基于多尺度時空卷積的唇語識別方法

葉鴻; 危勁松; 賈兆紅; 鄭輝; 梁棟; 唐俊

doi:10.11999/JEIT240161

基于多尺度時空卷積的唇語識別方法

doi: 10.11999/JEIT240161

葉鴻¹,
危勁松¹,
賈兆紅¹,
鄭輝^1, ,,
梁棟¹,
唐俊²

1.
安徽大學互聯網學院合肥 230039
2.
安徽大學電子信息工程學院合肥 230601

基金項目: 國家自然科學基金(71971002, 62273001)，安徽省自然科學基金(2108085QA35)，安徽省重點研究與開發計劃(202004a07020050)，安徽省科技重大專項(202003A06020016)，安徽省高校優秀科研創新團隊(2022AH010005)

詳細信息

作者簡介:
葉鴻：男，碩士生導師，研究方向為深度學習、人工智能、體系架構優化、并行計算

危勁松：男，碩士生，研究方向為計算機視覺

賈兆紅：女，教授，研究方向為人工智能、決策支持、多目標優化

鄭輝：男，講師，研究方向為多模態感知、計算機視覺

梁棟：男，教授，研究方向為計算機視覺與模式識別、信號處理與智能系統

唐?。耗?，教授，研究方向為計算機視覺與機器學習

通訊作者:
鄭輝　huizheng@ahu.edu.cn

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 290
- HTML全文瀏覽量: 124
- PDF下載量: 49
- 被引次數: 0
出版歷程
- 收稿日期: 2024-03-12
- 修回日期: 2024-09-10
- 網絡出版日期: 2024-09-16
- 刊出日期: 2024-11-10

Lipreading Method Based on Multi-Scale Spatiotemporal Convolution

1.
School of Internet, Anhui University, Hefei 230039, China
2.
School of Electronic and Information Engineering, Anhui University, Hefei 230601, China

Funds: The National Natural Science Foundation of China (71971002, 62273001), The Provincial Natural Science Foundation of Anhui (2108085QA35), Anhui Provincial Key Research and Development Project (202004a07020050), Anhui Provincial Major Science and Technology Project (202003A06020016), The Excellent Research and Innovation Teams in Anhui Province’s Universities (2022AH010005)

摘要

摘要: 現有的唇語識別模型大多采用將單層的3維卷積與2維卷積神經網絡結合的方式，從唇語視頻序列中挖掘出時空聯合特征。然而，由于單層的3維卷積不能很好地提取時間信息，同時2維卷積神經網絡對細粒度的唇語特征的挖掘能力有限，該文提出一種多尺度唇語識別網絡(MS-LipNet)以改善唇語識別任務。該文在Res2Net網絡中，采用3維時空卷積替代傳統的2維卷積以更好地提取時空聯合特征，同時提出時空坐標注意力模塊，使網絡關注于任務相關的重要區域特征。在LRW和LRW-1000數據集上進行實驗，驗證了所提方法的有效性。
- 唇語識別 /
- 多尺度時空卷積網絡 /
- Res2Net /
- 時空坐標注意力 /
- 數據增強
Abstract: Most of the existing lipreading models use a combination of single-layer 3D convolution and 2D convolutional neural networks to extract spatio-temporal joint features from lip video sequences. However, due to the limitations of single-layer 3D convolutions in capturing temporal information and the restricted capability of 2D convolutional neural networks in exploring fine-grained lipreading features, a Multi-Scale Lipreading Network (MS-LipNet) is proposed to improve lip reading tasks. In this paper, 3D spatio-temporal convolution is used to replace traditional two-dimensional convolution in Res2Net network to better extract spatio-temporal joint features, and a spatio-temporal coordinate attention module is proposed to make the network focus on task-related important regional features. The effectiveness of the proposed method was verified through experiments conducted on the LRW and LRW-1000 datasets.
- Lipreading /
- Multi-scale spatiotemporal convolutional network /
- Res2Net /
- Spatiotemporal coordinate attention /
- Data augmentation

HTML全文

圖 1 MS-LipNet整體框架

下載: 全尺寸圖片幻燈片

圖 2 STCA注意力模塊結構圖

下載: 全尺寸圖片幻燈片

圖 3 STCA子模塊結構圖

下載: 全尺寸圖片幻燈片

圖 4 ST-Res2Net結構圖

下載: 全尺寸圖片幻燈片

圖 5 模型的顯著性圖對比

下載: 全尺寸圖片幻燈片

表 1 不同方法在LRW和LRW-1000數據集上的識別準確率對比(%)

方法	LRW	LRW-1000
Two-Stream ResNet18+BiLSTM^[18]	84.07	–
2×ResNet18+BiGRU^[19]	84.13	41.93
ResNet18+3×BiGRU+MI^[30]	84.41	38.79
ResNet18+MS-TCN^[9]	85.30	41.40
SE-ResNet18+BiGRU^[13]	85.00	48.00
3D-ResNet18+BiGRU+TSM^[20]	86.23	44.60
ResNet18+HPConv+self-attention^[19]	86.83	–
WPCL+APFF^[31]	88.30	49.40
ResNet-18+DC-TCN^[10]	88.36	43.65
2DCNN+BiGRU+Lip Segmentation^[32]	90.38	–
ResNet18+DC-TCN+TimeMask^[33]	90.40	–
MS-LipNet	91.56	50.68

下載: 導出CSV

表 2 MS-LipNet網絡不同組件的消融實驗結果(%)

數據增強		注意力模塊	LRW	LRW-1000
Mixup	Cutout	STCA	LRW	LRW-1000
×	×	×	90.95	50.12
√	×	×	91.06	50.40
×	√	×	91.01	50.42
×	×	√	91.21	50.25
√	√	×	91.18	50.06
√	×	√	91.39	50.56
×	√	√	91.48	50.50
√	√	√	91.56	50.68

下載: 導出CSV

表 3 Cutout的不同取值對實驗結果的影響(%)

n_holes	length	LRW	LRW-1000
0	0	91.39	50.50
1	11	91.41	50.51
1	22	91.44	50.53
1	44	91.42	50.55
2	11	91.49	50.54
2	22	91.56	50.68
2	44	91.43	50.58
3	11	91.50	50.65
3	22	91.37	50.59
3	44	90.72	50.51

下載: 導出CSV
