融合神經輻射場和視覺同時定位與地圖構建的混合場景表示方法

周非; 周志遠; 張宇曈; 謝源遠

doi:10.11999/JEIT240316

融合神經輻射場和視覺同時定位與地圖構建的混合場景表示方法

doi: 10.11999/JEIT240316

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(62271096)

詳細信息

作者簡介:
周非：男，教授，研究方向?yàn)閳D像處理、機器視覺、信息安全等

周志遠：男，碩士生，研究方向?yàn)閳D像處理、視覺SLAM等

張宇曈：男，碩士生，研究方向?yàn)閳D像處理等

謝源遠：男，碩士生，研究方向?yàn)閳D像處理等

通訊作者:
周志遠　s220101223@stu.cqupt.edu.cn

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 243
- HTML全文瀏覽量: 55
- PDF下載量: 31
- 被引次數: 0
出版歷程
- 收稿日期: 2024-04-22
- 修回日期: 2024-08-26
- 網絡出版日期: 2024-08-30
- 刊出日期: 2024-11-10

Hybrid Scene Representation Method Integrating Neural Radiation Fields and Visual Simultaneous Localization and Mapping

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (62271096)

摘要

摘要: 目前，傳統顯式場景表示的同時定位與地圖構建(SLAM)系統對場景進行離散化，不適用于連續性場景重建。該文提出一種基于神經輻射場(NeRF)的混合場景表示的深度相機(RGB-D)SLAM系統，利用擴展顯式八叉樹符號距離函數(SDF)先驗粗略表示場景，并通過多分辨率哈希編碼以不同細節級別表示場景，實現場景幾何的快速初始化，并使場景幾何更易于學習。此外，運用外觀顏色分解法，結合視圖方向?qū)㈩伾纸鉃槁瓷漕伾顽R面反射顏色，實現光照一致性的重建，使得重建結果更加真實。通過在Replica和TUM RGB-D數據集上進行實驗，Replica數據集場景重建完成率達到93.65%，相較于Vox-Fusion定位精度，在Replica數據集上平均領先87.50%，在TUM RGB-D數據集上平均領先81.99%。
- 同時定位與地圖構建系統 /
- 神經輻射場 /
- 混合場景表示 /
- 鏡面反射
Abstract: Currently, traditional explicit scene representation Simultaneous Localization And Mapping (SLAM) systems discretize the scene and are not suitable for continuous scene reconstruction. A RGB-D SLAM system based on hybrid scene representation of Neural Radiation Fields (NeRF) is proposed in this paper. The extended explicit octree Signed Distance Functions (SDF) prior is used to roughly represent the scene, and multi-resolution hash coding is used to represent the scene with different details levels, enabling fast initialization of scene geometry and making scene geometry easier to learn. In addition, the appearance color decomposition method is used to decompose the color into diffuse reflection color and specular reflection color based on the view direction to achieve reconstruction of lighting consistency, making the reconstruction result more realistic. Through experiments on the Replica and TUM RGB-D dataset, the scene reconstruction completion rate of the Replica dataset reaches 93.65%. Compared with the Vox-Fusion positioning accuracy, it leads on average by 87.50% on the Replica dataset and by 81.99% on the TUM RGB-D dataset.
- Simultaneous Localization And Mapping (SLAM) system /
- Neural Radiation Fields (NeRF) /
- Hybrid scene representation /
- Specular reflection

HTML全文

圖 1 系統框架

下載: 全尺寸圖片幻燈片

圖 2 八叉樹SDF先驗

下載: 全尺寸圖片幻燈片

圖 3 擴展體素分配

下載: 全尺寸圖片幻燈片

圖 4 渲染圖像

下載: 全尺寸圖片幻燈片

圖 5 Replica數據集重建結果

下載: 全尺寸圖片幻燈片

圖 6 Replica數據集重建物體網格

下載: 全尺寸圖片幻燈片

圖 7 Apartment數據集重建結果

下載: 全尺寸圖片幻燈片

圖 8 八叉樹SDF先驗消融實驗

下載: 全尺寸圖片幻燈片

圖 9 擴展體素分配消融實驗

下載: 全尺寸圖片幻燈片

圖 10 外觀顏色分解消融實驗

下載: 全尺寸圖片幻燈片

表 1 超參設定值

超參	設定值	超參	設定值	超參	設定值	超參	設定值
L	16	F2	2	M_f	11	${\alpha _3}$	0.000 01
T	2¹⁶	${N_t}$	1024	${\alpha _1}$	5.0	${\alpha _4}$	1000
F1	1	$ M $	32	${\alpha _2}$	0.1	${\alpha _5}$	10

下載: 導出CSV

表 2 Replica數據集重建質量對比

方法	重建質量指標
方法	Depth L1(cm)↓	Acc. (cm)↓	Comp. (cm)↓	Comp. Ratio(%)↑
iMAP	4.64	3.62	4.93	80.50
NICE-SLAM	3.53	2.85	3.00	89.33
Vox-Fusion	2.91	2.37	2.28	92.86
vMAP	3.33	3.20	2.39	92.99
DNS SLAM	3.16	2.76	2.74	91.73
本文	1.76	2.29	2.11	93.65

下載: 導出CSV

表 3 Replica數據集軌跡誤差

方法	room0	room1	office0	office1	office3	office4	平均值
iMAP	70.00	4.53	2.32	1.74	58.40	2.62	23.27
NICE-SLAM	1.69	2.04	0.99	0.90	3.97	3.08	2.11
Vox-Fusion	1.37	4.70	8.48	2.04	1.11	2.94	3.44
vMAP	/	/	/	/	/	/	/
DNS SLAM	0.49	0.46	0.34	0.35	0.62	0.60	0.48
本文	0.41	0.52	0.31	0.37	0.46	0.53	0.43

下載: 導出CSV

表 4 TUM-RGBD數據集軌跡誤差

方法	fr1/desk	fr2/xyz	fr3/office	平均值
iMAP	4.9	2.0	5.8	4.23
NICE-SLAM	2.7	1.8	3.0	2.50
Vox-Fusion	3.5	1.5	26.0	10.33
vMAP	2.6	1.6	3.0	2.40
DNS SLAM	/	/	/	/
本文	2.0	1.5	2.1	1.86

下載: 導出CSV

表 5 Replica數據集消融實驗的定量分析

	Acc.(cm)↓	Comp.(cm)↓	Comp. Ratio(%)↑
w/o 八叉樹SDF先驗	2.99	2.20	93.88
w/o 擴展體素分配	2.88	2.10	95.05
w/o 外觀顏色分解	2.36	1.95	95.36
本文	2.27	1.92	95.75

下載: 導出CSV

表 6 添加體素的點的閾值分析

點數量閾值	Acc.(cm)↓	Comp.(cm)↓	Comp. Ratio(%)↑
5	5.00	2.08	93.11
10/本文	2.27	1.92	95.75
15	2.37	1.94	95.67
20	2.29	1.93	95.63

下載: 導出CSV

表 7 Replica數據集損失函數消融實驗

	Acc.(cm)↓	Comp.(cm)↓	Comp. Ratio(%)↑
w/o $ {{L}_{{\mathrm{rgb}}}} $	2.47	1.94	95.68
w/o $ {{L}_{\textq7j3ldu95}} $	2.48	1.93	95.54
w/o $ {{L}_{{\text{specular}}}} $	2.45	1.95	95.64
w/o $ {{L}_{{\text{sdf}}}} $	2.68	2.04	94.68
w/o $ {{L}_{{f_{\text{s}}}}} $	2.30	1.95	95.46
本文	2.27	1.92	95.75

下載: 導出CSV

表 8 Replica數據集性能對比

方法	Avg. fps↑	GPU Mem. (G)↓	param. (M)↓
iMAP	0.13	6.44	0.32
NICE-SLAM	0.61	4.70	17.4
Vox-Fusion	0.74	21.22	0.87
vMAP	4.03	\	0.66
DNS SLAM	0.13	\	\
本文	4.93	2.93	0.34

下載: 導出CSV
