一種面向AV1粗模式?jīng)Q策的高吞吐量硬件設計方法

盛慶華; 陶澤浩; 黃小芳; 賴昌材; 黃曉峰; 殷海兵; 董哲康

doi:10.11999/JEIT240823

一種面向AV1粗模式?jīng)Q策的高吞吐量硬件設計方法

doi: 10.11999/JEIT240823

1.
杭州電子科技大學電子信息學院杭州 310018
2.
杭州電子科技大學信息工程學院杭州 311305
3.
杭州電子科技大學通信工程學院杭州 310018

基金項目: 國家重點研發計劃(2023YFB4502804)

詳細信息

作者簡介:
盛慶華：男，副教授，研究方向?yàn)橐曨l編碼、FPGA硬件加速、電子系統集成等

陶澤浩：男，碩士生，研究方向?yàn)橐曨l編解碼、FPGA硬件加速等

黃小芳：女，講師，研究方向?yàn)橐曨l編碼、嵌入式應用等

賴昌材：男，高級工程師，研究方向?yàn)閳D像視頻壓縮、智能處理及其軟硬件加速實現等

黃曉峰：男，副教授，研究方向?yàn)橐曨l編解碼與芯片架構設計等

殷海兵：男，教授，研究方向?yàn)閿?shù)字視頻編解碼、多媒體信號處理、芯片結構設計驗證等

董哲康：男，副教授，研究方向?yàn)閼涀杵骷皯涀柘到y(tǒng)、人工神經網絡等

通訊作者:
黃小芳　20221016@hdu.edu.cn

中圖分類號: TN919.8
計量
- 文章訪問數: 102
- HTML全文瀏覽量: 25
- PDF下載量: 8
- 被引次數: 0
出版歷程
- 收稿日期: 2024-09-27
- 修回日期: 2025-01-02
- 網絡出版日期: 2025-01-09

A High-Throughput Hardware Design for AV1 Rough Mode Decision

1.
School of Electronic Information, Hangzhou Dianzi University, Hangzhou 310018, China
2.
School of Information Engineering, Hangzhou Dianzi University, Hangzhou 311305, China
3.
School of Communication Engineering, Hangzhou Dianzi University, Hangzhou 310018, China

Funds: The National Key R&D Program of China (2023YFB4502804)

摘要

摘要: 隨著視頻編碼標準的不斷更新迭代，開放媒體聯盟(AOM)發布最新視頻編碼標準開放媒體視頻編碼標準(AV1)。其中，幀內編碼技術采用更加豐富的預測模式來提高預測效率，預測種類從VP9中的10種擴展至61種。為了應對預測種類增加的變化并提高硬件的處理吞吐能力，該文提出基于全流水線結構的AV1粗模式?jīng)Q策硬件架構設計。在算法層面，以4×4塊為最小處理單元，按照Z(yǔ)順序?qū)?4×64編碼樹單元(CTU)中不同尺寸的預測單元(PUs)進行粗模式?jīng)Q策，同時采用基于1:1 PU的代價累加近似方法來完成1:2, 1:4, 2:1和4:1 PU的代價計算，以減少計算復雜度；在硬件層面，設計兼容4×4至32×32等多尺寸PU的粗模式?jīng)Q策電路，取代為不同尺寸PU單獨設計電路的方法，有效減少邏輯資源的閑置。實驗結果表明，在全幀內(AI)配置下，提出的改進算法相較于AV1標準算法平均節省了45.78%的時間，提高了1.94% BD-Rate。同時，提出的硬件架構設計能夠在1057個時鐘周期內完成64×64 CTU的粗模式?jīng)Q策，使用Synopsys公司的Design Compiler 2016工具及UMC 28 nm工藝庫對硬件設計綜合得到，該設計能夠在432.7 MHz工作頻率下實時處理8k@50.6fps的視頻。
- 開放媒體視頻編碼標準 /
- 幀內預測 /
- 粗模式?jīng)Q策 /
- 視頻編碼 /
- 流水線
Abstract: Objective As demand for 4K and 8K Ultra High Definition (UHD) videos increases, the latest generation of video coding standards has been developed to meet the growing need for UHD video transmission. UHD video coding requires processing more pixels and details, resulting in significant increases in computational complexity and resource consumption. Optimizing algorithms and implementing hardware acceleration are essential for achieving real-time encoding and decoding of UHD videos. In Alliance for Open Media Video 1 (AV1), richer intra-prediction modes have been introduced, expanding the number of modes from 10 in VP9 to 61, thereby increasing computational complexity. To address the added complexity of these modes and enhance hardware processing throughput, a hardware design for AV1 Rough Mode Decision (RMD) based on a fully pipelined architecture is proposed. Methods At the algorithm level, a 4×4 block is used as the minimum processing unit. RMD is applied to various sizes of Prediction Units (PUs) within a 64×64 Coding Tree Unit (CTU) following Z-order scanning. This approach allows for efficient processing of large blocks by dividing them into smaller, manageable units. To reduce computational complexity, the SATD cost calculations for different PU sizes (e.g., 1:2, 1:4, 2:1, and 4:1) are performed using a cost accumulation approximation method based on the 1:1 PU. This method minimizes the need to recalculate costs for every possible configuration, thus improving efficiency and reducing computational load. At the hardware level, the architecture supports RMD for PUs of various sizes (4×4 to 32×32) within a 64×64 CTU. This architecture differs from traditional designs, which use separate circuits for each PU size. It optimizes logical resource use and minimizes downtime. The design incorporates a 28-stage pipeline that enables parallel processing of intra-prediction modes, ensuring RMD for at least 16 pixels per clock cycle and significantly enhancing throughput and encoding efficiency. Additionally, the design emphasizes circuit compatibility and reusability across various PU sizes, reducing redundancy and maximizing hardware resource utilization. Results and Discussions Software analysis shows that the proposed AV1 coarse mode decision algorithm reduces processing time by an average of 45.78% compared to the standard AV1 algorithm under the All-Intra (AI) configuration, while achieving a 1.94% improvement in BD-Rate. The testing platform is an Intel(R) Core(TM) i9-9900K CPU @ 3.60 GHz with 16.0 GB of DRAM. Compared to existing methods, the algorithm significantly reduces processing time while maintaining encoding efficiency. It offers an optimized trade-off, with a slight BD-Rate loss in exchange for substantial reductions in encoding time. Hardware analysis reveals that the proposed hardware architecture has a total circuit area of 0.556 mm2 after synthesis, with a maximum operating frequency of 432.7 MHz, enabling real-time encoding of 8k@50.6fps video. Although the circuit area is slightly larger than in existing designs, the architecture demonstrates significant improvements in processing speed and video resolution capability, providing a balanced trade-off between hardware resource usage and throughput/area efficiency. These results further confirm the design's superiority in terms of hardware resource efficiency and processing performance. Conclusions This paper presents a high-throughput hardware design for AV1 RMD, capable of processing all PU sizes with 56 directional and 5 non-directional prediction modes. The design employs a 28-stage pipeline for parallel intra-frame prediction mode processing, enabling RMD for at least 16 pixels per clock cycle and significantly improving encoding efficiency. Techniques such as false-reconstructed reference pixels, Z-order scanning, PMCM circuit structures, and circuit reuse address the increased hardware resource demands of parallel processing. Experimental results show that the proposed algorithm reduces processing time by an average of 45.78% and improves BD-Rate by 1.94% compared to the AV1 standard, ensuring high speed and encoding quality. Circuit synthesis confirms the architecture's capability for real-time 8k@50.6fps video processing, meeting the demands of future UHD video encoding with exceptional performance and efficiency.
- Alliance for Open Media Video 1 (AV1) /
- Intra prediction /
- Rough Mode Decision (RMD) /
- Video coding /
- Pipeline

HTML全文

圖 1 RMD硬件總體架構設計

下載: 全尺寸圖片幻燈片

圖 2 硬件實現RMD流程圖

下載: 全尺寸圖片幻燈片

圖 3 整體架構時空?qǐng)D

下載: 全尺寸圖片幻燈片

圖 4 4×4 PU參考像素填充情況

下載: 全尺寸圖片幻燈片

圖 5 輸入順序示意圖

下載: 全尺寸圖片幻燈片

圖 6 方向性模式硬件設計

下載: 全尺寸圖片幻燈片

圖 7 DC模式硬件設計

下載: 全尺寸圖片幻燈片

圖 8 平滑模式硬件設計

下載: 全尺寸圖片幻燈片

圖 9 平滑模式權重PMCM硬件設計

下載: 全尺寸圖片幻燈片

圖 10 Paeth模式硬件設計

下載: 全尺寸圖片幻燈片

圖 11 4×4 PU的SATD代價計算硬件設計

下載: 全尺寸圖片幻燈片

圖 12 長度為8的亂序列雙調排序示例

下載: 全尺寸圖片幻燈片

圖 13 輸入序列長度為8的雙調排序硬件設計

下載: 全尺寸圖片幻燈片

表 1 改進算法與AV1標準算法的性能比較(%)

測試序列	BD-Rate	TS
A1(UHD 4K)	2.21	49.2
A2(UHD 4K)	1.77	46.4
B(1080P)	1.93	48.1
C(480P)	2.23	38.4
E(720P)	1.56	46.8
平均結果	1.94	45.78

下載: 導出CSV

表 2 本文改進算法與現有工作比較(%)

文獻	BD-Rate	TS
[33]	1.28	29.80
[34]	7.41	50.19
[35]	0.60	15.36
本文	1.94	45.78

下載: 導出CSV

表 3 基于ASIC實現的RMD相關硬件設計工作對比

對比指標	文獻[36]	文獻[37]	文獻[38]	文獻[39]	本文
工藝	TSMC 40 nm	TSMC 40 nm	TSMC 40 nm	TSMC 40 nm	UMC 28 nm
門電路(Kgates)	455.8	821.8	584.8	128.5	1011.3
工作頻率(MHz)	1,296	1,902	1,296	648	432.7
時鐘周期(Cycle)	7104	7104	7104	7104	1057
功耗(mW)	40.9	1613.3	4110.0	65.5	1891.6
吞吐量	4k@60fps	4k@60fps	4k@60fps	4k@30fps	8k@50.6fps
吞吐量/面積(px/gate)	1091.85	605.55	850.93	1936.44	1660.03
非方向性預測	×	×	×	√	√
方向性預測	√	√	√	×	√
模式?jīng)Q策	×	×	×	×	√

下載: 導出CSV
