SAR分布目標多視圖像分辨特性研究

王巖飛; 劉中梅

doi:10.11999/JETI170118

SAR分布目標多視圖像分辨特性研究

doi: 10.11999/JETI170118

王巖飛¹,
劉中梅²

1.
(中國科學院電子學研究所北京 100190) ②(中國科學院大學 北京 100049)

基金項目:

國家自然科學基金(61471340)

計量
- 文章訪問數: 1411
- HTML全文瀏覽量: 189
- PDF下載量: 313
- 被引次數: 0
出版歷程
- 收稿日期: 2017-02-15
- 修回日期: 2017-04-20
- 刊出日期: 2017-10-19

Study on Distributed Targets Resolution of Multilook SAR Image

WANG Yanfei¹,
LIU Zhongmei²

1.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National Natural Science Foundation of China (61471340)

摘要

摘要: 該文提出了結合目標特性與圖像多視數對SAR分辨特性進行分析和評定的方法?；趯AR目標可分辨概率的研究，以及對SAR復散射回波信號特性的分析，得到了目標之間關于信號幅度比、相位差和多視數的聯合概率密度函數，建立了SAR分布目標可分辨特性與目標統計特性以及圖像多視數之間的數學關系模型。結合目標可區分條件，探討分析了目標統計特性和多視處理對SAR系統分辨特性的影響。從該文的研究分析可以看出，由于分布目標信號具有的隨機特性，在目標間距離小于傳統的分辨率時也存在可分辨性，目標間距離大于系統分辨率時也存在不可分辨性。多視處理相當于增加了目標間的相關性，同樣對SAR的分辨特性有較大的影響。該文提出的分辨特性評價指標將SAR系統特性與目標特性相結合，更能真實反映SAR的分辨性能，對SAR系統參數設計和評定有重要意義。
- SAR /
- 分布目標 /
- 可分辨概率 /
- 統計特性 /
- 多視處理
Abstract: A method is proposed to analyze and assess the SAR resolution, which considers the statistical characteristics of the distributed targets and the number of multi-look. The joint probability density function of two points on the amplitude radio, phase difference, correlation coefficient, and the number of multi-look is deduced from the SAR complex scattering echo signal. Based on the study of the SAR separable probability and the PDF, a mathematical model is built that reflects the mathematical relationship between the SAR resolution and the statistical properties of the targets and the number of multi-look. Considering the condition that the points can be separated, the influence that the statistical properties of SAR distributed targets and multi-look processing have on SAR resolution is discussed. From the numerical results, when the distance between targets is less than the traditional resolution, the targets also can be distinguished; and when the distance is larger than the traditional resolution, the targets may not be distinguished. The effect of multi-look processing is equivalent to increasing the relevance between the targets, and it also has great influence on SAR resolution. The separable probability can reflect the resolution performance correctly and is important for designing and evaluating the SAR system.
- SAR /
- Distributed targets /
- Resolution characteristics /
- Statistical properties /
- Multi-look processing
