基于頻譜地圖重構的輻射源識別
doi: 10.11999/JEIT240050
-
北京交通大學電子信息工程學院 北京 100044
基金項目: 中央高?；究蒲袠I(yè)務費(2022JBQY004)，國家重點研發計劃(2020YFB1806903)，國家自然科學基金(62221001)，國家自然科學基金鐵路基礎研究聯合基金(U2368201)
Specific Emitter Identification Based on Radio Environment Map Reconstruction
-
School of Electronic and Information Engineering, Beijing Jiaotong University, Beijing 100044, China
Funds: The Fundamental Research Funds for the Central Universities (2022JBQY004), The National Key R&D Program of China (2020YFB1806903), The National Natural Science Foundation of China (62221001), The Joint Funds for Railway Fundamental Research of National Natural Science Foundation of China (U2368201)
-
摘要: 無線環境地圖(REM)是呈現電磁態勢的一種有效形式，考慮實際觀測的不完整頻譜地圖受到干擾和噪聲污染的問題，該文對頻譜地圖進行重構，并在此基礎上完成輻射源識別。首先，將復雜電磁環境下的頻譜地圖建模為高維張量，在預處理中通過線性插值對其初始化補全。然后，使用視覺Transformer模型解決語義分割問題以識別頻譜語義區域，區域中僅單一輻射源功率占主導，每個語義張量的低秩性得以保留。提出了一種壓縮式張量分解算法，并采用交替方向乘子法(ADMM)在語義區域中重構期望信號頻譜和干擾；最后，在重構的頻譜地圖上檢測未知輻射源的位置。該方法能夠充分利用頻譜數據的低秩性，適用于廣域多輻射源個體的電磁場景。實驗結果表明，所提方法比現有方法具有更優的重構性能，降低了達到相同頻譜地圖恢復精度時對觀測樣本比例的要求，并能夠準確檢測輻射源。
-
關鍵詞:
- 輻射源識別 /
- 頻譜地圖 /
- 語義分割 /
- 張量分解
Abstract: The Radio Environment Map (REM) is one of the effective ways to represent the electromagnetic situation. Considering the issue that the actual observed incomplete spectrum map is corrupted by the impulses and the noises, the incomplete radio environment map is reconstructed and the specific emitter identification is performed based on the reconstructed maps. First, the spectrum map in the complex electromagnetic environment is modeled as the high-dimensional spectrum tensor, and the incomplete spectrum tensor is initially completed by the linear interpolation in preprocessing. Then, the vision transformer model is employed to solve the semantic segmentation problem in order to identify the spectrum semantic regions, in which the power of only one emitter dominates and the low-rank property of each semantic tensor is further preserved. To reconstruct the REM, the compressed tensor decomposition algorithm is proposed, and the expected signal spectrum and impulses are recovered utilizing the Alternating Direction Method of Multipliers (ADMM) in the semantic regions. Finally, the locations of the unknown emitters are detected on the reconstructed spectrum map. The proposed approach leverages the low-rank property of spectrum data and works well in wide-area electromagnetic scenarios involving multiple emitters. The simulation results demonstrate that the proposed approach outperforms the comparative approach in terms of reconstruction performance. It requires fewer observation samples to achieve the same spectrum map recovery accuracy and can accurately detect emitters. -
1 基于語義分割的頻譜地圖重構算法
輸入：初始補全張量$ {{\tilde{ {\boldsymbol{\mathcal{Y}}}}}_m} $，語義標簽$ {{{\boldsymbol{\mathcal{L}}}}_m} $, $ m \in {{\mathcal{I}}_M} $，迭代次數K； 輸出：重構的期望頻譜$ {\tilde {\boldsymbol{\mathcal{X}}}} $； 初始化：$ {\tilde{ {\boldsymbol{\mathcal{X}}}}}_m^{(1)} = {\bf{0}} $, $ {\tilde {{\boldsymbol{\mathcal{S}}}}}_m^{(1)} = 0 $, $ {\lambda ^{(1)}} = 0 $, $ {\beta ^{(1)}} = {10^{ - 6}} $,
$ {\beta _{\max }} = {10^{10}} $, $ \rho = 1.2 $，m = 1, $ k = 1 $；(1) 當$ ||{{\boldsymbol{\mathcal{X}}}_m}||_{{\mathrm{F}}} ^2 $未收斂且$ k < K $，重復步驟(2)～(7)； (2) 使用式(22)更新$ {\boldsymbol{\mathcal{X}}}_m^{(k + 1)} $； (3) 使用式(24)更新$ {{\boldsymbol{\mathcal{S}}}}_m^{(k + 1)} $； (4) 使用式(25)更新$ \lambda _m^{(k + 1)} $； (5) 使用式(26)更新$ c_m^{(k + 1)} $； (6) $ {\beta ^{(k + 1)}} = \min \{ \rho {\beta ^{(k)}},{\beta _{{\text{max}}}}\} $； (7) k = k+1； (8) m = m+1； (9) 重復步驟(1)、步驟(8)，直到m = M； (10) $ {\tilde {\boldsymbol{\mathcal{X}}}}{\text{ = }}\displaystyle\sum\nolimits_{m = 1}^M {{{\boldsymbol{\mathcal{X}}}_m} \odot } {{{\boldsymbol{\mathcal{L}}}}_m} $。
下載: 導出CSV
-
[1] HO K C and LE T K. Integrating AOA with TDOA for joint source and sensor localization[J]. IEEE Transactions on Signal Processing, 2023, 71: 2087–2102. doi: 10.1109/TSP.2023.3280417. [2] LIU Yan, SHEN Yuan, and WIN M Z. Single-anchor localization and synchronization of full-duplex agents[J]. IEEE Transactions on Communications, 2019, 67(3): 2355–2367. doi: 10.1109/TCOMM.2018.2878843. [3] YILMAZ H B and TUGCU T. Location estimation-based radio environment map construction in fading channels[J]. Wireless Communications and Mobile Computing, 2015, 15(3): 561–570. doi: 10.1002/wcm.2367. [4] SHIN B, LEE J H, KIM C, et al. LTE RSSI based vehicular localization system in long tunnel environment[J]. IEEE Transactions on Industrial Informatics, 2023, 19(11): 11102–11114. doi: 10.1109/TII.2023.3240690. [5] CHAUDHARI S and CABRIC D. Cyclic weighted centroid algorithm for transmitter localization in the presence of interference[J]. IEEE Transactions on Cognitive Communications and Networking, 2016, 2(2): 162–177. doi: 10.1109/TCCN.2016.2586078. [6] 張國勇, 王軍, 陳霄南, 等. 基于空間稀疏采樣的頻譜態勢生成: 模型與算法[J]. 中國科學: 信息科學, 2022, 52(11): 2011–2036. doi: 10.1360/SSI-2021-0382.ZHANG Guoyong, WANG Jun, CHEN Xiaonan, et al. Spectrum situation generation from sparse spatial sampling: Model and algorithm[J]. Scientia Sinica Informationis, 2022, 52(11): 2011–2036. doi: 10.1360/SSI-2021-0382. [7] DEBROY S, BHATTACHARJEE S, and CHATTERJEE M. Spectrum map and its application in resource management in cognitive radio networks[J]. IEEE Transactions on Cognitive Communications and Networking, 2015, 1(4): 406–419. doi: 10.1109/TCCN.2016.2517001. [8] SATO K, SUTO K, INAGE K, et al. Space-frequency-interpolated radio map[J]. IEEE Transactions on Vehicular Technology, 2021, 70(1): 714–725. doi: 10.1109/TVT.2021.3049894. [9] ZHANG Yongliang and MA Lin. Radio map crowdsourcing update method using sparse representation and low rank matrix recovery for WLAN indoor positioning system[J]. IEEE Wireless Communications Letters, 2021, 10(6): 1188–1191. doi: 10.1109/LWC.2021.3061539. [10] CAI Jianfeng, CANDèS E J, and SHEN Zuowei. A singular value thresholding algorithm for matrix completion[J]. SIAM Journal on Optimization, 2010, 20(4): 1956–1982. doi: 10.1137/080738970. [11] SIDIROPOULOS N D, DE LATHAUWER L, FU Xiao, et al. Tensor decomposition for signal processing and machine learning[J]. IEEE Transactions on Signal Processing, 2017, 65(13): 3551–3582. doi: 10.1109/TSP.2017.2690524. [12] TANG Mengyun, DING Guoru, WU Qihui, et al. A joint tensor completion and prediction scheme for multi-dimensional spectrum map construction[J]. IEEE Access, 2016, 4: 8044–8052. doi: 10.1109/ACCESS.2016.2627243. [13] LIN Yun, TU Ya, DOU Zheng, et al. Contour Stella image and deep learning for signal recognition in the physical layer[J]. IEEE Transactions on Cognitive Communications and Networking, 2021, 7(1): 34–46. doi: 10.1109/TCCN.2020.3024610. [14] WANG Chenyue, WU Yuhang, ZHOU Fuhui, et al. Accurate spectrum map construction using an intelligent frequency-spatial reasoning approach[C]. 2022 IEEE Global Communications Conference, Rio de Janeiro, Brazil, 2022: 3460–3465. doi: 10.1109/GLOBECOM48099.2022.10001024. [15] SHRESTHA S, FU Xiao, and HONG Mingyi. Deep spectrum cartography: Completing radio map tensors using learned neural models[J]. IEEE Transactions on Signal Processing, 2022, 70: 1170–1184. doi: 10.1109/TSP.2022.3145190. [16] HU Tianyu, HUANG Yang, CHEN Junting, et al. 3D radio map reconstruction based on generative adversarial networks under constrained aircraft trajectories[J]. IEEE Transactions on Vehicular Technology, 2023, 72(6): 8250–8255. doi: 10.1109/TVT.2023.3239556. [17] LEVIE R, YAPAR ?, KUTYNIOK G, et al. RadioUNet: Fast radio map estimation with convolutional neural networks[J]. IEEE Transactions on Wireless Communications, 2021, 20(6): 4001–4015. doi: 10.1109/TWC.2021.3054977. [18] LIN Yun, ZHAO Haojun, MA Xuefei, et al. Adversarial attacks in modulation recognition with convolutional neural networks[J]. IEEE Transactions on Reliability, 2021, 70(1): 389–401. doi: 10.1109/TR.2020.3032744. [19] MENG Lingchen, LI Hengduo, CHEN B C, et al. AdaViT: Adaptive vision transformers for efficient image recognition[C]. 2022 IEEE/CVF Conference on Computer Vision and Pattern Recognition, New Orleans, USA, 2022: 12299–12308. doi: 10.1109/CVPR52688.2022.01199. [20] LI Hongyu, LI Jie, SHEN Feng, et al. SOC algorithm-based framework for spectrum occupancy completion[J]. IEEE Transactions on Cognitive Communications and Networking, 2023, 9(5): 1155–1166. doi: 10.1109/TCCN.2023.3269763. -
