自監督解耦動態分類器的小樣本類增量SAR圖像目標識別

趙琰; 趙凌君; 張思乾; 計科峰; 匡綱要

doi:10.11999/JEIT231470

自監督解耦動態分類器的小樣本類增量SAR圖像目標識別

doi: 10.11999/JEIT231470

國防科技大學電子科學學院長沙 410073

詳細信息

作者簡介:
趙琰：男，博士生，研究方向?yàn)镾AR圖像目標識別、增量學習、小樣本學習

趙凌君：女，博士，副教授，研究方向?yàn)檫b感信息處理、SAR圖像目標識別

張思乾：女，博士，副教授，研究方向?yàn)檫b感信息處理、SAR圖像目標識別

計科峰：男，博士，教授，研究方向?yàn)镾AR目標電磁散射特性建模、特征提取、檢測識別

匡綱要：男，博士，教授，研究方向?yàn)檫b感信息處理、SAR圖像目標識別

通訊作者:
趙凌君　nudtzlj@163.com

中圖分類號: TN957; TP751.2
計量
- 文章訪問數: 318
- HTML全文瀏覽量: 341
- PDF下載量: 98
- 被引次數: 0
出版歷程
- 收稿日期: 2024-01-10
- 修回日期: 2024-06-17
- 網絡出版日期: 2024-06-24
- 刊出日期: 2024-10-30

Few-Shot Class-Incremental SAR Image Target Recognition using Self-supervised Decoupled Dynamic Classifier

College of Electronic Science and Technology, National University of Defense Technology, Changsha 410073, China

摘要

摘要: 為提升基于深度學習(DL)的合成孔徑雷達自動目標識別(SAR ATR)系統在開放動態的非合作場景中對新類別目標的持續敏捷識別能力，該文研究了SAR ATR的小樣本類增量學習(FSCIL)問題，并提出了自監督解耦動態分類器(SDDC)。針對FSCIL 中“災難性遺忘”和“過擬合”本質難點和SAR ATR領域挑戰，根據SAR圖像目標信息的部件化與方位角敏感性特點，于圖像域構建了基于散射部件混淆與旋轉模塊(SCMR)的自監督學習任務，以提升目標表征的泛化性與穩健性。同時，設計了類印記交叉熵(CI-CE)損失并以參數解耦學習(PDL)策略對模型動態微調，以對新舊知識平衡判別。實驗在由MSTAR和SAR-AIRcraft-1.0數據集分別構建的覆蓋多種目標類別、觀測條件和成像平臺的FSCIL場景上驗證了該算法開放動態環境的適應能力。
- SAR目標識別 /
- 小樣本類增量學習 /
- 自監督學習 /
- 深度學習
Abstract: To power Deep-Learning (DL) based Synthetic Aperture Radar Automatic Target Recognition (SAR ATR) systems with the capability of learning new-class targets incrementally and rapidly in openly dynamic non-cooperative situations, the problem of Few-Shot Class-Incremental Learning (FSCIL) of SAR ATR is researched and a Self-supervised Decoupled Dynamic Classifier (SDDC) is proposed. Considering solving both the intrinsic Catastrophic forgetting and Overfitting dilemma of the FSCIL and domain challenges of SAR ATR, a self-supervised learning task powered by Scattering Component Mixup and Rotation (SCMR) is designed to improve the model’s generalizability and stability for target representation, leveraged by the partiality and azimuth dependence of target information in SAR imagery. Meanwhile, a Class-Imprinting Cross-Entropy (CI-CE) and a Parameter Decoupled Learning (PDL) strategy are designed to fine-tune networks dynamically to identify old and new targets evenly. Experiments on various FSCIL scenarios constructed by the MSTAR and the SAR-AIRcraft-1.0 datasets covering diverse target categories, observing environments, and imaging payloads, verify the method’s adaptability to openly dynamic world.
- SAR target recognition /
- Few-Shot Class-Incremental Learning(FSCIL) /
- Self-supervised learning /
- Deep Learning(DL)

HTML全文

圖 1 自監督動態解耦分類器(SDDC)整體結構

下載: 全尺寸圖片幻燈片

圖 2 SAR圖像目標結構與高維語義信息的方位角敏感性與相位模糊性

下載: 全尺寸圖片幻燈片

圖 3 基于誤差解耦理論對類印記初始化優勢分析

下載: 全尺寸圖片幻燈片

圖 4 FSCIL數據集構建過程

下載: 全尺寸圖片幻燈片

圖 5 MSTAR數據集10類目標SAR圖像與光學圖像對比

下載: 全尺寸圖片幻燈片

圖 6 SAR-AIRcarft-1.0數據集7類目標SAR圖像與光學圖像對比

下載: 全尺寸圖片幻燈片

圖 7 SMO對算法特征提取能力改善可視化結果

下載: 全尺寸圖片幻燈片

圖 8 采用SMO前后算法所提目標梯度激活圖與特征稀疏性與響應值

下載: 全尺寸圖片幻燈片

圖 9 采用SRO前后算法所提目標方位角特征歸一化值與梯度激活圖

下載: 全尺寸圖片幻燈片

圖 10 采用SRO前后算法所提類內特征相似性均值與方差

下載: 全尺寸圖片幻燈片

圖 11 算法分類準確率與歸一化分類器值。

下載: 全尺寸圖片幻燈片

圖 12 PDL不同解耦階段對算法在多種評價指標上分類性能影響的柱狀圖

下載: 全尺寸圖片幻燈片

圖 13 算法不同解耦位置對基類和增量類目標的梯度激活圖

下載: 全尺寸圖片幻燈片

圖 14 不同算法在MSTAR-FSCIL數據集和SAR-AIRcraft-1.0-FSCIL數據集測試性能曲線圖

下載: 全尺寸圖片幻燈片

圖 15 對比基準分類結果混淆矩陣

下載: 全尺寸圖片幻燈片

圖 16 不同學習階段MSTAR-FSCIL數據集類特征空間t-SNE分布

下載: 全尺寸圖片幻燈片

圖 17 不同學習階段SAR-AIRcraft-1.0-FSCIL數據集類特征空間t-SNE分布

下載: 全尺寸圖片幻燈片

1 散射混淆操作(SMO)處理過程

輸入：小批次基類訓練樣本 ${\boldsymbol} = \{ ({{\boldsymbol{x}}_i},{y_i})\} _{i = 1}^{\|{N_{}}\|} \in {{\boldsymbol{D}}^1}$
初始化：混淆次數 R ，混淆樣本存儲列表${S_{{\text{smo}}}}$
For r = 1 to R do
步驟1　采樣隨機順序數據${\boldsymbol{\tilde b}} = \{ ({{\boldsymbol{\tilde x}}_i},{\tilde y_i})\} _{i = 1}^{\|{N_{}}\|}$
步驟2　獲取原始$\{ {y_i}\} _{i = 1}^{\|{N_{}}\|}$與隨機順序$\{ {\tilde y_i}\} _{i = 1}^{\|{N_{}}\|}$標簽
步驟3　從${\boldsymbol}$中選取${\boldsymbol}' = \{ ({{\boldsymbol{x}}'_i},{y'_i})\} $，從${\boldsymbol{\tilde b}}$中選取　　　　　 $ {\boldsymbol{\tilde b}}' = \{ ({{\boldsymbol{\tilde x}}'_i},{\tilde y'_i})\} $，滿足${y'_j} \ne {\tilde y'_j},\forall j \in \|{N_{}}\|$
步驟4　根據式(1)從${\boldsymbol}'$與 $ {\boldsymbol{\tilde b}}' $中生成散射混淆樣本集　　　　　 $ {{\stackrel \frown{{\boldsymbol}} }} = \{ ({{{\stackrel \frown{{\boldsymbol{x}}} }}_i},{\stackrel \frown{y} _i})\} $
步驟5　將$ {{\stackrel \frown{{\boldsymbol}} }} $添加至${S_{{\text{smo}}}}$
End for
輸出：${S_{{\text{smo}}}}$

下載: 導出CSV

表 1 MSTAR-FSCIL數據集配置

學習階段	序號	類別	型號	訓練集	測試集
基類	1	BTR70	c71	233	196
	2	2S1	b01	299	274
	3	BRDM2	E-71	298	274
	4	BMP2	9563	233	196
增量類	5	ZIL131	E12	5	274
	6	T62	A51	5	274
	7	D7	13015	5	274
	8	BTR60	7532	5	195
	9	T72	132	5	196
	10	ZSU234	d08	5	274

下載: 導出CSV

表 2 SAR-AIRcraft-1.0-FSCIL數據集配置表

學習階段	序號	類別	訓練集	測試集
基類	1	Other	2 000	200
	2	A220	2 000	200
	3	Boeing787	2 000	200
	4	Boeing737	2 000	200
增量類	5	A320	5	200
	6	ARJ21	5	200
	7	A330	5	200

下載: 導出CSV

表 3 SDDC算法模塊與損失貢獻(%)

遷移性		判別性		Avg.Acc	Acc.Old	Acc.New	PD
SMO	SRO	CI-CE	PDL	Avg.Acc	Acc.Old	Acc.New	PD
				75.26	78.87	49.02	41.50
√				78.35	81.41	54.16	37.77
	√			77.79	81.27	52.24	35.29
√	√			79.50	82.68	54.46	34.47
√	√	√		73.30	72.62	79.12	55.83
√	√		√	75.81	79.01	47.22	42.35
√	√	√	√	81.73	83.37	66.70	31.61

下載: 導出CSV

參考文獻(18)

[1]	張路, 廖明生, 董杰, 等. 基于時間序列InSAR分析的西部山區滑坡災害隱患早期識別——以四川丹巴為例[J]. 武漢大學學報: 信息科學版, 2018, 43(12): 2039–2049. doi: 10.13203/j.whugis20180181. ZHANG Lu, LIAO Mingsheng, DONG Jie, et al. Early detection of landslide hazards in mountainous areas of West China using time series SAR interferometry-A case study of Danba, Sichuan[J]. Geomatics and Information Science of Wuhan University, 2018, 43(12): 2039–2049. doi: 10.13203/j.whugis20180181.
[2]	李永禎, 黃大通, 邢世其, 等. 合成孔徑雷達干擾技術研究綜述[J]. 雷達學報, 2020, 9(5): 753–764. doi: 10.12000/JR20087. LI Yongzhen, HUANG Datong, XING Shiqi, et al. A review of synthetic aperture radar jamming technique[J]. Journal of Radars, 2020, 9(5): 753–764. doi: 10.12000/JR20087.
[3]	傅興玉, 尤紅建, 付琨. 基于鄰域均方連續差分的SAR圖像邊緣提取算法[J]. 電子與信息學報, 2012, 34(5): 1030–1037. doi: 10.3724/SP.J.1146.2011.00920. FU Xingyu, YOU Hongjian, and FU Kun. An approach to extract edge in SAR image based on square successive difference of neighborhood averages[J]. Journal of Electronics & Information Technology, 2012, 34(5): 1030–1037. doi: 10.3724/SP.J.1146.2011.00920.
[4]	羅汝, 趙凌君, 何奇山, 等. SAR圖像飛機目標智能檢測識別技術研究進展與展望[J]. 雷達學報, 2024, 13(2): 307–330. doi: 10.12000/JR23056. LUO Ru, ZHAO Lingjun, HE Qishan, et al. Intelligent technology for aircraft detection and recognition through SAR imagery: Advancements and prospects[J]. Journal of Radars, 2024, 13(2): 307–330. doi: 10.12000/JR23056.
[5]	周大蔚, 汪福運, 葉翰嘉, 等. 基于深度學習的類別增量學習算法綜述[J]. 計算機學報, 2023, 46(8): 1577–1605. doi: 10.11897/SP.J.1016.2023.01577. ZHOU Dawei, WANG Fuyun, YE Hanjia, et al. Deep learning for class-incremental learning: A survey[J]. Chinese Journal of Computers, 2023, 46(8): 1577–1605. doi: 10.11897/SP.J.1016.2023.01577.
[6]	丁柏圓, 文貢堅, 余連生, 等. 屬性散射中心匹配及其在SAR目標識別中的應用[J]. 雷達學報, 2017, 6(2): 157–166. doi: 10.12000/JR16104. DING Baiyuan, WEN Gongjian, YU Liansheng, et al. Matching of attributed scattering center and its application to synthetic aperture radar automatic target recognition[J]. Journal of Radars, 2017, 6(2): 157–166. doi: 10.12000/JR16104.
[7]	HUMMEL R. Model-based ATR using synthetic aperture radar[C]. The IEEE 2000 International Radar Conference, Alexandria, USA, 2000: 856–861. doi: 10.1109/RADAR.2000.851947.
[8]	CHEN Sizhe, WANG Haipeng, XU Feng, et al. Target classification using the deep convolutional networks for SAR images[J]. IEEE Transactions on Geoscience and Remote Sensing, 2016, 54(8): 4806–4817. doi: 10.1109/TGRS.2016.2551720.
[9]	REBUFFI S A, KOLESNIKOV A, SPERL G, et al. iCaRL: Incremental classifier and representation learning[C]. 2017 IEEE Conference on Computer Vision and Pattern Recognition, Honolulu, USA, 2017: 5533–5542. doi: 10.1109/CVPR.2017.587.
[10]	HOU Saihui, PAN Xinyu, LOY C C, et al. Learning a unified classifier incrementally via rebalancing[C]. 2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Long Beach, USA, 2019: 831–839. doi: 10.1109/CVPR.2019.00092.
[11]	TAO Xiaoyu, HONG Xiaopeng, CHANG Xinyuan, et al. Few-shot class-incremental learning[C]. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Seattle, USA, 2020: 12180–12189. doi: 10.1109/cvpr42600.2020.01220.
[12]	ZHANG Chi, SONG Nan, LIN Guosheng, et al. Few-shot incremental learning with continually evolved classifiers[C]. 2021 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Nashville, USA, 2021: 12450–12459. doi: 10.1109/CVPR46437.2021.01227.
[13]	PENG Can, ZHAO Kun, WANG Tianren, et al. Few-shot class-incremental learning from an open-set perspective[C]. 17th European Conference on Computer Vision, Tel Aviv, Israel, 2022: 382–397. doi: 10.1007/978-3-031-19806-9_22.
[14]	SONG Zeyin, ZHAO Yifan, SHI Yujun, et al. Learning with fantasy: Semantic-aware virtual contrastive constraint for few-shot class-incremental learning[C]. 2023 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Vancouver, Canada, 2023: 24183–24192. doi: 10.1109/CVPR52729.2023.02316.
[15]	WANG Li, YANG Xinyao, TAN Haoyue, et al. Few-shot class-incremental SAR target recognition based on hierarchical embedding and incremental evolutionary network[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5204111. doi: 10.1109/TGRS.2023.3248040.
[16]	ZHAO Yan, ZHAO Lingjun, DING Ding, et al. Few-shot class-incremental SAR target recognition via cosine prototype learning[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 5212718. doi: 10.1109/TGRS.2023.3298016.
[17]	NOVAK L M, OWIRKA G J, BROWER W S, et al. The automatic target-recognition system in SAIP[J]. The Lincoln Laboratory Journal, 1997, 10(2): 187–202.
[18]	王智睿, 康玉卓, 曾璇, 等. SAR-AIRcraft-1.0: 高分辨率SAR飛機檢測識別數據集[J]. 雷達學報, 2023, 12(4): 906–922. doi: 10.12000/JR23043. WANG Zhirui, KANG Yuzhuo, ZENG Xuan, et al. SAR-AIRcraft-1.0: High-resolution SAR aircraft detection and recognition dataset[J]. Journal of Radars, 2023, 12(4): 906–922. doi: 10.12000/JR23043.
