全局感知與稀疏特征關聯圖像級弱監督病理圖像分割

張印輝; 張金凱; 何自芬; 劉珈岑; 吳琳; 李振輝; 陳光晨

doi:10.11999/JEIT240364

全局感知與稀疏特征關聯圖像級弱監督病理圖像分割

doi: 10.11999/JEIT240364

1.
昆明理工大學機電工程學院昆明 650500
2.
云南省腫瘤醫院病理科昆明 650106
3.
云南省腫瘤醫院放射科昆明 650106

基金項目: 國家自然科學基金(62061022, 62171206)

詳細信息

作者簡介:
張印輝：男，博士，教授，研究方向?yàn)閳D像處理、機器視覺及機器智能

張金凱：男，碩士生，研究方向?yàn)獒t(yī)學圖像處理

何自芬：女，博士，教授，研究方向?yàn)閳D像處理和機器視覺

劉珈岑：男，碩士生，研究方向?yàn)獒t(yī)學圖像處理

吳琳：女，碩士，副主任醫師，研究方向?yàn)槲改c病理、腫瘤病理

李振輝：男，博士，主治醫師，研究方向?yàn)槲改c道腫瘤影像組學

陳光晨：男，博士生，研究方向?yàn)橛?jì)算機視覺

通訊作者:
何自芬　zyhhzf1998@163.com

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 280
- HTML全文瀏覽量: 87
- PDF下載量: 57
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-09
- 修回日期: 2024-07-17
- 網絡出版日期: 2024-08-02
- 刊出日期: 2024-09-26

Global Perception and Sparse Feature Associate Image-level Weakly Supervised Pathological Image Segmentation

1.
Faculty of Mechanical and Electrical Engineering, Kunming University of Science and Technology, Kunming 650500, China
2.
Department of Pathology, Yunnan Cancer Hospital, Kunming 650106, China
3.
Department of Radiology, Yunnan Cancer Hospital, Kunming 650106, China

Funds: The National Natural Science Foundation of China (62061022, 62171206)

摘要

摘要: 弱監督語義分割方法可以節省大量的人工標注成本，在病理全切片圖像(WSI)的分析中有著廣泛應用。針對弱監督多實例學習(MIL)方法在病理圖像分析中存在的像素實例相互獨立缺乏依賴關系，分割結果局部不一致和圖像級標簽監督信息不充分的問題，該文提出一種全局感知與稀疏特征關聯圖像級弱監督的端到端多實例學習方法(DASMob-MIL)。首先，為克服像素實例之間的獨立性，使用局部感知網絡提取特征以建立局部像素依賴，并級聯交叉注意力模塊構建全局信息感知分支(GIPB)以建立全局像素依賴關系。其次，引入像素自適應細化模塊(PAR)，通過多尺度鄰域局部稀疏特征之間的相似性構建親和核，解決了弱監督語義分割結果局部不一致的問題。最后，設計深度關聯監督模塊(DAS)，通過對多階段特征圖生成的分割圖進行加權融合，并使用權重因子關聯損失函數以優化訓練過程，以降低弱監督圖像級標簽監督信息不充分的影響。DASMob-MIL模型在自建的結直腸癌數據集YN-CRC和公共弱監督組織病理學圖像數據集LUAD-HistoSeg-BC上與其他模型相比展示出了先進的分割性能，模型權重僅為14 MB，在YN-CRC數據集上F1 Score達到了89.5%，比先進的多層偽監督(MLPS)模型提高了3%。實驗結果表明，DASMob-MIL僅使用圖像級標簽實現了像素級的分割，有效改善了弱監督組織病理學圖像的分割性能。
- 弱監督語義分割 /
- 組織病理學圖像 /
- 多實例學習 /
- 全局感知 /
- 稀疏特征
Abstract: The weakly supervised semantic segmentation methods have been widely applied in the analysis of Whole Slide Images (WSI), saving a considerable amount of manual annotation costs. Addressing the issues of pixel instance independence, local inconsistency in segmentation results, and insufficient supervision from image-level labels in Multiple-Instance Learning (MIL) methods for pathological image analysis, a novel end-to-end MIL approach named DASMob-MIL is proposed in this paper. Firstly, to overcome the independence among pixel instances, features are extracted using a local perception network to establish local pixel dependencies, while a Global Information Perception Branch (GIPB) is constructed by cascading cross-attention modules to establish global pixel dependencies. Secondly, a Pixel-Adaptive Refinement (PAR) module is introduced to address the problem of local inconsistency in weakly supervised semantic segmentation results by constructing affinity kernels based on the similarity between multi-scale neighborhood local sparse features. Finally, a Deep Association Supervision (DAS) module is designed to optimize the training process by performing weighted fusion on the segmentation maps generated from multi-stage feature maps. Then, employing a weighted factor-associated loss function to mitigate the impact of insufficient supervision from weakly supervised image-level labels. Compared with other models, the DASMob-MIL model demonstrates advanced segmentation performance on the self-built colorectal cancer dataset YN-CRC and the public weakly supervised histopathology image dataset LUAD-HistoSeg-BC, with a model weight of only 14MB and an F1 score of 89.5% on the YN-CRC dataset, which was 3% higher than that of the advanced Multi-Layer Pseudo-Supervision (MLPS) model. Experimental results indicate that DASMob-MIL achieves pixel-level segmentation utilizing only image-level labels, effectively improving the segmentation performance of weakly supervised histopathological images.
- Weakly supervised semantic segmentation /
- Histopathological images /
- Multi-Instance Learning (MIL) /
- Global perception /
- Sparse features

HTML全文

圖 1 基于MIL的病理圖像弱監督語義分割示意圖

下載: 全尺寸圖片幻燈片

圖 2 所提出的DASMob-MIL模型總體框架

下載: 全尺寸圖片幻燈片

圖 3 交叉注意力結構與全局依賴關系建立過程

下載: 全尺寸圖片幻燈片

圖 4 不同模型在YN-CRC數據集上的分割結果

下載: 全尺寸圖片幻燈片

圖 5 不同模型在LUAD-HistoSeg-BC數據集上的分割結果

下載: 全尺寸圖片幻燈片

表 1 不同模型在YN-CRC數據集上的分割性能對比

模型		F1 EC (%)	F1 NEC (%)	F1 Score (%)	HD EC	Precision (%)	Recall (%)	權重 (MB)	推理時間
全監督	U-Net	91.4	99.6	93.0	5.973	95.1	91.4	33.0	0.0112
全監督	MobileUNetv3	91.6	99.6	93.1	5.378	95.2	91.6	26.6	0.0056
弱監督	SA-MIL	35.4	87.5	45.3	42.103	61.8	43.0	7.07	0.1218
	DWS-MIL	76.7	98.7	80.9	27.690	89.5	82.4	6.65	0.0144
	Swin-MIL	82.9	99.6	86.1	18.915	90.3	86.3	105	0.0279
	MLPS	83.4	99.8	86.5	41.701	83.8	91.7	453	0.0220
	本文(DASMob-MIL)	87.3	99.0	89.5	23.576	86.5	94.6	14.0	0.0712

下載: 導出CSV

表 2 不同模型在LUAD-HistoSeg-BC數據集上的分割性能對比

模型		F1 TM (%)	F1 NTM (%)	F1 Score (%)	HD TM	Precision (%)	Recall (%)	權重(MB)	推理時間
弱監督	MLPS	56.9	99.9	61.8	38.029	76.4	56.7	453	0.0133
	SA-MIL	65.9	100	69.8	19.012	78.6	70.8	7.07	0.0268
	DWS-MIL	68.5	94.9	71.5	19.578	76.9	75.9	6.65	0.0079
	Swin-MIL	71.6	99.4	74.7	19.148	74.5	82.5	105	0.0209
	本文(DASMob-MIL)	73.4	98.5	76.3	23.515	73.6	84.6	14.0	0.0378

下載: 導出CSV

表 3 不同局部特征提取主干對分割精度的影響

主干	F1 EC(%)	F1 NEC(%)	F1 Score(%)	HD EC	Precision(%)	Recall(%)	權重(MB)	推理時間
VGG-16	59.9	100	67.5	159.929	57.2	98.4	100	0.0624
ResNet50	70.7	99.8	76.2	42.565	74.6	85.8	281	0.0349
EfficientNetv2	73.2	99.6	78.2	78.894	72.0	91.3	212	0.0463
ShuffleNetv2	75.5	99.4	80.0	73.642	75.5	90.0	69.0	0.0185
U-Net	78.2	98.4	82.1	64.231	74.0	95.5	65.9	0.0364
MobileNetv3	80.1	99.4	83.7	26.621	86.2	86.3	13.3	0.0143

下載: 導出CSV

表 4 所提出的模塊對分割精度的影響

模型	模塊			評價指標
模型	GIPB	PAR	DAS	F1 EC (%)	F1 NEC (%)	F1 Score (%)	HD EC	Precision (%)	Recall (%)	權重(MB)	推理時間
基準				80.1	99.4	83.7	26.621	86.2	86.3	13.3	0.0143
消融1			√	82.4	99.6	85.7	15.667	86.3	87.3	13.8	0.0150
消融2	√			83.4	99.5	86.4	22.674	88.4	87.6	13.5	0.0285
消融3		√		84.5	99.7	87.4	28.712	86.8	90.5	13.3	0.0427
消融4	√		√	83.8	98.3	86.5	18.664	82.0	93.8	14.0	0.0316
消融5	√	√		85.4	99.5	88.1	27.261	89.5	89.2	13.5	0.0625
消融6		√	√	86.0	99.3	88.6	25.358	84.6	95.1	13.9	0.0448
DASMob-MIL	√	√	√	87.3	99.0	89.5	23.576	86.5	94.6	14.0	0.0712

下載: 導出CSV

表 5 PAR模塊中迭代次數對分割精度的影響

$ T $	F1 EC(%)	F1 NEC(%)	F1 Score(%)	HD EC	Precision(%)	Recall(%)	推理時間
基準	80.1	99.4	83.7	26.621	86.2	86.3	0.0143
5	80.6	99.8	84.3	38.394	84.5	88.8	0.0341
10	84.5	99.7	87.4	28.712	86.8	90.5	0.0427
15	83.7	99.7	86.7	33.183	86.5	90.7	0.0529
20	79.9	99.4	83.6	41.216	83.2	88.5	0.0640

下載: 導出CSV

表 6 不同GIPB配置對分割精度的影響

編碼器數	F1 EC(%)	F1 NEC(%)	F1 Score(%)	HD EC	Precision(%)	Recall(%)	權重(MB)	推理時間
基準	80.1	99.4	83.7	26.621	86.2	86.3	13.3	0.0143
1	80.1	99.8	83.9	16.783	84.9	87.0	13.4	0.0278
2	78.3	99.4	82.3	35.055	82.2	87.0	13.4	0.0265
3	83.4	99.5	86.4	22.674	88.4	87.6	13.5	0.0285
4	79.9	98.9	83.4	30.955	84.0	87.8	14.1	0.0328
5	75.6	99.8	80.2	34.782	84.2	82.5	16.0	0.0346

下載: 導出CSV

表 7 DAS結構中不同側分支權重系數對分割精度的影響

分組	權重系數	F1 EC(%)	F1 NEC(%)	F1 Score(%)	HD EC	Precision(%)	Recall(%)	推理時間
	基準	80.1	99.4	83.7	26.621	86.2	86.3	0.0143
1	[0.15,0.15,0.2,0.5]	82.4	99.6	85.7	15.667	86.3	87.3	0.0150
2	[0.1,0.1,0.3,0.5]	81.2	99.7	84.7	19.489	88.0	86.5	0.0151
3	[0.15,0.15,0.3,0.4]	74.3	99.7	79.1	21.112	75.2	88.8	0.0149
4	[0.2,0.2,0.3,0.3]	80.6	97.9	83.9	21.314	80.3	90.5	0.0152
5	[0.2,0.2,0.25,0.35]	81.2	99.6	84.7	20.356	83.0	90.6	0.0150

下載: 導出CSV
