一種基于自適應容錯鏈路的片上網絡設計與研究

徐冬雨; 歐陽一鳴; 黃正峰; 李建華; 梁華國

doi:10.11999/JEIT240162

一種基于自適應容錯鏈路的片上網絡設計與研究

doi: 10.11999/JEIT240162

1.
安徽工程大學計算機與信息學院蕪湖 241000
2.
合肥工業大學計算機與信息學院合肥 230009
3.
合肥工業大學微電子學院合肥 230009

基金項目: 國家自然科學基金( 62374049, 62174048, 62274052)

詳細信息

作者簡介:
徐冬雨：男，講師，研究方向為集成芯片與芯粒技術、可重構片上互連網絡架構

歐陽一鳴：男，教授，研究方向為片上系統與片上網絡

黃正峰：男，教授，研究方向為集成電路容錯設計

李建華：男，副教授，研究方向為計算機體系結構、存儲系統、片上網絡

梁華國：男，教授，研究方向為數字系統設計自動化

通訊作者:
歐陽一鳴　oyymhfut@163.com

中圖分類號: TN402
計量
- 文章訪問數: 182
- HTML全文瀏覽量: 93
- PDF下載量: 25
- 被引次數: 0
出版歷程
- 收稿日期: 2024-03-12
- 修回日期: 2024-09-12
- 網絡出版日期: 2024-09-28
- 刊出日期: 2024-11-01

A Design of On-chip Network with Self-adaptive Fault-Tolerant Link

1.
School of Computer and Information , Anhui Polytechnic University, Wuhu 241000, China
2.
School of Computer Science and Information Engineering, Hefei University of Technology, Hefei 230009, China
3.
School of Microlectronics, Hefei University of Technology, Hefei 230009, China

Funds: The National Natural Science Foundation of China (62374049, 62174048, 62274052)

摘要

摘要: 隨著芯片制程不斷深入到亞微納米級別，技術節點的持續縮小加速了片上網絡中鏈路故障的發生。故障鏈路的增多降低了可用的路由路徑數量，并可能導致嚴重的流量擁塞甚至系統崩潰。為了保證在遭遇故障鏈路時數據包的正常傳輸，該文提出一種基于自適應容錯鏈路的片上網絡設計(AFL_NoC)，它能夠?qū)⒃庥龉收湘溌返臄?shù)據包轉發到另一條可逆鏈路上。該方案包括了可逆鏈路的具體實現以及相應的分布式控制協議。這種動態容錯鏈路設計充分利用了網絡中空閑的可用鏈路資源，確保了在遭遇鏈路故障的情況下網絡通信不會中斷。與先進的容錯偏轉路由算法QFCAR-W相比，AFL_NoC平均延遲降低10%，面積開銷減少了14.2%，功耗開銷減少了9.3%。
- 片上系統 /
- 片上網絡 /
- 容錯 /
- 路由器架構 /
- 路由算法
Abstract: As chip manufacturing has advanced to the sub-micro-nanometer scale, shrinking technology nodes are accelerating link failures in on-chip network, and the growth of failure links reduces the number of available routing paths and might lead to severe traffic congestion or even system crashes. The difficulty in maintaining the correctness of the on-chip system dramatically rises as the technology node shrinks. Previous schemes typically utilize deflection algorithms to bypass packets. However, they incur additional transmission latency due to hop count and raise the probability of deadlock. In order to achieve normal packet transmission when encountering faulty links, a self-Adaptive Fault-tolerant Link NoC design (AFL_NoC) is proposed, which redirects packets encountering a faulty link to another reversible link. The scheme contains a specific implementation of the reversible link and the associated distributed control protocol. The dynamic fault-tolerant link design fully utilizes the idle, available link and ensures that the network communication is not interrupted in case of link failures. Compared with the advanced fault-tolerant deflection routing algorithm QFCAR-W, AFL_NoC can reduce the average delay by 10%, the area overhead by 14.2%, and the power overhead by 9.3%.
- System-on-Chip (SoC) /
- Network-on-Chip (NoC) /
- Fault-tolerance /
- Router architecture /
- Routing algorithm
