1.194 GHz,△f=19.4 MHz,通帶插入損耗LP4.3 dB,阻帶衰減Ls50 dB,實驗結果和CAD預測作了比較,兩者基本一致。這種濾波器可望在多種微波系統和移動通信系統中應用。
-
關鍵詞:
- 雙模曲折懸置線環濾波器; 平面微波濾波器; 微波濾波器
Abstract: The 4-pole microwave filters using dual-mode meander suspensive strip line loop resonators have been developed. The results of the full wave analysis of the filters have shown that 4-pole filters have better performance than the 2-pole fiilters of same type. A 4-pole filter of this type on r= 2.8 Teflon substrate having a bandwidth △f=19.4MHz at the central frequency f0 = 1.194GHz was designed and fabricated. The measured filter performance was compared with the prediction of CAD tool. The agreement was found to be good. -
J. A. Curtis, S. J. Fiedziuszko, Miniature dual-mode microstrip filters, IEEE 1991 MTT-S Dig.,443-446.[2]J. S. Hong, M.J. Lancaster, Bandpass characteristics of new dual-mode microstrip square loop resonators, Electron. Lett., 1995, 31(11), 891-892.[3]J.S. Hong, M. J. Lancaster, Microstrip bandpass filters using degenerate modes of a novel meander loop resonator, IEEE Microwave and Guided Wave Lett., 1995, 5(11), 371-372..[4]Z.M. Hejazi, P. S. Excell, Z. Jiang, Compact dual-mode filters for HTS Satellite systems, IEEE Microwave ＆ Guided Lett., 1998, 8(8), 275 277.[5]姜遵富,Z.M Hejazi,P S.Excell,新型高溫超導(HTS)雙模多次曲折微帶環窄帶濾波器,電子學報,2000,28(2),1-3[6]G.L. Mathau, L. Young, E. M. T. Jones, Microwave Filters, Impedance-Matching Network and Coupling Structures, Dedham, MA. Artech House, 1980, 664-665. -
