超大規模MIMO陣列可視區域空間分布數據集

高銳鋒; 苗艷春; 陳穎; 王玨; 張軍; 韓瑜; 金石

doi:10.11999/JEIT231273

超大規模MIMO陣列可視區域空間分布數據集

doi: 10.11999/JEIT231273 cstr: 32379.14.JEIT231273

高銳鋒¹,
苗艷春¹,
陳穎²,
王玨^2, ,,
張軍³,
韓瑜⁴,
金石⁴

1.
南通大學交通學院南通 226019
2.
南通大學信息科學技術學院南通 226019
3.
南京郵電大學通信與信息工程學院南京 210042
4.
東南大學移動通信國家重點實驗室南京 210096

基金項目: 國家自然科學基金 (62171240, 62001254)；江蘇省高校自然科學基金 (22KJB510039)

詳細信息

作者簡介:
高銳鋒：男，副教授，研究方向?yàn)闊o線通信、智能信息處理等

苗艷春：女，碩士生，研究方向?yàn)橹悄芡ㄐ?/p>
陳穎：女，碩士生，研究方向?yàn)橹悄芡ㄐ?/p>
王玨：男，副教授，研究方向?yàn)镸IMO 系統及超大規模 MIMO 系統等

張軍：男，教授，研究方向?yàn)榇笠?guī)模MIMO、人工智能通信等

韓瑜：女，副研究員，研究方向?yàn)槌笠?guī)模MIMO、可見區域等

金石：男，教授，研究方向?yàn)?G移動通信理論與關鍵技術研究等

通訊作者:
王玨　wangjue@ntu.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 612
- HTML全文瀏覽量: 307
- PDF下載量: 117
- 被引次數: 0
出版歷程
- 收稿日期: 2023-11-17
- 修回日期: 2024-04-30
- 網絡出版日期: 2024-05-15
- 刊出日期: 2024-08-30

Visibility Region Spatial Distribution Dataset for XL-MIMO Arrays

1.
School of Transportation, Nantong University, Nantong 226019, China
2.
School of Information Science and Technology, Nantong University, Nantong 226019, China
3.
School of Communications and Information Engineering, Nanjing University of Post and Telecommunications, Nanjing 210042, China
4.
National Mobile Communications Research Laboratory, Southeast University, Nanjing 210096, China

Funds: The National Natural Science Foundation of China (62171240, 62001254), The Natural Science Foundation of Jiangsu Provincial Universities (22KJB510039)

摘要

摘要: 可視區域(VR)信息可用于降低超大規模多輸入多輸出(XL-MIMO)系統傳輸設計復雜度，但現有理論分析與傳輸設計多基于簡化的VR統計分布模型。為評估分析XL-MIMO在實際物理傳播場景中的性能，該文公開了XL-MIMO陣列VR空間分布數據集，其由環境參數設置、射線追蹤仿真、天線場強數據預處理和VR判定準則等步驟構建。該數據集針對典型城區無線傳播場景，建立了用戶位置采樣與場強數據、VR數據之間的關聯，總數據條目數量達上億級。進一步對其中VR形態、VR分布進行了可視化展示與分析，并以基于VR的XL-MIMO用戶接入?yún)f(xié)議為例，利用該數據集對其在真實傳播場景中的性能進行了仿真，為該數據集的應用提供了典型樣例。
- 超大規模MIMO /
- 可視區域 /
- 射線追蹤 /
- 能量集中度 /
- 子陣列
Abstract: The Visibility Region (VR) information can be used to reduce the complexity in transmission design of EXtremely Large-scale massive Multiple-Input Multiple-Output (XL-MIMO) systems. Existing theoretical analysis and transmission design are mostly based on simplified VR models. In order to evaluate and analyze the performance of XL-MIMO in realistic propagation scenarios, this paper discloses a VR spatial distribution dataset for XL-MIMO systems, which is constructed by steps including environmental parameter setting, ray tracing simulation, field strength data preprocessing and VR determination. For typical urban scenarios, the dataset establishes the connections between user locations, field strength data, and VR data, with a total number of hundreds of millions of data entries. Furthermore, the VR distribution is visualized and analyzed, and a VR-based XL-MIMO user access protocol is taken as an example usecase, with its performance being evaluated with the proposed VR dataset.
- Extremely large-scale massive Multiple-Input Multiple-Output (MIMO) /
- Visibility region /
- Ray tracing /
- Energy concentration /
- Subarrays

HTML全文

圖 1 VRD構建整體流程圖

下載: 全尺寸圖片幻燈片

圖 2 實際3維城區場景以及采用射線追蹤技術仿真得到的部分天線場強數據圖

下載: 全尺寸圖片幻燈片

圖 3 所選用戶位置示例

下載: 全尺寸圖片幻燈片

圖 4 兩站點天線場強圖

下載: 全尺寸圖片幻燈片

圖 5 site2不同VR判定準則下的VR示意圖

下載: 全尺寸圖片幻燈片

圖 6 site2能量集中度80%時兩種準則下的VR天線/子陣列數量分布圖

下載: 全尺寸圖片幻燈片

圖 7 site2不同VR判定準則下的VR分布圖

下載: 全尺寸圖片幻燈片

圖 8 兩種隨機接入?yún)f(xié)議的接入性能在所公布VRD下的仿真比較

下載: 全尺寸圖片幻燈片

表 1 仿真參數設置

參數	參數設置
站點位置	場景內最高建筑物表面，site1: 150 m, site2: 50 m
天線類型及詳細參數	每個站點200根天線(10×20)，天線間距3 m，全向天線，頻率4800 MHz，發送功率1 W
天線序號	site1: 011～210，site2: 20011～20210
場強空間分辨率	1 m
用戶高度	高度統一為1.5 m
傳播模型	智能射線追蹤

下載: 導出CSV

1 天線能量集中度VR判定算法

輸入：用戶位置j天線場強數據$ {d_j}\left[ i \right] $，其中i表示天線標號；能量集中度P；初始化VR集合S_j為空；天線總數N_t
輸出：用戶j的VR集合S_j
1 計算用戶j所在位置的場強和：${F^j} = \sum\nolimits_{i = 1}^{{N_{\mathrm{t}}}} {{d_j}\left[ i \right]} $；
2 用戶j所能接收到的天線陣列上P (%)的能量，即閾值：${F^{j,P}} = {F^j} \times P$；
3 對數組$ {d_j}\left[ i \right] $按場強降序排序，生成新的2維數組${d'_j}\left[ {i,k} \right]$，其中i表示重新排序后的索引，k表示排序前天線的標號；
4 for (int t=0; t<=N_t; t++)
5 　${{\mathrm{sum}}} = {\text{sum}} + {d'_j}\left[ {i,k} \right]$；
6 　天線k加入集合S_j；
7 　if ${{\mathrm{sum}}} > {F^{j,P}}$
8 　　Break；
9 返回VR S_j。

下載: 導出CSV

表 2 數據集匯總表

數據集類型		數據集名稱	數據集含義	數據量
天線場強空間分布數據集		Antenna_site1	site1天線場強信息	60071000
天線場強空間分布數據集		Antenna_site2	site2天線場強信息	60071000
VRD	基于天線能量集中度的VRD	S1_Antenna_user_80	site1下能量集中度80%的用戶位置-天線VR構成信息	7702400
		S2_Antenna_user_80	site2下能量集中度80%的用戶位置-天線VR構成信息	3515400
		S1_Antenna_VR	site1峰值下天線VR分布	464
		S2_Antenna_VR	site2峰值下天線VR分布	279
	基于子陣列能量集中度的VRD	Antenna_subarray	天線-子陣列映射數據集	400
		S1_user_sub_power_80	site1下能量集中度80%的用戶位置-子陣列VR構成信息	547280
		S2_user_sub_power_80	site2下能量集中度80%的用戶位置-子陣列VR構成信息	725660
		S1_Subarray_VR	site1峰值下子陣列VR分布	27353
		S2_Subarray_VR	site2峰值下子陣列VR分布	36284

下載: 導出CSV

參考文獻(23)

[1]	LARSSON E G, EDFORS O, TUFVESSON F, et al. Massive MIMO for next generation wireless systems[J]. IEEE Communications Magazine, 2014, 52(2): 186–195. doi: 10.1109/MCOM.2014.6736761.
[2]	WANG Zhe, ZHANG Jiayi, DU Hongyang, et al. Extremely large-scale MIMO: Fundamentals, challenges, solutions, and future directions[J]. IEEE Wireless Communications. doi: 10.1109/MWC.132.2200443.
[3]	張軍, 陸佳程, 劉同順, 等. 超大規模MIMO系統中基于交疊可視區域的功率分配方法[J]. 電子與信息學報, 2023, 45(12): 4262–4270. doi: 10.11999/JEIT221468. ZHANG Jun, LU Jiacheng, LIU Tongshun, et al. Power allocation method based on overlapping visibility region in extra large scale MIMO system[J]. Journal of Electronics & Information Technology, 2023, 45(12): 4262–4270. doi: 10.11999/JEIT221468.
[4]	CUI Mingyao and DAI Linglong. Channel estimation for extremely large-scale MIMO: Far-field or near-field?[J]. IEEE Transactions on Communications, 2022, 70(4): 2663–2677. doi: 10.1109/TCOMM.2022.3146400.
[5]	IIMORI H, TAKAHASHI T, ISHIBASHI K, et al. Joint activity and channel estimation for extra-large MIMO systems[J]. IEEE Transactions on Wireless Communications, 2022, 21(9): 7253–7270. doi: 10.1109/TWC.2022.3157271.
[6]	丁瑞, 錢曉涵, 劉道華, 等. 超大規模MIMO信道測量建模研究綜述[J]. 電訊技術, 2022, 62(7): 1014–1022. doi: 10.3969/j.issn.1001-893x.2022.07.028. DING Rui, QIAN Xiaohan, LIU Daohua, et al. Survey of channel measurement and modeling for extra-large scale massive MIMO[J]. Telecommunication Engineering, 2022, 62(7): 1014–1022. doi: 10.3969/j.issn.1001-893x.2022.07.028.
[7]	DE CARVALHO E, ALI A, AMIRI A, et al. Non-stationarities in extra-large-scale massive MIMO[J]. IEEE Wireless Communications, 2020, 27(4): 74–80. doi: 10.1109/MWC.001.1900157.
[8]	ZHANG Jingjing, ZHANG Jun, HAN Yu, et al. Average spectral efficiency for TDD-based non-stationary XL-MIMO with VR estimation[C]. The 14th International Conference on Wireless Communications and Signal Processing, Nanjing, China, 2022: 973–977. doi: 10.1109/WCSP55476.2022.10039284.
[9]	ALI A, DE CARVALHO E, and HEATH R W. Linear receivers in non-stationary massive MIMO channels with visibility regions[J]. IEEE Wireless Communications Letters, 2019, 8(3): 885–888. doi: 10.1109/LWC.2019.2898572.
[10]	MARINELLO FILHO J C, BRANTE G, SOUZA R D, et al. Exploring the non-overlapping visibility regions in XL-MIMO random access and scheduling[J]. IEEE Transactions on Wireless Communications, 2022, 21(8): 6597–6610. doi: 10.1109/TWC.2022.3151329.
[11]	RODRIGUES V C, AMIRI A, ABR?O T, et al. Low-complexity distributed XL-MIMO for multiuser detection[C]. 2020 IEEE International Conference on Communications Workshops, Dublin, Ireland, 2020: 1–6. doi: 10.1109/ICCWorkshops49005.2020.9145378.
[12]	TIAN Jiachen, HAN Yu, JIN Shi, et al. Low-overhead localization and VR identification for subarray-based ELAA systems[J]. IEEE Wireless Communications Letters, 2023, 12(5): 784–788. doi: 10.1109/LWC.2023.3244000.
[13]	楊小龍, 佘媛, 周牧, 等. 基于CSI的三維聯合參數估計算法[J]. 電子與信息學報, 2022, 44(2): 627–636. doi: 10.11999/JEIT200698. YANG Xiaolong, SHE Yuan, ZHOU Mu, et al. 3D parameter estimation method based on CSI[J]. Journal of Electronics & Information Technology, 2022, 44(2): 627–636. doi: 10.11999/JEIT200698.
[14]	ALKHATEEB A. DeepMIMO: A generic deep learning dataset for millimeter wave and massive MIMO applications[EB/OL].https://doi.org/10.48550/arXiv.1902.06435, 2023.
[15]	ARNOLD M, HOYDIS J, and TEN BRINK S. Novel massive MIMO channel sounding data applied to deep learning-based indoor positioning[C]. The 12th International ITG Conference on Systems, Communications and Coding, Rostock, Germany, 2019: 1–6. doi: 10.30420/454862021.
[16]	DU Xu and SABHARWAL A. Massive MIMO channels with inter-user angle correlation: Open-access dataset, analysis and measurement-based validation[J]. IEEE Transactions on Vehicular Technology, 2022, 71(2): 1602–1616. doi: 10.1109/TVT.2021.3131606.
[17]	HAN Yu, TANG Wankai, JIN Shi, et al. Large intelligent surface-assisted wireless communication exploiting statistical CSI[J]. IEEE Transactions on Vehicular Technology, 2019, 68(8): 8238–8242. doi: 10.1109/TVT.2019.2923997.
[18]	TRINDADE I, MüLLER F, and KLAUTAU A. Accuracy analysis of the geometrical approximation of MIMO channels using ray-tracing[C]. 2020 IEEE Latin-American Conference on Communications, Santo Domingo, Dominican Republic, 2020: 1–5. doi: 10.1109/LATINCOM50620.2020.9282262.
[19]	LIN Zhijian, DU Xiaojiang, CHEN H H, et al. Millimeter-wave propagation modeling and measurements for 5G mobile networks[J]. IEEE Wireless Communications, 2019, 26(1): 72–77. doi: 10.1109/MWC.2019.1800035.
[20]	SHIKHANTSOV S, GUEVARA A, THIELENS A, et al. Spatial correlation in indoor massive MIMO: Measurements and ray tracing[J]. IEEE Antennas and Wireless Propagation Letters, 2021, 20(6): 903–907. doi: 10.1109/LAWP.2021.3066607.
[21]	HARON A S, MANSOR Z, AHMAD I, et al. The performance of 2.4GHz and 5GHz Wi-Fi router placement for signal strength optimization using Altair WinProp[C]. The IEEE 7th International Conference on Smart Instrumentation, Measurement and Applications, Bandung, Indonesia, 2021: 25–29. doi: 10.1109/ICSIMA50015.2021.9526299.
[22]	DE SOUZA J H I, AMIRI A, ABR?O T, et al. Quasi-distributed antenna selection for spectral efficiency maximization in subarray switching XL-MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2021, 70(7): 6713–6725. doi: 10.1109/TVT.2021.3081462.
[23]	LIU Daohua, WANG Jue, LI Ye, et al. Location-based visible region recognition in extra-large massive MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2023, 72(6): 8186–8191. doi: 10.1109/TVT.2023.3242615.
