基于雙重YOLOv8-pose模型的探地雷達雙曲線關鍵點檢測與目標定位

侯斐斐; 彭應昊; 董健; 銀雪

doi:10.11999/JEIT240242

基于雙重YOLOv8-pose模型的探地雷達雙曲線關鍵點檢測與目標定位

doi: 10.11999/JEIT240242

1.
中南大學自動化學院長沙 410083
2.
中南大學電子信息學院長沙 410004

基金項目: 國家自然科學基金(62406346)，湖南省自然科學基金(2022JJ30052)，長沙市自然科學基金(kq2208285)

詳細信息

作者簡介:
侯斐斐：女，講師，研究方向?yàn)樘降乩走_(dá)圖像解譯、無損探測、深度學習、目標識別

彭應昊：男，本科生，研究方向?yàn)閳D像識別與深度學習

董健：男，教授，研究方向?yàn)樘炀€、雷達信號處理、機器學習算法及其電磁應用

銀雪：女，本科生，研究方向?yàn)橛?jì)算機視覺與目標識別

通訊作者:
董健　dongjian@csu.edu.cn

中圖分類號: TN957.51; TP391
計量
- 文章訪問數: 611
- HTML全文瀏覽量: 260
- PDF下載量: 86
- 被引次數: 0
出版歷程
- 收稿日期: 2024-04-08
- 修回日期: 2024-09-12
- 網絡出版日期: 2024-09-19
- 刊出日期: 2024-11-10

Ground Penetrating Radar Hyperbolic Keypoint Detection and Object Localization Based on Dual YOLOv8-pose Model

1.
School of Automation, Central South University, Changsha 410083, China
2.
School of Electronic Information, Central South University, Changsha 410004, China

Funds: The National Natural Science Foundation of China (62406346), Hunan Provincial Natural Science Foundation (2022J30052), Changsha Natural Science Foundation (kq2208285)

摘要

摘要: 探地雷達(GPR)是一種可用于地下目標識別的無損檢測方法。針對現有方法存在不同尺度目標兼容性差、復雜圖像識別難度大、無法精確定位等問題，該文提出一種基于雙重YOLO姿態模型(YOLOv8-pose)的GPR雙曲線關鍵點檢測與目標定位，命名為雙重YOLO關鍵點定位方法(DYKL)，用于地下目標的檢測與精確定位。所提模型架構包含兩個階段：首先，第1階段是基于YOLOv8-pose模型的GPR目標檢測，以確定候選目標的位置；接著，第1階段的部分訓練權重被共享并傳遞到第2階段，后者以此為基礎繼續訓練YOLOv8-pose網絡，用于候選目標特征的關鍵點檢測及獲取，從而實現地下目標的自動化定位。通過與級聯區域卷積網絡(Cascade R-CNN)、更快的區域卷積網絡(Faster R-CNN)、實時對象檢測模型(RTMDet)以及“你只看一次”人臉模型(YOLOv7-face)4種先進的深度模型進行比較，所提模型平均識別準確率達到98.8%，性能優于其他模型。結果表明所提DYKL模型具有較高的識別準確性與較強的魯棒性，可以為地下目標的精確定位提供參考。
- 探地雷達 /
- 目標檢測 /
- 關鍵點檢測 /
- YOLOv8
Abstract: Ground Penetrating Radar (GPR) is identified as a non-destructive method usable for the identification of underground targets. Existing methods often struggle with variable target sizes, complex image recognition, and precise target localization. To address these challenges, an innovative method is introduced that leverages a dual YOLOv8-pose model for the detection and precise localization of hyperbolic keypoint. This method, termed Dual YOLOv8-pose Keypoint Localization (DYKL), offers a sophisticated solution to the challenges inherent in GPR-based target identification and positioning. The proposed model architecture includes two stages: firstly, the YOLOv8-pose model is employed for the preliminary detection of GPR targets, adeptly identifying regions that are likely to contain these targets. Secondly, building upon the training weights established in the first phase, the model further hones the YOLOv8-pose network. This refinement is geared towards the precise detection of keypoints within the candidate target features, thereby facilitating the automated identification and exact localization of underground targets with enhanced accuracy. Through comparison with four advanced deep-learning models— Cascade Region-based Convolutional Neural Networks (Cascade R-CNN), Faster Region-based Convolutional Neural Networks (Faster R-CNN), Real-Time Models for object Detection (RTMDet), and You Only Look Once v7(YOLOv7-face), the proposed DYKL model exhibits an average recognition accuracy of 98.8%, surpassing these models. The results demonstrate the DYKL model’s high recognition accuracy and robustness, serving as a benchmark for the precise localization of subterranean targets.
- Ground penetrating radar /
- Target detection /
- Keypoint detection /
- YOLOv8

HTML全文

圖 1 算法整體框架

下載: 全尺寸圖片幻燈片

圖 2 YOLOv8-pose網絡結構圖

下載: 全尺寸圖片幻燈片

圖 3 關鍵點標注

下載: 全尺寸圖片幻燈片

圖 4 2維坐標系轉換

下載: 全尺寸圖片幻燈片

圖 5 不同階段下模型訓練過程的損失曲線

下載: 全尺寸圖片幻燈片

圖 6 DYKL模型檢測結果

下載: 全尺寸圖片幻燈片

圖 7 不同關鍵點檢測算法在仿真圖像上的性能對比

下載: 全尺寸圖片幻燈片

圖 8 不同關鍵點檢測算法在實測圖像數據上的對比結果

下載: 全尺寸圖片幻燈片

圖 9 與傳統圖像處理算法在仿真圖像上的性能對比

下載: 全尺寸圖片幻燈片

表 1 GPR目標自動識別算法

文獻	模型類別	算法	檢測目標	數據集	性能指標(%)
蘭天等人^[34]	圖像學目標檢測	基于擬合誤差消除雙曲線識別模型	/	實測圖像和仿真圖像	/
Pham等人^[16]	兩階段目標檢測	Faster R-CNN	/	50張仿真圖像和100張實測圖像	/
Cui等人^[18]	兩階段目標檢測	Faster R-CNN	地層界面	/	檢測框Pre= 98.3
Zhao等人^[20]	兩階段實例分割	Mask R-CNN	隧道襯砌上缺陷位置	/	檢測框Pre=96.1 掩模預測Pre=95.6
Hou等人^[21]	兩階段實例分割	基于MS—RCNN定制錨定方案	樹根	95張實測圖像	掩膜預測AP50=38.6
Wang等人^[26]	單階段目標檢測	SSD引入FPN特征融合層網絡和廣義交并集損失	/	1 170張仿真圖像	檢測框Pre=92.0 檢測框Rec=90.3
Qiu等人^[28]	單階段目標檢測	YOLOv5	鐵實驗材料	412張實測圖像	檢測框Pre=82.6 檢測框Rec=68.0
Hu等人^[29]	單階段目標檢測	YOLOv5引入注意力機制	地下缺陷	3 256張圖像包含實測圖像和仿真圖像	檢測框mAP=85.4
胡榮明等人^[30]	單階段目標檢測	YOLOv7	隧道襯砌病害	506張仿真圖像和84張實測圖像	檢測框Pre=97.9 檢測框Rec=90.6
Wang等人^[31]	單階段目標檢測	YOLOv8引入CBAM注意力機制	地下缺陷	837張實測圖像	檢測框mAP50=90.8 檢測框F1=88.3
Li等人^[32]	單階段關鍵點檢測	YOLOv4引入關鍵點回歸并增加Wing損失函數	植物根	1 000張仿真圖像和2 320張實測圖像	檢測框Pre=94.0 檢測框Rec=96.7
方濤濤等人^[33]	單階段關鍵點檢測	YOLOv8引入 CBAM 注意力機制和關鍵點回歸	地下管線	545張實測圖像和795張仿真圖像	定位水平誤差8.6 定位深度誤差1.8

下載: 導出CSV

表 2 模型輸入圖像的數量與尺寸

參數	目標檢測階段	關鍵點檢測階段
批量大小	32	64
圖像尺寸	640×640	128×128

下載: 導出CSV

表 3 各種目標檢測算法的平均精度與平均召回率

模型	mAP50↑	mAP50-95↑	Av_Recall↑
DYKL	0.988	0.642	0.960
Cascade^[40]	0.962	0.597	0.675
Faster R-CNN^[17]	0.940	0.546	0.638
RTMDet^[41]	0.905	0.535	0.719

下載: 導出CSV
