接收域分離的跨接收系統通用性輻射源指紋識別
doi: 10.11999/JEIT240171
-
國防科技大學電子科學學院 長沙 410073
基金項目: 國家自然科學基金(62301575)，國防科技大學青年自主創新科學基金(ZK2023-19)
Universal Radio Frequency Fingerprinting across Receiving Systems Using Receiving Domain Separation
-
College of Electronic Science and Technology, National University of Defense Technology Changsha 410073, China
Funds: The National Natural Science Foundation of China (62301575), The Youth Independent Innovation Science Fund Project of National University of Defense Technology (ZK2023-19)
-
摘要: 受輻射源硬件失真和接收機硬件失真的耦合作用，實際接收信號中帶有當前輻射源系統和接收系統共同的“個體信息”，導致輻射源指紋識別技術(RFF)在跨接收系統場景下無法通用。為消除接收機染色效應，該文將接收機影響作為單獨作用域，提出一種基于接收域分離的跨接收系統通用性輻射源指紋識別方法。該方法通過雙標簽多通道特征聯合和域分離對抗重構方式實現信號中輻射源指紋作用域與接收機染色作用域分離，利用多部接收機數據預先訓練網絡對兩種作用域的分離能力，聚焦輻射源指紋信息提取，從而提升輻射源指紋識別技術在跨平臺跨接收系統、更新接收設備等場景下的適應能力。相比于直接特征提取和多接收機打包訓練方式，所提方法能夠真正適應實際無監督場景，且參與訓練的源域接收機數目越多，域適應效果越好，不需要重復訓練即可直接推廣應用于新接收系統，具有較高的實際應用價值。
-
關鍵詞:
- 輻射源指紋識別 /
- 特定輻射源識別 /
- 域分離網絡 /
- 對抗訓練 /
- 無監督域適應
Abstract: Due to the coupling effect of emitter distortion and receiver distortion, the actual received signal contains the information of the current emitter system and the receiving system, which makes the Radio Frequency Fingerprinting (RFF) technology unable to be generalized in cross-receiving system scenarios. In order to eliminate the effect of receiver, in this paper, a universal RFF method across receiving systems based on receiving domain separation is proposed which considers the influence of the receiver as a separate scope. Through the dual-label multi-channel fusion feature and domain separation adversarial reconstruction method, after trained with multi-receiver data in the source domain, the proposed method can separate domains of transmitting and receiving, extract emitter fingerprint information, which improves the generalization of RFF in scenarios such as cross-receiving system and cross-platform. Compared with the existing cross-receiver RFF methods, the proposed method can truly adapt to the actual unsupervised scenario. And the more the number of source domain receivers participating in the training, the better the domain adaptation effect. It can be directly applied to the new receiving system without repeated training, which has high practical application value. -
表 1 輻射源失真參數設置
標簽 濾波器失真 I/Q不平衡 功率放大器 雜散單音與載頻泄露 $({a_0},{a_1},{\alpha _1})$ $({b_0},{b_1},{\beta _1})$ $G$ $\tau $ $({a_1},{a_2},{a_3})$ ${a_{{\text{ST}}}}$ ${f_{{\text{ST}}}}$ $\xi ({10^{ - 3}})$ E1 (1, 0.030, 0.25) (1, 0.030 2, 0.25) 0.999 8 –0.018 (1, 0.50, 0.30) 0.008 2 0.012 9 1.3+8.2j E2 (1, 0.060, 0.25) (1, 0.029 5, 0.25) 1.005 6 0.0175 (1, 0.08, 0.60) 0.007 5 0.013 2 1.5+7.2j E3 (1, 0.085, 0.25) (1, 0.029 0, 0.25) 1.010 2 0.012 (1, 0.01, 0.01) 0.007 0 0.012 3 1.1+6.8j E4 (1, 0.073, 0.25) (1, 0.031 0, 0.25) 0.999 2 0.003 (1, 0.01, 0.40) 0.008 7 0.013 5 1.7+9.0j E5 (1, 0.040, 0.25) (1, 0.031 3, 0.25) 0.998 2 0.024 (1, 0.60, 0.08) 0.00 90 0.011 9 2.0+6.5j
下載: 導出CSV
表 2 接收機失真參數設置
標簽 隨機性失真 確定性失真 相位噪聲 采樣抖動 量化噪聲 濾波器失真 低噪聲放大器失真 ($\sigma _\theta ^2$,${\varOmega _0}$) $v$ $\beta $ $({a_0},{a_1},{T_{\text{a}}})$ $({b_0},{b_1},{T_{\text}})$ $({c_1},{c_2},{c_3})$ R1 (1,0.001) 0.020 1 (1,0.010,4) (1,0.031 5,4) (1,0.10,0.01) R2 (1,0.010) 0.023 2 (1,0.015,4) (1,0.030 5,4) (1,0.15,0.02) R3 (1,0.020) 0.030 3 (1,0.020,4) (1,0.029 5,4) (1,0.20,0.03) R4 (1,0.021) 0.040 4 (1,0.025,4) (1,0.028 5,4) (1,0.25,0.04) R5 (1,0.022) 0.045 5 (1,0.030,4) (1,0.027 5,4) (1,0.30,0.05) R6 (1,0.023) 0.050 6 (1,0.035,4) (1,0.026 5,4) (1,0.35,0.06) R7 (1,0.024) 0.060 7 (1,0.040,4) (1,0.025 5,4) (1,0.40,0.07) R8 (1,0.025) 0.070 3 (1,0.045,4) (1,0.024 5,4) (1,0.45,0.08) R9 (1,0.026) 0.073 3 (1,0.050,4) (1,0.023 5,4) (1,0.50,0.09) R10 (1,0.027) 0.080 3 (1,0.055,4) (1,0.022 5,4) (1,0.55,0.10)
下載: 導出CSV
表 3 單接收機直接訓練方法的正確識別率(%)
R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 正確識別率 100.00 100.00 99.50 100.00 99.50 98.00 98.50 98.50 100.00 97.50
下載: 導出CSV
表 4 單接收機直接訓練方法的跨域適應能力統計(%)
目標域 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 均值 平均識別率 43.00 49.50 54.50 55.94 56.67 55.50 51.44 48.83 46.28 39.00 50.07 源域 R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 均值 平均識別率 40.39 45.67 48.11 54.11 57.11 53.11 60.22 50.50 52.44 39.00 50.07
下載: 導出CSV
表 5 多接收機打包統一訓練方法的正確識別率(含跨域適應)(%)
R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 均值 R1 100.00 98.50 62.00 51.00 38.00 21.00 20.00 20.00 20.00 20.00 38.94 R12 100.00 100.00 99.50 89.50 66.50 47.00 29.00 21.00 20.00 20.00 49.06 R123 100.00 100.00 100.00 100.00 100.00 84.00 64.00 40.00 22.50 20.00 61.50 R1234 100.00 100.00 100.00 100.00 100.00 99.50 92.50 74.00 44.50 23.00 72.25 R12345 100.00 100.00 100.00 100.00 100.00 100.00 100.00 93.50 77.00 44.50 83.00 均值 100.00 99.70 92.30 88.10 80.90 70.30 61.10 49.70 36.80 25.50 -
下載: 導出CSV
表 6 接收域分離方法的正確識別率(%)
R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 均值 R1 100.00 99.48 89.58 44.79 55.21 44.27 37.50 30.73 38.54 20.83 51.22 R12 99.48 99.48 95.31 89.06 68.75 71.88 53.13 56.25 36.98 41.15 64.06 R123 100.00 99.48 99.48 100.00 93.23 96.88 91.15 85.94 79.17 48.96 85.05 R1234 100.00 100.00 96.35 100.00 100.00 99.48 97.92 93.75 90.10 73.44 92.45 R12345 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 100.00 均值 99.90 99.69 96.14 86.77 83.44 82.50 75.94 73.33 68.96 56.88 -
下載: 導出CSV
表 7 多接收域分離方法消融實驗的正確識別率(%)
損失函數 網絡組成 識別率 損失函數 網絡組成 識別率 ${\mathcal{L}_{{\text{2 }}}} + {\mathcal{L}_{{\text{3 }}}}$ RF1+RF2+EF+RC 91.67 ${\mathcal{L}_{{\text{1 }}}} + {\mathcal{L}_{{\text{2 }}}}$ RF1+RF2+EF 98.44 ${\mathcal{L}_{{\text{2 }}}} + {\mathcal{L}_{{\text{4 }}}}$ RF1+RF2+EF+DE 99.48 ${\mathcal{L}_{{\text{2 }}}} + {\mathcal{L}_{{\text{3 }}}}$ RF1+EF+RC+DE 95.31 ${\mathcal{L}_{{\text{1 }}}} + {\mathcal{L}_{{\text{2 }}}}$ RF1+RF2+EF+DE 98.50 ${\mathcal{L}_{{\text{2 }}}}$ EF 44.50 無GRL RF1+RF2+EF+RC+DE 94.27 等權重 RF1+RF2+EF+RC+DE 93.23
下載: 導出CSV
-
[1] XU Zhengwei, HAN Guangjie, LI Liu, et al. A lightweight specific emitter identification model for IIoT devices based on adaptive broad learning[J]. IEEE Transactions on Industrial Informatics, 2023, 19(5): 7066–7075. doi: 10.1109/TII.2022.3206309. [2] ZHA Haoran, WANG Hanhong, FENG Zhongming, et al. LT-SEI: Long-tailed specific emitter identification based on decoupled representation learning in low-resource scenarios[J]. IEEE Transactions on Intelligent Transportation Systems, 2024, 52(1): 929–943. doi: 10.1109/TITS.2023.3308716. [3] 韋建宇, 俞璐. 通信輻射源個體識別中的特征提取方法綜述[J]. 通信技術, 2022, 55(6): 681–687. doi: 10.3969/j.issn.1002-0802.2022.06.001.WEI Jianyu and YU Lu. Overview of radio frequency fingerprint extraction in communication specific emitter identification[J]. Communications Technology, 2022, 55(6): 681–687. doi: 10.3969/j.issn.1002-0802.2022.06.001. [4] HE Boxiang and WANG Fanggang. Specific emitter identification via sparse Bayesian learning versus model-agnostic meta-learning[J]. IEEE Transactions on Information Forensics and Security, 2023, 18: 3677–3691. doi: 10.1109/TIFS.2023.3287073. [5] REHMAN S U, SOWERBY K W, and COGHILL C. Analysis of impersonation attacks on systems using RF fingerprinting and low-end receivers[J]. Journal of Computer and System Sciences, 2014, 80(3): 591–601. doi: 10.1016/j.jcss.2013.06.013. [6] RAMSEY B W, STUBBS T D, MULLINS B E, et al. Wireless infrastructure protection using low-cost radio frequency fingerprinting receivers[J]. International Journal of Critical Infrastructure Protection, 2015, 8: 27–39. doi: 10.1016/j.ijcip.2014.11.002. [7] 樂波, 王桂良, 黃淵凌, 等. 接收機畸變對輻射源指紋識別的影響[J]. 電訊技術, 2020, 60(3): 273–278. doi: 10.3969/j.issn.1001-893x.2020.03.005.LE Bo, WANG Guiliang, HUANG Yuanling, et al. Influence of receiver distortion characteristics on specific emitter identification[J]. Telecommunication Engineering, 2020, 60(3): 273–278. doi: 10.3969/j.issn.1001-893x.2020.03.005. [8] ZHENG Yenan, YING Wenwei, HONG Shaohua, et al. A method for cross-receiver specific emitter identification based on CBAM-CNN-BDA[C]. 2022 IEEE 4th International Conference on Civil Aviation Safety and Information Technology (ICCASIT), Dali, China, 2022: 1320–1324. doi: 10.1109/ICCASIT55263.2022.9987240. [9] FANG Yuyuan, WEI Song, ZHAO Yang, et al. Radar-specific emitter identification with only envelope power based on multidimensional complex noncentral chi-square classifier[J]. IEEE Sensors Journal, 2023, 23(17): 20223–20235. doi: 10.1109/JSEN.2023.3298352. [10] TAN Kaiwen, YAN Wenjun, ZHANG Limin, et al. Semi-supervised specific emitter identification based on bispectrum feature extraction CGAN in multiple communication scenarios[J]. IEEE Transactions on Aerospace and Electronic Systems, 2023, 59(1): 292–310. doi: 10.1109/TAES.2022.3184619. [11] ZHU Chenyu, LIU Liang, and PENG Xiaoyan. Specific emitter identification based on temporal convolutional network sequence processing[J]. IEEE Communications Letters, 2023, 27(10): 2667–2671. doi: 10.1109/LCOMM.2023.3312390. [12] WU Zitao, WANG Fanggang, and HE Boxiang. Specific emitter identification via contrastive learning[J]. IEEE Communications Letters, 2023, 27(4): 1160–1164. doi: 10.1109/LCOMM.2023.3247900. [13] BALDINI G, GIULIANI R, GENTILE C, et al. Measures to address the lack of portability of the RF fingerprints for radiometric identification[C]. 9th IFIP International Conference on New Technologies, Mobility and Security, Paris, France, 2018: 1–5. doi: 10.1109/NTMS.2018.8328703. [14] SHI Mengkai, HUANG Yuanling, and WANG Guiliang. Carrier leakage estimation method for cross-receiver specific emitter identification[J]. IEEE Access, 2021, 9: 26301–26312. doi: 10.1109/ACCESS.2021.3058167. [15] HE Boxiang and WANG Fanggang. Cooperative specific emitter identification via multiple distorted receivers[J]. IEEE Transactions on Information Forensics and Security, 2020, 15: 3791–3806. doi: 10.1109/TIFS.2020.30017210. [16] FAWAZ H I, DEL GROSSO G, KERDONCUFF T, et al. Deep unsupervised domain adaptation for time series classification: A benchmark[EB/OL]. https://arXiv.org/abs/2312.09857v2, 2023. [17] LI Ya, GONG Mingming, TIAN Xinmei, et al. Domain generalization via conditional invariant representations[C]. The 32nd AAAI Conference on Artificial Intelligence, New Orleans, USA, 2018: 3579–3587. doi: 10.1609/aaai.v32i1.11682. [18] MATSUURA T and HARADA T. Domain generalization using a mixture of multiple latent domains[C]. The 34th AAAI Conference on Artificial Intelligence, New York, USA, 2020: 11749–11756. doi: 10.1609/aaai.v34i07.6846. [19] GANIN Y, USTINOVA E, AJAKAN H, et al. Domain-adversarial training of neural networks[J]. The Journal of Machine Learning Research, 2016, 17(1): 2096–2030. [20] BOUSMALIS K, TRIGEORGIS G, SILBERMAN N, et al. Domain separation networks[C]. The 30th International Conference on Neural Information Processing Systems, Barcelona, Spain, 2016: 343–351. [21] SUN Liting, WANG Xiang, HUANG Zhitao, et al. Radio-frequency fingerprint extraction based on feature inhomogeneity[J]. IEEE Internet of Things Journal, 2022, 9(18): 17292–17308. doi: 10.1109/JIOT.2022.3154595. [22] SRIDHARAN G. Phase noise in multi-carrier systems[D]. [Master dissertation], University of Toronto, 2010. [23] HUANG Yuanling and ZHENG Hui. Theoretical performance analysis of radio frequency fingerprinting under receiver distortions[J]. Wireless Communications and Mobile Computing, 2015, 15(5): 823–833. doi: 10.1002/wcm.2386. [24] 陳翔, 汪連棟, 許雄, 等. 基于Raw I/Q和深度學習的射頻指紋識別方法綜述[J]. 雷達學報, 2023, 12(1): 214–234. doi: 10.12000/JR22140.CHEN Xiang, WANG Liandong, XU Xiong, et al. A review of radio frequency fingerprinting methods based on Raw I/Q and deep learning[J]. Journal of Radars, 2023, 12(1): 214–234. doi: 10.12000/JR22140. [25] 郭瑞鵬. 基于深度學習的雷達輻射源個體識別技術研究[D]. [碩士論文], 西安電子科技大學, 2022. doi: 10.27389/d.cnki.gxadu.2022.002199.GUO Ruipeng. Research on individual identification technology of radar emitter based on deep learning[D]. [Master dissertation], Xidian University, 2022. doi: 10.27389/d.cnki.gxadu.2022.002199. [26] DING Lida, WANG Shilian, WANG Fanggang, et al. Specific emitter identification via convolutional neural networks[J]. IEEE Communications Letters, 2018, 22(12): 2591–2594. doi: 10.1109/LCOMM.2018.2871465. [27] AL-SHAWABKA A, RESTUCCIA F, D’ORO S, et al. Exposing the fingerprint: Dissecting the impact of the wireless channel on radio fingerprinting[C]. IEEE Conference on Computer Communications, Toronto, Canada, 2020: 646–655. doi: 10.1109/INFOCOM41043.2020.9155259. -
