SMCA：基于芯粒集成的存算一體加速器擴展框架

李雯; 王穎; 何銀濤; 鄒凱偉; 李華偉; 李曉維

doi:10.11999/JEIT240284

SMCA：基于芯粒集成的存算一體加速器擴展框架

doi: 10.11999/JEIT240284

李雯^{1, 2, 3},
王穎^{4, 5, ,},
何銀濤^{4, 5},
鄒凱偉⁶,
李華偉^{4, 5},
李曉維^{4, 5}

1.
山西大學計算機與信息技術學院(大數據學院) 太原 030006
2.
山西大學大數據科學與產業研究院太原 030006
3.
山西大學計算智能與中文信息處理教育部重點實驗室太原 030006
4.
中國科學院計算技術研究所處理器芯片全國重點實驗室北京 100190
5.
中國科學院大學 北京 100190
6.
清華大學電子工程系北京 100084

基金項目: 國家自然科學基金(62302283)，山西省基礎研究計劃項目(自由探索類)(202303021212015)

詳細信息

作者簡介:
李雯：女，講師，研究方向?yàn)槿蒎e(cuò)計算和集成電路設計

王穎：男，研究員，研究方向?yàn)樾滦虴DA、處理器與存儲系統體系結構

何銀濤：女，博士生，研究方向?yàn)榇嫠阋惑w芯片、專用處理器設計

鄒凱偉：女，博士后，研究方向?yàn)橹悄苄酒O(shè)計

李華偉：女，研究員，研究方向?yàn)閂LSI測試、容錯計算

李曉維：男，研究員，研究方向?yàn)橛布踩?、集成電路設計自動化

通訊作者:
王穎　wangying2009@ict.ac.cn

中圖分類號: TN40; TP389.1
計量
- 文章訪問數: 407
- HTML全文瀏覽量: 155
- PDF下載量: 67
- 被引次數: 0
出版歷程
- 收稿日期: 2024-04-16
- 修回日期: 2024-09-13
- 網絡出版日期: 2024-09-30
- 刊出日期: 2024-11-01

SMCA: A Framework for Scaling Chiplet-Based Computing-in-Memory Accelerators

LI Wen^{1, 2, 3},
WANG Ying^{4, 5
, ,},
HE Yintao^{4, 5},
ZOU Kaiwei⁶,
LI Huawei^{4, 5},
LI Xiaowei^{4, 5}

1.
School of Computer and Information Technology (School of Big Data), Shanxi University Taiyuan 030006, China
2.
Institute of Big Data Science and Industry, Shanxi University Taiyuan 030006, China
3.
Key Laboratory of Computational Intelligence and Chinese Information Processing of Ministry of Education, Shanxi University Taiyuan 030006, China
4.
State Key Laboratory of Processors, Institute of Computing Technology, Chinese Academy of Sciences, Beijing 100190, China
5.
University of Chinese Academy of Sciences, BeiJing 100190, China
6.
Department of Electronic Engineering, Tsinghua University, Beijing 100084, China

Funds: The National Natural Science Foundation of China (62302283), The Basic Research Program of Shanxi Province (Exploration Research)(202303021212015)

摘要

摘要: 基于可變電阻式隨機存取存儲器(ReRAM)的存算一體芯片已經成為加速深度學習應用的一種高效解決方案。隨著智能化應用的不斷發展，規模越來越大的深度學習模型對處理平臺的計算和存儲資源提出了更高的要求。然而，由于ReRAM器件的非理想性，基于ReRAM的大規模計算芯片面臨著低良率與低可靠性的嚴峻挑戰。多芯粒集成的芯片架構通過將多個小芯粒封裝到單個芯片中，提高了芯片良率、降低了芯片制造成本，已經成為芯片設計的主要發展趨勢。然而，相比于單片式芯片數據的片上傳輸，芯粒間的昂貴通信成為多芯粒集成芯片的性能瓶頸，限制了集成芯片的算力擴展。因此，該文提出一種基于芯粒集成的存算一體加速器擴展框架—SMCA。該框架通過對深度學習計算任務的自適應劃分和基于可滿足性模理論(SMT)的自動化任務部署，在芯粒集成的深度學習加速器上生成高能效、低傳輸開銷的工作負載調度方案，實現系統性能與能效的有效提升。實驗結果表明，與現有策略相比，SMCA為深度學習任務在集成芯片上自動生成的調度優化方案可以降低35%的芯粒間通信能耗。
- 芯粒 /
- 深度學習處理器 /
- 存算一體 /
- 任務調度
Abstract: Computing-in-Memory (CiM) architectures based on Resistive Random Access Memory (ReRAM) have been recognized as a promising solution to accelerate deep learning applications. As intelligent applications continue to evolve, deep learning models become larger and larger, which imposes higher demands on the computational and storage resources on processing platforms. However, due to the non-idealism of ReRAM, large-scale ReRAM-based computing systems face severe challenges of low yield and reliability. Chiplet-based architectures assemble multiple small chiplets into a single package, providing higher fabrication yield and lower manufacturing costs, which has become a primary trend in chip design. However, compared to on-chip wiring, the expensive inter-chiplet communication becomes a performance bottleneck for chiplet-based systems which limits the chip’s scalability. As the countermeasure, a novel scaling framework for chiplet-based CiM accelerators, SMCA (SMT-based CiM chiplet Acceleration) is proposed in this paper. This framework comprises an adaptive deep learning task partition strategy and an automated SMT-based workload deployment to generate the most energy-efficient DNN workload scheduling strategy with the minimum data transmission on chiplet-based deep learning accelerators, achieving effective improvement in system performance and efficiency. Experimental results show that compared to existing strategies, the SMCA-generated automatically schedule strategy can reduce the energy costs of inter-chiplet communication by 35%.
- Chiplet /
- Deep learning processor /
- Computing-in-Memory (CiM) /
- Task dispatching

HTML全文

圖 1 在 ReRAM 交叉陣列上執行卷積計算的示意圖

下載: 全尺寸圖片幻燈片

圖 2 SMCA 工作流程

下載: 全尺寸圖片幻燈片

圖 3 同構存算一體芯粒集成的深度學習芯片架構

下載: 全尺寸圖片幻燈片

圖 4 深度學習計算任務的平均劃分策略

下載: 全尺寸圖片幻燈片

圖 5 CAP 策略與 CMP 策略的對比

下載: 全尺寸圖片幻燈片

圖 6 歸一化的 NoP 能耗

下載: 全尺寸圖片幻燈片

圖 7 歸一化的 NoP 時延

下載: 全尺寸圖片幻燈片

圖 8 不同大小芯粒、不同規模系統的集成芯片上的 NoP 能耗對比

下載: 全尺寸圖片幻燈片

1 自適應層級網絡劃分策略

　1: 輸入：?jiǎn)蝹€(gè)芯粒的固定算力M；網絡$l({l_0},{l_1}, \cdots,{l_{L - 1}}) $的算力
　需求$w({w_0},{w_1}, \cdots ,{w_{L - 1}}) $。

　2: 輸出：網絡劃分策略bestP。

　3: ${C_{{\text{idle}}}}{{ = M}} $; /*初始化${C_{{\text{idle}}}} $*/

　4: for $i = 0,1, \cdots ,L - 1 $

　5: 　if ${C_{{\text{idle}}}} \ge {w_i} $ then

　6: 　　${\text{bestP}} \leftarrow {\text{NoPartition}}(i{\text{,}}{w_i}) $;

　7: 　else if $\left\lceil {\dfrac{{{w_i}}}{{{M}}} = = \dfrac{{{w_i} - {C_{{\text{idle}}}}}}{{{M}}}} \right\rceil $ then

　8: 　　${\text{bestP}} \leftarrow {\text{CMP}}(i{\text{,}}{w_i}) $;

　9: 　else

　10: 　 ${\text{bestP}} \leftarrow {\text{CAP}}(i{\text{,}}{w_i}) $;

　11: Update(${C_{{\text{idle}}}} $)

下載: 導出CSV

表 1 SMT約束中的符號表示

符號	含義
$ {T},{E},{C} $	計算任務集合，計算圖中邊的集合以及芯片封裝的芯粒集合
$ t,c $	計算任務$ t $，芯粒$ c $
$ {e}_{i,j} $	計算圖中，任務$ i $到任務$ j $的有向邊
$ {x}^{c},\;{y}^{c} $	芯粒$ c $在芯片上的$ \left(x,y\right) $坐標
$ {w}^{t} $	任務$ t $的計算需求
$ {o}^{t} $	任務$ t $計算產生的中間數據量
$ {s}^{t} $	任務$ t $的開始執行時間
$ q7j3ldu95^{t} $	完成任務t所有前置任務所需的芯粒間最小數據傳輸開銷
$ {\tau }^{t} $	任務$ t $的執行時間
$ \mathrm{s}{\mathrm{w}}^{c} $	芯粒$ c $所在的波前編號
$ \mathrmq7j3ldu95\mathrm{i}\mathrm{s}({c}_{i},{c}_{j}) $	芯粒$ i $到芯粒$ j $的距離

下載: 導出CSV

表 2 系統配置

架構層次	屬性	參數
封裝	頻率	1.8 GHz
	芯粒間互聯網絡帶寬	100 Gb/s
	芯粒間通信能耗	1.75 p/bit
芯粒	工藝制程	16 nm
	單個芯粒包含的計算核個數	16
	單個計算核包含的ReRAM交叉陣列個數	16
計算核	ReRAM交叉陣列大小	128$ \times $128
	ADC	1 bit
	DAC	8 bit
	一個ReRAM單元存儲的位數	2
	權重精度	8 bit
	數據流	權重固定型

下載: 導出CSV
