一種純方位多目標跟蹤的聯合多高斯混合概率假設密度濾波器
doi: 10.11999/JEIT240201
-
西北工業大學航海學院 西安 710072
基金項目: 國家自然科學基金(62071386)
Joint Multi-Gaussian Mixture Probability Hypothesis Density Filter for Bearings-only Multi-target Tracking
-
School of Marine Science and Technology, Northwestern Polytechnical University, Xi’an 710072, China
Funds: The National Natural Science Foundation of China (62071386)
-
摘要: 現有的多模型-高斯混合-概率假設密度(MM-GM-PHD)濾波器被廣泛用于不確定機動目標跟蹤，但它不能在不同模型下保持并行的估計，導致各模型的似然值滯后于目標機動。為此，該文提出一種聯合多高斯混合概率假設密度(JMGM-PHD)濾波器，并將其用于純方位多目標跟蹤。首先，推導了JMGM模型，其中每個單目標狀態估計由一組并行的、帶模型概率的高斯函數描述，該狀態估計的概率由一個非負的權重來表征。一組權值、模型概率、均值和協方差被統稱為JMGM分量。根據貝葉斯規則，推導了JMGM分量的更新方法。然后，利用JMGM模型近似多目標PHD。根據交互式多模型(IMM)規則，推導出JMGM分量的交互、預測和估計方法。將所提JMGM-PHD濾波器應用于純方位跟蹤(BOT)時，針對同時執行平移和旋轉的觀測站，基于復合函數求導規則推導出一種計算線性化觀測矩陣的方法。所提JMGM-PHD濾波器保持了單模型PHD濾波器的形式，但能夠自適應地跟蹤不確定機動目標。仿真結果表明，JMGM-PHD濾波器克服了似然值滯后于目標機動的問題，在跟蹤精度和計算成本方面均優于MM-GM-PHD濾波器。
-
關鍵詞:
- 不確定機動目標跟蹤 /
- 概率假設密度濾波器 /
- 交互多模型 /
- 平移和旋轉 /
- 純方位跟蹤
Abstract: The Multi-Model Gaussian Mixture-Probability Hypothesis Density (MM-GM-PHD) filter is widely used in uncertain maneuvering target tracking, but it does not maintain parallel estimates under different models, leading to the model-related likelihood lagging behind unknown target maneuvers. To solve this issue, a Joint Multi-Gaussian Mixture PHD (JMGM-PHD) filter is proposed and applied to bearings-only multi-target tracking in this paper. Firstly, a JMGM model is derived, where each single-target state estimate is described by a set of parallel Gaussian functions with model probabilities, and the probability of this state estimate is characterized by a nonegative weight. The weights, model-related probabilities, means and covariances are collectively called JMGM components. According to the Bayesian rule, the updating method of the JMGM components is derived. Then, the multi-target PHD is approximated using the JMGM model. According to the Interactive Multi-Model (IMM) rule, the interacting, prediction and estimation methods of the JMGM components are derived. When addressing Bearings-Only Tracking (BOT), a method based on the derivative rule for composite functions is derived to compute the linearized observation matrix of observers that simultaneously performs translations and rotations. The proposed JMGM-PHD filter preserves the form of regular single-model PHD filter but can adaptively track uncertain maneuvering targets. Simulations show that our algorithm overcomes the likelihood lag issue and outperforms the MM-GM-PHD filter in terms of tracking accuracy and computation cost. -
1 所提JMGM-PHD濾波應用于BOT時的算法
輸入：上一時刻PHD $ {v_{k - 1}} $、量測$ {{\boldsymbol{Z}}_k} $、觀測站姿態$ (x_k^{\text{O}},y_k^{\text{O}}) $, $ \theta _k^{\text{O}} $ (1) 根據式(12)–式(15)預測PHD，得到式(16)所述的$ {v_{k|k - 1}} $ (2) 根據式(17)–式(21)更新$ {v_{k|k - 1}} $，其中似然的計算見式(29)、
式(30)(3) 剔除權重小于$ {\lambda _{\textq7j3ldu95}} $的JMGM分量，后根據式(31)–式(35)執行合并 (4) 根據式(24)–式(26)估計目標數、目標狀態和多目標模型概率 輸出：當前時刻PHD$ {v_k} $，多目標的狀態估計$ \hat {\boldsymbol{x}}_k^{(i)} $和模型概率$ u_k^{(m)} $
下載: 導出CSV
表 1 各濾波器平均OSPA誤差曲線的均值、最大值和標準差
濾波器 均值 最大值 標準差 MM-GM-PHD 50.150 2 97.146 2 10.729 5 MMF-GM-PHD 74.883 5 100.000 0 19.286 3 JMGM-PHD 41.452 3 62.084 0 8.463 9
下載: 導出CSV
-
[1] 嚴靈杰, 顧杰, 姜余, 等. 基于隨機有限集的多目標跟蹤技術綜述[J]. 電子信息對抗技術, 2024, 39(1): 81–88. doi: 10.3969/j.issn.1674-2230.2024.01.013.YAN Lingjie, GU Jie, JIANG Yu, et al. Overview of multi-target tracking technology based on random finite set[J]. Electronic Information Warfare Technology, 2024, 39(1): 81–88. doi: 10.3969/j.issn.1674-2230.2024.01.013. [2] MAHLER R P S. Multitarget Bayes filtering via first-order multitarget moments[J]. IEEE Transactions on Aerospace and Electronic Systems, 2003, 39(4): 1152–1178. doi: 10.1109/TAES.2003.1261119. [3] MAHLER R. PHD filters of higher order in target number[J]. IEEE Transactions on Aerospace and Electronic Systems, 2007, 43(4): 1523–1543. doi: 10.1109/TAES.2007.4441756. [4] VO B T, VO B N, and CANTONI A. The cardinality balanced multi-target multi-Bernoulli filter and its implementations[J]. IEEE Transactions on Signal Processing, 2009, 57(2): 409–423. doi: 10.1109/TSP.2008.2007924. [5] 陳一梅, 劉偉峰, 孔明鑫, 等. 基于GLMB濾波和Gibbs采樣的多擴展目標有限混合建模與跟蹤算法[J]. 自動化學報, 2020, 46(7): 1445–1456. doi: 10.16383/j.aas.c180077.CHEN Yimei, LIU Weifeng, KONG Mingxin, et al. A modeling and tracking algorithm of finite mixture models for multiple extended target based on the GLMB filter and Gibbs sampler[J]. Acta Automatica Sinica, 2020, 46(7): 1445–1456. doi: 10.16383/j.aas.c180077. [6] üNEY M, CLARK D E, and JULIER S J. Distributed fusion of PHD filters via exponential mixture densities[J]. IEEE Journal of Selected Topics in Signal Processing, 2013, 7(3): 521–531. doi: 10.1109/JSTSP.2013.2257162. [7] LI Tiancheng and HLAWATSCH F. A distributed particle-PHD filter using arithmetic-average fusion of Gaussian mixture parameters[J]. Information Fusion, 2021, 73: 111–124. doi: 10.1016/j.inffus.2021.02.020. [8] 王奎武, 張秦, 虎小龍. 基于多目標不確定性改進的GM-PHD濾波器[J]. 兵工學報, 2022, 43(12): 3113–3121. doi: 10.12382/bgxb.2021.0693.WANG Kuiwu, ZHANG Qin, and HU Xiaolong. Improved GM-PHD filter based on multi-target uncertainty[J]. Acta Armamentarii, 2022, 43(12): 3113–3121. doi: 10.12382/bgxb.2021.0693. [9] HUANG Qiao, XIE Lei, and SU Hongye. Estimations of time-varying birth cardinality distribution and birth intensity in Gaussian mixture CPHD filter for multi-target tracking[J]. Signal Processing, 2022, 190: 108321. doi: 10.1016/j.sigpro.2021.108321. [10] WANG Linxi, HU Xiaoxi, HAN Xun, et al. Simulation of CBMeMber multi-target tracking algorithm based on Gauss mixture[C]. The IEEE 19th International Conference on Communication Technology, Xi’an, China, 2019: 1524–1528. doi: 10.1109/ICCT46805.2019.8947076. [11] YANG Chaoqun, CAO Xianghui, and SHI Zhiguo. Road-map aided Gaussian mixture labeled multi-Bernoulli filter for ground multi-target tracking[J]. IEEE Transactions on Vehicular Technology, 2023, 72(6): 7137–7147. doi: 10.1109/TVT.2023.3240740. [12] 邵鵬飛, 王蕾, 王方勇. 基于序貫蒙特卡洛與概率假設密度濾波的主動分布式聲納多目標跟蹤[J]. 兵工學報, 2020, 41(5): 941–949. doi: 10.3969/j.issn.1000-1093.2020.05.013.SHAO Pengfei, WANG Lei, and WANG Fangyong. Active distributed sonar multi-target tracking based on SMC-PHD filtering[J]. Acta Armamentarii, 2020, 41(5): 941–949. doi: 10.3969/j.issn.1000-1093.2020.05.013. [13] CAO Chenghu, ZHAO Yongbo, PANG Xiaojiao, et al. Sequential Monte Carlo cardinalized probability hypothesized density filter based on Track-Before-Detect for fluctuating targets in heavy-tailed clutter[J]. Signal Processing, 2020, 169: 107367. doi: 10.1016/j.sigpro.2019.107367. [14] WANG Haihuan, LYU Xiaoyong, and MA Long. Adaptive cardinality balanced multi-target multi-Bernoulli filter based on cubature Kalman[J]. The Journal of Engineering, 2019, 2019(21): 7667–7671. doi: 10.1049/joe.2019.0670. [15] HOU Liming, LIAN Feng, DE ABREU G T F, et al. Robust δ-generalized labeled multi-Bernoulli filter for nonlinear systems with heavy-tailed noises[C]. The IEEE 23rd International Conference on Information Fusion, Rustenburg, South Africa, 2020: 1–8. doi: 10.23919/FUSION45008.2020.9190250. [16] ZHAO Shunyi, AHN C K, SHI Peng, et al. Bayesian state estimation for Markovian jump systems: Employing recursive steps and pseudocodes[J]. IEEE Systems, Man, and Cybernetics Magazine, 2019, 5(2): 27–36. doi: 10.1109/MSMC.2018.2882145. [17] DU Xue, HU Xianbo, HU Junsheng, et al. An adaptive interactive multi-model navigation method based on UUV[J]. Ocean Engineering, 2023, 267: 113217. doi: 10.1016/j.oceaneng.2022.113217. [18] ZHOU Gongjian, ZHU Bin, and YE Xiaoping. Switch-constrained multiple-model algorithm for maneuvering target tracking[J]. IEEE Transactions on Aerospace and Electronic Systems, 2023, 59(4): 4414–4433. doi: 10.1109/TAES.2023.3242944. [19] PUNITHAKUMAR K, KIRUBARAJAN T, and SINHA A. Multiple-model probability hypothesis density filter for tracking maneuvering targets[J]. IEEE Transactions on Aerospace and Electronic Systems, 2008, 44(1): 87–98. doi: 10.1109/TAES.2008.4516991. [20] DA Kai, LI Tiancheng, ZHU Yongfeng, et al. Gaussian mixture particle jump-Markov-CPHD fusion for multitarget tracking using sensors with limited views[J]. IEEE Transactions on Signal and Information Processing over Networks, 2020, 6: 605–616. doi: 10.1109/TSIPN.2020.3016478. [21] 楊標, 朱圣棋, 余昆, 等. 貪婪的量測劃分機制下的多傳感器多機動目標跟蹤算法[J]. 電子與信息學報, 2021, 43(7): 1962–1969. doi: 10.11999/JEIT200498.YANG Biao, ZHU Shengqi, YU Kun, et al. Multi-sensor multiple maneuvering targets tracking algorithm under greedy measurement partitioning mechanism[J]. Journal of Electronics & Information Technology, 2021, 43(7): 1962–1969. doi: 10.11999/JEIT200498. [22] CAO Chenghu and ZHAO Yongbo. A multiple-model generalized labeled multi-Bernoulli filter based on blocked Gibbs sampling for tracking maneuvering targets[J]. Signal Processing, 2021, 186: 108119. doi: 10.1016/j.sigpro.2021.108119. [23] WU Sunyong, DONG Xudong, ZHAO Jun, et al. A fast implementation of interactive-model generalized labeled multi-Bernoulli filter for interval measurements[J]. Signal Processing, 2019, 164: 345–353. doi: 10.1016/j.sigpro.2019.05.028. [24] TURNER J D, MCMAHON J, and ZAVLANOS M M. Receding horizon tracking of an unknown number of mobile targets using a bearings-only sensor[C]. 2022 International Conference on Robotics and Automation, Philadelphia, USA, 2022: 7327–7334. doi: 10.1109/ICRA46639.2022.9811882. [25] ZHANG Yuexing, LI Yiping, LI Shuo, et al. A multi-AUV bearings-only multi-target tracking method based on the fast LMB filter[C]. The 4th International Conference on Control and Robotics, Guangzhou, China, 2022: 446–451. doi: 10.1109/ICCR55715.2022.10053872. [26] CHEN Jinfeng, MA Hong, LIANG Chengguo, et al. OTHR multipath tracking using the Bernoulli filter[J]. IEEE Transactions on Aerospace and Electronic Systems, 2014, 50(3): 1974–1990. doi: 10.1109/TAES.2013.120659. [27] SCHUHMACHER D, VO B T, and VO B N. A consistent metric for performance evaluation of multi-object filters[J]. IEEE Transactions on Signal Processing, 2008, 56(8): 3447–3457. doi: 10.1109/TSP.2008.920469. -
