聯合多曝光融合和圖像去模糊的深度網絡

張梅; 趙康威; 朱金輝

doi:10.11999/JEIT240113

聯合多曝光融合和圖像去模糊的深度網絡

doi: 10.11999/JEIT240113

張梅^{1, 2},
趙康威¹,
朱金輝^{3, 4, ,}

1.
華南理工大學自動化科學與工程學院廣州 510641
2.
華南理工大學自主系統與網絡控制教育部重點實驗室廣州 510641
3.
華南理工大學軟件學院廣州 510006
4.
華南理工大學大數據與智能機器人教育部重點實驗室廣州 510641

基金項目: 國家自然科學基金(62071184)

詳細信息

作者簡介:
張梅：女，副教授，研究方向?yàn)閮?yōu)化與調度、智能算法與仿真、圖形處理

趙康威：男，碩士生，研究方向?yàn)閳D像融合、深度學習

朱金輝：男，副教授，研究方向?yàn)橛?jì)算機應用技術

通訊作者:
朱金輝　csjhzhu@scut.edu.cn

中圖分類號: TN911.73; TP391
計量
- 文章訪問數: 280
- HTML全文瀏覽量: 84
- PDF下載量: 38
- 被引次數: 0
出版歷程
- 收稿日期: 2024-02-28
- 修回日期: 2024-10-08
- 網絡出版日期: 2024-10-12
- 刊出日期: 2024-11-10

Deep Network for Joint Multi-exposure Fusion and Image Deblur

ZHANG Mei^{1, 2},
ZHAO Kangwei¹,
ZHU Jinhui^{3, 4
, ,}

1.
School of Automation Science and Engineering, South China University of Technology, Guangzhou 510641, China
2.
Key Laboratory of Autonomous Systems and Network Control, Ministry of Education, South China University of Technology, Guangzhou 510641, China
3.
School of Software Engineering, South China University of Technology, Guangzhou 510006, China
4.
Key Laboratory of Big Data and Intelligent Robotics, Ministry of Education, South China University of Technology, Guangzhou 510641, China

Funds: The National Natural Science Foundation of China (62071184)

摘要

摘要: 多曝光圖像融合可提高圖像的動態范圍，從而獲取高質量的圖像。對于在像自動駕駛等快速運動場景中獲得的模糊的長曝光圖像，利用通用的圖像融合方法將其直接與低曝光圖像融合得到的圖像質量并不高。目前暫缺乏對帶有運動模糊的長曝光和短曝光圖像的端到端融合方法?；诖?該文提出一種聯合多曝光融合和圖像去模糊的深度網絡(DF-Net)端到端地解決帶有運動模糊的長短曝光圖像融合問題。該方法提出一種結合小波變換的殘差模塊用于構建編碼器和解碼器，其中設計單個編碼器對短曝光圖像進行特征提取，構建基于編碼器和解碼器的多級結構對帶有模糊的長曝光圖像進行特征提取，設計殘差均值激勵融合模塊進行長短曝光特征的融合，最后通過解碼器重建圖像。由于缺少基準數據集，創建了基于數據集 SICE 的帶有運動模糊的多曝光融合數據集，用于模型的訓練與測試。最后，從定性和定量的角度將所設計的模型和方法和其他先進的圖像去模糊和多曝光融合的分步優化方法進行了實驗對比，驗證了該文的模型和方法對帶有運動模糊的多曝光圖像融合的優越性。并在移動車輛上采集到的多曝光數據組上進行驗證，結果顯示了所提方法解決實際問題的有效性。
- 多曝光圖像融合 /
- 圖像去模糊 /
- 小波變換 /
- 特征融合
Abstract: Multi-exposure image fusion is used to enhance the dynamic range of images, resulting in higher-quality outputs. However, for blurred long-exposure images captured in fast-motion scenes, such as autonomous driving, the image quality achieved by directly fusing them with low-exposure images using generalized fusion methods is often suboptimal. Currently, end-to-end fusion methods for combining long and short exposure images with motion blur are lacking. To address this issue, a Deblur Fusion Network (DF-Net) is proposed to solve the problem of fusing long and short exposure images with motion blur in an end-to-end manner. A residual module combined with wavelet transform is proposed for constructing the encoder and decoder, where a single encoder is designed for the feature extraction of short exposure images, a multilevel structure based on encoder and decoder is built for feature extraction of long exposure images with blurring, a residual mean excitation fusion module is designed for the fusion of the long and short exposure features, and finally the image is reconstructed by the decoder. Due to the lack of a benchmark dataset, a multi-exposure fusion dataset with motion blur based on the dataset SICE is created for model training and testing. Finally, the designed model and method are experimentally compared with other state-of-the-art step-by-step optimization methods for image deblurring and multi-exposure fusion from both qualitative and quantitative perspectives to verify the superiority of the model and method in this paper for multi-exposure image fusion with motion blur. The validation is also conducted on a multi-exposure dataset acquired from a moving vehicle, and the effectiveness of the proposed method in solving practical problems is demonstrated by the results.
- Multi-exposure image fusion /
- Image deblurring /
- Wavelet transform /
- Feature fusion

HTML全文

圖 1 DF-Net網絡架構圖

下載: 全尺寸圖片幻燈片

圖 2 編碼器和解碼器結構圖

下載: 全尺寸圖片幻燈片

圖 3 小波殘差模塊結構圖

下載: 全尺寸圖片幻燈片

圖 4 殘差激勵均值融合模塊結構圖

下載: 全尺寸圖片幻燈片

圖 5 快速運動下長短曝光圖像及其頻域圖

下載: 全尺寸圖片幻燈片

圖 6 清晰圖像及其頻譜圖及添加運動模糊的圖像及其頻譜圖

下載: 全尺寸圖片幻燈片

圖 7 帶有模糊的多曝光圖像融合數據組

下載: 全尺寸圖片幻燈片

圖 8 測試集示例圖

下載: 全尺寸圖片幻燈片

圖 9 在帶有模糊的多曝光數據集的“塔”圖像上，DF-Net與“Deblur+MEF”策略下方法的圖像比較

下載: 全尺寸圖片幻燈片

圖 10 在帶有模糊的多曝光數據集的“森林”圖像上，DF-Net與“MEF+Deblur”策略下方法的圖像比較

下載: 全尺寸圖片幻燈片

圖 11 真實拍攝的帶有模糊多曝光數據集及融合結果圖

下載: 全尺寸圖片幻燈片

圖 12 模塊消融實驗的圖像比較

下載: 全尺寸圖片幻燈片

表 1 DF-Net與Deblur+MEF策略下最優方法在PSNR和SSIM上的比較

方法組合	DPE-MEF^[15]		IFCNN^[16]		MEFNet^[17]		U2fusion^[18]
方法組合	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM
DMPHN^[12]	18.012 0	0.822 6	19.470 0	0.813 5	16.630 0	0.746 0	18.075 9	0.700 9
MIMO-UNet^[13]	18.138 9	0.835 7	19.803 2	0.835 5	17.026 8	0.774 8	18.269 2	0.716 1
DeepRFT^[14]	19.052 9	0.912 8	20.517 4	0.906 0	18.154 6	0.870 8	18.760 7	0.752 9
DF-Net	PSNR = 21.712 6				SSIM = 0.924 6

下載: 導出CSV

表 2 DF-Net與MEF+Deblur策略下最優方法在PSNR和SSIM上的比較

方法組合	DPE-MEF^[15]		IFCNN^[16]		MEFNet^[17]		U2fusion^[18]
方法組合	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM	PSNR	SSIM
DMPHN^[12]	18.273 4	0.799 8	19.701 4	0.856 4	18.415 5	0.778 1	17.449 2	0.605 0
MIMO-UNet^[13]	20.089 6	0.873 1	20.187 9	0.876 1	18.601 4	0.797 1	19.563 0	0.815 0
DeepRFT^[14]	19.913 3	0.871 6	19.704 0	0.885 9	18.779 3	0.819 1	19.918 2	0.809 6
DF-Net	PSNR = 21.712 6				SSIM = 0.924 6

下載: 導出CSV

表 3 DF-Net在256p下與其他方法在FLOPs和Params上的比較

方法組合	DPE-MEF^[15]		IFCNN^[16]		MEFNet^[17]		U2fusion^[18]
方法組合	FLOPs	Params	FLOPs	Params	FLOPs	Params	FLOPs	Params
DMPHN^[12]	106.61	19.86	84.32	6.97	77.69	6.92	118.14	7.52
MIMO-UNet^[13]	180.95	28.33	158.66	15.44	152.03	15.39	192.48	15.99
DeepRFT^[14]	34.82	13.13	12.53	0.24	5.90	0.19	46.35	0.79
DF-Net	FLOPs = 2.01				Params = 0.28

下載: 導出CSV

表 4 模塊消融實驗比較

	小波殘差模塊	RMEFB	PSNR	SSIM
實驗1	×	×	21.216 1	0.912 4
實驗2	×	√	21.352 1	0.917 2
實驗3	√	×	21.602 4	0.919 6
DF-Net	√	√	21.712 6	0.924 6

下載: 導出CSV
