有限碼長域下針對多用戶大規模MIMO系統速率優化的高效功率分配算法
doi: 10.11999/JEIT240241
-
武漢大學電子信息學院 武漢 430000
基金項目: 國家重點研發計劃(2023YFE0206600)
Efficient Power Allocation Algorithm for Throughput Optimization of Multi-User Massive MIMO Systems in Finite Blocklength Regime
-
Electronic Information School, Wuhan University, Wuhan 430000, China
Funds: The National Key R&D Plan (2023YFE0206600)
-
摘要: 第六代(6G)移動通信網絡需要為大規模節點提供高可靠低時延通信(URLLC)服務。為此，該文針對多用戶大規模多輸入多輸出(MIMO)技術輔助的URLLC下行通信場景，基于有限碼長( FBL)域理論表征系統性能，以用戶速率公平性為目標，提出一種高效的功率分配算法。具體而言，該文首先針對傳統MIMO中基于全局奇異值分解(SVD)的線性預編碼方案復雜度高、不能兼顧用戶公平性等問題，設計基于局部SVD的預編碼方案，以相對較低的復雜度實現對MIMO用戶間干擾和用戶內干擾的有效抑制。其次，該文以功率分配因子為優化變量、以最大化最小用戶速率(MMR)為目標構建優化問題。為解決所構建的高維變量耦合非凸問題，該文通過引入輔助變量、分段McCormick包絡將目標函數中香農容量相關項凸松弛處理，實現MMR問題重構。進而該文提出基于連續凸近似(SCA)的優化算法有效求解MMR問題。仿真結果驗證了所提優化算法的收斂性與準確性，同時也表明所提優化方案相比于現有方案在系統MMR性能和魯棒性上均具有優勢。
-
關鍵詞:
- 超可靠低時延通信(URLLC) /
- 多用戶MIMO /
- 有限碼長(FBL) /
- 連續凸近似(SCA)
Abstract:Objective The 6th Generation (6G) mobile communication network aims to provide Ultra-Reliable and Low Latency Communication (URLLC) services to a large number of nodes. To support URLLC for massive users, Multiple-In-Multiple-Out (MIMO) technology has become a key enabler for improving system performance in 6G. However, URLLC systems typically operate with Finite BlockLength (FBL) codes, which pose unique challenges for resource allocation design due to their deviation from traditional methods in the infinite blocklength regime. Although prior studies have explored resource allocation strategies for MIMO-assisted URLLC, power allocation design that considers user fairness remains unresolved. This paper proposes an efficient power allocation algorithm for multi-user MIMO systems in the FBL regime, addressing the issue of user fairness. Methods This study investigates the MIMO-assisted URLLC downlink communication scenario. The system performance is first characterized based on FBL theory, revealing the achievable rate of MIMO downlink users, which introduces significant nonconvexity compared to the infinite blocklength regime. Given the base station's limited power resources, setting system throughput as the optimization objective fails to ensure user fairness. To address this, a Maximum Minimum Rate (MMR) optimization problem is formulated, with power allocation factors as the optimization variables, subject to a total power constraint. The formulated problem is highly nonconvex due to the nonconvex terms in the objective function. To develop an efficient power allocation design for the MMR problem, a low-complexity precoding strategy is first proposed to mitigate both inter-user and intra-user interference. This precoding strategy, based on the local Singular Value Decomposition (SVD) method, reduces complexity compared with the traditional global SVD precoding strategy and effectively suppresses interference. To address the nonconvexity introduced by the Shannon capacity and channel dispersion terms in the objective function, convex relaxation and approximation techniques are introduced. The convex relaxation involves auxiliary variables and piecewise McCormick envelopes to manage the Shannon capacity term, transforming the MMR problem into an optimization problem where only the channel dispersion term remains nonconvex. For the relaxed problem, the channel dispersion term is then approximated by an upper bound function, rigorously shown to be convex through analytical findings. Based on this convex relaxation and approximation, the original MMR problem can be approximated by a convex subproblem at a given feasible point and efficiently solved using the Successive Convex Approximation (SCA) algorithm. Convergence and optimality analyses of the proposed algorithm are provided. Results and Discussions The proposed power allocation design is evaluated and validated through numerical simulations. To demonstrate the superiority of the proposed design, several benchmarks are introduced for comparison. For the proposed precoding design based on local SVD, the global SVD precoding method is included to validate its advantage in terms of complexity. The Shannon-rate-oriented rate maximization methods are also introduced to verify the accuracy of the proposed convex relaxation design. Moreover, the suboptimality of the SCA-based algorithm is validated through comparisons with other benchmarks, including the exhaustive search method. First, the low-complexity advantage of the proposed precoding design is demonstrated ( Fig. 2 ). The proposed precoding strategy exhibits low complexity in both small-scale and large-scale user scenarios. The performance of the suboptimal solutions obtained using the proposed SCA-based algorithm is compared with the globally optimal solutions from the exhaustive search method (Fig. 3 ). The results confirm the accuracy of the proposed algorithm, with a performance loss of less than 3%. The effect of the base station's antenna number on both the MMR problem and the system throughput maximization problem is illustrated (Fig. 4 ), further validating the effectiveness and applicability of the local SVD precoding strategy. The tightness of the convex relaxation is examined (Fig. 5 ), confirming that the proposed design becomes more advantageous as the user antenna number increases. The effect of blocklength on MMR performance is explored (Fig. 6 ), while the variation trend of MMR with respect to average transmit power is shown (Fig. 7). The influence of antenna number at both base station and user sides on MMR performance is investigated (Fig. 8 ), while the effect of user number on MMR performance is demonstrated (Fig. 9 ).Conclusions This paper investigates the optimization of user rate fairness in downlink MIMO-assisted URLLC scenarios. The system performance in the FBL regime is characterized, and based on this modeling, an MMR optimization problem is formulated under a sum power constraint, which is inherently nonconvex. To address this nonconvexity, a local SVD-based precoding design is proposed to reduce precoding complexity while ensuring fairness. Furthermore, convex relaxation is applied by introducing auxiliary variables and piecewise McCormick envelopes. The relaxed objective function is then approximated by an upper bound function, whose convexity is rigorously proven. Building on this relaxation and approximation, an SCA-based algorithm is developed to effectively solve the MMR problem. The proposed design is validated through numerical simulations, where its validity and parameter influence on system performance are discussed. The approach can be extended to other URLLC scenarios, such as multi-cell MIMO, and provides valuable insights for solving nonconvex optimization problems in related fields. -
1 基于連續凸近似的MMR功率分配算法
(1) 初始化功率分配因子向量${{\boldsymbol{\beta}} ^{(0)}}$，設置閾值$ \varepsilon$； (2) 初始化迭代次數$m = 0$，根據${{\boldsymbol{\beta}} ^{(0)}}$計算${\gamma _{gk}}$，得到$\gamma _{gk}^{(0)}$； (3) 根據${\boldsymbol{\beta}} _{gk}^{^{(0)}}$，$\gamma _{gk}^{(0)}$求解凸子優化問題(SP1.3)，得到$\gamma _{gk}^{(1)}$, ${\boldsymbol{\beta}} _{gk}^{^{(1)}}$,
$R_{\min }^{(1)}\,$；(4) for $m = 2,3, \cdots $ (5) 根據${\boldsymbol{\beta}} _{gk}^{^{(m - 1)}}$，$\gamma _{gk}^{(m - 1)}$求解優化問題(SP1.3)，得到$\gamma _{gk}^{(m)}$,
${\boldsymbol{\beta}} _{gk}^{^{(m)}}$, $R_{\min }^{(m)}\,$；(6) if $\left\| R_{\min}^{(m)} -R_{\min}^{(m-1)} \right\| \ge \varepsilon $, then 更新$m \leftarrow m + 1$再次進
入步驟5并繼續計算；(7) else 根據${{\boldsymbol{\beta}} ^{(m)}}$計算目標函數$ {{\boldsymbol{R}}}_{\mathrm{min}}({\boldsymbol{\beta}} ) $，得到問題
(OP1)的有效解，終止迭代并返回結果；(8) end
下載: 導出CSV
-
[1] HAMIDI-SEPEHR F, SAJADIEH M, PANTELEEV S, et al. 5G URLLC: Evolution of high-performance wireless networking for industrial automation[J]. IEEE Communications Standards Magazine, 2021, 5(2): 132–140. doi: 10.1109/MCOMSTD.001.2000035. [2] International Telecommunication Union. IMT Vision—Framework and Overall Objectives of the Future Development of IMT for 2020 and Beyond[M]. Geneva: Electronic Publication, 2015. [3] ZHANG Zhengquan, XIAO Yue, MA Zheng, et al. 6G wireless networks: Vision, requirements, architecture, and key technologies[J]. IEEE Vehicular Technology Magazine, 2019, 14(3): 28–41. doi: 10.1109/MVT.2019.2921208. [4] 袁偉杰, 李雙洋, 種若汐, 等. 面向6G物聯網的分布式譯碼技術[J]. 電子與信息學報, 2021, 43(1): 21–27. doi: 10.11999/JEIT200343.YUAN Weijie, LI Shuangyang, CHONG Ruoxi, et al. A distributed decoding algorithm for 6G internet-of-things networks[J]. Journal of Electronics & Information Technology, 2021, 43(1): 21–27. doi: 10.11999/JEIT200343. [5] 黃崇文, 季然, 魏麗, 等. 面向全息MIMO 6G通信的電磁信道建模理論與方法[J]. 電子與信息學報, 2024, 46(5): 1940–1950. doi: 10.11999/JEIT231219.HUANG Chongwen, JI Ran, WEI Li, et al. Electromagnetic channel modeling theory and approaches for holographic MIMO wireless communications[J]. Journal of Electronics & Information Technology, 2024, 46(5): 1940–1950. doi: 10.11999/JEIT231219. [6] MA Wenyan, ZHU Lipeng, and ZHANG Rui. MIMO capacity characterization for movable antenna systems[J]. IEEE Transactions on Wireless Communications, 2024, 23(4): 3392–3407. doi: 10.1109/TWC.2023.3307696. [7] CHI Yuhao, LIU Lei, SONG Lei, et al. Constrained capacity optimal generalized multi-user MIMO: A theoretical and practical framework[J]. IEEE Transactions on Communications, 2022, 70(12): 8086–8104. doi: 10.1109/TCOMM.2022.3207813. [8] LV Zhihan, QIAO Liang, and YOU I. 6G-enabled network in box for internet of connected vehicles[J]. IEEE Transactions on Intelligent Transportation Systems, 2021, 22(8): 5275–5282. doi: 10.1109/TITS.2020.3034817. [9] WANG Bin, XU Ke, ZHENG Shilian, et al. A deep learning-based intelligent receiver for improving the reliability of the MIMO wireless communication system[J]. IEEE Transactions on Reliability, 2022, 71(2): 1104–1115. doi: 10.1109/TR.2022.3148114. [10] POLYANSKIY Y, POOR H V, and VERDU S. Channel coding rate in the finite blocklength regime[J]. IEEE Transactions on Information Theory, 2010, 56(5): 2307–2359. doi: 10.1109/TIT.2010.2043769. [11] YANG Wei, DURISI G, KOCH T, et al. Quasi-static multiple-antenna fading channels at finite blocklength[J]. IEEE Transactions on Information Theory, 2014, 60(7): 4232–4265. doi: 10.1109/TIT.2014.2318726. [12] ZHU Yao, HU Yulin, YUAN Xiaopeng, et al. Joint convexity of error probability in blocklength and transmit power in the finite blocklength regime[J]. IEEE Transactions on Wireless Communications, 2023, 22(4): 2409–2423. doi: 10.1109/TWC.2022.3211454. [13] ZHAO Linlin, YANG Shaoshi, CHI Xuefen, et al. Achieving energy-efficient uplink URLLC with MIMO-aided grant-free access[J]. IEEE Transactions on Wireless Communications, 2022, 21(2): 1407–1420. doi: 10.1109/TWC.2021.3104043. [14] PENG Qihao, REN Hong, PAN Cunhua, et al. Resource allocation for uplink cell-free massive MIMO enabled URLLC in a smart factory[J]. IEEE Transactions on Communications, 2023, 71(1): 553–568. doi: 10.1109/TCOMM.2022.3224502. [15] HE Shiwen, AN Zhenyu, ZHU Jianyue, et al. Beamforming design for multiuser uRLLC with finite blocklength transmission[J]. IEEE Transactions on Wireless Communications, 2021, 20(12): 8096–8109. doi: 10.1109/TWC.2021.3090197. [16] FANG Hao, HU Han, ZHANG Yao, et al. Achievable rate analysis and power optimization for cell-free massive MIMO URLLC systems over aging and correlated channels[J]. IEEE Internet of Things Journal, 2024, 11(14): 25239–25250. doi: 10.1109/JIOT.2024.3392298. [17] SHENG Zhichao, TUAN H D, NASIR A, et al. Power allocation for energy efficiency and secrecy of wireless interference networks[J]. IEEE Transactions on Wireless Communications, 2018, 17(6): 3737–3751. doi: 10.1109/TWC.2018.2815626. [18] JIANG Hao, ZHANG Zaichen, WU Liang, et al. A non-stationary geometry-based scattering vehicle-to-vehicle MIMO channel model[J]. IEEE Communications Letters, 2018, 22(7): 1510–1513. doi: 10.1109/LCOMM.2018.2834366. [19] HUANG Jie, WANG Chengxiang, CHANG Hengtai, et al. Multi-frequency multi-scenario millimeter wave MIMO channel measurements and modeling for B5G wireless communication systems[J]. IEEE Journal on Selected Areas in Communications, 2020, 38(9): 2010–2025. doi: 10.1109/JSAC.2020.3000839. [20] WANG Jun, WANG Chengxiang, HUANG Jie, et al. A general 3D space-time-frequency non-stationary THz channel model for 6G ultra-massive MIMO wireless communication systems[J]. IEEE Journal on Selected Areas in Communications, 2021, 39(6): 1576–1589. doi: 10.1109/JSAC.2021.3071850. [21] YANG Guanghua, ZHANG Huan, SHI Zheng, et al. Asymptotic outage analysis of spatially correlated rayleigh MIMO channels[J]. IEEE Transactions on Broadcasting, 2021, 67(1): 263–278. doi: 10.1109/TBC.2020.3028346. [22] JOUNG H, JO H S, MUN C, et al. Capacity loss due to polarization-mismatch and space-correlation on MISO channel[J]. IEEE Transactions on Wireless Communications, 2014, 13(4): 2124–2136. doi: 10.1109/TWC.2014.031314.131079. [23] LIU An, LAU V K N, and KANANIAN B. Stochastic successive convex approximation for non-convex constrained stochastic optimization[J]. IEEE Transactions on Signal Processing, 2019, 67(16): 4189–4203. doi: 10.1109/TSP.2019.2925601. [24] ZHAN Jinlong and DONG Xiaodai. Interference cancellation aided hybrid beamforming for mmwave multi-user massive MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2021, 70(3): 2322–2336. doi: 10.1109/TVT.2021.3057547. [25] LONG Wenxuan, CHEN Rui, MORETTI M, et al. Joint spatial division and coaxial multiplexing for downlink multi-user OAM wireless backhaul[J]. IEEE Transactions on Broadcasting, 2021, 67(4): 879–893. doi: 10.1109/TBC.2021.3081869. [26] FONTENLA-ROMERO O, PéREZ-SáNCHEZ B, and GUIJARRO-BERDI?AS B. LANN-SVD: A non-iterative SVD-based learning algorithm for one-layer neural networks[J]. IEEE Transactions on Neural Networks and Learning Systems, 2018, 29(8): 3900–3905. doi: 10.1109/TNNLS.2017.2738118. [27] KOLODZIEJ S, CASTRO P M, and GROSSMANN I E. Global optimization of bilinear programs with a multiparametric disaggregation technique[J]. Journal of Global Optimization, 2013, 57(4): 1039–1063. doi: 10.1007/s10898-012-0022-1. [28] DE ASSIS L S, CAMPONOGARA E, ZIMBERG B, et al. A piecewise McCormick relaxation-based strategy for scheduling operations in a crude oil terminal[J]. Computers & Chemical Engineering, 2017, 106: 309–321. doi: 10.1016/j.compchemeng.2017.06.012. [29] BOYD S and VANDENBERGHE L. Convex Optimization[M]. Cambridge: Cambridge University Press, 2004: 67–95. [30] NASIR A A, TUAN H D, NGO H Q, et al. Cell-free massive MIMO in the short blocklength regime for URLLC[J]. IEEE Transactions on Wireless Communications, 2021, 20(9): 5861–5871. doi: 10.1109/TWC.2021.3070836. -
