低秩和聯合平滑性約束下的時變海表面溫度重構方法

李姣; 萬騰汶; 邱偉

doi:10.11999/JEIT240253

低秩和聯合平滑性約束下的時變海表面溫度重構方法

doi: 10.11999/JEIT240253

李姣¹,
萬騰汶¹,
邱偉^2, ,

1.
長沙理工大學數學與統計學院長沙 410114
2.
中國人民解放軍國防科技大學氣象海洋學院長沙 410073

基金項目: 國家自然科學基金(42176197)，湖南省自然科學基金(2022JJ40461)，湖南省教育廳優秀青年項目(21B0301)

詳細信息

作者簡介:
李姣：女，副教授，研究方向?yàn)樽顑?yōu)化方法及應用、生物分子計算

萬騰汶：女，碩士生，研究方向?yàn)樽顑?yōu)化方法及應用

邱偉：男，副教授，研究方向?yàn)橄∈栊盘?hào)重構、海洋信息處理

通訊作者:
邱偉　qiuwei08@nudt.edu.cn

中圖分類號: TN911.7
計量
- 文章訪問數: 128
- HTML全文瀏覽量: 48
- PDF下載量: 18
- 被引次數: 0
出版歷程
- 收稿日期: 2024-04-09
- 修回日期: 2024-10-10
- 網絡出版日期: 2024-10-15
- 刊出日期: 2024-11-10

Time-varying Sea Surface Temperature Reconstruction Leveraging Low Rank and Joint Smoothness Constraints

LI Jiao¹,
WAN Tengwen¹,
QIU Wei^{2
, ,}

1.
School of Mathematics and Statistics, Changsha University of Science and Technology, Changsha 410114, China
2.
School of Meteorology and Oceanography, National University of Defense Technology, Changsha 410073, China

Funds: The National Natural Science Foundation of China (42176197), The Natural Science Foundation of Hunan Province (2022JJ40461), The Excellent Youth Foundation of Education Bureau of Hunan Province (21B0301)

摘要

摘要: 海表面溫度對于海洋動力過程及海氣相互作用等具有重要意義，是海洋環境關鍵要素之一。浮標是海表面溫度觀測的常用手段，但由于浮標在空間的分布不規則，浮標采集的海表面溫度數據也呈現非規則性。另外，浮標在實際工作中難免存在故障，致使采集的海表面溫度數據存在缺失。因此對存在缺失的非規則海表面溫度數據進行重構具有重要意義。該文通過將海表面溫度數據建立為時變圖信號，利用圖信號處理方法解決海表面溫度缺失數據重構問題。首先，利用數據的低秩性和時域-圖域聯合變差特性構建海表面溫度重構模型；其次，基于交替方向乘子法框架提出一種求解該優化模型的基于低秩和聯合平滑性(LRJS)的時變圖信號重構方法，并分析該方法的計算復雜度和估計誤差的理論極限；最后，采用南海和太平洋海域海表溫度數據對方法的有效性進行了評估，結果表明，與現有缺失數據重構方法相比，該文所提LRJS方法有更高的重建精度。
- 海表面溫度 /
- 時變圖信號 /
- 信號重構 /
- 低秩 /
- 聯合平滑性
Abstract: Sea surface temperature is one of the key elements of the marine environment, which is of great significance to the marine dynamic process and air-sea interaction. Buoy is a commonly used method of sea surface temperature observation. However, due to the irregular distribution of buoys in space, the sea surface temperature data collected by buoys also show irregularity. In addition, it is inevitable that sometimes the buoy is out of order, so that the sea surface temperature data collected is incomplete. Therefore, it is of great significance to reconstruct the incomplete irregular sea surface temperature data. In this paper, the sea surface temperature data is established as a time-varying graph signal, and the graph signal processing method is used to solve the problem of missing data reconstruction of sea surface temperature. Firstly, the sea surface temperature reconstruction model is constructed by using the low rank data and the joint variation characteristics of time-domain and graph-domain. Secondly, a time-varying graph signal reconstruction method based on Low Rank and Joint Smoothness (LRJS) constraints is proposed to solve the optimization problem by using the framework of alternating direction multiplier method, and the computational complexity and the theoretical limit of the estimation error of the method are analyzed. Finally, the sea surface temperature data of the South China Sea and the Pacific Ocean are used to evaluate the effectiveness of the method. The results show that the LRJS method proposed in this paper can improve the reconstruction accuracy compared with the existing missing data reconstruction methods.
- Sea surface temperature /
- Time-varying graph signal /
- Signal reconstruction /
- Low rank /
- Joint smoothness

HTML全文

圖 1 太平洋海域海表面溫度數據采集連接圖

下載: 全尺寸圖片幻燈片

圖 2 所有方法在太平洋海域海表面溫度數據集上的性能

下載: 全尺寸圖片幻燈片

圖 3 南海海域海表溫度數據采集連接圖

下載: 全尺寸圖片幻燈片

圖 4 所有方法在南海海域海表溫度數據集上的性能

下載: 全尺寸圖片幻燈片

1 共軛梯度法

輸入：$ {\boldsymbol{Y}},{\boldsymbol{J}},{{\boldsymbol{L}}_{\rm{G}}},{{\boldsymbol{L}}_T},{{\boldsymbol{Z}}^k},{{\boldsymbol{P}}^k},{\boldsymbol{D}},\alpha ,\beta ,\rho $，終止迭代閾值$ \varepsilon $，最　大迭代次數$ K $
輸出：重構信號時變圖信號$ {{\boldsymbol{X}}_{^i}} $
初始化設置：$ {{\boldsymbol{X}}_i} = 0,\Delta {{\boldsymbol{X}}_i} = 0,i = 0 $
迭代：
(1) 確定步長：　　　 $ \tau = - \dfrac{{\left\langle {\Delta {{\boldsymbol{X}}_i},\nabla f({{\boldsymbol{X}}_i})} \right\rangle }}{{\left\langle {\Delta {{\boldsymbol{X}}_i},\nabla f({{\boldsymbol{X}}_i}) + {\boldsymbol{Y}} + \rho {{\boldsymbol{Z}}_i} - {{\boldsymbol{P}}_i}} \right\rangle }} $
其中，$ \Delta {{\boldsymbol{X}}_i} $為第$ i $步的搜索方向，$ \tau $為第$ i $步的最優步長，其由　線性最小化步長準則$ \mathop {\min }\limits_\tau f({{\boldsymbol{X}}_i} + \tau \Delta {{\boldsymbol{X}}_i}) $決定。
確定步長：
(2) 更新搜索方向：
$ \begin{aligned} & {{\boldsymbol{X}}_{i + 1}} = {{\boldsymbol{X}}_i} + \tau \Delta {{\boldsymbol{X}}_i}; \xi {\text{ = }}\frac{{\|\|\nabla f({{\boldsymbol{X}}_{i + 1}})\|\|_{{\mathrm{F}}} ^2}}{{\|\|\nabla f({{\boldsymbol{X}}_{i + 1}})\|\|_{{\mathrm{F}}} ^2}};\\& \Delta {{\boldsymbol{X}}_{i + 1}} = - \nabla f({{\boldsymbol{X}}_{i + 1}}) + \xi \Delta {{\boldsymbol{X}}_i}\end{aligned}$
終止條件：如果$ i = K $或者$ {\text{\|\|}}\Delta {{\boldsymbol{X}}_i}\|{\|_{\mathrm{F}}} \le \varepsilon $，則停止迭代；否則令$ i = i + 1 $，繼續迭代，直至滿足終止條件。

下載: 導出CSV

2 LRJS算法求解步驟

輸入：$ {\boldsymbol{Y}},{\boldsymbol{J}},{{\boldsymbol{L}}_{{\mathrm{G}}} },{{\boldsymbol{L}}_{{{T}}} },{{\boldsymbol{Z}}^k},{{\boldsymbol{P}}^k},{\boldsymbol{D}},\alpha ,\beta ,\rho ,\mu $，終止迭代閾值$ \varepsilon $，　最大迭代次數$ K $
輸出：重構海表面溫度數據$ {{\boldsymbol{X}}^k} $
初始化設置：$ {{\boldsymbol{X}}^0} = {{\boldsymbol{Z}}^0} = {\boldsymbol{Y}},{{\boldsymbol{P}}^0} = 0,k = 0 $
迭代：
(1) 更新${{\boldsymbol{X}}^{k + 1}}$：利用算法1的共軛梯度法；
(2) 更新${{\boldsymbol{Z}}^{k + 1}}$：利用式(21)；
(3) 更新${{\boldsymbol{P}}^{k + 1}}$：利用式(17)；
終止條件：如果$ k = K $或者${\text{\|\|}}\Delta {{\boldsymbol{X}}^k}\|{\|_{{\mathrm{F}}} } \le \varepsilon $，則停止迭代；否則　令$k = k + 1$，繼續迭代，直至滿足終止條件。

下載: 導出CSV

參考文獻(25)

[1]	DONEY S C, RUCKELSHAUS M, EMMETT DUFFY J, et al. Climate change impacts on marine ecosystems[J]. Annual Review of Marine Science, 2012, 4: 11–37. doi: 10.1146/annurev-marine-041911-111611.
[2]	LODER J W, VAN DER BAAREN A, and YASHAYAEV I. Climate comparisons and change projections for the Northwest Atlantic from six CMIP5 models[J]. Atmosphere-Ocean, 2015, 53(5): 529–555. doi: 10.1080/07055900.2015.1087836.
[3]	BARREIRO M, CHANG Ping, and SARAVANAN R. Variability of the South Atlantic convergence zone simulated by an atmospheric general circulation model[J]. Journal of Climate, 2002, 15(7): 745–763. doi: 10.1175/1520-0442(2002)015<0745:VOTSAC>2.0.CO;2.
[4]	王奎民. 主要海洋環境因素對水下航行器航行影響分析[J]. 智能系統學報, 2015, 10(2): 316–323. doi: 10.3969/j.issn.1673-4785.201503006. WANG Kuimin. Influence of main ocean environments on the navigation of underwater vehicles[J]. CAAI Transactions on Intelligent Systems, 2015, 10(2): 316–323. doi: 10.3969/j.issn.1673-4785.201503006.
[5]	SHUMAN D I, NARANG S K, FROSSARD P, et al. The emerging field of signal processing on graphs: Extending high-dimensional data analysis to networks and other irregular domains[J]. IEEE Signal Processing Magazine, 2013, 30(3): 83–98. doi: 10.1109/MSP.2012.2235192.
[6]	LIU Jinling, JIANG Junzheng, LIN Jiming, et al. Generalized Newton methods for graph signal matrix completion[J]. Digital Signal Processing, 2021, 112: 103009. doi: 10.1016/j.dsp.2021.103009.
[7]	張彥海, 蔣俊正. 基于笛卡爾乘積圖上Sobolev平滑的時變圖信號分布式批量重構[J]. 電子與信息學報, 2023, 45(5): 1585–1592. doi: 10.11999/JEIT221194. ZHANG Yanhai and JIANG Junzheng. Distributed batch reconstruction of time-varying graph signals via Sobolev smoothness on Cartesian product graph[J]. Journal of Electronics & Information Technology, 2023, 45(5): 1585–1592. doi: 10.11999/JEIT221194.
[8]	QIU Kai, MAO Xianghui, SHEN Xinyue, et al. Time-varying graph signal reconstruction[J]. IEEE Journal of Selected Topics in Signal Processing, 2017, 11(6): 870–883. doi: 10.1109/JSTSP.2017.2726969.
[9]	MAO Xianghui, QIU Kai, LI Tiejian, et al. Spatio-temporal signal recovery based on low rank and differential smoothness[J]. IEEE Transactions on Signal Processing, 2018, 66(23): 6281–6296. doi: 10.1109/TSP.2018.2875886.
[10]	GIRALDO J H, MAHMOOD A, GARCIA-GARCIA B, et al. Reconstruction of time-varying graph signals via Sobolev smoothness[J]. IEEE Transactions on Signal and Information Processing over Networks, 2022, 8: 201–214. doi: 10.1109/TSIPN.2022.3156886.
[11]	索秋月, 林基明, 王俊義. 利用聯合平滑性的時變圖信號重構算法[J]. 計算機應用與軟件, 2022, 39(4): 275–280. doi: 10.3969/j.issn.1000-386x.2022.04.043. SUO Qiuyue, LIN Jiming, and WANG Junyi. A time-varying graph signal reconstruction algorithm based on joint smoothness[J]. Computer Applications and Software, 2022, 39(4): 275–280. doi: 10.3969/j.issn.1000-386x.2022.04.043.
[12]	ZHAI Shiyu, LI Guobing, ZHANG Guomei, et al. Spatio-temporal signal recovery under diffusion-induced smoothness and temporal correlation priors[J]. IET Signal Processing, 2022, 16(2): 157–169. doi: 10.1049/sil2.12082.
[13]	LIU Jinling, LIN Jiming, QIU Hongbing, et al. Time-varying signal recovery based on low rank and graph-time smoothness[J]. Digital Signal Processing, 2023, 133: 103821. doi: 10.1016/j.dsp.2022.103821.
[14]	QI Zefeng, LIAO Xuewen, LI Ang, et al. Signal recovery for incomplete ocean data via graph signal processing[C]. GLOBECOM 2022-2022 IEEE Global Communications Conference, Rio de Janeiro, Brazil, 2022: 4274–4279. doi: 10.1109/GLOBECOM48099.2022.10000902.
[15]	LI Siyuan, CHENG Lei, ZHANG Ting, et al. Graph-guided Bayesian matrix completion for ocean sound speed field reconstruction[J]. The Journal of the Acoustical Society of America, 2023, 153(1): 689–710. doi: 10.1121/10.0017064.
[16]	CHEN Yangge, CHENG Lei, and WU Y C. Bayesian low-rank matrix completion with dual-graph embedding: Prior analysis and tuning-free inference[J]. Signal Processing, 2023, 204: 108826. doi: 10.1016/j.sigpro.2022.108826.
[17]	LOUKAS A and FOUCARD D. Frequency analysis of time-varying graph signals[C]. 2016 IEEE Global Conference on Signal and Information Processing (GlobalSIP), Washington, USA, 2016: 346–350. doi: 10.1109/GlobalSIP.2016.7905861.
[18]	GRASSI F, LOUKAS A, PERRAUDIN N, et al. A time-vertex signal processing framework: Scalable processing and meaningful representations for time-series on graphs[J]. IEEE Transactions on Signal Processing, 2018, 66(3): 817–829. doi: 10.1109/TSP.2017.2775589.
[19]	HACKBUSCH W. Iterative Solution of Large Sparse Systems of Equations[M]. New York, USA: Springer, 1994: 248–295. doi: 10.1007/978-1-4612-4288-8.
[20]	BELL H E. Gershgorin’s theorem and the zeros of polynomials[J]. The American Mathematical Monthly, 1965, 72(3): 292–295. doi: 10.2307/2313703.
[21]	MA Shiqian, GOLDFARB D, and CHEN Lifeng. Fixed point and Bregman iterative methods for matrix rank minimization[J]. Mathematical Programming, 2011, 128(1/2): 321–353. doi: 10.1007/s10107-009-0306-5.
[22]	SIBSON R. A brief description of natural neighbour interpolation[M]. BARNETT V. Interpreting Multivariate Data. Hoboken: Wiley, 1981.
[23]	PERRAUDIN N, PARATTE J, SHUMAN D, et al. GSPBOX: A toolbox for signal processing on graphs[J]. Eprint Arxiv, 2016, 61(7): 1644–1656.
[24]	Physical Sciences Division, Earth System Research Laboratory, National Oceanic and Atmospheric Administration. Sea surface temperature (SST) V2[EB/OL]. http://www.esrl.noaa.gov/psd/data/gridded/data.noaa.oisst.v2.html, 2023.
[25]	China Argo Real-Time Data Center. Argo real-time data[EB/OL]. ftp: //data. argo. org. cn/pub/ARGO/, 2023.
