智能反射面輔助的環境反向散射通信系統信道估計算法研究

徐勇軍; 邱友靜; 張海波

doi:10.11999/JEIT240395

智能反射面輔助的環境反向散射通信系統信道估計算法研究

doi: 10.11999/JEIT240395

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(62271094, U23A20279)，重慶市自然科學基金重點項目(CSTB2022NSCQ-LZX0009, CSTB2023NSCQ-LZX0079)，重慶市教委科技重點項目(KJZD-K202200601)

詳細信息

作者簡介:
徐勇軍：男，教授，博士生導師，研究方向?yàn)榉聪蛏⑸渫ㄐ?、智能反射面、信道估?jì)、資源分配等

邱友靜：女，碩士生，研究方向?yàn)榉聪蛏⑸渫ㄐ?、智能反射面、信道估?jì)等

張海波：男，副教授，碩士生導師，研究方向?yàn)橘Y源分配、反向散射通信、車聯網等

通訊作者:
徐勇軍　xuyj@cqupt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 248
- HTML全文瀏覽量: 53
- PDF下載量: 46
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-20
- 修回日期: 2024-11-15
- 網絡出版日期: 2024-12-12
- 刊出日期: 2025-01-31

Channel Estimation for Intelligent Reflecting Surface Assisted Ambient Backscatter Communication Systems

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (62271094, U23A20279), The Key Fund of Natural Science Foundation of Chongqing (CSTB2022NSCQ-LZX0009, CSTB2023NSCQ-LZX0079), The Scientific and Technological Research Program of Chongqing Municipal Education Commission (KJZD-K202200601)

摘要

摘要: 環境反向散射通信(AmBC)是一種新型的低功耗通信技術，它能利用周圍環境中的射頻(RF)信號源實現無源信息傳輸，但由于其存在雙重衰落、障礙物阻擋等問題，導致反射鏈路信號強度弱。為此，該文將智能反射面(IRS)引入到AmBC系統中用以增強反射鏈路增益。然而，IRS與標簽均為無源器件使得信道估計極具挑戰性。為此，該文提出了一種IRS輔助的AmBC系統信道估計方案。首先，將信道分解為多個子信道，其中，反射鏈路的每個子信道對應一個IRS反射單元。然后，將最小二乘(LS)法作為估計準則，以最小化均方誤差(MSE)為目標，探索了IRS反射模式與信道估計的聯合設計。仿真結果表明，該信道估計方案具有良好的估計性能。
- 環境反向散射通信 /
- 智能反射面 /
- 信道估計
Abstract: Objective Ambient Backscatter Communication (AmBC) is an emerging, low-power, low-cost communication technology that utilizes ambient Radio Frequency (RF) signals for passive information transmission. It has demonstrated significant potential for various wireless applications. However, in AmBC systems, the reflected signals are often severely weakened due to double fading effects and signal obstruction from environmental obstacles. This results in a substantial reduction in signal strength, limiting both communication range and overall system performance. To address these challenges, Intelligent Reflecting Surface (IRS) technology has been integrated into AmBC systems. IRS can enhance reflection link gain by precisely controlling reflected signals, thereby improving system performance. However, the passive nature of both the IRS and tags makes accurate channel estimation a critical challenge. This study proposes an efficient channel estimation algorithm for IRS-assisted AmBC systems, aiming to provide theoretical support for optimizing system performance and explore the feasibility of achieving high-precision channel estimation in complex environments—key to the practical implementation of this technology. Methods This study develops a general IRS-assisted AmBC system model, where the system channel is divided into multiple subchannels, each corresponding to a specific IRS reflection element. To minimize the Mean Squared Error (MSE) in channel estimation, the Least Squares (LS) method is used as the estimation criterion. The joint optimization problem for channel estimation is explored by integrating various IRS reflection modes, including ON/OFF, Discrete Fourier Transform (DFT), and Hadamard modes. The communication channel is assumed to follow a Rayleigh fading distribution, with noise modeled as zero-mean Gaussian. Pilot signals are modulated using Quadrature Phase Shift Keying (QPSK). To thoroughly evaluate the performance of channel estimation, 1000 Monte Carlo simulations are conducted, with MSE and the Cramer-Rao Lower Bound (CRLB) serving as performance metrics. Simulation experiments conducted on the Matlab platform provide a comprehensive comparison and analysis of the performance of different algorithms, ultimately validating the effectiveness and accuracy of the proposed algorithm. Results and Discussions The simulation results demonstrate that the IRS-assisted channel estimation algorithm significantly improves performance. Under varying Signal-to-Noise Ratio (SNR) conditions, the MSE of methods based on DFT and Hadamard matrices consistently outperforms the ON/OFF method, aligning with the CRLB, thereby confirming the optimal performance of the proposed algorithms (Fig. 2, Fig. 3). Additionally, the MSE for direct and cascaded channels is identical when using the DFT and Hadamard methods, while the cascaded channel MSE for the ON/OFF method is twice that of the direct channel, highlighting the superior performance of the DFT and Hadamard approaches. As the number of IRS reflection elements increases, the MSE for the DFT and Hadamard methods decreases significantly, whereas the MSE for the ON/OFF method remains unchanged (Fig. 4, Fig. 5). This illustrates the ability of the DFT and Hadamard methods to effectively exploit the scalability of IRS, demonstrating better adaptability and estimation performance in large-scale IRS systems. Furthermore, increasing the number of pilot signals leads to a further reduction in MSE for the DFT and Hadamard methods, as more pilot signals provide higher-quality observations, thereby enhancing channel estimation accuracy (Fig. 6, Fig. 7). Although additional pilot signals consume more resources, their substantial impact on reducing MSE highlights their importance in improving estimation precision. Moreover, under high-SNR conditions, the MSE for all algorithms is lower than that under low-SNR conditions, with the DFT and Hadamard methods showing more pronounced reductions (Fig. 4, Fig. 5). This indicates that the proposed methods enable more efficient channel estimation under better signal quality, further enhancing system performance. In conclusion, the channel estimation algorithms based on DFT and Hadamard matrices offer significant advantages in large-scale IRS systems and high-SNR scenarios, providing robust support for optimizing low-power, low-cost communication systems. Conclusions This paper presents a low-complexity channel estimation algorithm for IRS-assisted AmBC systems based on the LS criterion. The channel is decomposed into multiple subchannels, and the optimization of IRS phase shifts is designed to significantly enhance both channel estimation and transmission performance. Simulation results demonstrate that the proposed algorithm, utilizing the DFT and Hadamard matrices, achieves excellent performance across various SNR and system scale conditions. Specifically, the algorithm effectively reduces the MSE of channel estimation, exhibits higher estimation accuracy under high-SNR conditions, and shows low computational complexity and strong robustness in large-scale IRS systems. These results provide valuable insights for the theoretical modeling and practical application of IRS-assisted AmBC systems. The findings are particularly relevant for the development of low-power, large-scale communication systems, offering guidance on the design and optimization of IRS-assisted AmBC systems. Additionally, this work lays a solid theoretical foundation for the advancement of next-generation Internet of Things applications, with potential implications for future research on IRS technology and their integration with AmBC systems.
- Ambient Backscatter Communication (AmBC) /
- Intelligent Reflecting Surface (IRS) /
- Channel estimation

HTML全文

圖 1 IRS輔助的AmBC系統

下載: 全尺寸圖片幻燈片

圖 2 直連信道均方誤差隨信噪比變化曲線

下載: 全尺寸圖片幻燈片

圖 3 級聯信道均方誤差隨信噪比變化曲線

下載: 全尺寸圖片幻燈片

圖 4 直連信道均方誤差隨反射單元數變化曲線

下載: 全尺寸圖片幻燈片

圖 5 級聯信道均方誤差隨反射單元數變化曲線

下載: 全尺寸圖片幻燈片

圖 6 直連信道均方誤差隨反射單元數變化曲線

下載: 全尺寸圖片幻燈片

圖 7 級聯信道均方誤差隨反射單元數變化曲線

下載: 全尺寸圖片幻燈片

參考文獻(26)

[1]	XU Yongjun, GUI Guan, GACANIN H, et al. A survey on resource allocation for 5G heterogeneous networks: Current research, future trends, and challenges[J]. IEEE Communications Surveys & Tutorials, 2021, 23(2): 668–695. doi: 10.1109/COMST.2021.3059896.
[2]	張曉茜, 徐勇軍. 面向零功耗物聯網的反向散射通信綜述[J]. 通信學報, 2022, 43(11): 199–212. doi: 10.11959/j.issn.1000-436x.2022199. ZHANG Xiaoxi and XU Yongjun. Survey on backscatter communication for zero-power IoT[J]. Journal on Communications, 2022, 43(11): 199–212. doi: 10.11959/j.issn.1000-436x.2022199.
[3]	XU Yongjun, XIE Hao, WU Qingqing, et al. Robust max-min energy efficiency for RIS-aided HetNets with distortion noises[J]. IEEE Transactions on Communications, 2022, 70(2): 1457–1471. doi: 10.1109/TCOMM.2022.3141798.
[4]	GALAPPATHTHIGE D L, REZAEI F, TELLAMBURA C, et al. RIS-empowered ambient backscatter communication systems[J]. IEEE Wireless Communications Letters, 2023, 12(1): 173–177. doi: 10.1109/LWC.2022.3220158.
[5]	LE A T, NGUYEN T N, TU L T, et al. Performance analysis of RIS-assisted ambient backscatter communication systems[J]. IEEE Wireless Communications Letters, 2024, 13(3): 791–795. doi: 10.1109/LWC.2023.3344113.
[6]	張曉茜, 徐勇軍, 吳翠先, 等. 智能反射面增強的全雙工環境反向散射通信系統波束成形算法[J]. 電子與信息學報, 2024, 46(3): 914–924. doi: 10.11999/JEIT230356. ZHANG Xiaoxi, XU Yongjun, WU Cuixian, et al. Beamforming design for reconfigurable intelligent surface enhanced full-duplex ambient backscatter communication networks[J]. Journal of Electronics & Information Technology, 2024, 46(3): 914–924. doi: 10.11999/JEIT230356.
[7]	YANG Hancheng, DING Haiyang, CAO Kunrui, et al. A RIS-segmented symbiotic ambient backscatter communication system[J]. IEEE Transactions on Vehicular Technology, 2024, 73(1): 812–825. doi: 10.1109/TVT.2023.3306037.
[8]	MA Shuo, WANG Gongpu, FAN Rongfei, et al. Blind channel estimation for ambient backscatter communication systems[J]. IEEE Communications Letters, 2018, 22(6): 1296–1299. doi: 10.1109/LCOMM.2018.2817555.
[9]	ZHAO Wenjing, WANG Gongpu, ATAPATTU S, et al. Blind channel estimation in ambient backscatter communication systems with multiple-antenna reader[C]. Proceedings of 2018 IEEE/CIC International Conference on Communications in China, Beijing, China, 2018: 320–324. doi: 10.1109/ICCChina.2018.8641171.
[10]	ZHU Yue, WANG Gongpu, TANG Hengliang, et al. Channel estimation for ambient backscatter systems over frequency-selective channels[C]. Proceedings of 2018 IEEE/CIC International Conference on Communications in China, Beijing, China, 2018: 384–388. doi: 10.1109/ICCChina.2018.8641250.
[11]	LIU Xuemeng, LIU Chang, LI Yonghui, et al. Deep residual learning-assisted channel estimation in ambient backscatter communications[J]. IEEE Wireless Communications Letters, 2021, 10(2): 339–343. doi: 10.1109/LWC.2020.3030222.
[12]	ABDALLAH S, SALAMEH A I, and SAAD M. Joint channel, carrier frequency offset and I/Q imbalance estimation in ambient backscatter communication systems[J]. IEEE Communications Letters, 2021, 25(7): 2250–2254. doi: 10.1109/LCOMM.2021.3075493.
[13]	ABDALLAH S, VERBOVEN Z, SAAD M, et al. Channel estimation for full-duplex multi-antenna ambient backscatter communication systems[J]. IEEE Transactions on Communications, 2023, 71(5): 3059–3072. doi: 10.1109/TCOMM.2023.3251387.
[14]	CUI Ziqi, WANG Gongpu, WEI Xusheng, et al. Channel estimation and optimal training design for ambient backscatter communication systems under sensitivity constraint[C]. Proceedings of 2022 IEEE 96th Vehicular Technology Conference, London, United Kingdom, 2022: 1–5. doi: 10.1109/VTC2022-Fall57202.2022.10012695.
[15]	CUI Ziqi, WANG Gongpu, GAO Jie, et al. Channel estimation for backscatter communication systems under circuit sensitivity constraint[J]. IEEE Transactions on Vehicular Technology, 2024, 73(5): 7441–7446. doi: 10.1109/TVT.2023.3347926.
[16]	ABEYWICKRAMA S, YOU Changsheng, ZHANG Rui, et al. Channel estimation for intelligent reflecting surface assisted backscatter communication[J]. IEEE Wireless Communications Letters, 2021, 10(11): 2519–2523. doi: 10.1109/LWC.2021.3106165.
[17]	LIN Junliang, WANG Gongpu, XU Rongtao, et al. Versatile-modulation and megabit-rate backscatter system: Design, implementation, and experimental results[J]. IEEE Internet of Things Journal, 2024, 11(5): 8240–8252. doi: 10.1109/JIOT.2023.3318634.
[18]	LI Dong. Two birds with one stone: Exploiting decode-and-forward relaying for opportunistic ambient backscattering[J]. IEEE Transactions on Communications, 2020, 68(3): 1405–1416. doi: 10.1109/TCOMM.2019.2957490.
[19]	XU Yongjun, GU Bowen, HU R Q, et al. Joint computation offloading and radio resource allocation in MEC-based wireless-powered backscatter communication networks[J]. IEEE Transactions on Vehicular Technology, 2021, 70(6): 6200–6205. doi: 10.1109/TVT.2021.3077094.
[20]	D’AMICO A A and MORELLI M. Symbol-spaced feedforward techniques for blind bit synchronization and channel estimation in FSO-OOK communications[J]. IEEE Transactions on Communications, 2024, 72(1): 361–374. doi: 10.1109/TCOMM.2023.3317931.
[21]	GU Bowen, LI Dong, LIU Ye, et al. Exploiting constructive interference for backscatter communication systems[J]. IEEE Transactions on Communications, 2023, 71(7): 4344–4359. doi: 10.1109/TCOMM.2023.3277519.
[22]	XIE Ning, XU Yuntao, ZHANG Jiaheng, et al. Joint estimation of channel responses and phase noises in asynchronous MIMO systems with intentional timing offset[J]. IEEE Transactions on Communications, 2023, 71(1): 412–426. doi: 10.1109/TCOMM.2022.3223711.
[23]	SENGIJPTA S K. Fundamentals of statistical signal processing: Estimation theory[J]. Technometrics, 1995, 37(4): 465–466. doi: 10.1080/00401706.1995.10484391.
[24]	MISHRA D and JOHANSSON H. Channel estimation and low-complexity beamforming design for passive intelligent surface assisted MISO wireless energy transfer[C]. Proceedings of 2019 IEEE International Conference on Acoustics, Speech and Signal Processing, Brighton, United Kingdom, 2019: 4659–4663. doi: 10.1109/ICASSP.2019.8683663.
[25]	JENSEN T L and DE CARVALHO E. An optimal channel estimation scheme for intelligent reflecting surfaces based on a minimum variance unbiased estimator[C]. Proceedings of 2020 IEEE International Conference on Acoustics, Speech and Signal Processing, Barcelona, Spain, 2020: 5000–5004. doi: 10.1109/ICASSP40776.2020.9053695.
[26]	ZHOU Zhengyi, GE Ning, WANG Zhaocheng, et al. Joint transmit precoding and reconfigurable intelligent surface phase adjustment: A decomposition-aided channel estimation approach[J]. IEEE Transactions on Communications, 2021, 69(2): 1228–1243. doi: 10.1109/TCOMM.2020.3034259.
