面向通感一體化的變分模態分解-希爾伯特-黃變換呼吸頻率感知算法

楊小龍; 張亭亭; 周牧; 高銘; 童睿軒

doi:10.11999/JEIT240640

面向通感一體化的變分模態分解-希爾伯特-黃變換呼吸頻率感知算法

doi: 10.11999/JEIT240640

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(62101085)，重慶市教委科學技術研究項目(KJQN202400647)，重慶市研究生科研創新項目(CYS240399)

詳細信息

作者簡介:
楊小龍：男，副教授，碩士生導師，研究方向為通感一體化，無線定位與感知

張亭亭：女，碩士生，研究方向為無線定位與感知

周牧：男，教授，博士生導師，研究方向為無線定位與感知，量子精密測量

高銘：女，博士生，研究方向為通感一體化

童睿軒：男，碩士生，研究方向為無線定位與感知

通訊作者:
周牧　zhoumu@cqupt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 217
- HTML全文瀏覽量: 55
- PDF下載量: 38
- 被引次數: 0
出版歷程
- 收稿日期: 2024-07-23
- 修回日期: 2024-12-11
- 網絡出版日期: 2024-12-17

Variational Mode Decomposition-Hilbert-Huang Transform Breathing Rate Sensing Algorithm for Integration of Sensing and Communication

School of Communications and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (62101085), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJQN202400647), Chongqing Graduate Student Research Innovation Project (CYS240399)

摘要

摘要: 通感一體化(ISAC)作為一種6G關鍵技術，將通信和感知功能集成到Wi-Fi設備，為室內人體呼吸頻率感知提供一種有效的方法。針對當前基于ISAC的呼吸頻率感知存在魯棒性低和“盲點”的問題，該文提出一種基于信號變分模態分解(VMD)- 希爾伯特-黃變換(HHT)呼吸頻率感知算法。首先，選擇對環境感知敏感度較強的Wi-Fi鏈路構建信道狀態信息(CSI)比值模型。其次，將濾波后的CSI比值時間序列的各子載波進行投影，結合幅相信息生成不同呼吸模式信號的候選集。再次，對于每一個子載波，根據周期性在候選集中選擇一個短期呼吸噪聲比最大的候選序列作為最終的呼吸模式，然后設置閾值選擇子載波，并對其進行VMD和HHT時頻分析，去除人體呼吸頻率成分以外的模態分量，并重構剩余模態分量。在此基礎上，利用主成分分析(PCA)對所有重構的子載波降維，選擇方差貢獻率達到99%以上的主成分分量，并使用ReliefF算法重新構建呼吸信號，得到融合信號。最后，對融合信號利用峰值檢測算法計算呼吸頻率。實驗結果表明，該感知方法在會議辦公室和走廊兩種場景下的平均估計精度超過97%，顯著提高了魯棒性并克服了“盲點”問題，優于其他現有的感知方案。
- 通感一體化 /
- 信道狀態信息 /
- 呼吸頻率 /
- Hilbert-Huang變換 /
- 變分模態分解
Abstract: Objective Breathing rate is a vital physiological indicator of human health. Abnormal changes in this rate can signify diseases like chronic obstructive pulmonary disease, sleep apnea syndrome, and nocturnal hypoventilation syndrome. Timely and accurate detection of these changes can help identify health risks early, enable professional medical intervention, and optimize treatment timing, thereby improving overall health. However, current detection methods often face limitations due to noise interference and “blind spot” issues, which impact accuracy and robustness. To address these challenges, this paper employs Wi-Fi devices to measure indoor human breathing rates using Integrated Sensing And Communication (ISAC) technology. By combining Variational Modal Decomposition (VMD) and Hilbert-Huang Transform (HHT), a new breathing rate sensing algorithm is proposed. This approach aims to enhance detection accuracy and robustness, resolve the “blind spot” problem in existing technologies, and offer an efficient and reliable solution for health monitoring. Methods Wi-Fi links with high environmental sensitivity were selected to construct the Channel State Information (CSI) ratio model. Subcarriers of the filtered CSI ratio time series were projected, and amplitude and phase information were combined to generate a candidate set of breathing mode signals. For each subcarrier, the sequence with the highest short-term breath noise ratio, determined by periodicity, was identified as the final breath pattern. A threshold was then applied to select relevant subcarriers. Time-frequency analysis using VMD and HHT eliminated modal components unrelated to the human breath rate, and the remaining components were reconstructed. Principal Component Analysis (PCA) was applied for dimensionality reduction, selecting components accounting for over 99% of the variance. The ReliefF algorithm was subsequently used to reconstruct the breath signal into a fused signal, from which the breathing rate was calculated using a peak detection algorithm. Results and Discussions Experiments were conducted in two scenarios: a conference office and a corridor. In both setups, a pair of transceivers was deployed, with a 2-meter distance maintained between the transmitter and receiver. The transmitter used one omnidirectional antenna, and the receiver had three antennas positioned perpendicular to the ground. Participants were seated on the vertical bisector of the Line Of Sight (LOS) path, synchronizing their breathing with a metronome as CSI data were recorded. Each test lasted 1 minute, with a confirmed breathing rate of 16 bpm. System parameters used in the experiments are detailed in Table 1. In the conference office scenario, this paper collected data at various distances from the participant to the transceiver. As illustrated in Figure 9, the Mean Estimation Accuracy (MEA) of our algorithm remains above 97%, even when the participant is 5 meters away. In contrast, the MEA of the other two methods drops by 4% and 5%, respectively. As the sensing distance increases, the multipath effect intensifies, leading to a gradual weakening of the reflected signal and greater noise interference. This impact significantly challenges the breathing detection accuracy of the other methods. The algorithm presented in this paper incorporates a VMD-HHT time-frequency analysis step. This enhancement allows for effective signal decomposition and feature extraction, markedly improving the accuracy of detecting the target breathing signal. Moreover, the method exhibits strong adaptability and robustness, effectively addressing noise interference and multipath effects in complex environments, thus demonstrating more stable performance. In the corridor scenario, we evaluated the algorithm's performance at varying distances. The average absolute error of the algorithm was measured with distances ranging from 2 meters to 5 meters. At 2 meters, the Mean Absolute Error (MAE) recorded was 0.37 bpm, and even at 5 meters, the MAE only increased to 0.45 bpm, remaining below 0.5 bpm. As the distance between the target and transceiver increased from 3 to 5 meters, the MAE gradually rose. This trend is attributed to the further attenuation of the signal reflected from the human target, along with the escalating multipath and signal attenuation effects in the environment. Conclusions The experimental results indicate that the MEA of this sensing method exceeds 97% in both the conference office and corridor scenarios. This effectively addresses the "blind spot" issue present in current technologies. The enhanced accuracy and robustness of the algorithm outperform existing sensing schemes. Moreover, this method broadens the application of ISAC in breathing detection and opens new avenues for developing intelligent health management systems in the future.
- Integrated Sensing And Communications (ISAC) /
- Channel State Information (CSI) /
- Breathing rate /
- Hilbert-Huang Transform (HHT) /
- Variational Mode Decomposition (VMD)

HTML全文

圖 1 Wi-Fi信號室內呼吸感知示意圖

下載: 全尺寸圖片幻燈片

圖 2 呼吸頻率感知算法系統框圖

下載: 全尺寸圖片幻燈片

圖 3 Wi-Fi鏈路選擇

下載: 全尺寸圖片幻燈片

圖 4 CSI投影圖

下載: 全尺寸圖片幻燈片

圖 5 VMD-HHT時頻分析

下載: 全尺寸圖片幻燈片

圖 6 實驗場景和設備圖

下載: 全尺寸圖片幻燈片

圖 7 步長對復雜度和精度的影響

下載: 全尺寸圖片幻燈片

圖 8 多天線收發系統實驗結果對比

下載: 全尺寸圖片幻燈片

圖 9 會議辦公室實測結果

下載: 全尺寸圖片幻燈片

圖 10 呼吸頻率測量結果CDF圖

下載: 全尺寸圖片幻燈片

圖 11 呼吸頻率誤差箱型圖

下載: 全尺寸圖片幻燈片

圖 12 5 m時10次估計值

下載: 全尺寸圖片幻燈片

圖 13 走廊場景實測結果和算法復雜度比較

下載: 全尺寸圖片幻燈片

表 1 收發機參數配置

參數	發射機	接收機
模式	Injection	Monitor
信道編號	64(5.32 GHz)
帶寬	20 MHz
發包速率	100 包/s
子載波個數	30
子載波編號	–58, –54,···, 54, 58
發射功率	15 dBm

下載: 導出CSV

參考文獻(29)

[1]	ISLAM S M M, MOLINAROA N, SILVESTRI S, et al. Respiratory feature extraction for contactless breathing pattern recognition using a single digital camera[J]. IEEE Transactions on Human-Machine Systems, 2023, 53(3): 642–651. doi: 10.1109/THMS.2023.3254895.
[2]	XIE Wangdong, GAN Liangyu, HUANG Leilei, et al. A real-time respiration monitoring system using WiFi sensing based on the concentric circle model[J]. IEEE Transactions on Biomedical Circuits and Systems, 2023, 17(2): 157–168. doi: 10.1109/TBCAS.2022.3229435.
[3]	YEO M, BYUN H, LEE J, et al. Robust method for screening sleep apnea with single-lead ECG using deep residual network: Evaluation with open database and patch-type wearable device data[J]. IEEE Journal of Biomedical and Health Informatics, 2022, 26(11): 5428–5438. doi: 10.1109/JBHI.2022.3203560.
[4]	余永程, 楊華榮, 鄭江環, 等. 多導睡眠呼吸監測的應用與效果研究[J]. 貴州醫藥, 2018, 42(3): 361–362. YU Yongcheng, YANG Huarong, ZHENG Jianghuan, et al. Study on the application and effect of polysomnographic sleep apnea monitoring[J]. Guizhou Medical Journal, 2018, 42(3): 361–362.
[5]	HUANG Xude, TANG Jinbu, LUO Jingchun, et al. A wearable functional near-infrared spectroscopy (fNIRS) system for obstructive sleep apnea assessment[J]. IEEE Transactions on Neural Systems and Rehabilitation Engineering, 2023, 31: 1837–1846. doi: 10.1109/TNSRE.2023.3260303.
[6]	NGUYEN P, ZHANG Xinyu, HALBOWER A, et al. Continuous and fine-grained breathing volume monitoring from afar using wireless signals[C]. The 35th Annual IEEE International Conference on Computer Communications, San Francisco, USA, 2016: 1–9. doi: 10.1109/INFOCOM.2016.7524402.
[7]	ADIB F, MAO Hongzi, KABELAC Z, et al. Smart homes that monitor breathing and heart rate[C]. The 33rd Annual ACM Conference on Human Factors in Computing Systems, Seoul, Republic of Korea, 2015: 837–846. doi: 10.1145/2702123.2702200.
[8]	HOU Yuxiao, WANG Yawen, and ZHENG Yuanqing. TagBreathe: Monitor breathing with commodity RFID systems[C]. 2017 IEEE 37th International Conference on Distributed Computing Systems (ICDCS), Atlanta, USA, 2017: 404–413. doi: 10.1109/ICDCS.2017.76.
[9]	ABDELNASSER H, HARRAS K A, and YOUSSEF M. UbiBreathe: A ubiquitous non-invasive WiFi-based breathing estimator[C]. The 16th ACM International Symposium on Mobile Ad Hoc Networking and Computing, Hangzhou, China, 2015: 277–286. doi: 10.1145/2746285.2755969.
[10]	ZHAO Zhe, LIU Ruiqi, and LI Junqiang. Integrated sensing and communication based breath monitoring using 5G network[C]. 2023 International Wireless Communications and Mobile Computing (IWCMC), Marrakesh, Morocco, 2023: 43–47. doi: 10.1109/IWCMC58020.2023.10182512.
[11]	LIU Fan, CUI Yuanhao, MASOUROS C, et al. Integrated sensing and communications: Toward dual-functional wireless networks for 6G and beyond[J]. IEEE Journal on Selected Areas in Communications, 2022, 40(6): 1728–1767. doi: 10.1109/JSAC.2022.3156632.
[12]	KIM K, KIM J, and JOUNG J. A survey on system configurations of integrated sensing and communication (ISAC) systems[C]. 2022 13th International Conference on Information and Communication Technology Convergence (ICTC), Jeju Island, Korea, 2022: 1176–1178. doi: 10.1109/ICTC55196.2022.9952602.
[13]	YANG Xiaolong, CAO Ruoyu, ZHOU Mu, et al. Temporal-frequency attention-based human activity recognition using commercial WiFi devices[J]. IEEE Access, 2020, 8: 137758–137769. doi: 10.1109/ACCESS.2020.3012021.
[14]	YANG Runming, YANG Xiaolong, WANG Jiacheng, et al. Decimeter level indoor localization using WiFi channel state information[J]. IEEE Sensors Journal, 2022, 22(6): 4940–4950. doi: 10.1109/JSEN.2021.3067144.
[15]	YANG Xiaolong, LI Quanchen, ZHOU Mu, et al. Phase-calibration-based 3-D beamspace matrix pencil algorithm for indoor passive positioning and tracking[J]. IEEE Sensors Journal, 2023, 23(17): 19670–19683. doi: 10.1109/JSEN.2023.3295370.
[16]	LIU Xuefeng, CAO Jiannong, TANG Shaojie, et al. Wi-sleep: Contactless sleep monitoring via WiFi signals[C]. 2014 IEEE Real-Time Systems Symposium, Rome, Italy, 2014: 346–355. doi: 10.1109/RTSS.2014.30.
[17]	LIU Jian, WANG Yan, CHEN Yingying, et al. Tracking vital signs during sleep leveraging off-the-shelf WiFi[C]. Proceedings of the 16th ACM International Symposium on Mobile Ad Hoc Networking and Computing, Hangzhou, China, 2015: 267–276. doi: 10.1145/2746285.2746303.
[18]	ZENG Youwei, WU Dan, GAO Ruiyang, et al. FullBreathe: Full human respiration detection exploiting complementarity of CSI phase and amplitude of WiFi signals[J]. Proceedings of the ACM on Interactive, Mobile, Wearable and Ubiquitous Technologies, 2018, 2(3): 148. doi: 10.1145/3264958.
[19]	ZENG Youwei, WU Dan, XIONG Jie, et al. FarSense: Pushing the range limit of WiFi-based respiration sensing with CSI ratio of two antennas[J]. Proceedings of the ACM on Interactive, Mobile, Wearable and Ubiquitous Technologies, 2019, 3(3): 121. doi: 10.1145/3351279.
[20]	YU Xin, YANG Xiaolong, ZHOU Mu, et al. Wi-breath: Monitoring sleep state with Wi-Fi devices and estimating respiratory rate[C]. The 9th International Conference on Communications, Signal Processing, and Systems, Singapore, 2021: 839–842. doi: 10.1007/978-981-15-8411-4_111.
[21]	WANG Hao, ZHANG Daqing, MA Junyi, et al. Human respiration detection with commodity WiFi devices: Do user location and body orientation matter?[C]. Proceedings of the 2016 ACM International Joint Conference on Pervasive and Ubiquitous Computing, Heidelberg, Germany, 2016: 25–36. doi: 10.1145/2971648.2971744.
[22]	WANG Wei, LIU A X, SHAHZAD M, et al. Device-free human activity recognition using commercial WiFi devices[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(5): 1118–1131. doi: 10.1109/JSAC.2017.2679658.
[23]	YANG Jieming, LIU Yanming, LIU Zhiying, et al. A framework for human activity recognition based on WiFi CSI signal enhancement[J]. International Journal of Antennas and Propagation, 2021, 2021: 6654752. doi: 10.1155/2021/6654752.
[24]	LI Xiang, LI Shengjie, ZHANG Daqing, et al. Dynamic-MUSIC: Accurate device-free indoor localization[C]. The 2016 ACM International Joint Conference on Pervasive and Ubiquitous Computing, Heidelberg, Germany, 2016: 196–207. doi: 10.1145/2971648.2971665.
[25]	HALPERIN D, HU Wenjun, SHETH A, et al. Tool release: Gathering 802.11n traces with channel state information[J]. ACM SIGCOMM Computer Communication Review, 2011, 41(1): 53. doi: 10.1145/1925861.1925870.
[26]	WU Dan, ZHANG Daqing, XU Chenren, et al. WiDir: Walking direction estimation using wireless signals[C]. The 2016 ACM International Joint Conference on Pervasive and Ubiquitous Computing, Heidelberg, Germany, 2016: 351–362. doi: 10.1145/2971648.2971658.
[27]	YUE Shichao, HE Hao, WANG Hao, et al. Extracting multi-person respiration from entangled RF signals[J]. Proceedings of the ACM on Interactive, Mobile, Wearable and Ubiquitous Technologies, 2018, 2(2): 86. doi: 10.1145/3214289.
[28]	陶凱, 吳定會. 基于VMD-JAYA-LSSVM的短期風電功率預測[J]. 控制工程, 2021, 28(6): 1143–1149. doi: 10.14107/j.cnki.kzgc.20190288. TAO Kai and WU Dinghui. Short-term wind power prediction based on VMD-JAYA-LSSVM[J]. Control Engineering of China, 2021, 28(6): 1143–1149. doi: 10.14107/j.cnki.kzgc.20190288.
[29]	ZHUO Hongyang, WU Xianda, ZHONG Qinghua, et al. Position-free breath detection during sleep via commodity WiFi[J]. IEEE Sensors Journal, 2023, 23(20): 24874–24884. doi: 10.1109/JSEN.2023.3309839.
